Samsung RT23 Manuel utilisateur
REFRIGERATOR
OWNER’S INSTRUCTIONS
Before operating the unit, please read this manual thoroughly, and
retain for future refefence.
DA99-00555E REV (0.1)
Size 207/140 mm
RT23/26/31/34
MAIN FEATURES
Large Freezer Storage Area
- Stores large quantities of food in the freezer.
Jumbo Storage Guard
- Holds large bottles securely.
Adjustable Storage Guards
Position them for your convenience and according
to the height of your food containers.
-
Bio-Fresh Zone (Select model)
Keeps vegetables fresh for longer periods.
-
Sliding Drawer (Select model)
- Extra storage space for vegetables and fruits.
ICooling
- Advanced air circulation for faster surround cooling.
Super Freeze Zone (Select model)
Freezes stored items quickly.
-
Twist Ice-Tray (Select model)
Spring mechanism for automatic release of ice cubes.
-
BASIC PREPARATION
Read Instructions.
Please read all safety and operating instructions before
operating this appliance.
Retain Instructions.
Please keep this Owner's Manual for future reference.
Heed Warnings.
All warnigns, Cautions and Notes on this refrigerator are
important; please pay attention to them.
Follow Instructions.
For best results, follow all instructions given in this manual.
Model and Serial Numbers.
Include both the model number and the serial number when
corresponding with your Dealer concerning this product.
Contents
MAIN FEATURES ................................
CONTENTS .........................................
BASIC PREPARATION ........................
- Getting Started ...................................
INSTALLATION ....................................
CAUTIONS WHILE USING .................
PARTS ..................................................
REPLACING THE LAMP ......................
STORING FOOD .................................
HOW TO USE ......................................
- Temperature control ...........................
- Ice cube maker ..................................
- Chiller Compartment .........................
- Vegetable bin .....................................
LEVELING THE APPLIANCE ..............
REMOVING ACCESSORIES ...............
BEFORE CALLING SERVICE ..............
1
1
1
2
2
3,4
5,6
7
8
9
9
10
11
11
12
13,14
15,16
Date of Purchase :
Model No. :
Serial No. :
11
Before plugging in for the first time, allow the
refrigerator to stabilize for at least one hour.
Allow the freezer compartment to cool for 2 to 3
hours before storing food.
22
22
11
11
Avoid locations affected by draughts
or dampness.
For optimum operation, normal room
temperature is recommended. Avoid
locations in direct sunlight, near heaters,
radiators, stoves or ovens.
33
33
Allow a 100mm space between the refrigeratgor and the wall.
If your refrigerator is going into a receased area, allow at
least 300mm clearance above the refrigerator.
44
44
For personal safety, properly ground this appliance.
Do not ground this refrigerator with a telephone line,
gas pipe, etc.
22
Getting Started
INSTALLATION
above 300mm
above 100mm above 100mm
11
11
Do not allow water to splash onto
the refrigerator.
Water impairs the insulation of
electric parts and may cause an
electrical shock or a fire hazard.
-
-
Do not use flammable sprays such
as lacquer and paint near the
refrigerator.
Heat from the refrigeration unit may
ignite flammable aerosols.
22
22
-
-
Do not allow unattended children to play in
or around refrigerators and other large
appliances. The child may get hurt or they
could damage the appliance.
Do not allow children to hand on to the
refrigerator door.
33
33
-
-
3
CAUTIONS WHILE USING
For optimum operation, do not leave the door open
for any longer than necessary.
Leaving the door open allows warmer air to enter
the refrigerator and causes the refrigeration unit to
use more energy to maintain the temperature.
-
-
Do not store volatile chemicals such as
ether and benzene in the refrigerator.
The fumes, besides damaging food, can
build up and cause an explosion.
-
-
Do not use the refrigerator if it is not operating
correctly or has been damaged. Disconnect it from
the power supply and call your local service center.
If the power cord is damaged, avoid a hazard by
replacing it through the manufacturer or its service
agent or a similarly qualified person
-
-
Always be careful of not banging your head on the
bracket lock while storing or taking out food.
-
Frequent opening of door can cause excessive
frost in the unit that will reduce the cooling
momentarily, this is a general phenomenon
especially in coastal or high humidity area. It is
not a malfunction. Opening of door should be avoided
while defrosting.
Avoid keeping freezer door open for long time to prevent
frost accumulation.
-
44
44
55
55
66
66
77
77
88
88
4
-
Twist Ice Cube Tray (Select model)
Ice Storage Bin (Select model)
Freezer Compartment Temperature
Control
Guard FRE upp (Select model)
Super-Freeze Zone
(Select model)
Wire Shelf (Economy only)
Chiller Compartment (Select model)
Refrigerator Compartment Temperature
Control
i-Cooling
Refrigerator Shelf (Plastic or Steel)
Lamp
Adjustable Storage Guard
Dairy Guard (Select model)
Jumbo Guard
Bottle Storage Guard
Bio-Fresh Zone (Select model)
Sliding Drawer (Select model)
55
PARTS (TYPE - I)
It is recommended to store fruits & vegetables in Bio-fresh Zone/Case vegetable.
66
Twist Ice Cube Tray (Select model)
Ice Storage Bin (Select model)
Freezer Compartment Temperature
Control
Super-Freeze Zone (Select model)
Freezer shelf
Chiller Compartment (Select model)
Refrigerator Compartment
Temperature Control
i-Cooling
Refrigerator Shelf (Plastic or Steel)
Lamp
Adjustable Storage Guard
Dairy Guard (Select model)
Jumbo Guard
Bottle Storage Guard
Bio-Fresh Zone (Select model)
Sliding Drawer (Select model)
Bottle Guide (Select model)
PARTS (TYPE - II)
It is recommended to store fruits & vegetables in Bio-fresh Zone/Case vegetable.
-
-
11
11
22
22
77
Press upper tab of the lamp cover
with some tool such as driver and
pull it out.
Turn the existing lamp bulb and replace it with a new one.
Replace the lamp cover by aligning the cover at the top ( ) and carefully pressing
it into place ( )
1
2
REPLACING THE LAMP
Store food in small portions (Optional)
Seal food in containers with lids, in plastic wrap or
in plastic bags to prevent drying and the mingling
of odors.
Allow hot food and drinks to cool to
room temperature before placing them in
the refrigerator or freezer.
Allow sufficient space between stuff
to help the circulation of cool air.
Place liquid at the front of the refrigerator
to avoid freezing.
Wash dry fruits and vegetables
before placing them in the
refrigerator.
88
STORING FOOD
Temperature control
COLDEST
Freezer Temperature control
Turn the Temperature Control to "COLDEST" if you;
have a lot of food to store (refrigerator or freezer)
want to make ice (freezer)
require fast freezing (freezer)
-
-
-
Refrigerator Temperature control
Turn the Temperature Control to the midway point
between "COLDEST" and "COLD" for normal
refrigerating or freezing mode.
Turn the Temperature Control to "COLD" if you
want to store only a small amount of food in the
refrigerator or freezer.
When the air surrounding the refrigerator is below 5°C, turn the
Temperature Control to "COLD" to avoid freezing.
Apart from above mentioned Knob setting settings if you desire to
increase or reduce the cooling, turn the Knob clockwise or
anticlockwise beyond the marked positions respectively.
NOTE
-
-
99
HOW TO USE
NORMAL
COLD
Refrigerator
Freezer
Freezer Refrigerator
Freezer Refrigerator
