Samsung VC-8828E Manuel utilisateur
Operating Instructions
VACUUM CLEANER
❈Before operating this unit, please read the instructions carefully.
DJ68-00104A 10/18/01 11:53 AM Page 1
1. Do not use to suck up water.
2. Do not immerse in water for cleaning
3. The hose should be checked regularly and must not be used if damaged.
WARNING
1. Read all instructions carefully. Before switching on, make sure that the voltage of your electricity sup-
ply is the same as that indicated on the rating plate on the bottom of the cleaner.
2. WARNING: Do not use the vacuum cleaner when rug or floor is wet.
3. Close supervision is necessary when any appliance is used by or near children. Do not allow the vac-
uum cleaner to be used as a toy. Do not allow the vacuum cleaner to run unattended at any time. Use
the vacuum cleaner only for its intended use as described in these instructions.
4. Do not use the vacuum cleaner without a dust bag. Change the dust bag before it is full in order to
maintain the best efficiency.
5. Do not use the vacuum cleaner to pick up matches,live ashes or cigarette butts. Keep the vacuum
cleaner away from stoves and other heat sources. Heat can deform and discolour the plastic parts of
the unit.
6. Avoid picking up hard,sharp objects with the vacuum cleaner as they may damage the cleaner parts.
Do not stand on the hose assembly. Do not put a weight on the hose. Do not block the suction or the
exhaustion part.
7. Switch the vacuum cleaner off at the machine before unplugging from the electrical outlet. Grasp the
plug to disconnect cord from electrical outlet before changing the dust bag.
8. The use of an extension cord is not recommended.
9. If your vacuum cleaner is not operating correctly,switch off the power supply and consult an autho-
rized service agent.
10. Do not attempt to replace a damaged power supply cord. Only the manufacturer or qualified service
personnel can replace power cords. Serious injury may result.
IMPORTANT SAFEGUARDS
Features include indicator and automatic cord rewind.
1
NOTE : Not all models have the same features.
FEATURES
DJ68-00104A 10/18/01 11:53 AM Page 2
IDENTIFICATIONS OF PARTS
Features marked with
*
may vary according to model.
REMOTE POWER CONTROL *
(REMOTE CONTROL TYPE ONLY)
CARRYING HANDLE
DUST COVER
TOOL STORAGE COVER
BUTTON FOR SUCTION HOSE REMOVAL
ON/OFF
BUTTON
POWER CONTROL SWITCH *
AUTO BUTTON *
CORD REWIND
BUTTON
FLOOR NOZZLE *
TUBE *
TRANSPARENT TUBE *
SUCTION REGULATOR *
HANDLE *
HOSE *
2
CLAMPER FOR DUST BAG COMPARTMENT
DJ68-00104A 10/18/01 11:53 AM Page 3
3
ASSEMBLING THE VACUUM-CLEANER READY FOR USE
2)
Adjust the suction tube(depending on model).
4)
Connect the body connector to the body of the
cleaner.
3)
Connect the nozzle to the suction tube.
EXTENDING :
Holding the narrow part of
the telescopic tube with one
hand, push the handle in the
opposite direction with your
other hand.
➁SHORTENING :
Holding the narrow part of
the telescopic tube with
one hand, pull the handle
towards it using the other hand.
OPTION :
Connect the suction tubes together.
1)
Connect the suction hose to the suction tube.
NOTE :
Adjustable telescopic tube is not
available with all models.
DJ68-00104A 10/18/01 11:53 AM Page 4
4
You can start or stop your vacuum cleaner by pressing the
on/off switch lightly with your toe.
ON/OFF SWITCH
POWER CONTROL(VARIABLE CONTROL TYPE ONLY)
The vacuuming power can be adjusted to suit any situation with electrical power control.
MIN = For delicate fabrics, e.g. net curtains.
ECO = Economy setting for normally soiled carpets.
MAX = For hard floors and heavily soiled carpets.
1) For slider control types
Slide the controller to upwards or downwards to adjust the power output.
Model with controller on the body of cleaner
Model with controller on the body of cleaner
2) For button control types
Press (+)button to heighten the power.
Press (
-
)button to lower the power.
Model with controller on the handle
NOTE :
When removing the power cord from the electrical outlet,grasp the plug,not the cord.
POWER CORD
1) PULLING OUT :
The power cord is long enough to
drawn out for convenience.
2) REWINDING :
When you have finished cleaning,discon-
nect the plug from the electrical outlet
and simply press the cord rewind button
lightly with your toe.
Model with controller on the handle
DJ68-00104A 10/18/01 11:53 AM Page 5
5
AUTO MODE (BUTTON CONTROL TYPE ONLY)
If you press AUTO MODE, the power is automatically set at
1200~1300 watt.
This mode reduces the suction power fluctuation which is caused by
the fluctuation of airflow quantity to the motor.
For example, when dust bag is full, the quantity of air to the motor will
be decreased and power will be down followingly. AUTO MODE, in
this case, increases the power automatically for sufficient suction.
If you want to go back to the normal control type, just press "+" or "-"
buttons.
Open the tool storage cover upwards.
USING THE ACCESSORIES
CREVICE DUSTING UPHOLSTERY
Crevice tool for radiators, crevices,
corners, between cushions. Dusting brush for furniture,
shelves, books, etc. Upholstery brush for cushions
and drapery.
DJ68-00104A 10/18/01 11:53 AM Page 6
6
PARK POSITION
TRANSPORTING AND STORING THE VACUUM CLEANER
Located in the top rear side of the vacuum cleaner,there is
a nozzle support that can be used to park the nozzle during
pauses in cleaning
For easy storage and transportation, this vacuum cleaner has a
clip system built into body, which will keep the wand, hose and
nozzle in an upright position.
REPLACING THE DUST BAG
2)
Remove the dust bag from the cleaner
1)
To open the dust cover of the dust bag com-
partment, press the clamper upwards(the clam-
per is located at the front of the dust cover).
4)
Press the dust cover down gently until the
clamper relocks.
3)
After removing the used dust bag, insert the
cardboard bag collar of the new dust bag into
its original position.
DJ68-00104A 10/18/01 11:53 AM Page 7
7
MAINTENANCE OR REPLACEMENT OF THE FILTERS
INLET FILTER
The secondary filter, located behind the grille in the back of dust bag compartment, protects the motor from
dirt particles.
Do not allow the filter to become clogged.
Suction power reduction or motor damage may result. If filter becomes dirty, pull off the grille and lift out filter.
After cleaning the secondary filter attach it in place.
NOTE :
The filters must be completely dried before being replaced in the dust compartment.
FOR CLOTH FILTER BAG
After using,if the cloth filter bag is full of dust, clean the cloth filter bag and use it again.
NOTE :
Used dust bags can be sealed by removing
the film from the paper and sticking over the
suction opening.
DUST-FULL INDICATOR
If the “Dust-Full” indicator switch changes to “RED” while you are cleaning, the dust bag is
full and must be replaced.
NOTE :
If the “Dust-Full” indicator continues to display “RED” even after changing the dust
bag, turn the cleaner off and check whether the hose, tube or nozzle is clogged.
DJ68-00104A 10/18/01 11:53 AM Page 8
8
For HEPA Filter Type For Micro Filter Type
OUTLET FILTER
Open the dust cover and lift off the grille.
Grasp filter and pull it out with preliminary filter.
After cleaning preliminary filter, reposition new filter
and preliminary filter by reversing this procedure.
Grasp grille filter and pull it out with preliminary fil-
ter. After cleaning preliminary filter, reposition
new filter compartment and preliminary filter by
reversing this procedure.
HEPA Filter
Preliminary
Filter
Grille Filter
Micro Filter
Preliminary Filter
TRANSPARENT TUBE
Transparent tube prevent the tube and hose
from being clogged by obstacle like as socks
and clothes.
When transparent tube is clogged.
Separate the nozzle from the tube. Remove
the alien substance with a stick from it. After
cleaning it, reassemble the nozzle to the tube.
DJ68-00104A 10/18/01 11:53 AM Page 9
NOTE: For optimum efficiency, clean floor brush with crevice tool.
9
FOR UNIVERSAL BRUSH
Use the floor nozzle for cleaning all surfaces.
USAGE OF FLOOR NOZZLE
Select the carpet indicator ➀when cleaning carpets.
Select flat surface indicator ➁when cleaning the floors, tiles, etc.
FOR RUG / FLOOR SELECTOR
Before use make sure that the position of the selector is in the right position for the type of surface to be
cleaned.
