Samsung SC7803 Manuel utilisateur

VACUUM CLEANER

❈Before operating this unit, please read the instructions carefully.

❈Indoor use only.

Operating Instructions

Mode d’emploi

Gebruiksaanwijzing

DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 1

IMPORTANT SAFEGUARDS

1. Read all instructions carefully. Before switching on, make sure that the voltage of your

electricity supply is the same as that indicated on the rating plate on the bottom of the

cleaner.

2. WARNING: Do not use the vacuum cleaner when rug or floor is wet.

Do not use to suck up water.

3. Close supervision is necessary when any appliance is used by or near children. Do not

allow the vacuum cleaner to be used as a toy. Do not allow the vacuum cleaner to run

unattended at any time. Use the vacuum cleaner only for its intended use as described in

these instructions.

4. Do not use the vacuum cleaner without a dust bag(dust bin). Empty the dust bin before it

is full in order to maintain the best efficiency.

5. Do not use the vacuum cleaner to pick up matches,live ashes or cigarette butts. Keep the

vacuum cleaner away from stoves and other heat sources. Heat can deform and dis-

colour the plastic parts of the unit.

6. Avoid picking up hard,sharp objects with the vacuum cleaner as they may damage the

cleaner parts. Do not stand on the hose assembly. Do not put a weight on the hose. Do

not block the suction or the exhaust port.

7. Switch the vacuum cleaner off on the body of the machine before unplugging from the

electrical outlet. Disconnect plug from the electrical outlet before changing the dust bag or

dust container. To avoid damage, please remove the plug by grasping the plug itself, not

by pulling on the cord.

8. The plug must be removed from the socket outlet before cleaning or maintaining the appli-

ance.

9. The use of an extension cord is not recommended.

10. If your vacuum cleaner is not operating correctly,switch off the power supply and consult

an authorized service agent.

11. If the supply cord is damaged, it must be replaced by the manufacturer or its service

agent or a similarly qualified person in order to avoid a hazard.

12. Don’t carry the vacuum cleaner by holding the hose.

Use the handle on the vacuum cleaner set.

EN-1

DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 2

1ASSEMBLING THE CLEANER

Features may vary according to model.

▼

For storage, park the floor nozzle.

OPTION

EN-2

DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 3

2OPERATING THE CLEANER

2-1 POWER CORD 2-2 ON/OFF SWITCH

2-3 POWER CONTROL

NOTE

When removing the

plug from the

electrical outlet,grasp the

plug,not the cord.

MIN = For delicate surface e.g. net curtains.

MAX = For hard floors and heavily soiled carpets.

2-4 AIR CONTROL

To reduce suction for cleaning draperies, small

rugs, and other light fabrics, pull the tap air until

the hole is open.

EN-3

DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 4

- Detach transparent drum

cover for easy cleaning.

- Transparent tube

CREVICE

DUSTING

UPHOLSTERY

2-5 USING FLOOR TOOLS

Carpets

Bare floors

OPTION

EN-4

DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 5

3-1 CHANGING THE DUST BAG

3INDICATOR LIGHTS (BAG TYPE)

When the indicator light comes on,

please change the DUST BAG(3-1)

as shown in the following illustrations.

134

OPTIONAL

• FOR CLOTH BAG

After using, if the cloth bag is full of dust, clean the cloth bag and use it again.

NOTE

Please make sure to retain the support-filter when you dispose of the dust bag.

NOTE

A used dust bag can be sealed by removing the paper from the adhesive strip and

sealing the strip over the hole.

support-filter support-filter

EN-5

DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 6

INDICATOR LIGHTS (CASSETTE FILTER TYPE)

1 2 3

4 5 6

NOTE

The Cyclone Filter must

be used at all times to

retain optimum efficiency.

4-1 CLEANING THE CYCLONE FILTER

When the indicator light comes on, please empty

and clean the Cyclone Filter (4-1) and the cassette

filter (4-2) as shown in the following illustrations.

OPTIONAL

DIGITAL SIGNAL

EN-6

DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 7

NOTE

You can rinse the cassette filter with water.

Do not immerse the whole cleaner in water.

Ensure completely dry before replacing.

1 2 3 4

5 6 7

4-2 CLEANING THE CASSETTE FILTER

4-2-1 EMPTYING THE CASSETTE FILTER

21 3 4

5 6 7 8

4-2-2 CLEANING THE GRILL

EN-7

DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 8

5CLEANING THE INLET FILTER

123

4 5

5-1 BAG TYPE

NOTE :

Please do not throw away the filter. It must be retained to maintain cleaning efficiency.

123

4 5

NOTE

Please do not throw

away the filter. It must

be retained to maintain

cleaning efficiency.

5-2 CASSETTE FILTER TYPE

EN-8

DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 9

6OUTLET FILTER

- MICRO FILTER

Remove and replace the blocked outlet-filter.

NOTE :

Replacement filters or bags can be bought from your local Samsung distributor.

OPTION - CARBON FILTER

OPTION - HEPA-FILTER

EN-9

DJ68-00234E (3EA)-0.2 3/26/04 10:55 AM Page 10
