Samsung MS9796 Manuel utilisateur

MICROWAVE OVEN

MS9796W/MS9796

Owner’s Instructions

and

Cooking Guide

Code No.: DE68-01723A

MS9796(GB1) 9/4/01 12:05 PM Page 1

SAMSUNG

Installing Your Microwave Oven

Place the oven on a flat, level surface strong enough to safely bear the weight

of the oven.

✽Never block the air vents as the oven may overheat and automatically switch itself off. It will

remain inoperable until it has cooled sufficiently.

✽For your personal safety, plug the cable into a 3-pin, 230 Volt, 50Hz, AC earthed socket. If

the power cable of this appliance is damaged, it must be replaced by a special cable.

Contact your local dealer to have it replaced.

✽Do not install the microwave oven in hot or damp surroundings like next to a traditional oven

or radiator. The power supply specifications of the oven must be respected and any

extension cable used must be of the same standard as the power cable supplied with the

oven. Wipe the interior and the door seal with a damp cloth before using your microwave

oven for the first time.

1When you install your oven, Make sure there is adequate

ventilation for your oven by leaving at least 10 cm (4 inches) of

space behind, on the sides of the oven and 20 cm (8 inches) of

above.

20 cm

above 10 cm

behind

10 cm

of the side

2Remove all packing materials inside the oven.

Install the roller guide and turntable.

Check that the turntable rotates freely.

Setting the Time

Your microwave oven has an inbuilt clock. The time can be displayed in either

the 24-hour or 12-hour notation. You must set the clock:

◆When you first install your microwave oven

◆After a power failure

➢Do not forget to reset the clock when you switch to and from summer and

winter time.

1 To display the time in the... Then press the button...

24-hour notation Once

12-hour notation Twice

3When the right time is displayed, press the button again to start

the clock.

Result: The time is displayed whenever you are not using the

microwave oven.

Set the hour with the hbutton and the minutes with the

min button.

MS9796(GB1) 9/4/01 12:05 PM Page 10

SAMSUNG

Technical Specification

SAMSUNG strives to improve its products at all times. Both the design specifi-

cations and these user instructions are thus subject to change without notice.

Model MS9796W / MS9796

Power source 230V ~ 50 Hz

Power consumption

Microwave 1500 W

Output power 100 W / 1000 W (IEC-705)

Operating frequency 2450 MHz

Magnetron OM75P(31)

Cooling method Cooling fan motor

Dimensions (W x H x D)

Outside 601 x 338 x 460 mm

Oven cavity 441 x 276 x 451 mm

Volume 55 liter

Weight

Net 21 kg approx

MS9796(GB2) 9/4/01 12:04 PM Page 35
