Samsung U28E590D Manuel utilisateur

User manual

U28E590D

U24E590D

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00481B-06

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

7 Copyright

7 Icons used in this manual

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

10 Safety Precautions

10 Symbols

11 Electricity and Safety

12 Installation and Safety

14 Operation and Safety

18 Correct posture to use the product

PREPARATIONS 19 Checking the Contents

19 Checking the Components

20 Parts

20 Control Panel

21 Direct Key guide

22 Function Key Guide

24 Reverse Side

25 Installation

25 Attaching the Stand

26 Removing the Stand

27 Installing a Wall-mount Kit or Desktop Stand

28 Adjusting the Product Tilt

28 Anti-theft Lock

CONNECTING AND USING

A SOURCE DEVICE

29 Before Connecting

29 Pre-connection Checkpoints

Table Of Contents

Table Of Contents 3

29 Connecting and Using a PC

29 Connection Using the HDMI Cable

30 Connection Using an DP Cable

31 Connecting to Headphones

31 Tidying Up the Connected Cables

32 Connecting the Power

34 Driver Installation

35 Setting Optimum Resolution

SCREEN SETUP 36 SAMSUNG MAGIC Bright

36 Configuring SAMSUNG MAGIC Bright

38 Brightness

38 Configuring Brightness

39 Contrast

39 Configuring Contrast

40 Sharpness

40 Configuring Sharpness

41 Color

41 Configuring Color

43 SAMSUNG MAGIC Angle (U28E590D)

43 Configuring SAMSUNG MAGIC Angle

45 HDMI Black Level

45 Configuring the HDMI Black Level Settings

46 Eye Saver Mode

46 Configuring Eye Saver Mode

47 Game Mode

47 Configuring Game Mode

48 Response Time

48 Configuring the Response Time

49 Picture Size

49 Changing the Picture Size

Table Of Contents

Table Of Contents 4

51 Screen Adjustment

51 Configuring H-Position & V-Position

CONFIGURING THE PIP/

PBP SETTINGS

52 PIP/PBP

53 Configuring PIP/PBP Mode

54 Configuring Size

55 Configuring Position

56 Configuring Sound Source

57 Configuring Source

59 Configuring Picture Size

63 Configuring Contrast

COORDINATING OSD 65 Transparency

65 Changing Transparency

66 Language

66 Configuring Language

67 Display Time

67 Configuring Display Time

SETUP AND RESET 68 FreeSync

68 Configuring FreeSync

71 Eco Saving Plus

71 Configuring Eco Saving Plus

72 Off Timer

72 Configuring Off Timer

73 Configuring Turn Off After

74 PC/AV Mode

74 Configuring PC/AV Mode

75 DisplayPort Ver.

75 Configuring DisplayPort Ver.

76 Source Detection

76 Configuring Source Detection

Table Of Contents

Table Of Contents 5

77 Key Repeat Time

77 Configuring Key Repeat Time

78 Power LED On

78 Configuring Power LED On

79 Reset All

79 Initializing Settings (Reset All)

INFORMATION MENU AND

OTHERS

80 Information

80 Displaying Information

81 Configuring Eye Saver Mode, Brightness,

and Contrast from the Initial Screen

82 Configuring Volume in the Initial Screen

82 Volume

INSTALLING THE

SOFTWARE

83 Easy Setting Box

83 Installing the Software

84 Removing the Software

TROUBLESHOOTING

GUIDE

85 Requirements Before Contacting

Samsung Customer Service Center

85 Testing the Product

85 Checking the Resolution and Frequency

85 Check the following.

88 Q & A

SPECIFICATIONS 90 General

91 PowerSaver

92 Standard Signal Mode Table

Table Of Contents

Table Of Contents 6

APPENDIX 97 Responsibility for the Pay Service (Cost

to Customers)

97 Not a product defect

97 A Product damage caused by customer's fault

97 Others

98 Correct Disposal

98 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

99 Terminology

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair center and there is no defect in the product

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is

carried out.

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center if the inside of the monitor needs cleaning.

(A service fee will be charged.)

3.93

inches

(10 cm)

3.93

inches

(10 cm)

3.93 inches(10 cm)

3.93 inches

(10 cm)

Before Using the Product

Safety Precautions

Symbols

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR

BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO

QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside. It is dangerous to

make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and

maintenance has been included with this product.

Warning A serious or fatal injury may result if instructions are not followed.

Caution Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.
