E-Manual

Activating 3D Mode

Choose a 3D mode according to the input signal. Available 3D modes may vary depending on the

input signal.

o _ Off: Deactivates 3D viewing.

o _ Normal: Converts normal images to 3D images. Some formats do not support this mode.

o _ L/R: Splits a single image into left and right overlapping images to create the 3D effect.

_ T/B: Splits a single image into top and bottom overlapping images to create the 3D effect.

o _ Horizontal Line: Switches between left and right images one horizontal line at a time. This

mode is not supported on the LED 9000 and UHD $9 series models.

o _ Vertical Line: Switches between left and right images one vertical line at a time. This mode is

not supported on the LED 9000 and UHD $9 series models.

o _ Pixel: Switches between left and right images one pixel at a time. This mode is not supported

on the LED 9000 and UHD $9 series models.

o D Frame: Switches between left and right images one frame at a time. This mode is not

supported on the LED 9000 and UHD $9 series models.

(Horizontal Line)__ (Vertica Line), and _ (Pixel) can only be seected when the computer's reso ution

is set to 1920x1080 or the computer is connected to the TV via an HDIVH-DVI cable_

(Frame) can only be seected when the computers resolution is set to 1920x1080 and the frequency to

60Hz_

Resolutions supported by the TV may vary, depending on the 3D mode. For details, see "Supported 3D

Resolutions".

Setting 3D Effects

There are several adjustments that can be made to make 3D content more enjoyable.

3D Perspective: Adjusts the 3D perspective.

Depth: Adjusts the 3D depth. This function is not available if 3D mode is set to _ (L/R) or

<T/B).

L/R Change: Swaps the left and right pictures.

3D _2D: Converts 3D images to normal images. This function is not available if 3D mode is set

to _ (Normal) or _ (Off).

3D Auto View: Setting 3D Auto View to On switches the TV to 3D automatically. Setting 3D Auto

View to Message Notice brings up a message screen when the TV receives a 3D signal. If some

applications are running, The TV can not switch 3D. In this case, close the application and then

watch the 3D. This function is available for LED 7400, 7500, 8000, 8200, 8500 series models only.

o 3D Light control: Adjust the brightness of 3D images. If the screen is too dark, select High. This

function is available for LED 7400, 7500, 8000, 8200, 8500 series models only.

3D Channel Viewing

2_2@£_] > Menu_ > Broadeastning > View 3D Channels {:_

Block or allow 3D channels. If 3D channels aren't shown, configure from Auto Program (Broadcasting

> Auto Program).

A message will appear on the screen if the program you are watching supports 3D. Follow the

onscreen instructions to view the program in 3D.

Selecting Off hides 3D channels from the channel lists and Guide.

ThedispIayedimagemaydifferdependingonthemodet,

Displayvideofroman externaldeviceon themainscreenandthe TVasa picture-in-picture.For

example,you candisplaya Blu-raymovieon themainscreenandsimultaneouslywatchTV asa

picture-in-picture.PIPis notavailablewhile theSmartHubor 3DTV isactive.Turningoff the TV while

PIPisactiveautomaticallydeactivatesPIP.

o PP: Activates/deactivatesPIP.

o Channel:SelectsthePIPsub-picturechannel.

o Size:Selectsthe PIPsub-picturesize.

o Position:Selectsthe PIPsub-pictureposition.

o SoundSelect:Selectstheaudiosource.

Playingagameorusingthekaraokefeatureonthemainscreencanresultina lowerPIPpicturequalit'¢_

ToenjoyPIP,themainscreen'ssourcemustbeComponentorHDMIandtheinputresoutionmustbeless

thanFHD,Thesubscreensupportsdigitalchannesonbz

Analog Screen Calibration

The dispIayed image may diffeF depending on the modet,

Analog pictures can become shaky and full of noise, If this happens, you can fine tune the signal

and/or reduce noise to clear up the picture,

Fine Tune

?_{_2_]] > Menu@ > Broadcasting > Channel Settings > Fine Tune

Clear up shaky pictures, Fine tune the pictures until they are clear and then select Save or Close,

Select Reset to reset the Fine Tune operation, This option is only available for analog broadcasts,

Broadcast Audio

3_2_:3 > Menu@ > Broadcasting ) Audio Options

The displayed image may differ depending on the model,

Configure the program's audio language. Using this option is different for analog and digital channels.

Digital Broadcast Audio Options

Preferred Language: Digital broadcasts are embedded with audio signals in multiple languages

which users can choose from. Users do not need to manually configure digital broadcasts that

support the designated language. If the designated language is not supported, the default audio

language chosen by the TV station will be heard.

, Visual _mpaired: Activate the audio guide for the visually impaired. This is only available with

broadcasts that provide this service.

Analog Broadcast Audio Options

Auto Stereo: Choose between stereo and mono. Auto lets the TV automatically choose the audio

mode for each channel and Manual sets audio for all channels to mono. Try Auto first and then

switch to Manual if the audio quality is unsatisfactory.

Multi-Track Sound: Configure the audio for the current broadcast. Multi-Track Sound can be set

to mono or stereo, depending on the broadcast signal or program. Although user set this option

to stereo, if the broadcast signal or program is not supported a stereo, this option will be set to

mono automatically.

Select the (:_._ £(A_ button on the virtual remote panel to view the current broadcast's audio signal

information_

Select the _lo_ button on the virtua remote pane[ whie watching TV to access and configure the Mu_ti_

Track Sound setting,

Subtitles

?[_2_:] ) Menu@ ) Broadcasting ) Caption

The displayed image may differ depending on the model,

View subtitles along with subtitle-enabled digital and analog broadcasts.

Show Subtitles

?_2_:] ) Menu@ ) Broadcasting ) Caption ) Caption

Show subtitles. Subtitles will be displayed when you choose a broadcast that supports subtitles.

DVD Subtitles are only available when connected to an external input connecto_:

Subtitle Options

?_2_:] ) Menu@ ) Broadcasting ) Caption ) Caption Mode

Select a subtitle mode. The list of modes may vary depending on the broadcast.

o Default /English /Korean: Select which analog broadcast subtitles to display. Watching a

broadcast with subtitles in English with this option set to Korean may result in corrupted

characters. In this case, change the option to English,

o Default /Service1 ~ Service6: Select which digital broadcast subtitles to display. Only Service1

is supported in South Korea. Please choose Default or Service1.

Default supports Korean subtitles.

Subtitle Display Options

Specify the foreground and background settings.

o Size: Choose the subtitle size from the list. This option is not available for analog channels.

Font Color: Choose a foreground color from the list.

Background Color: Choose a background color from the list.

Font Opacity: Choose a foreground opacity level from the list.

Background Opacity: Choose a background opacity level from the list.

Return to Default: Restores all subtitle display options to the DefauNt settings. Default applies

settings chosen by the TV station.

The foreground and background color and opac ty sett ngs cannot be the same_

Basic Picture Settings

2_2_:] ) Menu@ ) Picture

The dispIayed image may differ depending on the modet.

The basic image settings alter the look and feel of the image displayed on the TV screen.

Changing the Picture Mode

2_2_:] ) Menu@ ) Picture ) Picture Mode

Choose the optimal picture mode for your TV viewing conditions. When connected to a computer via

an HDMI-to-DVl cable, only the Standard and Entertain modes can be chosen.

, Dynamic: This increases the brightness of the screen. It is most suitable for bright environments.

, Standard: This is the default mode.

, Natural: This is useful for reducing eye strain.

o Movie: Darkens the screen and reduces glare. Appropriate for darkened rooms, for watching

movies, and when experiencing eye fatigue.

o Entertain: Sharpens images for a more dynamic viewing experience. This mode is only available

when connected to a computer via an HDMI-to-DVl cable.

Picture Quamity

2_:] > Menu_ > Picture

Choose a Picture Mode and then select the following options to display a slide bar that allows

the corresponding setting to be adjusted. Adjust the value by dragging left/right on the touch pad

and change the setting by dragging up/down on the touch pad. Adjusted values are applied to the

current source and will remain in effect the next time the source is selected. The CoNor and Tint (G/R)

adjustment options are not available when connected to a computer via an HDMI-to-DVl cable..

o BacMight: Adjusts the brightness of individual pixels. Decreasing the brightness reduces power

consumption.

Contrast: Adjusts the screen contrast.

Brightness: Adjusts the overall brightness.

Sharpness: Sharpens or dulls the edges of objects.

Color: Adjusts the overall color saturation.

Tint (G/R): Adjusts the ratio of green to red. Increase the green value to saturate the greens and

the red value to saturate the reds.

Applying the Current Picture Quality Setting to Another _nput

2_2_} > Menu_ > Picture > Apply Picture Mode

Users can apply the picture quality setting that you configured for the TV to all external devices

connected to the TV.

To apply the setting to all external devices connected to the TV, select ANI Sources. To only apply the

setting to the current input, select Current Source.
