Owner’s Instructions

PL-42S5S

This device is a Class B digital apparatus.

BN68-00866C-00Eng(cover) 8/4/05 6:28 PM Page 3

Important Warranty Information

Regarding Television Format Viewing

Wide screen format PDP Displays (16:9, the aspect ratio of the screen width to height) are primarily

designed to view wide screen format full-motion video. The images displayed on them should primarily

be in the wide screen 16:9 ratio format, or expanded to fill the screen if your model offers this feature

and the images are constantly moving. Displaying stationary graphics and images on screen, such as

the dark side-bars on nonexpanded standard format television video and programming, should be

limited to no more than 5% of the total television viewing per week.

Additionally, viewing other stationary images and text such as stock market reports, video game

displays, station logos, web sites or computer graphics and patterns, should be limited as described

above for all televisions. Displaying stationary images that exceed the above guidelines

can cause uneven aging of PDP Displays that leave subtle, but permanent burned-in

ghost images in the PDP picture. To avoid this, vary the programming and images,

and primarily display full screen moving images, not stationary patterns or dark

bars.

On PDP models that offer picture sizing features, use these controls to view different formats as a full

screen picture.

Be careful in the selection and duration of television formats used for viewing. Uneven PDP aging as a

result of format selection and use, as well as burned-in images, are not covered by your Samsung

limited warranty.

BN68-00866C-00Eng(002~031) 8/4/05 6:17 PM Page 2

User Instructions

Screen Image retention

Do not display a still image (such as on a video game) on the plasma display panel for more than

several minutes as it can cause screen image retention. This image retention is also known as

“screen burn”. To avoid such image retention, refer to page 45 of this manual to reduce the

degree of brightness and contrast of the screen when displaying a still image.

Altitude

The PDP will not operate normally at altitudes above 6500 ft.

Heat on the top of the PDP TV

The top side of the product may be hot after long periods of use as heat dissipates from the panel

through the vent hole in the upper part of the product.

This is normal and does not indicate any defect or operation failure of the product.

However, children should be prevented from touching the upper part of the product.

The product is making a ‘cracking’ noise.

A ‘cracking’ noise may occur when the product contracts or expands due to a change of

surrounding environment such as temperature or humidity. This is normal and not a defect of the

unit.

Cell Defects

The PDP uses a panel consisting of 1,230,000(SD-level) to 3,150,000(HD-level) pixels which

require sophisticated technology to produce. However, there may be few bright or dark pixels on

the screen. These pixels will have no impact on the performance of the product.

Avoid operating the TV at temperatures below 5°C(41°F)

A still image displayed too long may cause permanent damage to the PDP Panel.

Watching the PDP TV in 4:3 format for a long period of time may leave

traces of borders displayed on the left, right and center of the screen caused

by the difference of light emission on the screen.

Playing a DVD or a game console may cause similar effect to the screen.

Damages caused by the above effect are not covered by the Warranty.

Afterimage on the Screen.

Displaying still images from Video games and PC for longer than a certain period of time may

produce partial afterimages.

To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images for a

long time.

Warranty

Warranty does not cover any damage caused by image retention.

Burn-in is not covered by the warranty.

Installation

Be sure to contact an authorized service center when installing your set in a location with heavy

dust, high or low temperatures, high humidity, and chemical substances, or where it will be

operated for 24 hours continuously such as an airport, train station, etc.

Failure to do so may cause serious damage to your set. 3

BN68-00866C-00Eng(002~031) 8/4/05 6:17 PM Page 3

General Information

Your New Plasma Display Panel......................8

Remote Control Buttons ................................11

Wall Installation Instructions ..........................13

How to assemble the Stand-Base ..................17

Connections

Connecting VHF and UHF Antennas ..............20

Connecting Cable TV ..................................21

Connecting a VCR ......................................23

Connecting a Camcorder ............................24

Connecting a DVD Player (480i, 480p) ........25

Connecting a DTV Receiver (480p, 720p,

1080i) ......................................................26

Connecting to HDMI (High Definition

Multimedia Interface) (480p, 720p, 1080i) ..27

Connecting a Digital TV Set-Top Box (480p,

720p, 1080i) ............................................28

Connecting to an Analog Amplifier ..............29

Operation

Turning the TV On and Off ..........................32

Plug & Play Feature ....................................34

Memorizing the Channels ............................37

Adding and Erasing Channels ......................39

Viewing an External Signal Source................41

Picture Control

Changing the Picture Standard ....................44

Customizing the Picture Settings ....................45

Viewing the DNIe Demonstration ..................47

Changing the Screen Size ............................48

Viewing the Picture-in-Picture.........................50

Setting the My Color Control Mode ...............56

Sound Control

Customizing the Sound ..............................62

Using Automatic Sound Settings ...................63

Setting the TruSurround XT............................64

Choosing a Multi-Channel Sound (MTS) track ..65

Using the Auto Volume ................................66

Setting the On/Off Melody ..........................67

Selecting the Internal Mute ..........................68

Channel Control

Fine Tuning Analog Channels ......................70

LNA (Low Noise Amplifier) ..........................71

Connecting a PC and Operation

Connecting a PC ........................................74

Changing the Position of the Image ..............78

Picture Quality Adjustment............................79

Image Reset ................................................82

Table of Contents

BN68-00866C-00Eng(002~031) 8/4/05 6:17 PM Page 4

Time Setting

Setting the Clock ........................................84

Setting the Sleep Timer ................................85

Setting the On/Off Timer..............................86

Function Description

Selecting a Menu Language ........................88

Digital Noise Reduction................................89

Setting the Blue Screen ................................90

Using the Color Weakness Enhancement

Option ......................................................91

Viewing Closed Captions ............................92

Using the Energy Saving Feature ..................93

Preventing Screen Burn-in ............................94

Reducing the Effects of Screen Burn ..............95

Using the V-Chip (for USA) ..........................96

Using the V-Chip (for Canada) ....................102

Appendix

Troubleshooting ........................................112

Care and Maintenance ..............................113

Specifications............................................114

Note

•The information contained in this Owner’s

Instructions is subject to change without prior

notice for improvement, and may vary

depending on the version of the TV’s software

and the regional conditions.

BN68-00866C-00Eng(002~031) 8/4/05 6:17 PM Page 5

BN68-00866C-00Eng(002~031) 8/4/05 6:17 PM Page 6

PLASMA DISPLAY PANEL

General Information

Your New Plasma Display Panel ......................................................8

Remote Control Buttons ................................................................11

Wall Installation Instructions ..........................................................13

How to assemble the Stand-Base....................................................17

BN68-00866C-00Eng(002~031) 8/4/05 6:17 PM Page 7

Your New Plasma Display Panel

Front Panel

ŒSOURCE button

Press to display all of the available video

sources (TV, AV, S-Video, Component1,

Component2, PC, and HDMI).

´MENU button

Displays the main on-screen menu.

ˇVOL +,

buttons

Press to increase or decrease the volume.

Also used to select or adjust items on the

on-screen menu.

¨CH( , ) buttons

Press CH or CH to change channels.

Also used to move up or down in the on-screen

menu.

ˆ(Enter) button

Press to confirm a selection.

ØPower button

Press to turn the TV on and off.

Power indicator

- Power Off : Blue

- Power On : Off

∏Remote Control Sensor

Aim the remote control towards this spot on

the TV.

”

Speakers

∏”Ø

BN68-00866C-00Eng(002~031) 8/4/05 6:17 PM Page 8

Checking Accessories

Power Cord Cloth-CleanWarranty Card/

Registration Card/

Safety Guide Manual

(Not available in all locations)

Owner’s Instructions Remote Control/

AAA Batteries

The following parts are sold separately and are available at most electronics stores.

Once you have unpacked your TV, check to make sure that you have all the parts shown here.

If any piece is missing or broken, call your dealer.

Antenna Cable

Component Cables (RCA)

HDMI/DVI cable

S-VIDEO Cable HDMI Cable

PC Cable PC Audio Cable

BN68-00866C-00Eng(002~031) 8/4/05 6:17 PM Page 9

Rear Panel

ŒPOWER IN

Connect the supplied power cord.

´SERVICE ONLY

Connector for service only.

ˇHDMI/DVI IN

Connect to the HDMI jack of a device with

HDMI output.

These inputs can also be used as a DVI

connection with separate analog audio inputs.

An optional HDMI/DVI cable will be

necessary to make this connection.

When using the optional HDMI/DVI adapter,

the DVI analog audio inputs on your TV allow

you to receive left and right audio from your

DVI device. (Not compatible with PC)

¨DVI AUDIO IN (AUDIO-L/R)

Connect to the DVI audio output jack of an

external device.

ˆPC IN

Connect to the video output jack on your PC.

ØPC AUDIO IN

Connect to the audio output jack on your PC.

∏COMPONENT IN 1, 2

Video (Y/PB/PR) and audio (L-AUDIO-R)

component inputs.

”ANT IN

75ΩCoaxial connector for Antenna/Cable

Network.

’AV OUT (VIDEO / AUDIO L/R)

Outputs for external devices.

˝AV IN (VIDEO / AUDIO L/R)

Video and audio inputs for external devices,

such as a camcorder or VCR.

ÔS-VIDEO

Video input for external devices with an

S-Video output, such as a camcorder or VCR.

Notes

•Please be sure to match the color coded input terminals and cable jacks.

•For further details about connections, refer to pages 20-29.

•Whenever you connect an audio or video system to your television, ensure that all elements are

switched off. Refer to the documentation supplied with your equipment for detailed connection

instructions and associated safety precautions.

BN68-00866C-00Eng(002~031) 8/4/05 6:17 PM Page 10

Table des matières

Autres manuels Samsung Moniteur

Samsung

Samsung SyncMaster S22A650D Manuel utilisateur

Samsung

Samsung SyncMaster 932BW PLUS Guide de l'utilisateur

Samsung

Samsung S55CG97 Series Manuel utilisateur

Samsung

Samsung SyncMaster S22A650D Manuel utilisateur

Samsung

Samsung SMT-3222 Manuel utilisateur

Samsung

Samsung SyncMaster P2070H Manuel utilisateur

Samsung

Samsung 932BW - SyncMaster - 19" LCD Monitor Manuel utilisateur

Samsung

Samsung S24C570HL Guide de l'utilisateur

Samsung

Samsung SyncMaster S22A650S Guide de l'utilisateur

Samsung

Samsung 971P - SyncMaster - 19" LCD Monitor Manuel utilisateur

Samsung

Samsung ViewFinity S32A700NWP Manuel utilisateur

Samsung

Samsung DM82D Manuel utilisateur

Samsung

Samsung DP15HS Manuel utilisateur

Samsung

Samsung SyncMaster C27A650X Manuel utilisateur

Samsung

Samsung 2232BW - SyncMaster - 22" LCD Monitor Manuel utilisateur

Samsung

Samsung 720N - SyncMaster - 17" LCD Monitor Manuel utilisateur

Samsung

Samsung SyncMaster 245B, 245BW Manuel utilisateur

Samsung

Samsung S22C650P Manuel utilisateur

Samsung

Samsung SyncMaster 400TXn Manuel utilisateur

Samsung

Samsung Flip WM55R Manuel utilisateur

Samsung

Samsung S24F354FH Manuel utilisateur

Samsung

Samsung SyncMaster 320MX-3 Manuel utilisateur

Samsung

Samsung SyncMaster 933SN Guide de l'utilisateur

Samsung

Samsung C H71 Series Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
