Samsung SC9210 Manuel utilisateur
Operating Instructions
VACUUM CLEANER
❈Before operating this unit, please read the instructions carefully.
❈Indoor use only.
DJ68-00208A(EN)REV(0.0) 5/16/03 11:46 AM Page 2
DJ68-00208B REV(0.0)
1
IMPORTANT SAFEGUARDS
1. Read all instructions carefully. Before switching on, make sure that the voltage of your
electricity supply is the same as that indicated on the rating plate on the bottom of the
cleaner.
2. WARNING: Do not use the vacuum cleaner when rug or floor is wet.
Do not use to suck up water.
3. Close supervision is necessary when any appliance is used by or near children. Do not
allow the vacuum cleaner to be used as a toy. Do not allow the vacuum cleaner to run
unattended at any time. Use the vacuum cleaner only for its intended use as described in
these instructions.
4. Do not use the vacuum cleaner without a dust bag(dust bin). Empty the dust bin before it
is full in order to maintain the best efficiency.
5. Do not use the vacuum cleaner to pick up matches,live ashes or cigarette butts. Keep the
vacuum cleaner away from stoves and other heat sources. Heat can deform and dis-
colour the plastic parts of the unit.
6. Avoid picking up hard,sharp objects with the vacuum cleaner as they may damage the
cleaner parts. Do not stand on the hose assembly. Do not put a weight on the hose. Do
not block the suction or the exhaust port.
7. Switch the vacuum cleaner off at the machine before unplugging from the electrical outlet.
Grasp the plug to disconnect cord from the electrical outlet before changing the dust bag.
8. The plug must be removed from the socket outlet before cleaning or maintaining the appli-
ance.
9. The use of an extension cord is not recommended.
10. If your vacuum cleaner is not operating correctly,switch off the power supply and consult
an authorized service agent.
11. If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
12. Don’t carry the vacuum cleaner by holding the hose.
Use the handle on the vacuum cleaner set.
DJ68-00208A(EN)REV(0.0) 5/16/03 11:46 AM Page 4
2
1ASSEMBLING THE CLEANER
Features may vary according to model.
▼
For storage, park the floor nozzle.
OPTION
DJ68-00208A(EN)REV(0.0) 5/16/03 11:46 AM Page 5
3
2OPERATING THE CLEANER
2-1 POWER CORD 2-2 ON/OFF SWITCH
(BODY-CONTROL TYPE ONLY)
2-3 POWER CONTROL
NOTE
When removing the
plug from the
electrical outlet,grasp the
plug,not the cord.
1)BODY-CONTROL TYPE
MIN = For delicate surface e.g. net curtains.
MAX = For hard floors and heavily soiled carpets.
INFRARED-CONTROL
Press control button repeatedly to select correct mode.
(STOP MIN MID MAX)
NOTE
If the cleaner is not working by handle-control you can operate the vacuum
cleaner with the CONTROL-BUTTON on the body.
2)REMOTE-CONTROL TYPE
DJ68-00208A(EN)REV(0.0) 5/16/03 11:46 AM Page 6
4
- TRANSPARENT TUBE
HARD FLOOR (OPTION)
CREVICE
DUSTING
UPHOLSTERY
PARQUET SPECIALIST (OPTION)
POWER PET (OPTION)
2-4 USING FLOOR TOOLS
DJ68-00208A(EN)REV(0.0) 5/16/03 11:46 AM Page 7
5
4
CHANGING THE DUST BAG
3LAMP SIGNALS
1)BODY-CONTROL TYPE
Check the Dust bag and change it.
(Check the Dust bin and empty it.)
2)REMOTE-CONTROL TYPE
Check the Dust bag and change it.
(Check the Dust bin and empty it.)
*LAMP SIGNALS
1. INDICATOR LAMP ON:
The dust bag is full, or the pipe is blocked.
2. POWER LAMP ON:
The power is applied to the vacuum cleaner
134
25
INDICATOR
LAMP
INDICATOR
LAMP
POWER
LAMP
OPTIONAL
●FOR CLOTH BAG
After using, if the cloth bag is full of dust, clean the cloth bag and use it again.
NOTE
Please make sure to retain the support-filter when you dispose of the dust bag.
NOTE
A used dust bag can be sealed by removing the paper from the adhesive strip and
sealing the strip over the hole.
DJ68-00208A(EN)REV(0.0) 5/16/03 11:46 AM Page 8
6
5
CLEANING THE CYCLONE FILTER (Optional)
1 2 3
4 5 6
78
NOTE
Use Cyclone Filter for the
best efficiency.
1 2 3
6-1 EMPTY THE DUST BIN
6CARING THE DUST BIN(OPTIONAL)
DJ68-00208A(EN)REV(0.0) 5/16/03 11:47 AM Page 9
7
4 5 6
7
OPTIONAL
You can rinse the bin with water.
Do not immerse the whole cleaner in water.
Ensure completely dry before replacing.
1 2 3
6-2 CLEANING THE GRILL
DJ68-00208A(EN)REV(0.0) 5/16/03 11:47 AM Page 10
8
7CHANGE THE BATTERY(OPTIONAL)
1)BATTERY TYPE : AA Size
WARNING
1. Never disassemble or recharge the batteries.
2. Never heat up the batteries or throw them into fire. 3. Do not reverse (+),(-) terminals.
4. Dispose the batteries properly.
NOTE
1. When the vacuum cleaner does not operate, replace the batter
ies. If the problem persists, please contact our authorized dealer.
2. 2 of Battery type
4 5
8CLEANING THE INLET FILTER
1234
NOTE :
Don’t throw away the filter
DJ68-00208A(EN)REV(0.0) 5/16/03 11:47 AM Page 11
9OUTLET FILTER
PROBLEM CAUSE REMEDY 0
- IF YOU HAVE A PROBLEM
Motor does not start.
No power supply.
Thermal cut-out.
Check cable, plug and socket.
Leave to cool.
Suction force is gradually
decreasing. Nozzle, suction hose or tube
is blocked. Check for blockage and
remove.
Cord does not rewind fully. Check that the cord is not
twisted or wound unevenly. Pull the cord out 2-3m and
push down the cord rewind
button.
Vacuum cleaner does not
pick up dirt.
Crack or hole in hose.
Check hose and replace if
required.
HEPA
FILTER(OPTION)
MICRO FILTER
NOTE :
Replacement filters or bags can be bought from your local Samsung distributor.
123
9
