Samsung RS22 55 Series Manuel utilisateur

Refrigerator

User manual

RS22*55*/RS27*55*

Free Standing Appliance

Untitled-4 1 2021-10-07  6:49:18

English2

Contents

Safety information 3

What you need to know about the safety instructions 3

Important safety symbols and precautions: 5

Important safety precautions 6

Severe warning signs for transportation and site 10

Critical installation warnings 11

Installation cautions 14

Critical usage warnings 15

Usage cautions 20

Cleaning cautions 23

Critical disposal warnings 25

Additional tips for proper usage 26

Instructions about the WEEE 27

Installation 28

Refrigerator at a glance 28

Step-by-step installation 29

Operations 42

User interface 42

SmartThings 46

Recommendations for voice recognition 49

Samsung Family Hub 49

Dispenser panel (applicable models only) 51

Special features 52

Maintenance 55

Handle and care 55

Cleaning 58

Replacement 60

Troubleshooting 62

General 62

Do you hear abnormal sounds from the refrigerator? 66

SmartThings 68

Samsung Family Hub 69

LCD 69

Open Source Announcement 70

Untitled-4 2 2021-10-07  6:49:18

English 3

Safety information

Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure

that you know how to operate the features and functions that your new appliance offers

safely and efciently.

What you need to know about the safety

instructions

• Warnings and Important Safety Instructions in this manual

do not cover all possible conditions and situations that

may occur.

It is your responsibility to use common sense, caution,

and care when installing, maintaining, and operating your

appliance.

• Because these following operating instructions cover

various models, the characteristics of your refrigerator

may differ slightly from those described in this manual and

not all warning signs may be applicable. If you have any

questions or concerns, contact your nearest service center

or nd help and information online at www.samsung.com.

• R-600a or R-134a is used as a refrigerant. Check the

compressor label on the rear of the appliance or the rating

label inside the fridge to see which refrigerant is used for

your appliance. When this product contains ammable gas

(Refrigerant R-600a), contact your local authority in regard

to safe disposal of this product.

• In order to avoid the creation of a ammable gas-air

mixture if a leak in the refrigerating circuit occurs, the size

of the room in which the appliance may be sited depends

on the amount of refrigerant used.

Safety information

Untitled-4 3 2021-10-07  6:49:18

Safety information

English4

Safety information

• Never start up an appliance showing any signs of damage.

If in doubt, consult your dealer. The room must be 1 m3

in size for every 8 g of R-600a refrigerant inside the

appliance.

The amount of refrigerant in your particular appliance is

shown on the identication plate inside the appliance.

• Refrigerant squirting out of the pipes could ignite or cause

an eye injury. When refrigerant leaks from the pipe, avoid

any naked ames and move anything ammable away

from the product and ventilate the room immediately.

- Failing to do so may result in re or explosion.

Untitled-4 4 2021-10-07  6:49:18

English 5

Safety information

Important safety symbols and precautions:

Please follow all safety instructions in this manual. This

manual uses the following safety symbols.

WARNING

Hazards or unsafe practices that may result in severe personal

injury, property damage, and/or death.

CAUTION

Hazards or unsafe practices that may result in severe personal

injury and/or property damage.

NOTE

Useful information that helps users understand or benet

from the refrigerator.

These warning signs are here to prevent injury to you and

others.

Please follow them carefully.

After reading this section, keep it in a safe place for future

reference.

Untitled-4 5 2021-10-07  6:49:18

Safety information

English6

Safety information

Important safety precautions

Warning; Risk of re / ammable materials

WARNING

• When positioning the appliance, ensure the supply cord is

not trapped or damaged.

• Do not locate multiple portable socket-outlets or portable

power supplies at the rear of the appliance.

• Fill with potable water only.

• Connect to potable water supply only.

• Keep ventilation openings, in the appliance enclosure or in

the built-in structure, clear of obstruction.

• Do not use mechanical devices or any other means

to accelerate the defrosting process, other than those

recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the type

recommended by the manufacturer.

• This appliance is not intended for use by persons

(including children) with reduced physical, sensory, or

mental capabilities, or those who lack experience and

knowledge, unless they have been given supervision or

instruction concerning the use of the appliance by a person

responsible for their safety.

Untitled-4 6 2021-10-07  6:49:18

English 7

Safety information

• This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge

if they have been given supervision or instruction

concerning use of the appliance in a safe way and

understand the hazards involved.

Children shall not play with the appliance. Cleaning and

user maintenance shall not be made by children without

supervision.

• If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly qualied

persons in order to avoid a hazard.

• The socket must be easily accessible so that the appliance

can be quickly disconnected from the supply in an

emergency.

- It must be outside the area of the rear of the appliance.

• Do not store explosive substances such as aerosol cans

with a ammable propellant in this appliance.

• If the product is equipped with LED lamps, do not

disassemble the Lamp Covers and LED lamps yourself.

- Contact a Samsung service center.

- Use only the LED Lamps provided by the manufacturer

or its service agents.

• New hose-sets supplied with the appliance are to be used

and old hose-sets should not be reused.

• Have the refrigerator’s water supply connected only to a

potable water supply. To operate the ice maker properly,

water pressure of 20 psi and 125 psi (138 and 862 kPa) is

required.

Untitled-4 7 2021-10-07  6:49:18

Safety information

English8

Safety information

• For the most efcient use of energy, please keep the all

inner ttings such as baskets, drawers, shelves on the

position supplied by manufacturer.

• To get the best energy efciency of this product, please

leave all shelves, drawers and baskets on their original

position.

How to minimize the energy consumption

• Install the appliance in a cool, dry room with adequate

ventilation.

• Ensure that it is not exposed to direct sunlight and never

put it near a direct source of heat (radiator, for example).

- Not to block any vents or grilles is recommended for

energy efciency.

- Allow warm food to cool down before placing it in the

appliance.

- Put frozen food in the refrigerator to thaw. You can

then use the low temperatures of the frozen products to

cool food in the refrigerator.

- Do not keep the door of the appliance open for too long

when putting food in or taking food out.

- The shorter time for which the door is open, the less ice

will form in the freezer.

- Clean the rear of the refrigerator regularly. Dust

increases energy consumption.

- Do not set temperature colder than necessary.

- Ensure sufcient air exhaust at the refrigerator base

and at the back wall of the refrigerator. Do not cover air

vent openings.

Untitled-4 8 2021-10-07  6:49:18

English 9

Safety information

- Allow clearance to the right, left, back and top when

installing. This will help reduce power consumption and

keep your energy bills lower.

• We recommend the value of clearance to be :

- Right, left, and back side: more than 50 mm

- Top side: more than 100 mm

This appliance is intended to be used in household and similar

applications such as

- staff kitchen areas in shops, ofces and other working

environments;

- farm houses and by clients in hotels, motels and other

residential type environments;

- bed and breakfast type environments;

- catering and similar non-retail applications.

Untitled-4 9 2021-10-07  6:49:18

Safety information

English10

Safety information

Severe warning signs for transportation and site

WARNING

• When transporting and installing the appliance, care should

be taken to ensure that no parts of the refrigerating circuit

are damaged.

- Refrigerant leaking from the pipe work could ignite

or cause an eye injury. If a leak is detected, avoid any

naked ames or potential sources of ignition and air

the room in which the appliance is standing for several

minutes.

- This appliance contains a small amount of isobutane

refrigerant (R-600a), a natural gas with high

environmental compatibility that is, however, also

combustible. When transporting and installing the

appliance, care should be taken to ensure that no parts

of the refrigerating circuit are damaged.

• When transporting and installing the refrigerator, do not

touch the water hose on the back side of the refrigerator.

- This may damage the refrigerator and as a result the

water dispenser can not be used.

Untitled-4 10 2021-10-07  6:49:18
