Safety & Care

Your Samsung FlipTop powered by DIRECTV® has been designed and manufactured to stringent

quality and safety standards. You should, however, be aware of the following important precautions

for safe and optimal use of the equipment.

Meaning of symbols printed on the rear panel of the product:

• The “ bolt of lightning” indicates un-insulated material within your unit may cause an

electrical shock. For the safety of everyone in your household, please do not remove product

covering.

• The “exclamation point” calls attention to features for which you should read the enclosed

literature closely to prevent operating and maintenance problems.

Important Safety Instructions

1) When you use product, certainly read this instruction about safety.

2) When you use product, certainly keep this instruction about safety.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including ampliﬁers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has

two blades with one wider than the other. A grounding type plug has two blades and a third

grounding prong. The wide blade or the third prong are provided for your safety. If the provided

plug does not ﬁt into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

TIP

We highly recommend plugging

the Samsung FlipTop powered

by DIRECTV® into a surge

protector to prevent damage from

ﬂuctuations in your power supply.

WARNING

To reduce the risk of fire or

electric shock, do not expose this

product to rain or moisture. The

apparatus shall not be exposed

to dripping or splashing and that

no objects filled with liquids, such

as vases, shall be placed on the

apparatus

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK

OF ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

Note to Satellite Dish Installer

This reminder is provided to call your attention to articles 810 and 820 of the 2002 National Electrical Code. Refer

to article 810, in particular 810-1 and 810-15, for required grounding of the metal structure of the dish antenna.

Refer also to the 810-2 which, by reference to article 820, requires that the satellite dish coaxial cable shield be

connected to the grounding system of the building as close to the point of cable entry as practical.

11) Only use attachments/accessories speciﬁed by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table speciﬁed by the manufacturer, or sold with

the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to

avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus has

been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does

not operate normally, or has been dropped.

• If you operate it by wet hand, product may be broken down or you may be struck by electricity.

• Do not install near cooking instrument such as gas range and inﬂammable apparatus for cooking.

• CAUTION: Avoid moisture to reduce the risk of ﬁre or electric shock. The Samsung FlipTop

basement). Also, never spill liquid on the receiver, and do not place vases or other vessels

containing liquid on top of it.

• Ensure proper ventilation — the vent slots on the Samsung FlipTop powered by DIRECTV® must

be left uncovered to allow proper airﬂow to the unit. Blocking the airﬂow to the unit could impair

performance or damage your receiver and other components.

• Do not stack electronic components or other objects on top of the Samsung FlipTop powered by

DIRECTV®. Also, do not stack the receiver on top of a “hot component” such as an audio power

ampliﬁer.

• Protect your components from power surges by connecting all the components before plugging any

power cords into the wall outlet. Use of a surge protector is also recommended.

• Don’t overload power outlets or extension cords, which can result in the risk of ﬁre or shock.

It’s also important to use only the type of power source indicated on the marking label or in this

manual.

The apparatus shall not be

exposed to dripping or splashing

and no objects filled with liquids,

such as vases, shall be placed on

the apparatus.

Safety & Care

iii

• To prevent electrical shock, this apparatus shall be connected to a mains socket outlet with a

protective earthing and fully inserted.

• Avoid audio hum or interference by inserting all cable plugs ﬁrmly into their jacks. Also, place

Audio/Video (A/V) cables to the sides of the LCD rather than down the middle once connected.

Try not to coil any twin-lead cables and keep them away from A/V cables as much as possible.

• Never insert objects of any kind into any openings in the Samsung FlipTop powered by

DIRECTV® (other than the DIRECTV® Access Card as detailed in this chapter).

• Place it on a ﬂat, hard surface — do not operate the Samsung FlipTop powered by DIRECTV® on a

carpet or other padded surface.

• Always unplug your Samsung FlipTop powered by DIRECTV® before moving it.

• Leave the main power connector accessible the mains connector at the back of the unit in case of

emergency shutdown

• CAUTION: Electric Shock — never attempt to disassemble the Samsung FlipTop powered by

DIRECTV® yourself; always take it to a qualiﬁed service person when repair is required. Opening

or removing covers may expose dangerous voltage or other risks, and incorrect reassembly can

cause shock when receiver is subsequently used. Attempted self-repair may also void your warranty.

Changes or modiﬁcations not expressly approved by the party responsible for compliance (by the

warranty or by the manufacturer) could void the user’s authority to operate the equipment.

• Do not drop your Samsung FlipTop powered by DIRECTV® and always move it with care.

• Have your Samsung FlipTop powered by DIRECTV® professionally serviced (do not attempt to

service it yourself)

• Any changes or modiﬁcations in construction of this device which are not expressly approved by

the party responsible for compliance could void the user’s authority to operate the equipment.

• Do not use near water. accident may occur due to humidity such as short and electrical shock.

Also, it shall not be exposed to frying oil.

• If smoke occurs or fumes smell during stop operation. then, promptly stop power source and

remove plug. After this, contact service center.

• Pay attention to touch LCD with head during use.

For your information:

The identiﬁcation sticker can be located underneath or on the back of your receiver.

The telecommunication network voltage used is the category number 3.

Safety & Care

IMPORTANT: Be sure not to place

your Samsung FlipTop powered

by DIRECTV® near anything WET

or HOT!

Using the Remote

123

456

789

VOL

MUTE PREV

DEFABC

JKL MNOGHI

TUV WXYZPQRS

DASH ENTER

CHAN

PAGE

INFO

BACK

AV1 AV2 TV

OFF

POWER

INPUT

FORMAT

EXIT

LIST

GUIDE

ACTIVE

SELECT

PWR

MODE SWITCH

Changes remote to control other equipment,

i.e., a VCR

TV POWER/ON/OFF

Turns your Receiver on and off when mode

switch is set to DIRECTV

TV INPUT

Not used in this model

To Place batteries in your remote control:

1. Remove cover from the battery

compartment by sliding it downward

2. Insert 2 AA batteries (supplied), matching

the positive (+) and negative (–) at each end

3. Slide the cover back on and you’re

good to go.

Quick Tip

BLUE

Will provide future functionality

ADVANCE

PLAY

RECORD

FFWD

STOP

REPLAY

REWIND

PAUSE

ACTIVE

Access to special features services,

DIRECTV news and info.

GUIDE

Displays the on-screen programming guide

EXIT

Exits any menu and returns

to last channel viewed

ARROWS

Move highlight to items in

whatever direction needed

INFO

Displays information on a chosen program or item

SELECT

Chooses or activates any highlighted item

Brings up a helpful menu of settings and services

BACK

Takes you to the screen you visited previously

RED

Function changes with context — for example, on

the left-most tab, press to jump to the right-most tab

CHAN/PAGE

In live TV, changes channel up or down; in a menu,

such as the Guide, moves entire page up or down

Tunes to the last channel viewed

YELLOW

Cycles through alternate audio tracks, when available

NUMBER KEYS & DASH

Tunes to a channel directly; also used to input numbers

and letters when needed in on-screen menus

GREEN

Function changes with context — for example, on the

right-most tab, press to jump to the left-most tab

VOLUME

Raises or lowers volume (For the setup procedures

to use the Volume button, refer to page 12

“The Setup Procedures to Use the Volume Button on

the Remote Control”.)

MUTE

Temporarily turns off sound volume

LIST

Displays your To Do List of programs

ENTER

Activates number entries more quickly; also,

sets a highlighted program for autotune

Keys in this shaded area

can be programmed to

function with your VCR,

DVD player or stand-alone

DVR unit.

Great TV viewing

is in your hands!

A good way to begin learning about your

Samsung FlipTop powered by DIRECTV®

is to familiarize yourself with the remote

control. You’ll ﬁ nd further details

throughout the User Guide relating to

speciﬁ c functions.

Navigating 101

You’ll ﬁ nd you can get around nearly all

on-screen menus the same simple way.

Highlight… a menu or button by

using the ARROW keys (up, down,

left and right).

Choose it… by pressing SELECT while

the item is highlighted.

Note: Don’t worry about getting stuck in any

menu or on any item. You can always press

EXIT or BACK.

POWER

Turns your Receiver on and off when mode

switch is set to DIRECTV

FORMAT

Not used in this model

Chapter 1 – Introduction

Welcome ..............................................................................................................................2

About Your User Guide ....................................................................................................3

Chapter 2 – Getting Connected

Making the Right Connections .......................................................................................6

Helpful Hardware References .........................................................................................7

Getting Familiar ..............................................................................................................10

Mounting Instruction .....................................................................................................16

Choose the Setup That Suits You .................................................................................18

Guided Setup & Activation ...........................................................................................22

Chapter 3 – What’s On

Watching ...........................................................................................................................26

The Guide .........................................................................................................................29

Autotune ............................................................................................................................31

Pay Per View .....................................................................................................................33

Chapter 4 – The Quick Menu

What’s on the MENU? ...................................................................................................36

Settings ..............................................................................................................................37

Audio Options ................................................................................................................. 40

Category Sort ....................................................................................................................41

Pay Per View .....................................................................................................................42

Find By ..............................................................................................................................43

Date & Time .....................................................................................................................45

Favorites ............................................................................................................................46

Caller ID & Messages .....................................................................................................47

Parental Controls .............................................................................................................49

Chapter 5 – Other Information

Programming Your Remote Control ............................................................................54

Troubleshooting ...............................................................................................................56

Speciﬁcation .....................................................................................................................68

Warranty ...........................................................................................................................70

Table of Contents

vii

2 Welcome

3 About Your User Guide

Chapter 1

Welcome

Congratulations on choosing the best entertainment experience around!

With its astounding variety of channels and choices, crisp digital-quality picture and sound and

one-of-a-kind sports and events… DIRECTV® service offers everything you want in your television

experience. You can expect more than ever before, with access to over 250 channels, including over

30 premium movie channels, with something sure to please everyone in the family. DIRECTV® Pay

Per View offers a handy choice in recent hit movies, plus exciting live sports, concerts and specials.

There’s exclusive sports subscriptions for every taste and team. Even access to 36 commercial-free

channels and make 67 XM satellite radio music channels!

To deliver this unique programming and enhance your entertainment experience, the

Samsung FlipTop powered by DIRECTV® has been designed to be simple and user-friendly. You’ll

ﬁnd that most features are self-explanatory, with on-screen directions to lead you through them.

Now that you’re part of the DIRECTV family, you’re sure to discover that using and watching TV is

easier and more enjoyable that ever.

Introduction

2Introduction

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung TV

Samsung

Samsung CK765DSX3X/NWT Manuel utilisateur

Samsung

Samsung CS29Z47 Manuel utilisateur

Samsung

Samsung TXN2668WH Manuel utilisateur

Samsung

Samsung PN51D440A5D Manuel utilisateur

Samsung

Samsung HG40AC670 Manuel utilisateur

Samsung

Samsung CW-29Z308T Guide de l'utilisateur

Samsung

Samsung CB15K10 Manuel utilisateur

Samsung

Samsung UN49M5300A Manuel utilisateur

Samsung

Samsung WS28V53NS8XXEC Manuel utilisateur

Samsung

Samsung QE49Q6FNAU Manuel utilisateur

Samsung

Samsung UN58TU7 Series Manuel utilisateur

Samsung

Samsung CT-21T20MQ Manuel utilisateur

Samsung

Samsung LN19C350 Manuel utilisateur

Samsung

Samsung UE49MU7000 Manuel utilisateur

Samsung

Samsung LN40D550K1F Manuel utilisateur

Samsung

Samsung HL-R4656W Manuel utilisateur

Samsung

Samsung UE48JS9000L Manuel utilisateur

Samsung

Samsung Tantus TSK 3092WF Manuel utilisateur

Samsung

Samsung UE49KS8000 Manuel utilisateur

Samsung

Samsung UE49KS7000 Manuel utilisateur

Samsung

Samsung LN32D403E4DXZA Manuel utilisateur

Samsung

Samsung KE55S9CSL Mode d’emploi

Samsung

Samsung The Terrace Manuel utilisateur

Samsung

Samsung Smart TV UE37D5520 Mode d’emploi

Manuels TV populaires d'autres marques

Philips

Philips Colour Television Manuel utilisateur

Toshiba

Toshiba 27A10 Manuel utilisateur

Philips

Philips 42PF9630A/37 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Philips

Philips Matchline 21CE7551 Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Philips

Philips 25PT4523-16 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Philips

Philips PR0930X3 Manuel utilisateur

Philips

Philips Brilliance 231P4QPY Manuel utilisateur

Philips

Philips 32HF9385D Guide de dépannage

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Philips

Philips 32PFH5300 Manuel utilisateur

Sylvania

Sylvania 6427FB Manuel utilisateur
