SAMSUNG Confidential

MODEL

LSC460HJ03

Doc. No

Page

1 / 42

SAMSUNG TFT-LCD

MODEL: LSC460HJ03

(LCD Panel + Driver Ass’y Kit)

The Information described in this specification is for the first draft and can be changed without prior notice

Customer:

DATE: 23.Nov.2012

Samsung Display Co., LTD

SAMSUNG Confidential

MODEL

LSC460HJ03

Doc. No

Page

2 / 42

Contents

Revision History ……………………………………………………………………………………………….(3)

General Description ……………………………………………………………………………………………(4)

General Information ……………………………………………………………………………………………(4)

1. Absolute Maximum Ratings ……………………………………………………………………………….(5)

2. Optical Characteristics ……………………………………………………………………….....................(6)

3. Electrical Characteristics …………………………………………………………………………………….(11)

3.1 TFT LCD Module

4. Block Diagram ………………………………………………………………………………………………(12)

5. Input Terminal Pin Assignment …………………………………………………………………………….(13)

5.1 Input Signal & Power

5.2 LVDS Interface

5.3 Input Signals, Basic Display Colors and Gray Scale of Each Color

6. Interface ………………………………………………………………………………………………………..(19)

6.1 Timing Parameters (DE only mode)

6.2 Characteristics of LVDS Input data

6.3 Timing Diagrams of interface Signal (DE only mode)

6.4 Power ON/OFF Sequence

7. Outline Dimension ………………………………………………………………….…………………….…..(23)

7.1 The adhesive size of POL

7.2 The drawing sheet for the size of the OLB bonding

7.4 Cross Section of cell

7.5 Source PCB

7.6 FFC cable

7.7 Control PCB

8. Reliability Test ………………………………………………………………………….…………………..…(24)

9. General Precaution ………………………………………………………………………………..….…..….(25)

9.1 Handling

9.2 Storage

9.3 Operation

9.4 Guide for the Operation Condition

9.5 Others

10. Special Precautions………………………………………………………………………………….……...(29)

11. Example ……………………………………………………………………………………………….……..(30)

Appendix1 ……………………………………………………………………………………………….…….(31)

Appendix2 ……………………………………………………………………………………………….…….(35)

SAMSUNG Confidential

MODEL

LSC460HJ03

Doc. No

Page

3 / 42

Date

Rev. No

Page

Summary

23. Nov. 2012

000

all

First Issue (First Draft)

The revision history

SAMSUNG Confidential

MODEL

LSC460HJ03

Doc. No

Page

4 / 42

General Description

Description

This model uses a liquid crystal display (LCD) of amorphous silicon TFT as switching components. This

model is composed of a TFT LCD panel, a driver circuit, and an ass’y KIT of source PBA. This 46.0”

model has a resolution of a 1920 x 1080 and can display up to 16.7 million colors with the wide viewing

angle of 89° or a higher degree in all directions. This panel is designed to support applications by

providing a excellent performance function of the flat panel display such as home-alone multimedia TFT-

LCD TV and a high definition TV.

General Information

Features

RoHS compliance (Pb-free)

High contrast ratio & aperture ratio with the wide color gamut

SVA(Super Vertical align) mode

Wide viewing angle (±178°)

High speed response

FHD resolution (16:9)

Low power consumption

DE (Data enable) mode

The interface (2pixel/clock) of 2ch LVDS (Low voltage differential signaling)

Items

Specification

Unit

Note

Active Display Area 1018.08(H) x 572.67(V) ㎜

Switching Components

a-Si TFT Active matrix

Glass Size

TFT : 1036.08(H) x 591.4(V)

CF : 1030.88(H) x 588.7(V) mm ±0.4mm

Panel Size

1036.08(H) x 591.4(V) mm ±0.4mm

1.80(D) mm ±0.1mm

Weight 2,500 g

Display Colors 16.7M (True Display)

1.07B (Dithered 10bit) color

Number of Pixels 1,920 × 1,080 pixel 16 : 9

Pixel Arrangement RGB Vertical Stripe

Display Mode Normally Black

Surface Treatment AG POL(Anti Glare),

Haze

2.3 %

± 2.1%

Hardness

SAMSUNG Confidential

MODEL

LSC460HJ03

Doc. No

Page

5 / 42

1. Absolute Maximum Ratings

If the figures on measuring instruments exceed maximum ratings, it can cause the malfunction or the

unrecoverable damage on the device.

Item

Symbol

Min.

Max.

Unit

Note

Power supply voltage

VDD

10.8

13.2

(1)

Temperature for storage TSTG -20 65 ℃

(2),(4)

Temperature of glass surface TOPR2 0 65 ℃(2)

Operating temperature

TOPR 0 50 ℃

(2),(5)

Humidity for storage

HSTG

%RH

(2),(4)

Operating humidity

HSTG

%RG

(2),(5)

Endurance on static electricity

150 V (3)

Note (1) The power supply voltage at Ta= 25 ± 2 °C

(2) Temperature and the range of relative humidity are shown in the figure below.

a. 95 % RH Max. (Ta ≤ 39 °C)

b. The relative humidity is 90% or less. (Ta ＞39 °C)

c. No condensation

d. Operating condition with SET

(3) Keep the static electricity under 150V in Polarizer attaching process.

(4) Operating condition with source PCB

(5) Storage temperature condition including glass

(6) Condition without packing. (Unpacking condition)

SAMSUNG Confidential

MODEL

LSC460HJ03

Doc. No

Page

6 / 42

2. Optical characteristics

The optical characteristics should be measured in the dark room or the space surrounded by the similar

setting.

Measuring equipment : TOPCON RD-80S, TOPCON SR-3 ,ELDIM EZ-Contrast

(Ta = 25 ± 2°C, VDD=12.0V, fv=60Hz, fDCLK=148.5MHz, Light source: D65 Standard light)

Item

Symbol

Condition

Min.

Typ.

Max.

Unit

Light Source

Note

Contrast ratio

(At the center of screen) C/R - 5,000 - Standard

(1)

SR-3

Response

time

G-to-G Tg TPAN,SUR

=29.9℃ - 6.0 15.0 msec

Standard

VD BLU

(3)

RD-80S

Luminance of white

(At the center of screen) YL

Normal

qL,R=0

qU,D=0

Viewing

Angle

TBD TBD - cd/m2VD BLU

(4)

SR-3

Chromaticity

(CIE 1931)

Red

TYP.

-0.03

0.640

TYP.

+0.03

VD BLU (5),(6)

SR-3

0.330

Green

0.300

0.600

Blue

0.150

0.060

White

0.280

0.290

sRGB Concordance

(5)

SR-3

Color gamut

VD BLU

Color

7,000

10,000

Viewing

Angle

Hor.

C/R≥10

75 89 -

Degree

Standard

VD BLU

(6)

SR-3

EZ-Contrast

qR75 89 -

Ver.

qU75 89 -

qD75 89 -

Brightness uniformity

(9 Points) Buni TBD

Transmissivity T 5.25 5.65 - % Standard

(7)

D65/SR3

Transmissivity Uniformity Tuni

- - 10 % Standard

(8)

D65/SR3

Gamma Value GMA 2.0 2.2 2.4 Standard

VD BLU

(9)

SR-3

Gamma variation Gdiff (@20G~128G) -0.14 - 0.14

(11)

SR-3

ACC Linearity ACC_lin -0.015 0.0 0.015

Standard

VD BLU

(12)

SR-3

5nit Uniformity Buni_5nit -30 0.0 30 %

Standard

(38G/255G)

(10)

SR-3

White Color Coordinate

Uniformity

Wx uni

0.005

Standard (13)

SR-3

Wy uni

0.008

Notice

SAMSUNG Confidential

MODEL

LSC460HJ03

Doc. No

Page

7 / 42

(a) Setup for test equipment

The measurement should be executed in a stable, windless, and dark room for 40min and 60min after

operating the panel at the given temperature for stabilization of the standard light. (SDC uses the standard

luminance of the D65 media).

This measurement should be measured at the center of screen.

The environment condition: Ta = 25 ± 2 °C

(b) D65 media has the general light source.

The temperature of color is 6847K. The coordinate of color is Wx 0.313, Wy 0.329

The luminance of this product is 7217cd/㎡.

Photo detector

Field

SR-3

2°/1°

RD-80S

1°

[D65] is intended to represent average daylight and has a correlated color temperature of

approximately 6500 K. CIE standard illuminant D65 should be used in all colorimetric calculations

requiring representative daylight, unless there are specific reasons for using a different illuminant.

- Definition of the test point

Note (1) Definition of contrast ratio (C/R)

: The ratio of gray max (Gmax) & gray min (Gmin) at the center point ⑤of the panel

The measurement goes in D65 Standard light source

Gmax : The luminance with all white pixels

C R

max

min

SAMSUNG Confidential

MODEL

LSC460HJ03

Doc. No

Page

8 / 42

Gmin : The luminance with all black pixels

Note (2) Definition of the brightness uniformity of 9 points (Test pattern : The full white)

The measurement shall be executed with the standard light source of D65 .

Bmax : The maximum brightness

Bmin : The minimum brightness

Note (3) Definition of the response time : Sum of Tr, Tf

※G-to-G : Average response time between whole gray scale to whole gray scale.

The response time is the value that was measured after it was operated in Samsung's standard BLU for

one hour.( at room temperature)

Note (4) The definition of luminance of white: The luminance of white at the center point ⑤

The measurement shall be executed with the standard light source of D65.

Note (5) The definition of chromaticity (CIE 1931)

The color coordinate of red, green, blue and white at the center point ⑤

The measurement shall be executed with the standard light source of D65.

Note (6) Definition of viewing angle

: The range of viewing angle (C/R ≥10)

The measurement shall be executed with the standard light source of D65.

The response

Of optical instruments

Buni

B B

= ∗

−

100

(max min)

max

Display data

SAMSUNG Confidential

MODEL

LSC460HJ03

Doc. No

Page

9 / 42

Note (7) Definition of transmissivity

The measurement shall be executed with the standard light source of D65.

Note (8) Definition of the Transmissivity uniformity of 9 points (Test pattern: The full white)

The measurement shall be executed with the standard light source of D65.

Tmax : The maximum Transmissivity

Tmin : The minimum Transmissivity

Note (9) Management Criteria of Gamma Value

Note (10) 5nit Low Gray Uniformity

Tuni

= 100*

(𝑻𝒎𝒂𝒙−𝑻𝒎𝒊𝒏)

𝑻𝒎𝒂𝒙

Gamma Value

- 20 ~ 200Gray: 2.2 ±0.2

Buni_5nit

= 100*

(𝐵𝑚𝑎𝑥_5𝑛𝑖𝑡−𝐵𝑚𝑖𝑛_5𝑛𝑖𝑡)

𝐵𝑚𝑎𝑥_5𝑛𝑖 𝑡

Bmax_5nit : The maximum brightness at 5nit Gray

Bmin_5nit : The minimum brightness at 5nit Gray

Vertical 1/6 Point

[Panel Measure Point]

Vertical 1/6 Point

SAMSUNG Confidential

MODEL

LSC460HJ03

Doc. No

Page

10 / 42

Note (11) Gamma Variation between Center and Left (or Right)

Gamma measured at 10cm point from the left & right side is more less than 0.14 than Gamma

measured at Center

(Gamma measured at 10cm of the P-4 & P-6 is more less than 0.1 than Gamma measured at P-5)

Note (12) Management Criteria of ACC Linearity

Note (13) White Color Coordinate Uniformity of 9 points (Test pattern: The full white)

255Gray Wx/Wy value basis (a module unit basis)

a. Color coordinate differences are less than 15/1,000 at

Any Point above 30Gray and 255Gray

b. When Wx/Wy coordinates reverse at 0Gray, it permits

an once intersection under, 30Gray

Wx, uni

= Wx max-Wx min

Wx max : The maximum Wx

Wx min : The minimum Wx

Wy, uni

= Wy max-Wy min

Wy max: The maximum Wy

Wy min: The minimum Wy

Table des matières

Autres manuels Samsung Moniteur

Samsung

Samsung SyncMaster 940BW Manuel utilisateur

Samsung

Samsung SyncMaster S27A850D Manuel utilisateur

Samsung

Samsung SyncMaster Magic P2770H Guide de l'utilisateur

Samsung

Samsung SyncMaster BN59-00977A-00 Manuel utilisateur

Samsung

Samsung S A33 Series Manuel utilisateur

Samsung

Samsung SyncMaster 733N Manuel utilisateur

Samsung

Samsung F24T40 Series Manuel utilisateur

Samsung

Samsung SyncMaster 2343BW Manuel utilisateur

Samsung

Samsung SyncMaster 1100MB Manuel utilisateur

Samsung

Samsung SyncMaster 173P plus, 193P plus Guide de l'utilisateur

Samsung

Samsung SyncMaster 320TSn-3 Manuel utilisateur

Samsung

Samsung S27BM500EE Manuel utilisateur

Samsung

Samsung SyncMaster 2494LW Manuel utilisateur

Samsung

Samsung LH43PMFXTBC/EN Manuel utilisateur

Samsung

Samsung SyncMaster 171 T Manuel utilisateur

Samsung

Samsung HPN4235 Manuel utilisateur

Samsung

Samsung SyncMaster 400MX-2 Manuel utilisateur

Samsung

Samsung SyncMaster 2043NW Manuel utilisateur

Samsung

Samsung SyncMaster 153S, 173S, 193S, 174V, 175V Manuel utilisateur

Samsung

Samsung C H71 Series Manuel utilisateur

Samsung

Samsung 950B - SyncMaster 950 B Manuel utilisateur

Samsung

Samsung SyncMaster NC190 Manuel utilisateur

Samsung

Samsung Odyssey S49AG954NP Manuel utilisateur

Samsung

Samsung SAMTRON 94V Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
