VIDEOWALL DISPLAY SOLUTIONS

Samsung Commercial Displays

Videowalls are a powerful new way to break through the clutter and

engage with your intended audience. Samsung pioneered LCD-based

videowalls and is now the market leader in ultra-thin, eco-friendly,

LED-based videowalls. Our complete solution includes a wide range

of advanced LED display panels, robust management software, and

media players to suit almost any need and budget. Samsung videowalls

are used by leading retailers, airports, businesses, public venues and

educational facilities around the world.

ENJOY COMPLETE DESIGN FREEDOM

WITH THE WIDEST RANGE OF PANELS

The six models enable a wide range of creative configuration options. Create a single landscape display for a shop window. Or a multi-panel portrait wall in

a meeting room. Or a massive 10x10 videowall in a public space. Samsung MagicInfo VideoWall software gives even greater design freedom by enabling

asymmetric videowalls that are unique and artistic.

UDC UDC-B UEC UD22B

Virtually seamless bezels with

advanced color management

Virtually seamless displays that

won’t break your budget

Affordable displays with advanced

color management

Unique 1:1 aspect ratio displays for

unique and artistic designs

46" and 55" 46" 46" and 55" 21.6"

16:9 aspect ratio 16:9 aspect ratio 16:9 aspect ratio 1:1 aspect ratio

700 nit brightness 450 nit brightness 500 nit brightness 450 nit brightness

24/7 operation 24/7 operation 24/7 operation

Samsung’s wide range of videowall display sizes and shapes enables you to create stunning videowalls in almost any location and with almost any

configuration. The UDC, UDC-B and UEC Series panels have a traditional 16:9 aspect ratio and are available in 46" and 55" sizes. The UD22B display has a

unique square shape (1:1 aspect ratio) for even more design options.

GRAB VIEWER ATTENTION WITH ADVANCED DISPLAYS

AND DYNAMIC CONTENT

Ultra-Narrow Bezels Maximize Visuals

Don’t let beautiful visuals get chopped up with gridlines from thick

bezels. Samsung videowall displays have ultra-narrow bezels for a

nearly seamless visual experience. The UDC and UDC-B models

have a bezel-to-bezel width of just 0.22 inches (5.5 mm), while the

UEC models have a narrow bezel width of 0.43 inches (11 mm).

Advanced Color Management Ensures Color Uniformity

Select Samsung videowall displays have Advanced Color Management

(ACM) features to adjust color levels across the videowall. In addition,

all Samsung displays are color calibrated at the factory to save the time

and effort of managing color uniformity and white balance

during installation.

MagicInfo VideoWall Software for Dynamic Content

The optional MagicInfo VideoWall software enables many creative

ways to display content. Schedule content based on time of day. Show

live camera or PC feeds on one or many displays. Create distinctive art

walls with unique shapes. The possibilities are endless.

Bright, Full-HD Panels That Get Noticed

Samsung LED displays produce brilliant, vivid images that grab the

viewer’s attention. The displays have full HD resolution and up to

700 nits brightness for crystal-clear, sharp images.

.22"

LOWER UPFRONT

OPERATING COSTS

Conventional DisplaySamsung Display

Lower Upfront Costs

Think videowalls are too expensive to purchase and operate? Not

with Samsung. Since we design and build our displays in-house, we

can offer cost-effective videowall solutions to fit almost any budget.

For basic functionality, the UDC-B displays enable virtually seamless

videowalls at an affordable price. The UDC and UEC Series have on-

board processors and storage for basic playback without the need to

attach a separate PC or media player.

Reduce Electricity Costs

Samsung videowall displays use advanced LED technology, which reduces

electricity consumption by up to 40% compared to CCFL-based panels.

The panels also run cooler, so air conditioning costs are lower.

Rely on Samsung Quality and Reliability

Samsung is the global leader in advanced video displays. We

manufacture millions of displays for televisions, smartphones, tablets,

monitors and, of course, videowalls. Our videowall displays are built for

demanding commercial installations with high-quality components to

ensure reliable, long-term performance.

VIDEOWALL

CONFIGURATION OPTIONS

Basic Intermediate Advanced

Simple playback

without scheduling

Various content playback

with scheduling

Various content, IP camera, and multi-PC

playback with scheduling

Max Displays Up to 100 Up to 16 Up to 250

Displays Supported UEC and UDC Series UEC, UDC and UD22B Series UEC and UDC Series

Functions

Linear only (2x2, 3x3) Linear and asymmetric Linear and asymmetric

No scheduling Scheduled play Scheduled and live play

16:9 aspect ratio Multiple aspect ratios Multiple aspect ratios

1920 x 1080 across entire wall Full HD on every screen Full HD on every screen

Display single source only Display multiple sources Display multiple sources

4k Videowall on 2x2 configuration Display images across single or

multiple screens

Display images across single or

multiple screens

HDCP support HDCP support

Image rotation Image rotation

Art wall (parallel/vertical) Art wall (any angle)

Remote monitor management Remote monitor management

Live camera and PC feeds

Technology

On-board processors and storage

(included) MagicInfo VideoWall - S MagicInfo VideoWall - I

DisplayPort (included) Network switch/LAN/Gb Ethernet PC running MagicInfo VideoWall - I

Set Back Box (SBB) for each display

Network switch/LAN/Gb Ethernet

Depending on the desired functionality, Samsung offers three different deployment options:

Basic Content Playback Using On-Board

Processors and Storage

For basic video playback, simply use the on-board processors

and storage in the UEC and UDC Series to daisy chain up to 100

displays. These displays use DisplayPort connectors to daisy chain

the video loop from one source panel. It is a cost-effective solution

for deployments that may not need complex features.

Semi-Complex Deployments with MagicInfo

VideoWall - S Software

For more robust deployments, the MagicInfo VideoWall - S

software and a single PC or notebook can drive up to 16 displays.

Unlike competitor videowall systems, this option does not require

a separate media player for each display. So hardware, wiring and

installation costs are significantly minimized.

The MagicInfo VideoWall - S is a network-based solution, so it

does require a Gigabit Ethernet LAN network with a switch. The

software has many additional features for including asymmetric

configurations, schedule-based playback and mixed panel sizes/

aspect ratios.

Live Streaming and Large-Scale Deployments with

MagicInfo VideoWall - I Software

For deployments with more than 16 panels or additional

functionality, the MagicInfo VideoWall - I software and associated

hardware is ideal. The VideoWall - I software enables live camera

feeds and controls up to 250 displays. This option is ideal for large

videowalls, conference rooms and control rooms where the ability

to display PC and camera feeds may be required, in addition to

providing flexibility of rotating or overlapping your screens.

Camera Feed

Source 6

Network Switch

PC Running MagicInfo

VideoWall-S Console PC Running MagicInfo

VideoWall Console

SBB-C Media Player for each LFD,

running MagicInfo VideoWall Player

Network Switch

Up to 10 PCs Running MagicInfo

VideoWall Console

Impress Visitors at Your Business Facility

Impress visiting prospects, customers and partners by communicating

your company message in lobbies, entrances, and trade show booths.

The Samsung videowall panels have sleek and thin profiles that suit

almost any business décor. For complex deployments like operations

centers and control rooms, the optional MagicInfo VideoWall - I software

enables live video camera and PC feeds directly onto the displays for

real-time data sharing.

Engage Viewers in Public Spaces

Public spaces require large videowalls to break through the clutter and

visual noise. Whether it’s a busy airport terminal or an elite art gallery,

Samsung videowalls render bright, bold images that can be displayed

in a variety of sizes and shapes. For public spaces that need always-on

videowalls, the UDC, UDC-B and UD22B displays are rated for

24/7 operation.

Ideal For:

• Museums and Galleries

• Convention Centers

• Stadiums and Arenas

• Airport and RailRoad Terminals

• Performing Arts Centers

Ideal For:

• Lobbies and Entrances

• High-Profile Areas

• Customer Briefing Centers

• Trade Show Booths

• Operations Centers and Control Rooms

Entice Customers at Retail Venues

Samsung videowall solutions are ideal for almost any size and type

of retail environment. Boutiques and specialty retailers can create

stunning videowalls with artistic designs and shapes that set the right

mood. Department stores can deploy videowalls in high traffic areas

with attention-catching promotions. Malls and shopping centers can

communicate upcoming events and create a shopping-friendly ambiance.

Samsung videowalls can also be deployed in bank branches and retail

investment centers to promote new products and display stock tickers

and market information.

Connect with Students and Alumni

Samsung videowalls can support outreach efforts when visitors, alumni

and benefactors are on campus for sporting events, reunions and

meetings. The videowalls can be used to tastefully message university

achievements like distinguished faculty awards, student achievements

and athletic performance.

Samsung videowalls can also be used to promote student organizations,

activities and upcoming events in student unions and common spaces.

Ideal For:

• Stadiums and Arenas

• Alumni Centers

• Building Entrances

• High-Profile Areas

• Student Unions and Common Areas

• College Museums and Performing Arts Centers

Ideal For:

• Department Stores

• Boutiques and Specialty Retail

• Shopping Malls

• Movie Theaters

• Themed Restaurants and Clubs

• Bank Branches and Investment Centers

Model UE46C UE55C

Panel

Diagonal Size 46" 55"

Type 240Hz e-LED BLU 240Hz e-LED BLU

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Pixel Pitch (mm) 0.15375 (H) x 0.46125 (V) 0.210 (H) x 0.630 (V)

Active Display Area (mm) 1018.08 (H) x 572.67 (V) 1209.6 (H) x 680.4 (V)

Brightness (Typ.) 500 nits 500 nits

Contrast Ratio 5000:1 5000:1

Viewing Angle (H/V) 178º / 178º 178º / 178º

Response Time (G-to-G) 4ms 4ms

Display Colors 10bit Dithering - 1.07 Billion 10bit Dithering - 1.07 Billion

Color Gamut 72% 72%

Connectivity

Input

RGB Analog D-SUB, DVI-D, DisplayPort 1.2 Analog D-SUB, DVI-D, DisplayPort 1.2

Video HDMI1, HDMI2, Component (CVBS Common) HDMI1, HDMI2, Component (CVBS Common)

Audio Stereo Mini Jack Stereo Mini Jack

Output

RGB DP1.2 (Loop-out) DP1.2 (Loop-out)

Audio Stereo Mini Jack Stereo Mini Jack

External Control RS232C (in/out) thru Stereo Jack, RJ45 RS232C (in/out) thru Stereo Jack, RJ45

Mechanical

Spec

Dimension

Set 40.6" x 23" x 1.18" 48.1" x 27.3" x 1.18"

Package 46.1" x 27.8" x 7.8" 53.7" x 33.4" x 7.8"

Weight

Set 25.6 lbs. 34 lbs.

Package 34.1 lbs. 45.4 lbs.

VESA Mount 400 x 400mm 400 x 400mm

Stand Type Foot Stand (Optional) Foot Stand (Optional)

Media Player Option Type Embedded, Optional Accessories, SBB-C, SBB-CD7, SBB-CQ7 Embedded, Optional Accessories, SBB-C, SBB-CD7, SBB-CQ7

Bezel Width (mm) 5.5 5.5

Videowall Panel Specifications

Autres manuels pour UD46C

Ce manuel convient aux modèles suivants

Autres manuels Samsung Moniteur

Samsung

Samsung SyncMaster 933BW Manuel utilisateur

Samsung

Samsung SyncMaster U70 Manuel utilisateur

Samsung

Samsung 2233BW - SyncMaster - 22" LCD Monitor Manuel utilisateur

Samsung

Samsung SyncMaster P2050 Guide de l'utilisateur

Samsung

Samsung SyncMaster 731NPlus Manuel utilisateur

Samsung

Samsung SyncMaster 2443DW Manuel utilisateur

Samsung

Samsung 2232BW - SyncMaster - 22" LCD Monitor Manuel utilisateur

Samsung

Samsung SyncMaster T190N Manuel utilisateur

Samsung

Samsung SyncMaster 2343BW Manuel utilisateur

Samsung

Samsung 910MP - SyncMaster 19" LCD Monitor Manuel utilisateur

Samsung

Samsung S34BG850SE Manuel utilisateur

Samsung

Samsung OH46F Manuel utilisateur

Samsung

Samsung 192mp - SyncMaster 19" LCD Monitor Manuel utilisateur

Samsung

Samsung 22T35 Series Manuel utilisateur

Samsung

Samsung 730B - SyncMaster - 17" LCD Monitor Manuel utilisateur

Samsung

Samsung S27CG51 Series Manuel utilisateur

Samsung

Samsung SyncMaster 242MP Manuel utilisateur

Samsung

Samsung 320MP-2 - SyncMaster - 32" LCD Flat Panel... Manuel utilisateur

Samsung

Samsung SyncMaster 2043BW Manuel utilisateur

Samsung

Samsung CN17A series Manuel utilisateur

Samsung

Samsung LTN154BT02-001 Manuel utilisateur

Samsung

Samsung S22E390H Manuel utilisateur

Samsung

Samsung 940MW - SyncMaster - 19" LCD Monitor Manuel utilisateur

Samsung

Samsung SyncMaster 930MP Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
