Samsung RS68C Series Manuel utilisateur

Refrigerator

User manual

RS68A**/RS68C*/RS6GC*/RS6EC*

SEUK Free Standing Appliance

Untitled-2 1 2023-03-23  2:07:07

English2

Contents

Safety information 4

What you need to know about the safety instructions 4

Important safety symbols and precautions: 6

Important safety precautions 7

Severe warning signs for transportation and site 10

Critical installation warnings 11

Installation cautions 14

Critical usage warnings 14

Usage cautions 19

Cleaning cautions 21

Critical disposal warnings 23

Additional tips for proper usage 23

Instructions about the WEEE 25

Installation 26

Refrigerator at a glance 26

Step-by-step installation 28

Door removal for entrance 40

Operations 45

Feature panel 45

Turning on or off the ice maker 48

Resetting or dismissing the water lter replacement alarm (applicable models only) 48

Turning on or off the Wi-Fi 49

SmartThings 50

Dispenser panel (applicable models only) 53

Special features 54

Maintenance 62

Handle and care 62

Cleaning 64

Replacement 65

Untitled-2 2 2023-03-23  2:07:07

English 3

Contents

Troubleshooting 66

General 66

Do you hear abnormal sounds from the refrigerator? 70

SmartThings 72

Open Source Announcement 73

Appendix 74

Safety Instruction 74

Install Instruction 74

Temperature Instruction 75

Information for model and ordering spare parts 79

Untitled-2 3 2023-03-23  2:07:07

English4

Safety information

Before using your new Samsung Refrigerator, please read this manual thoroughly to

ensure that you know how to operate the features and functions that your new appliance

offers safely and efciently.

What you need to know about the safety instructions

• Warnings and Important Safety Instructions in this manual do not

cover all possible conditions and situations that may occur.

It is your responsibility to use common sense, caution, and care

when installing, maintaining, and operating your appliance.

• Because these following operating instructions cover various

models, the characteristics of your refrigerator may differ slightly

from those described in this manual and not all warning signs may

be applicable. If you have any questions or concerns, contact your

nearest service center or nd help and information online at www.

samsung.com.

• R-600a or R-134a is used as a refrigerant. Check the compressor

label on the rear of the appliance or the rating label inside the

fridge to see which refrigerant is used for your appliance. When

this product contains ammable gas (Refrigerant R-600a), contact

your local authority in regard to safe disposal of this product.

• In order to avoid the creation of a ammable gas-air mixture

if a leak in the refrigerating circuit occurs, the size of the room

in which the appliance may be sited depends on the amount of

refrigerant used.

• Never start up an appliance showing any signs of damage. If in

doubt, consult your dealer. The room must be 1 m3in size for

every 8 g of R-600a refrigerant inside the appliance.

The amount of refrigerant in your particular appliance is shown on

the identication plate inside the appliance.

Safety information

Untitled-2 4 2023-03-23  2:07:08

English 5

Safety information

• Refrigerant squirting out of the pipes could ignite or cause an eye

injury. When refrigerant leaks from the pipe, avoid any naked

ames and move anything ammable away from the product and

ventilate the room immediately.

- Failing to do so may result in re or explosion.

• To avoid contamination of food, please respect the following

instructions:

- Opening the door for long periods can cause a signicant

increase of the temperature in the compartments of the

appliance.

- Clean regularly surfaces that can come in contact with food and

accessible drainage systems.

- Clean water tanks if they have not been used for 48 h; ush

the water system connected to a water supply if water has not

been drawn for 5 days.

- Store raw meat and sh in suitable containers in the

refrigerator, so that it is not in contact with or drip onto other

food.

- Two-star frozen-food compartments are suitable for storing

pre-frozen food, storing or making icecream and making ice

cubes.

- One-, two- and three-star compartments are not suitable for the

freezing of fresh food.

- If the refrigerating appliance is left empty for long periods,

switch off, defrost, clean, dry, and leave the door open to

prevent mould developing within the appliance.

Untitled-2 5 2023-03-23  2:07:08

Safety information

English6

Safety information

Important safety symbols and precautions:

Please follow all safety instructions in this manual. This manual uses

the following safety symbols.

WARNING

Hazards or unsafe practices that may result in severe personal injury,

property damage, and/or death.

CAUTION

Hazards or unsafe practices that may result in severe personal injury

and/or property damage.

NOTE

Useful information that helps users understand or benet from the

refrigerator.

These warning signs are here to prevent injury to you and others.

Please follow them carefully.

After reading this section, keep it in a safe place for future reference.

Untitled-2 6 2023-03-23  2:07:08

English 7

Safety information

Important safety precautions

WARNING; Risk of re / ammable materials

WARNING

• When positioning the appliance, ensure the supply cord is not

trapped or damaged.

• Do not locate multiple portable socket-outlets or portable power

supplies at the rear of the appliance.

• Fill with potable water only.

• Connect to potable water supply only.

• Keep ventilation openings, in the appliance enclosure or in the

built-in structure, clear of obstruction.

• Do not use mechanical devices or any other means to accelerate

the defrosting process, other than those recommended by the

manufacturer.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the type

recommended by the manufacturer.

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory, or mental capabilities,

or those who lack experience and knowledge, unless they have

been given supervision or instruction concerning the use of the

appliance by a person responsible for their safety.

Untitled-2 7 2023-03-23  2:07:08

Safety information

English8

Safety information

• This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance

in a safe way and understand the hazards involved. Children

shall not play with the appliance. Cleaning and user maintenance

shall not be made by children without supervision. Children aged

from 3 to 8 years are allowed to load and unload refrigerating

appliances.

• If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualied persons in

order to avoid a hazard.

• The socket must be easily accessible so that the appliance can be

quickly disconnected from the supply in an emergency.

- It must be outside the area of the rear of the appliance.

• Do not store explosive substances such as aerosol cans with a

ammable propellant in this appliance.

• If the product is equipped with LED lamps, do not disassemble the

Lamp Covers and LED lamps yourself.

- Contact a Samsung service center.

- Use only the LED Lamps provided by the manufacturer or its

service agents.

• New hose-sets supplied with the appliance are to be used and old

hose-sets should not be reused.

• Have the refrigerator’s water supply connected only to a potable

water supply. To operate the ice maker properly, water pressure

of 206-861 kPa (30-125 psi) is required.

• For the most efcient use of energy, please keep the all inner

ttings such as baskets, drawers, shelves on the position supplied

by manufacturer.

Untitled-2 8 2023-03-23  2:07:08

English 9

Safety information

• To get the best energy efciency of this product, please leave all

shelves, drawers and baskets on their original position.

How to minimize the energy consumption

• Install the appliance in a cool, dry room with adequate ventilation.

• Ensure that it is not exposed to direct sunlight and never put it

near a direct source of heat (radiator, for example).

- Not to block any vents or grilles is recommended for energy

efciency.

- Allow warm food to cool down before placing it in the

appliance.

- Put frozen food in the refrigerator to thaw. You can then use

the low temperatures of the frozen products to cool food in the

refrigerator.

- Do not keep the door of the appliance open for too long when

putting food in or taking food out.

- The shorter time for which the door is open, the less ice will

form in the freezer.

- Clean the rear of the refrigerator regularly. Dust increases

energy consumption.

- Do not set temperature colder than necessary.

- Ensure sufcient air exhaust at the refrigerator base and at the

back wall of the refrigerator. Do not cover air vent openings.

- Allow clearance to the right, left, back and top when installing.

This will help reduce power consumption and keep your energy

bills lower.

Untitled-2 9 2023-03-23  2:07:08

Safety information

English10

Safety information

This appliance is intended to be used in household and similar

applications such as

- staff kitchen areas in shops, ofces and other working

environments;

- farm houses and by clients in hotels, motels and other

residential type environments;

- bed and breakfast type environments;

- catering and similar non-retail applications.

Severe warning signs for transportation and site

WARNING

• When transporting and installing the appliance, care should be

taken to ensure that no parts of the refrigerating circuit are

damaged.

- Refrigerant leaking from the pipe work could ignite or cause

an eye injury. If a leak is detected, avoid any naked ames

or potential sources of ignition and air the room in which the

appliance is standing for several minutes.

- This appliance contains a small amount of isobutane refrigerant

(R-600a), a natural gas with high environmental compatibility

that is, however, also combustible. When transporting and

installing the appliance, care should be taken to ensure that no

parts of the refrigerating circuit are damaged.

• When transporting and installing the refrigerator, do not touch the

water hose on the back side of the refrigerator.

- This may damage the refrigerator and as a result the water

dispenser can not be used.

Untitled-2 10 2023-03-23  2:07:08

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung Réfrigérateur

Samsung

Samsung RS627LHQESR Manuel utilisateur

Samsung

Samsung RS25H5111SR Manuel utilisateur

Samsung

Samsung RF265B Series Manuel utilisateur

Samsung

Samsung Refrigerator Manuel utilisateur

Samsung

Samsung RL40L series Manuel utilisateur

Samsung

Samsung RS23 SERIES Manuel utilisateur

Samsung

Samsung RF4289HARS Manuel utilisateur

Samsung

Samsung SR-606EVSS Manuel utilisateur

Samsung

Samsung RS257BABB Manuel utilisateur

Samsung

Samsung RL26DCAS Manuel utilisateur

Samsung

Samsung RF22K938 Manuel utilisateur

Samsung

Samsung RH25H5611S Manuel utilisateur

Samsung

Samsung RT29xx Manuel utilisateur

Samsung

Samsung RR39M7 Series Manuel utilisateur

Samsung

Samsung RF26DEUS Manuel utilisateur

Samsung

Samsung RF267ABRS - 26 cu. ft. Refrigerator Mode d’emploi

Samsung

Samsung RS68A8840WW/EF Manuel utilisateur

Samsung

Samsung RL29THCSW Manuel utilisateur

Samsung

Samsung BRB26 0 Series Manuel utilisateur

Samsung

Samsung RF220NCTASG/AA Manuel utilisateur

Samsung

Samsung RSG257AA Series Manuel utilisateur

Samsung

Samsung RS25H50 SERIES Manuel utilisateur

Samsung

Samsung Model RS27KLMR Guide de sécurité

Samsung

Samsung RF265ABPN Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur

Teledyne

Teledyne 6712FR and Mode d'emploi
