Samsung DA-E660 Manuel utilisateur

Wireless Audio with Dock

user manual

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more a complete service,

please register your product at

www.samsung.com/register

DA-E660

DA-E661

features

Galaxy Docking Audio Speaker System

Using the system's docking station, dock, charge, and then play any Samsung Galaxy devices through the system's

built-in speakers.

USB Host support

Connect and play music files from external USB storage devices such as MP3 players, USB flash memory, etc.

using the Wireless Audio with Dock's USB HOST function.

Bluetooth Function

Connect a Bluetooth device to the Wireless Audio with Dock and enjoy music from the device with high quality

stereo sound, all without wires!

aptX®

aptX enables high quality Bluetooth stereo audio, delivering wired audio quality wirelessly.

EnG

safety information

SAFETY WARNINGS

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK).

NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates “dangerous voltage”

inside the product that presents a risk of

electric shock or personal injury.

This symbol indicates important instructions

accompanying the product.

WARNING : To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

• This apparatus shall always be connected to a AC outlet with a protective grounding connection.

• To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains

plug shall be readily operable.

CAUTION

• Do not expose this apparatus to dripping or splashing. Do not put objects filled with liquids, such as vases on the

apparatus.

• To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the power

plug must be easily and readily accessible at all times.

PRECAUTIONS

Ensure that the AC power supply in your house complies with the power requirements listed on the identification sticker located on the

back of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (70~100

mm). Make sure the ventilation slots are not covered. Do not place the

unit

on amplifiers or other equipment which may become hot. This

unit

is designed for continuous use. To fully turn off the unit, disconnect the AC plug from the wall outlet. Unplug the unit if you intend to

leave it unused for a long period of time.

During thunderstorms, disconnect the AC plug from the

wall outlet. Voltage peaks due to lightning could damage the unit.

Protect the

product

from moisture (i.e. vases) , and excess heat

(e.g.fireplaces) or equipment creating strong magnetic or electric fields

Disconnect the power cable from the AC supply if the unit malfunctions.

Your

product

is not intended for industrial use. This product is for

personal use only.

Condensation may occur if your

product

has been stored in cold temper-

atures. If transporting the

unit

during the winter, wait approxi

mately 2 hours

until the unit has reached room temperature before using.

Do not expose the unit to direct sunlight or other heat sources.

This could cause the unit to overheat and malfunction.

The batteries used with this product contain chemicals that are harmful to

the environment.

Do not dispose of batteries in the general household trash.

The batteries used with this product contain chemicals that are harmful to

Phones

3.9 inch 3.9 inch

2.7 inch

3.9 inch

99.1mm

68.6mm

99.1mm

EnG

contents

FEATURES

2 Features

SAFETY INFORMATION

3 Safety warnings

4 Precautions

GETTING STARTED

6 Before reading the user’s manual

6 What’s included

DESCRIPTIONS

7 Front/Rear Panel

REMOTE CONTROL

9 Tour of the remote control

POWER ON AND VOLUME

CONTROL

10 Turning the Power on/off

10 Adjusting the volume

CONNECTIONS

11 Installing the Toroidal Ferrite on the Power

Cable

12 Using Rubber

13 Connecting a device to the Galaxy Dock

14 Connecting an audio device using AUX IN

16 Connecting to Bluetooth devices

PLAYING

18 Using the TV mode (SoundShare)

18 Using the docking mode with Samsung

Galaxy Devices

19 Using the Bluetooth mode

20 Using the USB mode

FUNCTIONS

21 Basic functions

22 Advanced functions

23 Software upgrade (only USB mode)

TROUBLESHOOTING

24 Troubleshooting

APPENDIX

25 Specifications

BEFORE READING THE USER’S MANUAL

Note the following terms before reading the user manual.

Icons used in this manual

Icon Term Definition

Caution

Indicates a situation where a function does not operate or settings may be

canceled.

Note

Indicates tips or instructions on the page that help a function operate.

Safety Instructions and Troubleshooting

1) Familiarise yourself with the Safety Instructions before using this product. (See page 3)

2) If a problem occurs, check Troubleshooting. (See page 24)

written permission of Samsung Electronics Co.,Ltd.

getting started

▪The appearance of the accessories may differ slightly from the illustrations above.

WHAT’S INCLUDED

Check for the supplied accessories shown below.

MUTE

VOL

BASS

FUNCTION

Remote Control / Lithium Battery (3V)

DC Adapter Power Cable Audio Cable

(Rubber-Support: 2EA)

(Rubber-Skin) (Large)

(For Power Cable 1EA)

Rubber-Support / Rubber-Skin Ferrite Core Cloth User Manual

EnG ●DEscriptions

descriptions

FRONT/REAR PANEL

ONLYFOR

SERVICE

AUX IN

DC 14V 4A

USB

5V 500mA

ONLYFOR

SERVICE

AUX IN

DC 14V 4A

USB

5V 500mA

ONLYFOR

SERVICE

AUX IN

DC 14V 4A

USB

5V 500mA

ONLY FOR

SERVICE

AUX IN

DC 14V 4A

USB

5V 500mA

1 2 3

<FRONT>

<REAR>

FUNCTION

Switches the mode as follows : ;;;;AUX (LED Off)

VOLUME -/+

Controls the volume level.

PLAY/PAUSE

Play or pause a music file.

GALAXY DOCK

Provides a 5-pin dock for Samsung Galaxy devices and a 30-pin dock

for Samsung Galaxy Tab devices.

When you change the mode with the Function button, the selected

mode will be displayed in red on the Function Display.

The LED stops blinking when the power of the unit turns on.

5DC 14V

Connect the unit's DC adapter to this jack.

6USB PORT

Connect an external USB storage device such as an MP3 player here

to play files located on the device.

7AUX IN

Connect to the Analog output of an external device.

8ONLY FOR

SERVICE

This jack is for service only.

▪When you turn on this unit, there will be a 4 to 5 second delay before it produces sound.

▪To update the product’s software via USB port, it is required to use a USB memory device.

▪This unit can connect to mobile devices with high audio output levels. When you connect this

unit to external devices with high output levels, it may lower the audio output to protect the amp

and speakers.

▪When disconnecting the power cable from the wall outlet, hold the plug.

Do not pull the cable.

EnG ●rEmotE control

remote control

TOUR OF THE REMOTE CONTROL

Operation Range of the Remote Control

You can use the remote control up to 7 meters (23 feet) in a straight line from the unit. You can also operate the

remote at a horizontal angle of up to 30° from the remote control sensor.

MUTE

VOL

BASS

FUNCTION

POWER BUTTON

Turns the unit on and off.

CONTROL BUTTON

Search for the next or previous

music file.

VOLUME

Adjusts the volume level of the unit.

PLAY/PAUSE BUTTON

Play or pause a music file.

FUNCTION BUTTON

Selects the Function mode.

MUTE BUTTON

Mutes the sound from this unit.

Press again to restore the sound

to the previous volume level.

BASS BUTTON

Optimise the sound based on

your tastes.

▪Be careful not to catch your fingernail in the gap when you lift the cover. You can damage

your fingernail.

Installing battery in the Remote Control

1. Open the cover of the remote

control by putting your fingernail

into the gap between the cover

and body of the remote control.

Then, lift the cover and separate

it completely.

2. Install a 3V Lithium battery.

Insert the battery into the battery

compartment with the + side facing

up.

3. Fit the remote control's cover to the

remote control. Next, lower the cover so

that it is flush with the body of the remote,

and then press the cover into the body by

pushing the edges down with your hand.

power on and volume control

TURNING THE POWER ON/OFF

MUTE

VOL

BASS

FUNCTION

MUTE

VOL

BASS

FUNCTION

ONLYFOR

SERVICE

AUX IN

DC 14V 4A

USB

5V 500mA

ONLY FOR

SERVICE

AUX IN

DC 14V 4A

USB

5V 500mA

1.To turn on this unit, touch any button on the unit's front panel when the unit is in Standby mode.

or,

Press POWER on the remote control.

2.To turn off this unit, touch the +# button on the unit's front panel for more than 3 seconds.

or,

Press POWER on the remote control again.

ADJUSTING THE VOLUME

Use +,- buttons to adjust the volume. The function LEDs light from left to right when you turn the volume up and

from right to left when you turn the volume down. The LEDs do not light if you try to increase the volume when it has

already been set to maximum or try to decrease the volume when it has already been set to minimum.

ONLYFOR

SERVICE

AUX IN

DC 14V 4A

USB

5V 500mA

ONLY FOR

SERVICE

AUX IN

DC 14V 4A

USB

5V 500mA

MUTE

VOL

BASS

FUNCTION

MUTE

VOL

BASS

FUNCTION

Touch the +/– button on the right side of the front panel.

or,

Press VOL +/– on the remote control.

▪The volume level increases or decreases when you press VOL +/–.

▪You can also use the volume controls of devices connected using the Galaxy Dock or Bluetooth to control

the volume. However, your ability to control the volume using the volume controls of devices connected

using Bluetooth may be limited.
