Samsung WAP-701 Manuel utilisateur
----------------------------------------------------
The antenna(s) used for this transmitter must be installed to provide
a separation distance of at least 20 cm from all persons and must
not be co-located or operating in conjunction with any other antenna
or transmitter.
FCC RF Radiation Exposure Statement
1
SAFETY CONCERNS
For product safety and correct operation, the following information must be given to the operator/user
and shall be read before the installation and operation.
Conventions
Warning
This paragraph contains safety instructions
that users must follow in order to avoid
personal injuries.
This icon indicates a general caution.
Caution
This paragraph contains instructions that
users must follow in order to avoid service
failures or system damages.
This icon indicates specific actions that must
be avoided when handling a product.
Note
This paragraph contains supplementary
information that should be read as a
reference.
This icon indicates specific actions that must
be executed by the user.
WAP-701 User Guide
2
Warning
Warning
Be careful not to drop
the product.
This is to prevent product
damage.
Do not install the
product in a humid or
dusty area.
This is to prevent
electrocution and fire.
Do not install the
product near heating
apparatus (e.g. heater
and cigarette fire).
This is to prevent
electrocution and fire.
Do not use or keep
combustible sprays or
flammable objects near
this product.
This is to prevent
electrocution and fire.
WAP-701 User Guide
3
Do not place water
cups, chemicals, or
metals above the
product.
This is to prevent
electrocution and fire.
Do not pull or
excessively bend the
power cord, and do not
use damaged power
cables or loose sockets.
This is to prevent
electrocution and fire.
Do not touch the plug with wet hands.
This is to prevent electrocution and fire.
WAP-701 User Guide
4
Insert the power plug fully and
firmly into the outlet.
This is to prevent electrocution and
fire.
If the product makes strange
sound, smell, or smoke, unplug
the power cable immediately and
contact the service center.
This is to prevent electrocution and
fire.
Unplug the power cable when
not using the product for a long
time.
This is to prevent electrocution and
fire.
WAP-701 User Guide
5
Caution
Caution
Do not install the
product under direct
sunlight.
This is to prevent parts of the
product from being
damaged.
Do not place heavy
objects on top of the
product.
This is to prevent product
damage.
Do not clean the
product with chemicals
such as wax, benzene,
alcohol, thinner,
insecticide, air
freshener, lubricant, and
detergent.
Doing so may discolor or
damage the product.
Do not disassemble, repair or
modify the product without
proper authorization. Any
changes or modifications to
the equipment not expressly
approved by the party
responsible for compliance
could void user’s authority to
operate the equipment.
WAP-701 User Guide
6
Please use the product
properly according to
the user manual.
This is to prevent
malfunctions or a decrease
in life span.
The power adaptor must be
connected to a AC 220 V outlet.
And the socket-oulet shall be
installed near the equipment and
shall be easily accessible.
Clean the product with a dry cloth
after unplugging the power cord.
This is to prevent product damage.
7
Table of Contents
SAFETY CONCERNS 1
Conventions ............................................................ 1
Warning .................................................................... 2
Caution...................................................................... 5
Things You Should Know 8
What is a Wireless LAN (WLAN) Repeater?.... 8
WAP-701 Functions and Installation
Environment............................................................ 9
Selecting Location of Installation ..................10
Product Content...................................................10
WAP-701 Specification .....................................11
Preparation 12
Main Function .......................................................12
Shape ......................................................................17
Front View..............................................17
Bottom View........................................... 18
Side View .............................................. 19
Installation 20
Installing WAP-701............................................. 20
WAP-701 Cable Connection............................22
Checking WAP-701 LED Status......................23
Troubleshooting 24
Screw Location Diagram............................ 25
8
Things You Should Know
What is a Wireless LAN (WLAN) Repeater?
Power of signals generated from an WLAN Access Point (AP) decreases as the signals reach further
distances. To extend the transmission distance without attenuation of power, the frequency must be
regenerated or the power must be increased by a separate device. A WLAN repeater is a device that
regenerates and relays transmitted signals.
WAP-701 User Guide
9
WAP-701 Functions and Installation Environment
WAP-701 is a wireless repeater that can be used for constructing a wireless network or as a wireless AP.
Installed inside a cell area of an AP or repeater, the WAP-701 retransmits data received from wireless
terminals, such as lap tops and wireless PDAs, located outside the cell area of a neighboring AP, to the AP.
The figure below shows an example of installing WAP-701:
Cell
Cell refers to an area covered by frequency transmitted by an AP in a WLAN environment.
Mobile Unit
Note PC
PDA
Mobile Unit Note PC
PDA
Root AP WAP -701
