Samsung TV

F/W Upgrade Guide

Samsung Electronics

LN46A580P6F, LN52A580P6FL580

LN32A550P3F, LN37A550P3F, LN40A550P3F

LN46A550P3F, LN52A550P3F

L550

LN40A540P2F, LN46A540P2F, LN52A540P2FL540

Model CodeSeries (L5)

Notice: Please read completely prior to upgrade

¾There are two separate firmware packages required to

complete the upgrading process of the L5 series:

Version 1005.1 or higher for the main processor

L540_L550_L580 firmware 1005.1.exe

Version 1006.1 for the sub processor

L540_L550_L580 firmware 1006.1.exe

¾First determine what the current firmware version is for the

main processor (see below). If the version is 1005.1 or higher

proceed to Step 2 and upgrade the sub processor with 1006.1.

¾How to check the firmware version

User Menu -> Setup -> SW Upgrade

When highlighted the “SW Upgrade”, press the “Info” button on Remote

TV F/W Version : XXXX

Step1. Upgrade the firmware version 1005.1

2. Connect the USB Memory Drive

to the USB port of your PC.

Copy the file into the USB Memory Drive.

3. Go to the USB Memory Drive and then double click the file

L540_L550_L580 firmware 1005.1.exe.

1. Save the firmware file onto your computer.

File : L540_L550_L580 firmware 1005.1.exe

4. Press “Unzip” button. 5. Unzipping is in progress.

6. After completing, press

“OK” and “Close” button.

7. The USB driver should contain one folder

named ‘T-PRL3AUS’

8. Safely disconnect the USB memory drive

by right clicking the green check mark

on the taskbar and then left click

“Safely Remove”.

9. Turn your TV on, and then insert

the USB Memory Drive containing

the firmware upgrade into the

WISELINK port at the Side-AV panel.

NOTE: If you get the “WiseLink” on-

screen selection menu, select “NO”

※Important

If the firmware version you downloaded from the Samsung website

or received from Samsung is older than or has smaller version

number than the version on your TV, do not install it.

10. Press the Menu button on your

Remote Control.

11. Go to Setup.

On the Setup Menu,

select SW Upgrade, and then

press Enter or the arrow button

(▶) on your remote.

12. The TV will scan the USB Memory

Drive.

13. When the software upgrade is

complete; the TV will turn off and

then back on by itself.

Proceed with the ‘Plug & Play’

setup.

14. Once ‘Plug & Play’ is complete;

“Enjoy your watching.” is displayed.

Press the ‘Enter’ key and you are

done.

You can find more information in

User Manual.

※Do not pull the USB drive out and

unplug the power cable until

complete

※Important

If the firmware version you downloaded from the Samsung website

or received from Samsung is older than or has smaller version

number than the version on your TV, do not install it.

Step2. Upgrade the firmware version 1006.1

3. Connect the USB Memory Drive

to the USB port of your PC.

Copy the file into the USB Memory Drive.

4. Go to the USB Memory Drive and then double click the file

L540_L550_L580 firmware 1006.1.exe.

2. Save the firmware file onto your computer.

File : L540_L550_L580 firmware 1006.1.exe

5. Press “Unzip” button. 6. Unzipping is in progress.

7. After completing, press

“OK” and “Close” button.

8. The USB driver should contain one folder

named ‘T-PRL3AUS’

9. Safely disconnect the USB memory drive

by right clicking the green check mark

on the taskbar and then left click

“Safely Remove”.

1. If you completed Step 1 from above, remove the File and Folder (listed

below) on your USB drive.

File : L540_L550_L580 firmware 1005.1.exe

Folder : T-PRL3AUS

10. Turn your TV on and insert

the USB Memory Drive containing

the firmware upgrade into the

WISELINK port at the Side-AV panel.

NOTE: If you get the “WiseLink” on-

screen selection menu, select “NO”

※Important

If the firmware version you downloaded from the Samsung website

or received from Samsung is older than or has smaller version

number than the version on your TV, do not install it.

11. Press the Menu button on your

Remote Control.

12. Go to Setup.

On the Setup Menu,

select SW Upgrade, and then

press Enter or the arrow button

(▶) on your remote.

13. The TV will scan the USB Memory

Drive.

14. When the software upgrade is

complete the TV will turn off and

then back on by itself.

Proceed with the ‘Plug & Play’

setup

15. Once ‘Plug & Play’ is complete;

“Enjoy your watching.” is

displayed. Press the ‘Enter’ key

and you are done.

You can find more information in

User Manual.

※Do not pull the USB drive out and

unplug the power cable until

complete

※Important

If the firmware version you downloaded from the Samsung website

or received from Samsung is older than or has smaller version

number than the version on your TV, do not install it.
