Samsung DA-E750 Manuel utilisateur

Wireless Audio with Dock

user manual

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service,

please register your product at

www.samsung.com/register

DA-E750

DA-E751

features

AllShare Play

Play music saved on your devices (such as your PC, Smart phone, or NAS) through the Wireless Audio with Dock

via a network connection.

AirPlay

Play music saved on your Apple devices on the Wireless Audio with Dock.

Dual Docking Audio Speaker System

Using the system's dual docking station, dock, charge, and then play either Samsung Galaxy devices or Apple

devices through the system's built-in speakers.

USB Host support

Connect and play music files from external USB storage devices such as MP3 players, USB flash memory, etc.

using the Wireless Audio with Dock's USB HOST function.

Bluetooth Function

Connect a Bluetooth device to the Wireless Audio with Dock and enjoy music from the device with high quality

stereo sound, all without wires!

aptX®

aptX enables high quality Bluetooth stereo audio, delivering wired audio quality wirelessly.

LICENSE

AirPlay, AirPlay logo, iPhone, iPod, iPod classic, iPod nano, iPod shuffle, and iPod touch are trademarks of Apple

Inc., registered in the U.S. and other countries. iPad is a trademark of Apple lnc.

EnG

safety information

SAFETY WARNINGS

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK).

NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates “dangerous voltage”

inside the product that presents a risk of

electric shock or personal injury.

This symbol indicates important instructions

accompanying the product.

WARNING : To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

• This apparatus shall always be connected to a AC outlet with a protective grounding connection.

• To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains

plug shall be readily operable.

CAUTION

• Do not expose this apparatus to dripping or splashing. Do not put objects filled with liquids, such as vases on the

apparatus.

• To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the power

plug must be easily and readily accessible at all times.

PRECAUTIONS

Ensure that the AC power supply in your house complies with the power requirements listed on the identification sticker located on the

back of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4

inches). Make sure the ventilation slots are not covered. Do not place the

unit

on amplifiers or other equipment which may become hot.

This

unit

is designed for continuous use. To fully turn off the unit, disconnect the AC plug from the wall outlet. Unplug the unit if you intend

to leave it unused for a long period of time.

During thunderstorms, disconnect the AC plug from the

wall outlet. Voltage peaks due to lightning could damage the unit.

Protect the

product

from moisture (i.e. vases) , and excess heat

(e.g.fireplaces) or equipment creating strong magnetic or electric fields

Disconnect the power cable from the AC supply if the unit malfunctions.

Your

product

is not intended for industrial use. This product is for

personal use only.

Condensation may occur if your

product

has been stored in cold temper-

atures. If transporting the

unit

during the winter, wait approxi

mately 2 hours

until the unit has reached room temperature before using.

Do not expose the unit to direct sunlight or other heat sources.

This could cause the unit to overheat and malfunction.

The batteries used with this product contain chemicals that are harmful to

the environment.

Do not dispose of batteries in the general household trash.

The batteries used with this product contain chemicals that are harmful to

Phones

3.9 inch 3.9 inch

2.7 inch

3.9 inch

EnG

contents

FEATURES

2 Features

2 License

SAFETY INFORMATION

3 Safety warnings

4 Precautions

GETTING STARTED

6 Before reading the user’s manual

6 What’s included

DESCRIPTIONS

7 Top/Front/Rear Panel

REMOTE CONTROL

9 Tour of the remote control

POWER ON AND VOLUME

CONTROL

10 Turning the Power on/off

10 Adjusting the volume

CONNECTIONS

11 Installing the Toroidal Ferrite on the Power

Cable

Installing the Ferrite Core on the LAN Cable

12 Using the Spacer Cover

13 Connecting a device to the Dual Dock

14 Connecting an audio device using AUX IN

15 Connecting to your Network

21 Connecting to Bluetooth devices

PLAYING

23 Using the TV mode (SoundShare)

23 Using the docking mode with Samsung

Galaxy and Apple Devices

25 Using the Bluetooth mode

26 Using the USB mode

27 Using AirPlay and AllShare Play mode

FUNCTIONS

28 Basic functions

29 Advanced functions

30 Software upgrade (only USB mode)

TROUBLESHOOTING

31 Troubleshooting

APPENDIX

32 Specifications

BEFORE READING THE USER’S MANUAL

Note the following terms before reading the user manual.

Icons used in this manual

Icon Term Definition

Caution

Indicates a situation where a function does not operate or settings may be

canceled.

Note

Indicates tips or instructions on the page that help a function operate.

Safety Instructions and Troubleshooting

1) Familiarize yourself with the Safety Instructions before using this product. (See page 3)

2) If a problem occurs, check Troubleshooting. (See page 31)

written permission of Samsung Electronics Co.,Ltd.

getting started

▪The appearance of the accessories may differ slightly from the illustrations above.

WHAT’S INCLUDED

Check for the supplied accessories shown below.

MUTE

VOL BASS

FUNCTION

Remote Control / Lithium Battery (3V) Power Cable

Audio Cable LAN Cable

(Large)

(For Power Cable 1EA)

(Small)

(For LAN Cable 1EA)

Toroidal Ferrite Core Spacer Cover/

Protection Cover Cloth User Manual

EnG ●DEscriPtions

descriptions

TOP/FRONT/REAR PANEL

PUSH

AUX IN

WPS / RESET

ONLYFOR

SERVICE

LAN

USB 5V 500mA

POWER

PUSH

AUX IN

WPS / RESET

ONLYFOR

SERVICE

LAN

USB 5V 500mA

POWER

DOCK

PUSH

AUX IN

WPS / RESET

ONLYFOR

SERVICE

LAN

USB 5V 500mA

POWER

PUSH

AUX IN

WPS / RESET

ONLYFOR

SERVICE

LAN

USB 5V 500mA

POWER

DOCK

PUSH

AUX IN

WPS / RESET

ONLYFOR

SERVICE

LAN

USB 5V 500mA

POWER

PUSH

AUX IN

WPS / RESET

ONLYFOR

SERVICE

LAN

USB 5V 500mA

POWER

DOCK

PUSH

AUX IN

WPS / RESET

ONLYFOR

SERVICE

LAN

USB 5V 500mA

POWER

PUSH

AUX IN

WPS / RESET

ONLYFOR

SERVICE

LAN

USB 5V 500mA

POWER

DOCK

PUSH

AUX IN

WPS / RESET

ONLY FOR

SERVICE

LAN

USB 5V 500mA

POWER

PUSH

AUX IN

WPS / RESET

ONLY FOR

SERVICE

LAN

USB 5V 500mA

POWER

DOCK

<TOP>

VACUUM

TUBE AMP

<FRONT>

<REAR>

PLAY/PAUSE

BUTTON

Play or pause a music file.

FUNCTION

BUTTON

Switches the mode as follows :

;;;;;;AUX (LED Off)

VOLUME +/-

BUTTON

Controls the volume level.

FUNCTION

DISPLAY

When you change the mode with the Function button, the icon of the

selected mode is displayed in white on the Function Display.

The LED blinks when you turn the power on and stops blinking when

the unit is on and ready to play.

5DUAL DOCK

Provides a 5 pin dock for Samsung Galaxy devices and a 30 pin dock

for Apple devices.

6LAN TERMINAL

Lets you connect to a network using a LAN cable.

7WPS/RESET

BUTTON

Used in procedures for connecting the unit to wireless networks.

8USB PORT

Connect an external USB storage device such as an MP3 player here

to play files located on the device.

9POWER JACK

Connect the power cord to this product.

10 AUX IN

Connect to the Analog output of an external device.

11 ONLY FOR

SERVICE

This jack is for service only.

▪When you turn on this unit, it needs about 20 seconds to heat-up the Vacuum tube and

produce stable sounds.

▪To update the product’s software via USB port, it is required to use a USB memory device.

▪When holding or moving the product, care must be taken as there is located the woofer

speaker in the bottom of the product.

▪This unit can connect to mobile devices with high audio output levels. When you connect this

unit to external devices with high output levels, it may lower the audio output to protect the amp

and speakers.

▪When disconnecting the power cable from the wall outlet, hold the plug.

Do not pull the cable.

▪If you put other electronic products on top of the product, audio from the product may be

distorted.

▪Please make sure children do not touch the product's surface when the product is on.

The surface will be hot.

EnG ●rEmotE control

remote control

TOUR OF THE REMOTE CONTROL

Installing battery in the Remote Control

1. Open the cover of the remote

control by putting your fingernail

into the gap between the cover

and body of the remote control.

Then, lift the cover and separate

it completely.

2. Install a 3V Lithium battery.

Insert the battery into the battery

compartment with the + side facing

up.

3. Fit the remote control's cover to the

remote control. Next, lower the cover so

that it is flush with the body of the remote,

and then press the cover into the body by

pushing the edges down with your hand.

Operation Range of the Remote Control

You can use the remote control up to 23 feet (7 meters) in a straight line from the unit. You can also operate the

remote at a horizontal angle of up to 30° from the remote control sensor.

MUTE

VOL BASS

FUNCTION

POWER BUTTON

Turns the unit on and off.

CONTROL BUTTON

Search for the next or previous

music file.

VOLUME

Adjusts the volume level of the unit.

PLAY/PAUSE BUTTON

Play or pause a music file.

FUNCTION BUTTON

Selects the Function mode.

▪Be careful not to catch your fingernail in the gap when you lift the cover. You can damage

your fingernail.

MUTE BUTTON

Mutes the sound from this unit.

Press again to restore the sound

to the previous volume level.

BASS BUTTON

Optimise the sound based on

your tastes.

power on and volume control

TURNING THE POWER ON/OFF

MUTE

VOL BASS

FUNCTION

MUTE

VOL BASS

FUNCTION

DOCK

1.To turn on this unit, press any button on the unit's top panel when the unit is in Standby mode.

or,

Press POWER on the remote control.

2.To turn off this unit, press the +# button on the unit's top panel for more than 3 seconds.

or,

Press POWER on the remote control again.

▪It will take about 20 seconds until the power of the unit turns on because of the preheating time of

the amplifier.

ADJUSTING THE VOLUME

Use +,- buttons to adjust the volume. The function LEDs light from left to right when you turn the volume up and

from right to left when you turn the volume down. The LEDs do not light if you try to increase the volume when it has

already been set to maximum or try to decrease the volume when it has already been set to minimum.

MUTE

VOL BASS

FUNCTION

MUTE

VOL BASS

FUNCTION

DOCK

Press the +/– button on the right side of the top panel.

or,

Press VOL +/– on the remote control.

▪The volume level increases or decreases when you press VOL +/–.

▪You can also use the volume controls of devices connected using the Dual Dock or Bluetooth to control

the volume. However, your ability to control the volume using the volume controls of devices connected

using Bluetooth may be limited.

Autres manuels pour DA-E750

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Samsung Système stéréo

Samsung

Samsung MM-KG36 Manuel utilisateur

Samsung

Samsung HW-K350 Manuel utilisateur

Samsung

Samsung MX-T50 Instructions d'installation

Samsung

Samsung MAX-6020 Manuel utilisateur

Samsung

Samsung MM-VB7 Manuel utilisateur

Samsung

Samsung MAX-DA75 Manuel utilisateur

Samsung

Samsung MX-T70 Instructions d'installation

Samsung

Samsung HW-H610 Manuel utilisateur

Samsung

Samsung AH68-02275X Manuel utilisateur

Samsung

Samsung MM-DA25 Manuel utilisateur

Samsung

Samsung Sound+ SWA-9000S Manuel utilisateur

Samsung

Samsung DA-E570 Manuel utilisateur

Samsung

Samsung MM-J4 Manuel utilisateur

Samsung

Samsung CM3430B Manuel utilisateur

Samsung

Samsung MM-L2G Manuel utilisateur

Samsung

Samsung MM-ZJ9 Manuel utilisateur

Samsung

Samsung MX-T70 Instructions d'installation

Samsung

Samsung MM-16 Guide de l'administrateur

Samsung

Samsung DVD-V5500 Manuel utilisateur

Samsung

Samsung MAX-S725 Manuel utilisateur

Samsung

Samsung MX-JS9000 Manuel utilisateur

Samsung

Samsung MAX-DT99 Manuel utilisateur

Samsung

Samsung MM-DG25 Manuel utilisateur

Samsung

Samsung harman/kardon HW-Q80R Manuel utilisateur

Manuels Système stéréo populaires d'autres marques

LG CM3330B Manuel utilisateur

Sony

Sony SS-CEP50 Manuel utilisateur

Cetacea Sound

Cetacea Sound CVS-II Manuel utilisateur

Aiwa

Aiwa XR-H66MD Manuel utilisateur

Denon

Denon UCD-250 Manuel utilisateur

Sanyo

Sanyo DC-MX41i Manuel utilisateur

Sharp

Sharp CD-ES600V Manuel utilisateur

Exibel

Exibel BDX600-UK Manuel utilisateur

Sanyo

Sanyo DC-F320 Manuel utilisateur

Philips

Philips FWM583X Manuel utilisateur

Sharp

Sharp CD-C462 Manuel utilisateur

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio Manuel utilisateur

Aiwa

Aiwa XR-EM70 Manuel utilisateur

Cyrus

Cyrus Lyric Manuel utilisateur

Philips

Philips MCM159/98 Manuel utilisateur

Philips/Magnavox

Philips/Magnavox Magnavox FW 62C Manuel utilisateur

RCA

RCA RS3965SB Manuel utilisateur

Sharp

Sharp XL-UH240 Manuel utilisateur
