HL-S5086W

50" Widescreen DLP®HDTV with 720p Resolution

TV/Video

• DLP®TV by Samsung

• Thin bezel (.9"), depth (15.6") design–

fits where others won’t™

• Built-in analog/digital tuner (NTSC/ATSC)

• Samsung Cinema Smooth™ 720p light engine

- single panel digital micro-mirror device (DMD)

design for a crystal clear picture without any

possibility of convergence errors

- Up to 2500:1 contrast ratio with outstanding

colors and deep black levels

- Whisper-quiet operation

• Brilliant Color™ provides brightness increase

in non-primary colors and boosts overall

color intensity

• 1280 x 720 digital format converter for all inputs

• Samsung DNIe™ video enhancement

• Samsung’s Cinema Smooth™ film-mode

3:2 pull down

• No burn-in or uneven screen aging

• New Photo Viewer Interface (with USB 1.1)

• Game mode

Audio

• Audio wattage – 10W x 2 output

• SRS®TruSurround XT™ sound

Connections

• 2 HDMI inputs (High Definition

Multimedia Interface)

• 2-component video inputs

(480i/480p/720p/1080i)

• 3 (2 rear/1 side) A/V composite inputs and

2 S-video inputs

• USB 1.1

• PC (RGB) input

Featuring a thin bezel design that “fits where

others won’t™”, Samsung’s 50" Widescreen DLP®

TV delivers an astounding HDTV experience.

Samsung, the recognized leader in DLP technology,

created the breakthrough Cinema Smooth™ light

engine that produces razor-sharp pictures in

720p. The natural, vivid colors of Samsung’s

HL-S5086W are achieved through our advanced

Brilliant Color™ technology with a faster color

wheel. A contrast ratio of up to 2500:1 captures

blacker blacks and crisper whites. And the

ultra-fast DLP chip results in the fastest video

performance of any HDTV. Best yet, Samsung’s

superior technology ensures no image burn-in for

a reliable, long-lasting picture.

Shown with optional stand (TR50X3B)

DLP®tv

HL-S5086W 50" Widescreen DLP®HDTV with 720p Resolution

Cinema Smooth 720p Light Engine

Samsung’s Cinema Smooth 720p light engine is the culmination of years of industry-

leading research and development. It releases the maximum power of the new generation

of DMD microdisplays for the most film-like picture. It creates an image with no visible pixel

structure and accurate shading and better low-light detail.

Next Generation DLP Chips from Texas Instruments

Samsung employs a Texas Instruments DLP chip that is comprised of millions of micro-

scopic mirrors. The DLP chip is faster than any HDTV technology, with the mirrors capable

of switching on & off at 15,000 or more times a second to deliver a razor-sharp picture for

fast moving images When combined with Samsung’s new Cinema Smooth light engine,

the result is a crisp, bright picture with deep, rich colors that’s closer to film.

Faster Color Wheel

Samsung’s 2.2” color wheel spins at 14,400 rpm for smooth fast-motion video, and

has five color segments for more accurate colors. Comprised of the 3 primary colors,

Red, Green and Blue plus Cyan and Yellow. It achieves film-like transitions and

eliminates the pixel breakup found in slower color wheel designs and slower-switching

LCD microdisplays. The Cinema Smooth™ light engine uses a whisper quiet air

bearing design.

Samsung’s DNIe™– Digital Natural Image Engine

Samsung’s exclusive Digital Natural Image engine makes the sharpest and clearest images

possible, regardless of the profile of input signals. Five image processors and a six-times

density enhancer ensure the best picture from any source. Now in its fourth generation,

DNIe guarantees the truest colors and highest contrast, while virtually eliminating digital artifacts.

My Color Control

You can get the pink tones, the green of the grass and the blue of the sky just the way

you like, without affecting the other colors on the screen. The three primary colors can be

adjusted to perfectly fit your taste. Self expression meets display perfection.

Green

Blue

Pink

Integrated HDTV Tuner

with the addition of a suitable UHF/VHF antenna delivers the world of free off-air DTV and HDTV local broadcast channels.

Cinema Smooth™Light Engine

Samsung is the worldwide leader in creating light engines that harness DLP HDTV technology from Texas Instruments. Samsung’s

Cinema Smooth light engine brings together the right optics, electronic circuitry and replaceable light source to create a brilliant

picture that’s more lifelike and much closer to film. Now in its fifth year of evolution, Samsung’s Cinema Smooth light engine

delivers crisp, 720p High Definition resolution with high contrast and brightness, defined edges and sharp detail.

Cinema Mode

Samsung’s Cinema Mode lets you see colors the way the

director intended, by matching them more closely to production

standards. This creates more accurate colors and natural skin

tones when viewing Hollywood movies on your TV—the perfect

setting when enjoying movies with the lights off.

Cinema Smooth™

Film Mode 3:2

Pull Down

Smooth technology, 3:2 Pull Down

corrects for the artificial frames created

when films are converted to DVDs.

The result is a clearer image without

the subtle motion artifacts caused by

24-to-30 frames per second video

conversion.

Picture Format Size

Adjustment

Enjoy all your 4:3 aspect-ratio pro-

gramming in smooth, wide-screen

without black bars. Four pre-set

aspect ratio modes—Normal, Wide,

Zoom 1 and Zoom 2—stretch your

image to fill the screen naturally.

Color Temperature Adjustments

Cool1, Cool2, Normal, Warm1, Warm2 selectable

with on-screen display.

3D Comb Filter

dramatically reduces edge image artifacts

while improving transition detail.

Previous Channel

returns to the previously viewed channel at the push of a button.

Game Mode

enhances dark areas, sharpens the picture, speeds up the

image processing response and enhances the sounds of your

games. Picture and sound quality optimized for the special

needs of gaming systems at the touch of a button.

HL-S5086W

V-Chip1

enables parental control for channel and program blocking

of TV programs that incorporate the rating code signal.

Clock with On/Off Timer

Closed Caption displays dialog that can be read along with

encoded broadcast TV programs and pre-recorded videos.

Non Volatile Memory

preserves audio, video and menu settings

during power outages.

Auto Volume Leveler

keeps audio volume consistent during channel changing to

minimize static sound bursts.

Discrete IR Codes

This set is equipped with discrete IR codes for use with an

optional macro/programmable remote (see owners manual

for details).

Universal Remote Control

permits control of the TV, DVD, VCR and a Tuner/Receiver.

HDMI (High-Definition

Multimedia Interface)

addresses both pure digital audio and video

performance and simplifies connections from

the new generation set-top boxes and DVD

players by reducing cable connections to one

cable and plug.

DTV and DVD

Compatible Connect

your DVD and DTV sources with two smart

component video (Y/Pb/Pr) inputs that

accept 480p/720p/1080i signals.

A Samsung HDTV using DLP technology

can also function as a high-quality XGA

PC monitor.

Interlaced

Progressive

Cinema

Progressive

4:3 16:9 wide

Zoom 1 Zoom 2

Samsung Electronics America, Inc.

105 Challenger Road

Ridgefield Park, NJ 07660-0511

Tel (201) 229-4000 • 1-800-SAMSUNG

www.samsung.com

Specifications

VIDEO

Display device: Single digital micro

mirror device

Pixel count: 1280 horizontal x 720 vertical

Color wheel: 55 mm/5 segment

Resolution: 720p

Contrast ratio: 2500:1

Channel coverage: VHF 2-13,

UHF 14-69, CATV 1-125 (up to 181

pre-selected channels), ATSC 1-69

AUDIO

Output power: 10Wx2

Speakers: 2

Sound mode: 5 modes

MTS stereo

Connections

ANALOG VIDEO

RF in: 1 rear

AV in: 2 rear/1 side

S-Video input: 2 rear

Monitor & sound out: 1 rear

Component video input (Y/Pb/Pr):

2 rear

PC (RGB) input: 1 rear

PC audio input: 1 rear

USB: 1 side

Digital sound out (optical)

HDMI: 2 rear (digital audio & video)

HL-S5086W

50" Widescreen DLP®HDTV with 720p Resolution

Quality

Warranty: 1 year parts and labor

warranty, including lamp, with in-home

service backed by Samsung toll-free

support. 1-800-SAMSUNG

Accessories

Remote control

User manual

Net dimensions and weight

(WxHxD)

TV: 45.4"0 x 32.3" x 15.6"

TV weight: 62.8 lbs.

Shipping dimensions

(WxHxD)

Carton: 50.0" x 37.6" x 19.7"

Carton weight: 78.3 lbs.

Order code

HLS5086WX/XAA

UPC

036725250864

Optional stand: (WXHXD)

TR50X3B

Net dimensions: 45.6" x 17.7" x 17.4"

Net weight: 72.2 lbs.

Shipping dimensions:

52" x 7.5" x 19.6"

Shipping weight: 83.6 lbs.

UPC: 036725296015

Order code: TX50X3BX/XAA

1Feature dependent upon broadcasting of information

by local off-air TV and cable channels.

Design and specifications are subject to change

without notice. Non-metric weights and measure-

ments are approximate.

DLP, and the DLP logo are registered trademarks

or trademarks of Texas Instruments.

HDMI, the HDMI logo and High Definition Multimedia

Interface are trademarks or registered trademarks

of HDMI Licensing LLC.

SRS TruSurround XT is a registered trademark of

SRS Labs, Inc.

DNIe™, Cinema Smooth™ and BrilliantColor™ are

trademarks of Samsung Electronics Co., Ltd.

trademarks are trademarks of the National

Football League.

rights reserved Samsung is a registered trademark

of Samsung Electronics Co., Ltd. All product and

brand names are trademarks or registered trade-

marks of their respective companies.

406-SS Printed in USA.

For more information on digital TV technology

please visit www.samsung.com/dtvguide
