Samsung PS42P4A1X Manuel utilisateur

PLASMA DISPLAY TV

Chassis : D68A(P)Europe42”_DNIe3

Model : PS42P4A1X/XEC

PLASMA DISPLAY TV CONTENTS

Specifications

Alignment and Adjustments

Exploded View and Parts List

Service Item

Schematic Diagrams

SERVICE Manual

ELECTRONICS

This Service Manual is a property of Samsung Electronics Co.,Ltd.

Any unauthorized use of Manual can be punished under applicable

International and/or domestic law.

©Samsung Electronics Co., Ltd. Nov. 2004

Printed in Korea

AA82-02078A

Specifications

Samsung Electronics 1-1

1. Specifications

Alignment and Adjustments

Samsung Electronics 2-1

2. Alignment and Adjustments

2-1 Service Mode

2-1-1 SERVICE MODE Entry Method (General Transmitter)

■For the General Transmitter

1. Turn the power off and set to stand-by mode.

2. Press the buttons of the transmitter in this order; INFO-MENU-MUTE-POWER ON to turn the set on.

3. The set turns on and enters service mode.

■For the Factory Transmitter

1. Turn the power on.

2. Press the buttons of the transmitter in this order : INFO-Factory.

3. The set enters service mode.

* If you fail to enter service mode, repeat steps 1 and 2 above.

2-1-2 Initial DISPLAY State of SERVICE MODE

2-1-2(A) OSD DISPLAY

2-1-2(B) Button Operations in SERVICE MODE

Menu Displays all menus

UP/DOWN Cursor move to select items

LEFT/RIGHT Enable to increase and decrease the data of the selected items

(ENTER) Confirm your choice(Store OR Enter)

☞Indicates selected input mode

☞Picture Adjustment

☞Setting the Initial Values

☞Setting the Special Features

☞Options-1 : Options of the Product Particulars

☞Options-2 : Options of the PDP Properties

☞Initializing after saving the adjustments

☞Software Version Information

Factory Mode Current Input Mode

01. Picture Improvement ▶

02. Initial Setting ▶

03. PIP/TTX/Test Pattern ▶

04. Option-1 ▶

05. Option-2 ▶

06. Reset ▶

Release : Oct 06 2004 11 : 41 : 14

Version : T-NPL42PEU1-1215

Alignment and Adjustments

2-2 Samsung Electronics

2-2 WHITE Balance Coordinates

2-2-1 PS42P4A1 White Balance Adjustment

1. W/B Adjustment is required for the following four modes: DVI-> COMPONENT-> PC->VIDEO

2. Adjustment Method

(Signal equipment : MSPG-925LTH, Measurement equipment : CA210)

(1) Adjust the target set by adjusting the panel logic and the video DNIe adjustment register in

order to determine the referential W/B of the panel with a DVI input, which is the full digital path.

(2)For Component adjustment, adjust the adjustment register of AD9883 to align the DTV signal

to the DNIe and logic panel value which was fixed with a DVI adjustment so that they are

in effect considered to be the same signals. (At this time, do not adjust the gain of AD9883 -> the Highlight W/B does not need

to be adjusted since its deviation falls within valid distribution range.)

(3)PC adjustment is same as Component adjustment. (The offset can be applied to the values obtained through DTV adjustment.

However, additional adjustment is required for Y, Cb, and Cr of Component since PC processes R, G, and B signals.)

* Attention for Component/PC adjustment

- Load the Auto color pattern. (Pattern #21)

- Excute Auto color of factory mode to adjust gain and offset.

- Load the Toshiba Pattern.(Pattern #16) and then adjust W/B.

(4)Video adjustment is performed with the Toshiba pattern (in-house signal) and differs from the VG828 signals in the above

three modes. Hence, it should be performed with the same method of (1) DVI adjustment.

Also, Video adjustment should be performed with Video port and Graphic port separately.

* Thus, Micom saves the W/B data separately for each memory mode of the block (See the block diagram given below) during W/B

adjustment.

Alignment and Adjustments

Samsung Electronics 2-3

1-3-1 Factory OSD Main Menu

1-3 Factory Data

01.Picture Improve

H/L

L/L

Y(fL)

VIDEOI

268

263

268

263

1.6

Component

268

263

268

263

1.4

283

295

283

295

0.9

DVI

283

295

283

295

0.9

1-2-2 White Balance Coordinates by Mode

☞Indicates selected input mode

☞Picture Adjustment

☞Setting the Initial Values

☞Setting the Special Features

☞Setting the Options of the Product Particulars

☞Setting the Options of the PDP Properties

☞Initializing after saving the adjustments

☞Software Version Information

Factory Mode Current Input Mode

01. Picture Improvement ▶

02. Initial Setting ▶

03. PIP/TTX/Test Pattern ▶

04. Option-1 ▶

05. Option-2 ▶

06. Reset ▶

Release : Oct 06 2004 11 : 41 : 14

Version : T-NPL42PEU1-1215

☞White Balance Adjustment

☞Color Adjustment

☞Contrast & Brightness Enhancement

☞Detail Enhancement Sharpness Adjustment

☞Y/C Delay Setting according to the System and

Input Modes

☞Motion Enhancing Adjustment

☞DNIe Registers

☞Logic Registers of the Panel

☞Picture Size Registers

01.Picture Improvement Current Input Mode

01. White Balance ▶

02. Color ▶

03. Cont/Bri Enhancement ▶

04. Detail Enhancement ▶

05. Y/C Delay ▶

06. Motion ▶

07. DNIe ▶

08. DNIe Additional ▶

09. Logic ▶

10. Picture Size ▶

Alignment and Adjustments

2-4 Samsung Electronics

01.Picture Improve => 01.White Balance Adjustment

01.White Balance

01.R Drive

02.G Drive

03.B Drive

04.R Cutoff

05.G Cutoff

06.B Cutoff

07.Sub Contrast

08.Sub Brightness

09.R Gain

10.G Gain

11.B Gain

12.R/Cr Offset

13.G/Y Offset

14.B/Cb Offset

15.Auto color

128

120

on/off

Mode-1

128

120

W/B

Mode-2

128

120

W/B

128

144

128

Mode-3

128

120

W/B

128

Mode-4

128

120

W/B

Initial Values of Input Modes

Video Component PC DVI

Relevant IC

DNIe

ASI510

AD9883

ITEM

hInput modes require respective storing the changes after adjustment.

01~06 : DNIe

07~08 : ASI510

09~15 : AD9883

Alignment and Adjustments

Samsung Electronics 2-5

01.Picture Improve => 02.Color Adjustment

02.Color

01.U-Saturation

02.V-saturation

03.RGB/YUV U-SAT

04.RGB/YUV V-SAT

05.RGB/YUV Tint

06.FLI-saturation

07.R Gamma

08.G Gamma

09.B Gamma

10.Gain-Sel

11.Cr Gain

12.Cb Gain

13.Y Gain

14.FLI - Y/G Bir

15.FLI - Cr/R Bir

16.FLI - Cb/B Bir

120

Mode-1

120

Mode-2

Mode-3

Mode-4

Initial Values of Input Modes

PC DVI

Relevant IC

VSP9437

FLI2310

ASI510

CXA2151

FLI2310

ITEM

01 ~05 : VSP9437

07~09 : ASI510

06 , 14~16 : FLI2310

10~13 : CXA2151

Video Component

Alignment and Adjustments

2-6 Samsung Electronics

01.Picture Improve => 03.Contrast & Brightness Enhancement

03.Cont/Bri Enhancement

01.Contrast

02.Brightness

03.RGB/YUV Contrast

04.RGB/YUV Brightness

05.FLI-Contrast

06.FLI-Brightness

07.R Contrast

08.G Contrast

09.B Contrast

10.R Brightness

11.G Brightness

12.B Brightness

100

128

Mode-1

100

128

Mode-2

Mode-3

Mode-4

Initial Values of Input Modes

PC DVI

Relevant IC

VSP9437

FLI2310

ASI510

ITEM

01~04 : VSP9437

07~12 : ASI510

05~06 : FLI2310

Video Component

Alignment and Adjustments

Samsung Electronics 2-7

01.Picture Improve => 04.Detail Enhancement

04.Detail Enhancement

01.VAPGAIN

02.VAPINV

03.YPFT

04.YPFG

05.APK-1st-BPM

06.APK-2nd-BPM

07.Denoise-BPM

08.APK-1st-HPM

09.APK-2nd-HPM

10.Denoise-HPM

11.HenhGain

12.HLEGain

13.HChrEnGain

Mode-1

Mode-2

Mode-3

Mode-4

Initial Values of Input Modes

PC DVI

Relevant IC

uPD64083

VSP9437

FLi2310

ITEM

01~04 : uPD64083

05~10 : VSP9437

11~13 : FLI2310

Video Component
