SEC-VD-DSW Multiple Display Control - 0008

Ver. 2.1

2008-06-26

Multiple Display Control Protocol

for SyncMaster 42TS/42PS P50Hn

P50F(n) P63F(n)

320MX(n) 400CX(n)

400MX(n) 460CX(n)

SEC-VD-DSW Multiple Display Control - 0008

Ver. 1.0

2008-06-26

「This document is a technical asset of Samsung Electronics, Co. and using or copying

this material without the authorization from the technical data management group is strictly

prohibited..」

Contact Information

Display S/W Group, VD Business Division

Samsung Electronics Co., Ltd

Address : 416, Maetan-3Dong, Paldal-Gu,

Suwon City, Kyungki-Do, Korea

442-742

Telephone : 82-31-277-2764

E-mail : [email protected]

Prepared by : Display S/W, Video Display Division.

Status : Prepared

Subject : Technical Writer, Programmer, Developer

Outline : Protocol type document of Multiple Display Control 1.0

History :

Version Date Content Prepared by Compared by

1.0 2005. 01. 05. Protocol for Multiple Display Control S. Jang

1.1 2005. 01. 07 Add Safety Lock S. Jang

1.2 2005. 01. 18 Add Video Wall J. Lee

1.3 2005. 01. 26 modify Maintenance Control S. Jang

1.4 2005. 03. 11 modify Baudrate, PIP Control J. Lee

1.5 2005. 07. 04 Add Commands S. Jang

1.6 2005. 11. 11 Add Command ( Screen Scroll On) S. Jang

1.7 2006. 02. 01 Add Commands H. Park

1.8 2006. 10. 02 Add Commands H. Park

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

1.9 2006. 12. 18 Add Commands ( New Video Wall ) H. Park

Version Date Content Prepared by Compared by

2.0 2007. 04. 17. Add Commands H. Park

2.1 2008. 06. 26. Add Commands J. Choi

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

1. INTERFACE

1.1. Connecting Method

1) Connecting method

-As of Figure 1-1, connect RS232-In(9Pin) to Personal Computer, connect thenext

TV of Display to be connected from RS232-Out (9Pin).

-In doing so, each TV or Monitor ID can be given from 0 to 99.

-ID cannot be given duplicated.

-When granting ID, it does not need to be given out in the connecting order.

Figure1-1 PC,TV or Monitor connecting method

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

LCD 1

OUTIN

UART LCD 2

OUTIN

UART LCD 3

OUTIN

UART LCD 4

OUTIN

UART

Personal

Computer

RS232

LCD 1

OUTIN

UART LCD 2

OUTIN

UART LCD 3

OUTIN

UART LCD 4

OUTIN

UART

Personal

Computer

RS232

1.2. Connection Spec.

1) Connection Spec.

-Interactive communications using RS232.

-Of RS232 standards, three signals TxD(No.2), RxD(No.3) and GND(No.5) are used →

Refer to Figure 1

-Limit the distance between devices to less than 4m.

- Currently, out of 9 PIN RS232 terminal, PINS in use are numbers 2, 3 and 5.

-ID should show hexadecimal value of assigned ID, but ID 0 should be 0xFF.

-Every communication will be made in hexadecimals and Checksum is the sum of all

remainings. If it exceeds two digits, for example, it is 11+FF+01+01=112, discard the

number in the first digit like below.

example) Power On & ID=0

Header Command ID Data Length Data 1 Check

Sum

0xAA 0x11 1 Power

→

Header Command 0xFF Data Length Data 1 12

0xAA 0x11 1 1

-If you want to control every mechanism connected with Serial Cable regardless of its

ID,setIDpartto"0xFE"andsendcommands.Atthetime,eachSETwillfollow

commands but it will not respond with ACK.

Table 2-1 RS232 Network spec

Bits Rate 9600 bps

Data Bits 8 bits

Parity None

Stop Bits 1 bit

Flow Control None

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

Figure 2-1 RS-232 pin out DB-9 pin used for Asynchronous Data

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

2. Commanding words

No Command Type Command Value Range

1 Status Control 0x00 -

2 Time Control 0x01 -

3 On Time Control 0x02 -

4 Off Time Control 0x03 -

5VideoControl 0x04 -

6AudioControl 0x05 -

7RGBControl 0x06 -

8PIP Status Control 0x07 -

9Maintenance Control 0x08 -

10 Serial Number Control 0x0B -

11 Display Status Control 0x0D -

12 Software Version Control 0x0E -

13 Model Number Control 0x10 -

14 Power Control 0x11 0~1

15 Volume Control 0x12 0 ~ 100

16 Mute Control 0x13 0 ~ 1

17 Input Source Control 0x14 -

18 ImageSizeControl 0x15 -

19 Direct Channel Control 0x16 -

20 Screen Mode Control 0x18 -

21 Screen Size Control 0x19 0 ~ 255

22 Red Offset Control 0x1A 0 ~ 100

23 Green Offset Control 0x1B 0 ~ 100

24 Blue Offset Control 0x1C 0 ~ 100

25 Contrast Control 0x24 0 ~ 100

26 Brightness Control 0x25 0 ~ 100

27 Sharpness Control 0x26 0 ~ 100

28 Color Control 0x27 0 ~ 100

29 Tint Control 0x28 0 ~ 100

30 Red Gain Control 0x29 0 ~ 100

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

31 Green Gain Control 0x2A 0 ~ 100

32 Blue Gain Control 0x2B 0 ~ 100

33 Treble Control 0x2C 0 ~ 100

34 Bass Control 0x2D 0 ~ 100

35 Coarse Control 0x2F 0 ~ 1

36 Fine Control 0x30 0 ~ 1

37 H-Position Control 0x31 0 ~ 1

38 V-Position Control 0x32 0 ~ 1

39 Clear Menu Control 0x34 0

40 Remote Control 0x36 0 ~ 1

41 RGB Contrast Control 0x37 0 ~ 100

42 RGB Brightness Control 0x38 0 ~ 100

43 PIP On/Off Control 0x3C 0 ~ 1

44 Auto Adjustment Control 0x3D 0

45 Color Tone Control 0x3E 0 ~ 4

46 Color Temperature Control 0x3F 0 ~ 10

47 PIP Source Control 0x40 -

48 Main-PIP Swap Control 0x41 0 ~ 1

49 PIP Size Control 0x42 -

50 PIP Locate Control 0x43 0 ~ 4

51 Sound Select Control 0x47 0 ~ 1

52 Pixel Shift Control 0x4C -

53 Video Wall Control 0x4F -

54 Auto Lamp Control 0x57 -

55 Manual Lamp Control 0x58 0 ~ 100

56 Safety Screen Run Control 0x59 0 ~ 6

57 Safety Screen Control 0x5B -

58 Video Wall Mode Control 0x5C 0 ~ 1

59 Safety Lock 0x5D 0 ~ 1

60 Panel Lock 0x5F 0 ~ 1

61 OSD On/OFF 0x70 0 ~ 1

62 P. Mode Control 0x71 -

63 S. Mode Control 0x72 0 ~ 4

64 NR Mode Set 0x73 0 ~ 1

65 PC Color Tone Control 0x75 0 ~ 3

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

66 Auto AutoAdjustment 0x76 0 ~ 1

67 All Keys Lock 0x77 0 ~ 1

68 SRS TSXT Control 0x78 0 ~ 1

69 Film Mode 0x79 0 ~ 1

70 Signal Balance 0x7A 0 ~ 1

71 SB Gain 0x7E 0 ~ 100

72 SB Sharpness 0x7F 0 ~ 100

73 Panel On Time 0x83 -

74 Video Wall On 0x84 0 ~ 1

75 Temperature Control 0x85 0 ~ 125

76 Brightness Sensor 0x86 0 ~ 1

77 Dynamic Contrast 0x88 0 ~ 1

78 Safety Screen On 0x88 1 ~ 5

79 Video Wall User Control 0x89 -

80 Model Name 0x8A -

"-" indicates multiple setting items-refer to "2.1. Command Detailed Explanation" for more

details.

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

2.1. Command Detailed Explanation

* Status Control

●Function

Personal Computer shows current setting condition of TV / Monitor.

●Get Status

Header Command ID Data Length Check

Sum

0xAA 0x00 0

●Ack

Header Command ID Data Length Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 9 'A' 0x00 Power Volume

Val 3 Val 4 Val 5 Val 6 Val 7 Check

Sum

Mute Input Aspect NTimeNF FTimeNF

Power : Power code to be set on TV / Monitor

Volume : Volume value code ( 0 ~ 100 ) to be set on TV / Monitor

Mute : Mute code to be set on TV / Monitor

Input :InputSourcecodetobesetonTV/Monitor

Aspect : Image Size code to be set on TV/Monitor

NTimeNF: OnTime ON/OFF value of time to set TV/Monitor

FTimeNF : OffTime ON/OFF value of time to set TV/Monitor

●Nak

Header Command ID Data Length Ack/Nak r-CMD Val 1 Check

Sum

0xAA 0xFF 3 'N' 0x00 ERR

ERR : Error code that shows what occurred error is

0 Check Sum Error

1etc.

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics
