Samsung S22C450D Manuel utilisateur

User manual

S22C450D

S23C450D

S24C450D

S24C450DL

S27C450D

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00294D-00

Table Of Contents 2

Table Of Contents

BEFORE USING

THE PRODUCT

7 Copyright

7 Icons used in this manual

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

10 Safety Precautions

10 Symbols

11 Electricity and Safety

12 Installation and Safety

14 Operation and Safety

18 Correct posture to use the product

PREPARATIONS 19 Checking the Contents

19 Removing the Packaging

20 Checking the Components

21 Parts

21 Frontal Buttons

23 Reverse Side

24 Installation

24 Attaching the Stand

25 Adjusting the Product Tilt and Height

25 Rotating the Monitor

26 Installing a Wall-mount Kit or Desktop Stand

27 Anti-theft Lock

CONNECTING AND

USING A SOURCE

DEVICE

28 Before Connecting

28 Pre-connection Checkpoints

28 Connecting the Power

Table Of Contents

Table Of Contents 3

29 Connecting and Using a PC

29 Connecting to a PC

31 Driver Installation

32 Setting Optimum Resolution

33 Changing the Resolution Using a PC

SCREEN SETUP 37 Brightness

37 Configuring Brightness

38 Contrast

38 Configuring Contrast

39 Sharpness

39 Configuring Sharpness

40 SAMSUNG MAGIC Bright

40 Configuring SAMSUNG MAGIC Bright

41 SAMSUNG MAGIC Angle

41 Configuring SAMSUNG MAGIC Angle

42 Image Size

42 Changing the Image Size

44 H-Position & V-Position

44 Configuring H-Position & V-Position

45 Coarse

45 Adjusting Coarse

46 Fine

46 Adjusting Fine

CONFIGURING

TINT

47 Red

47 Configuring Red

48 Green

48 Configuring Green

Table Of Contents

Table Of Contents 4

49 Blue

49 Configuring Blue

50 Color Tone

50 Configuring the Color Tone Settings

51 Gamma

51 Configuring Gamma

RESIZING OR

RELOCATING THE

SCREEN

52 Language

52 Changing the Language

53 Menu H-Position & Menu V-Position

53 Configuring Menu H-Position & Menu V-

Position

54 Display Time

54 Configuring Display Time

55 Transparency

55 Changing Transparency

SETUP AND

RESET

56 Reset

56 Initializing Settings (Reset)

57 Eco Saving

57 Configuring Eco Saving

58 Off Timer

58 Configuring Off Timer

59 Turn Off After

59 Configuring Turn Off After

60 PC/AV Mode

60 Configuring PC/AV Mode

61 Key Repeat Time

61 Configuring Key Repeat Time

Table Of Contents

Table Of Contents 5

62 Source Detection

62 Configuring Source Detection

63 Customized Key

63 Configuring Customized Key

INFORMATION

MENU AND

OTHERS

64 INFORMATION

64 Displaying INFORMATION

65 Configuring Brightness and Contrast in

the Initial Screen

INSTALLING THE

SOFTWARE

66 Magic Tune

66 What is MagicTune?

66 Installing the Software

67 Removing the Software

68 MultiScreen

68 Installing the Software

69 Removing the Software

70 MagicRotation

70 Installing the Software

72 Removing the Software

TROUBLESHOOTING

GUIDE

73 Requirements Before Contacting

Samsung Customer Service Center

73 Testing the Product

73 Checking the Resolution and Frequency

73 Check the following.

75 Q & A

SPECIFICATIONS 77 General

81 PowerSaver

Table Of Contents

Table Of Contents 6

82 Standard Signal Mode Table

APPENDIX 88 Contact SAMSUNG WORLD WIDE

94 Responsibility for the Pay Service (Cost

to Customers)

94 Not a product defect

94 A Product damage caused by customer's fault

94 Others

95 Correct Disposal

95 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

96 Terminology

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair center and there is no defect in the product

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is

carried out.

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center (page 88) if the inside of the monitor needs

cleaning. (Service fee will be charged.)

3.93

inches

(10 cm)

3.93

inches

(10 cm)

3.93 inches(10 cm)

Before Using the Product

Safety Precautions

Symbols

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)

THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance

has been included with this product.

Warning A serious or fatal injury may result if instructions are not followed.

Caution Personal injury or damage to properties may result if instructions are not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.
