Samsung NC221-TS Manuel utilisateur

User manual

NC221

NC221-S

NC221-TS

NC221-TW

NC221W

NC241

NC241-TS

NC241-TW

NC241W

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00099F-03

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

7 Copyright

7 Icons used in this manual

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

10 Safety Precautions

10 Symbols

11 Electricity and Safety

12 Installation and Safety

14 Operation and Safety

17 Correct posture to use the product

PREPARATIONS 18 Checking the Contents

18 Checking the Components

19 Parts

19 Frontal Buttons

21 Reverse Side

22 Installation

22 Attaching the cradle

23 Adjusting the Product Tilt and Height

23 Rotating the Monitor

24 Installing a Wall-mount Kit or Desktop Stand

26 Anti-theft Lock

USING "PCOIP" 27 What is a "PC over IP"?

28 Connection to Use "PCoIP"

28 LAN Connection

28 Connecting USB Devices

29 Connecting a Microphone

29 Connecting to Headphones or Speakers

30 Connecting to a Secondary Monitor

30 Connecting the Power

Table Of Contents

Table Of Contents 3

31 Connect to the host PC using a LAN

cable

32 "PCoIP"

32 On Screen Display (OSD)

32 Connect Screen

33 OSD Options Menu

34 Configuration Window

49 Diagnostics Window

53 Information Window

55 User Settings Window

62 Password Window

64 Wake On LAN

65 Wake on USB

66 OSD Logo Upload

67 Firmwre Update

CONNECTING AND USING

A SOURCE DEVICE

68 Before Connecting

68 Pre-connection Checkpoints

69 Connecting and Using a PC

69 Connecting to a PC

70 "Windows Driver" Installation

71 Setting Optimum Resolution

SCREEN SETUP 72 Brightness

72 Configuring Brightness

73 Contrast

73 Configuring Contrast

74 Sharpness

74 Configuring Sharpness

75 SAMSUNG MAGIC Bright

75 Configuring SAMSUNG MAGIC Bright

76 Coarse

76 Adjusting Coarse

Table Of Contents

Table Of Contents 4

77 Fine

77 Adjusting Fine

CONFIGURING TINT 78 SAMSUNG MAGIC Color

78 Configuring SAMSUNG MAGIC Color

79 Red

79 Configuring Red

80 Green

80 Configuring Green

81 Blue

81 Configuring Blue

82 Color Tone

82 Configuring the Color Tone Settings

83 Gamma

83 Configuring Gamma

RESIZING OR

RELOCATING THE

SCREEN

84 H-Position & V-Position

84 Configuring H-Position & V-Position

85 Menu H-Position & Menu V-Position

85 Configuring Menu H-Position & Menu V-

Position

SETUP AND RESET 86 Reset

86 Initializing Settings (Reset)

87 Language

87 Changing the Language

88 Display Time

88 Configuring Display Time

89 Menu Transparency

89 Changing Menu Transparency

Table Of Contents

Table Of Contents 5

90 Power Key

90 Enabling Power Key

INFORMATION MENU AND

OTHERS

91 INFORMATION

91 Displaying INFORMATION

91 Configuring Volume in the Initial Screen

INSTALLING THE

SOFTWARE

92 Natural Color

92 What is Natural Color?

93 MultiScreen

93 Installing the Software

94 Removing the Software

TROUBLESHOOTING

GUIDE

95 Requirements Before Contacting

Samsung Customer Service Center

95 Testing the Product

95 Checking the Resolution and Frequency

95 Check the following.

98 Q & A

SPECIFICATIONS 100 General

102 Standard Signal Mode Table

APPENDIX 104 Contact SAMSUNG WORLD WIDE

110 Responsibility for the Pay Service (Cost

to Customers)

110 Not a product defect

110 A Product damage caused by customer's fault

110 Others

111 Correct Disposal

111 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

111 Correct disposal of batteries in this product

Table Of Contents

Table Of Contents 6

112 Terminology

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair centre and there is no defect in the product

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is

carried out.

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center (page 104) if the inside of the monitor needs

cleaning. (Service fee will be charged.)

10 cm (3.9 Inches)

10 cm

(3.9 Inches)

10 cm

(3.9 Inches)

Before Using the Product

Safety Precautions

Symbols

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR

BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO

QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside. It is dangerous to

make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and

maintenance has been included with this product.

Warning A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.
