Samsung SyncMaster 2243NW Manuel utilisateur

LCD MONITOR

quick start guide

245BPLUS

Packa

e Contents

Please make sure the following items are included with your monitor.

If any items are missing, contact your dealer.

Contact a local dealer to buy optional items.

ackin

Without Stand

Monitor

With Stand

Monitor & Sliding Stand

Manual

Quick Setup Guide

Warranty Card

(Not available in all

locations)

User's Guide, Monitor Driver,

Natural Color,

MagicTune™

Cable

Power Cord D-sub Cable

Sold se

aratel

DVI Cable

Others

Cleaning Cloth

This is only provided for highly polished black products as a product feature.

eaker

acka

(

tion

)

Speaker

our Monito

Front

MENU button [ ]

Opens the on-screen menu and exits from the menu.

MagicBright™ button

[]

MagicBright™ is a new feature providing optimum viewing

environment depending on the contents of the image you are

watching. Currently seven different modes are available: Custom,

Text, Internet, Game, Sport and Movie, Dynamic Contrast. Each

mode has its own pre-configured brightness value. You can easily

select one of seven settings by simply pressing MagicBright™ control

button.

1) Custom

Although the values are carefully chosen by our engineers, the

pre-configured values may not be comfortable to your eyes

depending on your taste.

If this is the case, adjust the brightness and contrast by using the

OSD menu.

2) Text

For documentations or works involving heavy text.

3) Internet

For working with a mixture of images such as texts and graphics.

4) Game

For watching motion pictures such as a game.

5) Sport

For watching motion pictures such as a sport.

6) Movie

For watching motion pictures such as a DVD or Video CD.

7) Dynamic Contrast

Dynamic Contrast is to automatically detect distribution of inputted

visual signal and adjust to create optimum contrast.

>> Click here to see an animation clip

Brightness button [ ]

When OSD is not on the screen, push the button to adjust brightness.

>> Click here to see an animation clip

Not available in MagicBright mode of Dynamic Contrast.

Adjust buttons [ ] Adjust items in the menu.

Enter button [ ] /

Source button

Activates a highlighted menu item. /

Push the ' ', then selects the video signal while the OSD is off.

(When the button is pressed to change the input mode, a message

appears in the upper left of the screen displaying the current mode --

analog or digital input signal.)

>> Click here to see an animation clip

If you select the digital mode, you must connect your monitor to the

graphic card's DVI IN(HDCP) port using the DVI cable.

AUTO button Use this button for auto adjustment.

>> Click here to see an animation clip

Power button [ ] Use this button for turning the monitor on and off.

Power indicator

This light glows blue during normal operation, and blinking blue once

as the monitor saves your adjustments.

See PowerSaver described in the manual for further information regarding power saving

functions. For energy conservation, turn your monitor OFF when it is not needed, or

when leaving it unattended for long periods.

Rea

The configuration at the back of the monitor may vary from product to product.

POWER S/W / POWER

POWER S/W

: Switches the monitor On/Off.

POWER

: Connect the power cord for your monitor to the POWER on

the back of the monitor.

DVI IN(HDCP) / RGB IN

DVI IN(HDCP)

: Connect the DVI cable to the DVI IN(HDCP) port

on the back of your monitor.

RGB IN

: Connect the RGB IN terminal at the back of your monitor to

your computer.

AUDIO POWER

zConnect the speaker power line connected to the speaker to

the AUDIO POWER terminal of the monitor

Kensington Lock

zThe Kensington lock is a device used to physically fix the

system when using it in a public place.

(The locking device has to be purchased separately.)

For using a locking device, contact where you purchase it.

Stand Stopper

zRemove the fixing pin on the stand to lift the monitor up and

down.

See Connecting Cables for further information regarding cable connections.

Connectin

Cables

Connect the power cord for your monitor to the POWER port on the back of the monitor.

Plug the power cord for the monitor into a nearby outlet.

Use appropriate connection for your computer.

Using the RGB (Analog) connector on the video card.

- Connect the signal cable to the 15-pin, RGB IN port on the back of your monitor.

[ RGB IN ]

Using the DVI (Digital) connector on the video card.

- Connect the DVI cable to the DVI IN(HDCP) port on the back of your monitor.

[ DVI IN(HDCP) ]

Connected to a Macintosh.

Connect the monitor to the Macintosh computer using the RGB connection cable.

If the monitor and the computer are connected, you can turn them on and use them.

Connectin

a S

eake

When connecting a speaker, be careful that the grooves of the monitor and the speaker .

( )are aligned with each other.

djust the aligned positions until you hear a ‘click’. If a speaker is connected correctly,

you can hear a ‘click’.If a speaker is connected without you hearing a ‘click’, the holding

part may become damaged.

If you need to separate, please pull ( ) a little and push to the right.

MIC / SPK

Connect the red cable of the cables provided when the speaker was purchased to the audio

output terminal at the back of the computer.

Connect the other end of the cable to the red terminal at the back of the speaker.

Connect the light green cable of the cables provided when purchasing the speaker to the

audio output terminal at the back of the computer.

Connect the other end of the cable to the light green terminal at the back of the speaker.

Connect a headphone to the black terminal at the right of the speaker.

Connect a microphone to the red terminal at the right of the speaker.

By turning part ( + , - ) in the direction shown in the figure below, the speaker turns on and the

volume increases.

Connect the power line connected to the speaker to the black terminal of the monitor.

This speaker is not connected to an external power source. It is connected to a monitor for the

required power.

Usin

the Stand

Slidin

stand

Stand Stopper

Swivel stand

Using ( ),You can swivel the monitor left and right at an angle of 350° to set the monitor

lengthwise. The rubber under the stand is to avoid the monitor slide.

When you try to rotate the monitor in the state of the power cord or cable connecting to

the monitor, the power cord of cable can be destroyed.

Tilt an

Using ( ), You can adjust the tilt anlgle within a range of 3° forward to 25° backward for

the most comfortable viewing angle.

Attachin

a Base

This monitor accepts a 200 mm x 100 mm VESA-compliant Mounting interface pad.

Monitor

Mounting interface pad (Sold separately)

1. Turn off your monitor and unplug its power cord.

2. Lay the LCD monitor face-down on a flat surface with a cushion beneath it to protect the

screen.

3. Remove four screws and then remove the stand from the LCD monitor.
