Samsung Q8FN Manuel utilisateur

Q8FN TV

PRODUCT HIGHLIGHTS

•Q | Contrast Elite™

•Q | HDR Elite™

•Q | Style™

•Smart TV with Bixby Voice

SIZE CLASS

KEY FEATURES

Performance is the calling of the 2018 Q8 with Full Array Backlight control and impressive HDR for a cutting-edge picture.

An anti-glare screen and quantum color make this TV ideal—even in bright rooms.

Product Type

•QLED TV

Q Picture™

•Q | Color™

•Q | Contrast Elite™

•Q | HDR Elite™

•100% Color Volume

•Full Array Backlight

•Ultra Black Elite™

•Auto Game Mode

•Q | Engine™

•Motion Rate 240

Q Style™

•Ultrawide Viewing Angle

•Ambient Mode™

•Boundless 360° Design™

•Bezel Color: Carbon Silver

•Stand Color: Carbon Silver

•Bezel-free Design

Q Smart™ with Bixby Voice

•Universal Browse

•Connect & Share

•Samsung OneRemote1

Connections

•4 HDMI Connections2

•2 USB Connections

•LAN Port

•802.11AC built-in Wi-Fi

•Bluetooth®

•RS232 Control (EX-Link)

•IP Control Support3

•Optical Audio Output Port

Audio

•Dolby®Digital Plus

•40 Watt 4.1 Channel

Included Accessories

•Samsung OneRemote

Industry Certifications

•UHDA Ultra HD Premium

•CTA 4K Ultra HD Connected

1Color may vary by model.

2HDMI—CEC (Consumer Electronics Control) facilitates convenient control functions with compatible devices.

3Requires third-party control system installation. See www.samsung.com/us/business/custominstall.

SEE BACK FOR DETAILS

82"

82Q8FN

75"

75Q8FN

65"

65Q8FN

55"

55Q8FN

S:8.25”

S:10.75”

T:8.5”

T:11”

B:8.75”

B:11.25”

Samsung TV • TracyLocke

210798 Studio# 213661

TV Spec Sheets

Sell Sheet • Q8FN

tss210798_mch_sls_Q8FN.indd

Print Code: –

Contact: Denise Thomas

Studio Artist: SB

Built At: 100% • Print Scale: None

4-Color Process: Cyan, Magenta, Yellow, Black

Placed Images:1850Qled-NorthAmerica (1).tif (CMYK; 989 ppi;

30.32%)

QN65Q8FNBFXZA_001_Front_Carbon-Silver.tif (CMYK; 1205 ppi;

24.89%)

Document Fonts:SamsungOne (800, 400), Samsung InterFace

(Regular)

6-5-2018 6:02 PM

Mech Trim: 8.5” x 11”

Mech Live: 8.25” x 10.75”

Mech Bleed: 8.75” x 11.25”

Final Trim: 8.5” x11”

Final Live: 8.25” x10.75”

Final Bleed: 8.75” x11.25”

01 TV Installation

Mounting the TV on a wall

If you mount this TV on a wall, follow the instructions exactly as set out by the manufacturer. Unless it is

correctly mounted, the TV may slide or fall and cause serious injury to a child oradult and serious damage

to the TV.

Formodels providing wall mount adapters, install them as shown in the figure below before installing the wall mount

kit.

•Referto the installation manual included with the Samsung wall mount kit.

Wall mount

bracket

Wall mount

bracket

Wall mount Adapter

•Samsung Electronics is not responsible for any damage to the product orinjury to yourself or others if you choose

to install the wall mount on your own.

•To orderthe wall mount kit, contact Samsung Customer Care at1-800-SAMSUNG (1-800-726-7864).

•You can install yourwall mount on a solid wall perpendicularto the floor. Before attaching the wall mount to

surfaces otherthan plaster board, contact yournearest dealer for additional information. If you install the TV on a

ceiling or slanted wall, it may fall and result in severe personal injury.

•When installing a wall mount kit, we recommend you fasten all fourVESA screws.

•If you want to install a wall mount kit that attaches to the wall using two top screws only, be sure to use a Samsung

wall mount kit that supports this type of installation. (You may not be able to purchase this type of wall mount kit,

depending on the geographical region.)

•Standard dimensions forwall mount kits are shown in the table below.

•If you are installing a third-party wall mount, note that the length of the screws you can use to attach the TV to the

wall mount is shown in column C in the table below.

TV size in

inches

VESA screw hole specs

(A * B) in millimeters C (mm)Standard

Screw

Pitch

(mm)Quantity

55 200 x 200

43-45 M8 1.25 465-75 400 x 400

82 600 x 400

03 Initial Setup

When you turn on your TV for the first time, it immediately starts the Initial Setup. Follow the instructions displayed on

the screen and configure the TV's basic settings to suit yourviewing environment.

•Noise may occur temporarily when the TV communicates with mobile devices.

•The SmartThings app is available on mobile devices forAndroid 6.0 or higher and iOS 10 or higher.

•To perform initialization by using the SmartThings app, the mobile device must have been connected via Wi-Fi.

•When the pop-up for setup does not appear automatically on the SmartThings app of your mobile device, proceed

with the process after manually adding the TV using Add Device on the dashboard of the SmartThings app.

Using the TV Controller

You can turn on the TV with the TV Controller button at the bottom of the TV, and then use the Control menu. The

Control menu appears when the TV Controller is pressed while the TV is On. For more information about its usage, refer

to the figure below.

•The screen may dim if the protective film on the SAMSUNG logo orthe bottom of the TV is not detached. Please

remove the protective film.

TV Controller / Remote control sensor

Press: Move

Press & Hold: Select

The TV Controller is located on the bottom of the TV.

Control menu

: Power Off : Volume Up

: Channel Up : Volume Down

: Channel Down : Source

Dimensions

Port panel detail / Rearview

•The displayed image may differ from your TV, depending on the model.

(Unit: inches)

Model name 123

QN55Q8FN 8.2 20.2 11.5

QN65Q8FN 4.1 20.6 12.5

QN75Q8FN 9.6 25.0 12.3

QN82Q8FN 8.6 24.2 1 7.0

MODELS

MODEL: QN82Q8FN

ORDER CODE: QN82Q8FNBFXZA

SCREEN SIZE CLASS: 82"

SCREEN DIAGONAL MEASUREMENT: 81.5"

UPC CODE: 887276276663

COUNTRY OF ORIGIN: Mexico

DIMENSIONS (INCHES W x H x D):

•TV WITHOUT STAND: 72.1 x 41.4x 2.5

•TV WITH STAND: 72.1 x 44.9 x 15.2

•SHIPPING: 79.4 x 48.1 x 11.6

•STAND FOOTPRINT: 2.5 x 10.3 x 15.2

WEIGHT (LB):

•TV WITHOUT STAND: 104.3

•TV WITH STAND: 106.9

•SHIPPING: 140.7

VESA SUPPORT: Yes (600mm x 400mm)

ACCESSORIES INCLUDED IN BOX:

•REMOTE MODEL: TM-1850A

MODEL: QN75Q8FN

ORDER CODE: QN75Q8FNBFXZA

SCREEN SIZE CLASS: 75”

SCREEN DIAGONAL MEASUREMENT: 74.5”

UPC CODE: 887276256993

COUNTRY OF ORIGIN: Mexico

DIMENSIONS (INCHES W x H x D):

•TV WITHOUT STAND: 66 x 37.9 x 2.3

•TV WITH STAND: 66 x 41.3 x 14.1

•SHIPPING: 73.3 x 44.2 x 9.1

•STAND FOOTPRINT: 2.5 x 9.2 x 14.1

WEIGHT (LB):

•TV WITHOUT STAND: 80.7

•TV WITH STAND: 82.7

•SHIPPING: 113.5

VESA SUPPORT: Yes (400mm x 400mm)

ACCESSORIES INCLUDED IN BOX:

•REMOTE MODEL: TM-1850A

Q8FN TV

S:8.25”

S:10.75”

T:8.5”

T:11”

B:8.75”

B:11.25”

Samsung TV • TracyLocke

210798 Studio# 213661

TV Spec Sheets

Sell Sheet • Q8FN

tss210798_mch_sls_Q8FN.indd

Print Code: –

Contact: Denise Thomas

Studio Artist: SB

Built At: 100% • Print Scale: None

4-Color Process: Cyan, Magenta, Black

Placed Images:None

Document Fonts:SamsungOne (800, 400), Minion Pro (Regular) 6-5-2018 6:02 PM

Mech Trim: 8.5” x 11”

Mech Live: 8.25” x 10.75”

Mech Bleed: 8.75” x 11.25”

Final Trim: 8.5” x11”

Final Live: 8.25” x10.75”

Final Bleed: 8.75” x11.25”

MODELS

MODEL: QN55Q8FN

ORDER CODE: QN55Q8FNBFXZA

SCREEN SIZE CLASS: 55"

SCREEN DIAGONAL MEASUREMENT: 54.6"

UPC CODE: 887276256931

COUNTRY OF ORIGIN: Mexico

DIMENSIONS (INCHES W x H x D):

•TV WITHOUT STAND: 48.5 x 27.8 x 2.3

•TV WITH STAND: 48.5 x 30.7 x 9.8

•SHIPPING: 53.5 x 33.1 x 7.6

•STAND FOOTPRINT: 2.1 x 7.3 x 9.8

WEIGHT (LB):

•TV WITHOUT STAND: 43.2

•TV WITH STAND: 44.1

•SHIPPING: 56.4

VESA SUPPORT: Yes (200mm x 200mm)

ACCESSORIES INCLUDED IN BOX:

•REMOTE MODEL: TM-1850A

Q8FN TV

MODEL: QN65Q8FN

ORDER CODE: QN65Q8FNBFXZA

SCREEN SIZE CLASS: 65”

SCREEN DIAGONAL MEASUREMENT: 64.5”

UPC CODE: 887276256962

COUNTRY OF ORIGIN: Mexico

DIMENSIONS (INCHES W x H x D):

•TV WITHOUT STAND: 57.1 x 32.7 x 2.3

•TV WITH STAND: 57.1 x 35.8 x 11.6

•SHIPPING: 62.5 x 38 x 7

•STAND FOOTPRINT: 2.2 x 7.9 x 11.6

WEIGHT (LB):

•TV WITHOUT STAND: 58.4

•TV WITH STAND: 59.7

•SHIPPING: 79.1

VESA SUPPORT: Yes (400mm x 400mm)

ACCESSORIES INCLUDED IN BOX:

•REMOTE MODEL: TM-1850A

S:8.25”

S:10.75”

T:8.5”

T:11”

B:8.75”

B:11.25”

Samsung TV • TracyLocke

210798 Studio# 213661

TV Spec Sheets

Sell Sheet • Q8FN

tss210798_mch_sls_Q8FN.indd

Print Code: –

Contact: Denise Thomas

Studio Artist: SB

Built At: 100% • Print Scale: None

4-Color Process: Cyan, Magenta, Black

Placed Images:None

Document Fonts:SamsungOne (800, 400), Minion Pro (Regular) 6-5-2018 6:02 PM

Mech Trim: 8.5” x 11”

Mech Live: 8.25” x 10.75”

Mech Bleed: 8.75” x 11.25”

Final Trim: 8.5” x11”

Final Live: 8.25” x10.75”

Final Bleed: 8.75” x11.25”
