Samsung CL29K40MQ2XXAP Manuel utilisateur

COLOR TELEVISION RECEIVER

Chassis : K16A(N)_Ray

Model : CL29K40MQ2XXAP

COLOR TELEVISION RECEIVER FEATURES

■■Turbo Plus

■DNIe jr.

■■Low Stand-By Power Wattage

■SOUND Equalizer

SERVICE Manual

CL-29K40MQ

Wiring Diagram

Samsung Electronics 8-1

8. Wiring Diagram

8-1 Overall Wiring

CONTROL PCB

POWERSWITCH

SPEAKER

PIP MODULE

AV PCB

CRT SIGNAL

& POWER

Wiring Diagram

8-2 Samsung Electronics

8-2 Pin Connection

CN901

Pin NO. Pin Name

1STD-LED

2TIME-LED

3GND

4VCC

5I.R

CN902

Pin NO. Pin Name

1KEY-IN2

2KEY-IN1

3GND

4KEY-IN3

CN503

Pin NO. Pin Name

1B-OUT

2G-OUT

3R-OUT

4GND

5SENSE

6GND

7N.C

8GND

9GND

10 N.C

11 GND

12 HEAT ER

13 N.C

14 B+ 200V

CN701

Pin NO. Pin Name

1AV2-R-IN

2AV2-L-IN

3AV2-L-OUT

4AV2-R-OUT

5GND

6 AV2-V-IN

7GND

8 AV2-V-OUT

CN702

PinNO. PinName

1C-OUT

2GND

3Y-OUT

4GND

5C-IN

6GND

7Y-IN

TU01S

TU02S

CN501A

Pin NO. Pin Name

1GND

2N.C

3GND

4HEATER

5N.C

6B+200V

CN502

Pin NO. Pin N ame

1B-OUT

2G-OUT

3R-OUT

4GND

5SENSE

6GND

7N.C

8GND

FN01

PinNO. PinName

1TILTOUT

2TILTOUT

3GND

4GND

CN601

NO.

Pin Name

1R+OUT

2R-OUT

3L+OUT

4L-OUT

CN900

Pin NO. Pin Name

1SCL

2GND

3B+3.3V

4SDA

PIP MODULE

CNP01 CNP02

CNP01

Pin NO. Pin Name

1B+8V

2B+5V

3GND

4SCL

5SDA

6GND

7H-SYNC

8V-SYNC

9PIP-F/B

10 PIP- B

11 PIP- G

12 PIP- R

CNP02

Pin NO. Pin Name

1OSD-R

2OSD-G

3OSD-B

4OSD-F/B

SU b-

CVBS

6GND

PIP-

CVBS

8N.C

Troubleshooting

Samsung Electronics 6-1

6. Troubleshooting

6-1 Checkpoints by Error Mode

■Power LED: Check that the LED works when turning the Master Switch ON/OFF

■LED Indicators: See table 6-2-1 Basic Troubleshooting: LED Diagnosis on the Front Panel.

■In case of a power failure or abnormal screen, check the following items.

1) Check that the power cord is correctly connected to a 230V wall outlet.

2) Check that the Master Switch has been pressed.

3) Check that the transmitter is turned on.

4) Check that transmitter device selection is set to TV.

5) Check that the signal cable is properly connected.

6) Check that channel setting has been set.

Troubleshooting

6-2 Samsung Electronics

6-1-1 Flow Chart for Malfunction

dnuoSoN&erutciPoN

ehtkcehC

erpmiegatlov

ret

htkcehC

tiw

ehtkceh

”S1

“E

ehtkc

#”S108D“

htkce

76W

”S

108

F“

egnah

taelpm

rew

riapeR

”S108

D“

egnahC

seY

”S

08CI“egnahC

seY trap

srehto

dnuoson&erutcipoN

)KOrewopts1(

enilV521+e

htkcehC

3#niP+B

44T

kcehcdnanepO

srehtoehtkcehC

il+B

”1

04Q

“

eht

ehC

tael

ponr

”104Q“ehtegnahC

nep

)805AD

(”

118D

“

kcehcdn

805A”

D“

htegnahC

805A)D

(

enilV

21+e

kcehC

trapsrehto

IC901 TU01S

IC201S

IC601

IC802

IC803

IC804

LED

Power cord IC801S QE01 IC301S

T401S

Q401S

Troubleshooting

Samsung Electronics 6-3

6-2 Troubleshooting Procedures by Error Modes

6-2-1 Basic Troubleshooting: Diagnosis of LED on the Front Panel

6-2-2 Troubleshooting by the Checksum

■Diagnosis of trouble by the checksum is neither reliable nor convenient.

You can only use the checksume of the current direct-view TV to determine whether the software is corrupted or not.

The Checksum value is determined according to the version of the software loaded on the set.

Therefore, you can determine whether the software has been properly downloaded, if you know the correct checksum for that

version of the software.

You can check the checksum according in the following order.

Factory Mode →Checksum →Right Button →Calculate Checksum →Output Checksum (e.g. 3036)

■Checksum Examples

T-TR2PEU-1000 : checksum = 8036

T-TR2PEU-1010 : checksum = B612

Power Description

○This happens when the Master Switch is not pressed or the power cord is disconnected.

●This happens when the power cord is connected and the power switch is pressed.

If you cannot set the power switch on by pressing it, check the power switch Ass'y.

○→◑→●

If you press the power switch of the transmitter or the channel key on the remote control when in

St-BY status, the screen will be turned on.

If the LED blinks and the screen is not displayed, check the connection between the Control

Assy and the Main Board.

●: Light is On

◑: Light is Blinking

○: Light is Off

Troubleshooting

6-4 Samsung Electronics

6-3 Troubleshooting Procedures by ASS'Y

6-3-1 No Power (1st Power)

No Picture & No Sound

Check the AC

voltage impress

Check the master

switch on

Check the

FUSE “FP801S”

Check the

“D801S” #1

Yes

Check the

IC801S #1

W6750F

Change “FP801S”

Compleat

Repair No Power

Yes

Change “D801S”

Yes

Change “IC801S”

Yes Check the others part

6-3-2 No Picture(2nd Power)

No picture

(1st power OK)

Check the +125V line

T444 B+ Pin #3

Open and check

Check the others

B+ line

Yes

Check the “Q401”

Yes

Compleat

repair no picture

Change the “Q401”

Yes

“D811”(D811A) open

and check

Change the “D811”

(D811A)

Yes

Check IC501 Pin#6

Yes Change IC201

Change IC501

Troubleshooting

Samsung Electronics 6-5

6-3-3 No Sound

No sound

(1st power OK)

Check the +14V line

Check D807

Yes

Check IC601 Pin#6

Yes

Compleat

repair no sound

Change IC601”

Yes

Check FD801S

(FD802S)

Change FD801S

(FD802S)

Check IC201 Pin#58,59

Yes Change IC201

IC901 TU01S

IC201S

IC601

IC802

IC803

IC804

LED

Power cord IC801S QE01 IC301S

T401S

Q401S

6-6 Samsung Electronics

MEMO

TP02

TP01

TP03

TP08

10. Schematic Diagram

Samsung Electronics

Schematic Diagram

10-1

10-1 Power & Deflection Block

This Document can not be used without Samsung’s authorization. TP01

TP02

TP03

TP08

Power

Signal
