Safety Precautions
◆Use only the adapter of this own product.
◆Do not touch the plug with wet hands or lips.
It may cause an electric shock.
◆Do not disassemble, repair or reconstruct this
product for yourself. You can get electric shock or
you may be in danger of fire. If you want to make a
service request, contact with your agent centre.
◆Keep this product away from children. If this product
falls, children may be hurt.
WARNING
CAUTION ◆
Do not clean this product with water, benzene or
thinner. It may cause an electric shock.
◆
Do not make the adapter covered with a blanket or
carpet.
◆
Do not install on the high place or around
heat-emission equipments. Cooling capacity may
decrease and power consumption may increase.
◆
Avoid installing on the humid place. It may occur
troubles and cause a short circuit.
◆
Use this product for only cosmetics.
◆
Pull the power plug before cleaning this product.
Read All Instructions Before Using Cosmetic Cool-kits.
Contents
◆◆
S
AFETY
P
RECAUTIONS
◆◆
F
EATURES
◆◆
V
IEW OF
P
RODUCT
◆◆
H
OW TO
I
NSTALL
◆◆
H
OW TO
U
SE
◆◆
S
ETTING THE BACKLIGHT OF
LCD
◆◆
H
OW TO
D
ISSASSEMBLE
◆◆
H
OW TO
C
LEAN
◆◆
T
ROUBLESHOOTING
◆◆
S
PECIFICATIONS
2
4
6
8
9
10
11
12
13
14
E-3E-2
FEATURES Before using Cometic Cool-Kits, keep informations about your own skin
type. And then choose Skin Selection button for your own skin.
Specific Character
Skin Selection
Choice
◆Cosmetic Cool-Kits has a new cooling device(Refrigeration thermoelectric
semiconductor), which stops a noise from condenser and pollution by freon gas.
No noise and No pollution
◆Cosmetic Cool-Kits controls the temperature for your own skin types and season
selection. This product, therefore, makes perfect make-up possible.
Adjustable temperature control
◆Cosmetic Cool-Kits preserves the original condition of cosmetics permanently
because it controls the temperature and humidity.
Safe preservation
◆Air shower system prevents an inflow of air.
The indirect refrigerating system doesn't make dew
inside Cool-Kits. These two functions enhance
a cool breeze.
Excellent refrigerating system
◆It supplies two compartments, Main chilled room and Versatile bin. You can store
lipsticks or pencils on Versatile bin.
Separate compartments
◆You can place Cosmetic Cool-Kits wherever you want. It is lightweight and easy
to move. Refined design will have your room more beautiful.
Lightweight, Refined design
Your skin is likely to have pimples or breakouts,
especially around T-line(the forehead and nose).
And much rosacea and a lack of moisture.
Choose Combination
Choose Dry
Choose Sensitive
Choose Oily
Choose Normal & Dry
Skin strains after washing face. The layer of skin
is thin and sensitive. When tired, make-up is not
applied well.
Skin strains after washing face. T-line is also dry.
Your skin has psoriasis and wrinkles. The layer of
dead skin cells is thick.
When making up, you feel itchy and swollen.
Face is easy to get rough when it blows.
The layer of dead skin cells and pores are easily
built up. Much rosacea and pimples. Make-up is
removed easily.
E-5E-4
View of Product
LCD
Season Selection button
Skin Selection button
Handle
Front
Refrigerating system
Adapter port
Rear
Air outlet
Fan cover
Versatile tray
Temperature sensor
Versatile door shelve
Air outlet
Versatile bin
Non-slip base
Lipstic case
◆
You can arrange lipsticks, mascaras and pencils which are
not easy to be rotted even on the warm temperature.
Inside
D.C Adapter
(DC 12V/4.5A) Power Plug Owner’s
Instruction
Accessories
E-7E-6
How to Install How to Use
Decide the area where you want to place this product.
◆Avoid installing this product on the humid area or
upon the area shone directly.
1
First, confirm if LCD lights on.
◆It is normal that LCD lights on as soon as you turn on
Cool-Kits.
1
You can choose a season by pressing Season Selection
button .
◆Each time you press Season Selection button ,
season is adjusted repeatedly as followings:
2
You can choose your own Skin Selection by pressing
Skin Selection button .
◆Each time you press Skin Selection button ,
each type is adjusted repeatedly as followings :
LCD indicates Summer and Dry.
3
Keep a distance from the wall or other equipments.
◆
The rear of Cosmetic Cool-Kits must remain more than
5cm away from the wall or other devices.
2
Connect the jack of adapter to the adapter port.
Insert the power plug to the adapter.
◆
You must use the adapter of this own product.
3
Insert the power plug to the adapter.
And then insert the power plug into a wall power outlet.
4Put cosmetics into Cool-Kits.
4
◆15 minutes after the door is opened,
warning bell beeps every two minutes.
◆You should choose the right season
selection to store cosmetics freshly.
C
Ca
au
ut
ti
io
on
n
To use Cosmetic Cool-kits rightly, you must install this product on the right place with
the right way. You can choose Season Selection button and Skin Selection button for your own situation.
E-9E-8
Setting the backlight of LCD How to Disassemble
LCD lights on for
20 seconds.
When you don't change
the normal display after
Cool-Kits operates ➺➺
➺➺
➺➺
➺➺
LCD lights on.When the door of
Cool-Kits is opened
LCD lights on for 10 seconds
after the door is closed.
When the door of
Cool-Kits is closed
LCD lights on for
10 seconds.
When you press the
button
A few cases that the backlight of LCD turns on the normal play.
If you want to turn the backlight of LCD on all the time,
Push Season Selection ( ) and Skin Selection ( ) button for
one or two seconds at the same time. Then, the backlight of LCD
turns on with the bell sound.
Inserting Versatile door shelve
Hold both ends and push them slightly.
And then insert it to the groove.
Inserting Versatile tray
Put tray slantly and fix it into the groove.
And then put it down slowly.
Assembly
When Cosmetic Cool-Kits operates, the backlight of LCD is already set as the normal
display. You can change the backlight of LCD from the normal display to other displays
according to cases.
If you want to cancel setting the backlight of LCD on,
Push Season Selection ( ) and Skin Selection ( ) button
for one or two seconds at the same time again. Then the backlight
of LCD returns to the normal display with the bell sound.
Disassembly
Versatile tray
Lift tray up slightly and pull it out.
Versatile door shelve
Hold both ends and push them
slightly. And draw the shelve out.
E-11E-10
Clean Cool-Kit’s surface with a smooth cloth or wet cloth,
only after squeeze the wet cloth properly.
Surface
Clean the inside and outside with dry cloth after
disassembling it.
Clean Versatile door shelve, Versatile tray and Versatile bin
with water.
Inside
Solution
◆
Check the power plug and adapter is connected well.
◆Check Cool-Kits is situated under the area shone directly.
If it is situated under direct sunlight, you must cut sunlight with
the curtain or something.
◆
Check there are heat-emission equipments around Cool-Kits.
Avoid installing Cool-Kits near heat-emission equipments.
◆
Check the main chilled room has too many cosmetics.
Cosmetics Cool-Kits must not be packed.
◆
If you turn on Cool-Kits, it may not cool for 20 minutes after
turned on.
Cosmetic Cool-Kits
doesn't cool at all.
◆
Check it is not installed upon the slanted or uneven place.
You must install it upon the even place.
◆
Check the wall or other objects stop the rear of Cool-Kits.
You must keep the rear of this product 5cm away from the wall
or other objects.
Cool-Kits sounds
strange.
◆
If the adapter is covered with a blanket or carpet, take it away
from Cool-Kits.
◆
It is normal that the adapter gets hot when operating. If,
however, the adapter becomes too hot, it may have a trouble.
You must contact with your agent centre.
The adapter gets hot.
◆
If E1, E2, E3 shows on LCD, it operates but has something
troubles. You must contact with your agent centre.
LCD indicates error.
Problem
How to Clean Troubleshooting
Before cleaning this product, please pull the power plug. Before contacting with your agent centre, check the followings.
They may save you time and expense of an unnecessary call.
◆You must not clean Cool-Kits with alcohol,
benzene or acetone.
◆Do not stick something to it. Cool-Kits may
be damaged.
C
Ca
au
ut
ti
io
on
n
◆You are advised to learn how to disassemble
and reassemble before cleaning Cool-Kits.
Refer to page 11.
N
No
ot
te
e
E-13E-12
Troubleshooting (cont.) Specifications
RC09EASI/RC09EAGO/RC09EARE
AC 100~240V 50/60Hz
0.4A
40W
4.5kg
Main chilled room : 7.9l
Versatile bin : 1.3l
305 x 382 x 283(mm)
PSCV540103A / DC12V / 4.5A
Power supply
Operating current
Power consumption
Weight
Capacity
Dimensions(W x H x D)
Adapter
MODEL
The reason of error
Problem on the temperature sensor of the inside
Problem on the sensor of the radiant heat part
Overheat of the radiant heat part
Problem on the radiant heat fan
Problem on the refrigeration fan
and ( or )
and ( or )
and
and and ( or )
and ( or )
On LCD
When errors as follows indicates on LCD, please contact with the agent centre
or your purchase site.
E-15E-14
ELECTRONICS
THIS COSMETIC COOL-KITS IS MANUFACTURED BY:
ESTA REFRIGERADORA PARA COSMÉTICOS HA SIDO FABRICADA POR:
CETTE ARMOIRE À PRODUITS DE BEAUTÉ EST FABRIQUÉE PAR :
Printed in Korea
RC09EASI
RC09EAGO
RC09EARE
OWNER’S INSTRUCTIONS
INSTRUCCIONES DEL USUARIO
MODE D’EMPLOI
Cosmetic Cool-Kits
Refrigeradora para cosméticos
Armoire àproduits de beauté
E S F A DB98-07237A(1)
