Samsung SyncMaster T23A750 Manuel utilisateur
LED TV MONITOR
user manual
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
(MFM TV)
imagine the possibilities
TA750
TA950
2
English
Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance.
Product design and specifications may be changed without notice.
Digital TV notice
1. Functionalities related to Digital TV (DVB) are only available in countries/areas where DVB-T (MPEG2 and MPEG4 AVC) digital terrestrial signals are
broadcasted or where you are able to access to a compatible DVB-C (MPEG2 and MPEG4 AAC) cable-TV service. Please check with your local
dealer the possibility to receive DVB-T or DVB-C signal.
2. DVB-T is the DVB European consortium standard for the broadcast transmission of digital terrestrial television and DVB-C is that for the broadcast
transmission of digital TV over cable.
3. Although this TV set meets the latest DVB-T and DVB-C standards, as of [August, 2008], the compatibility with future DVB-T digital terrestrial and
DVB-C digital cable broadcasts cannot be guaranteed.
4. Depending on the countries/areas where this TV set is used some cable-TV providers may charge an additional fee for such a service and you may
be required to agree to terms and conditions of their business.
5. Some Digital TV functions might be unavailable in some countries or regions and DVB-C might not work correctly with some cable service providers.
6. For more information, please contact your local Samsung customer care centre.
✎
The reception quality of TV may be affected due to differences in broadcasting method between the countries. Please check the TV
performance in the local SAMSUNG Authorized Dealer, or the Samsung Call Centre whether it can be improved by reconfiguring TV setting or
not.
Still image warning
Avoid displaying still images (like jpeg picture files) or still image element (like TV programme logo, panorama or 4:3 image format, stock or news bar at
screen bottom etc.) on the screen. Constant displaying of still picture can cause ghosting of screen, which will affect image quality. To reduce risk of this
effect, please follow below recommendations:
• Avoid displaying the same TV channel for long periods.
• Always try do display any image on full screen, use TV set picture format menu for best possible match.
• Reduce brightness and contrast values to minimum required to achieve desired picture quality, exceeded values may speed up the burnout process.
• Frequently use all TV features designed to reduce image retention and screen burnout, refer to proper user manual section for details.
Securing the Installation Space
Keep the required distances between the product and other objects (e.g. walls) to ensure proper ventilation.
Failing to do so may result in fire or a problem with the product due to an increase in the internal temperature.
Install the product so the required distances shown in the figure are kept.
✎
The appearance may differ depending on the product.
• An administration fee may be charged if either
– (a) an engineer is called out at your request and there is no defect in the product
(i.e. where you have failed to read this user manual).
– (b) you bring the unit to a repair centre and there is no defect in the product
(i.e. where you have failed to read this user manual).
• The amount of such administration charge will be advised to you before any work or home visit is carried out.
10 cm
10 cm
10 cm
3
Contents
ENGLISH
English
Check the Symbol!
This function can be used by
pressing the TOOLS button on the
remote control.
Note Step by Step Guide
TOOLS
Contents
Other Information
68
68 Analogue Channel Teletext Feature
69 Assembling the Cables
69 Anti-theft Kensington Lock
70 Troubleshooting
75 Specifications
76 Index
Advanced Features
47
47 Getting Started with Smart Hub
52 Using the Smart Hub
63 About AllShare™
64 Anynet+
Basic Features
24
24 How to Navigate Menus
24 Using the INFO button (Now & Next guide)
24 Using the Channel Menu
27 Channel Menu
29 Picture Menu
35 Sound Menu
37 Network Menu
41 System Menu
45 Support Menu
Connections
14
14 Connecting to an Antenna
14 Plug & Play (Initial Setup)
15 Connecting to an AV Device
17 Connecting to a COMMON INTERFACE slot
18 Connecting to an Audio Device
19 Connecting to a PC
21 Changing the Input Source
22 Network Connection
Getting Started
4
4 Safety Precautions
11 Accessories
12 Viewing the Control Panel
13 Viewing the Remote Control
4
Getting Started
English
Safety Precautions
Icons used for safety precautions
WARNING Failing to follow the precautions marked with this sign may result in a serious injury or
even a fatality.
CAUTION Failing to follow the precautions marked with this sign may result in a personal injury or
property damage.
Do not perform.
Must be followed.
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE.
REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage is
present inside. It is dangerous to make any kind
of contact with any internal part of this product.
This symbol alerts you that important literature
concerning operation and maintenance has
been included with this product.
Power Related
✎
The following images are for your reference and may differ depending on models and countries.
Warning
Avoid using a damaged power cord or
plug or a loose power outlet.
yOtherwise, it may result in electric
shock or fire.
Avoid connecting multiple electric
appliances to a single wall outlet.
yOtherwise, it may result in fire due
to overheating of the wall outlet.
Avoid plugging in or unplugging the
power supply with wet hands.
yOtherwise, it may result in electric
shock.
!
Plug the power plug in firmly.
yOtherwise, it may result in fire.
!
Make sure to connect the power cord
to a grounded wall outlet (for insulation
class 1 equipment only).
yOtherwise, it may result in electric
shock or injury.
Avoid bending or twisting the power
cord excessively and avoid placing
heavy objects on the cord.
yOtherwise, it may result in electric
shock or fire due to a damaged
power cord.
Getting Started
5
Getting Started
English
Keep the power cord and the product
away from a heater.
yOtherwise, it may result in electric
shock or fire.
!
If the pins of the power plug or the
wall outlet are covered in dust, clean it
using a dry cloth.
yOtherwise, it may result in fire.
Caution
Avoid unplugging the power plug while
the product is operating.
yOtherwise, it may damage the
product due to electric shock.
!
Make sure to use only the power cord
supplied by our company. In addition,
do not use the power cord of another
electric appliance.
yOtherwise, it may result in electric
shock or fire.
!
When unplugging the power plug from
the wall outlet, make sure to hold it by
the plug and not by the cord.
yOtherwise, it may result in electric
shock or fire.
!
Connect the power plug to a wall outlet
that can be easily reached.
yWhen a problem occurs with the
product, you must unplug the
power plug to cut the power off
completely. You cannot cut the
power off completely using only
the power button on the product.
Installation Related
Warning
Avoid placing burning candles,
mosquitorepellentor cigarettes on the
product.
yOtherwise, it may result in fire.
!
Ask an installation engineer or relevant
company to install the product onto
the wall.
yOtherwise, it may result in injury.
yMake sure to use the specified
wall mount.
Avoid installing the product in a badly-
ventilated location such as inside a
bookshelf or closet.
yOtherwise, it may result in fire due
to internal over-heating.
!
Keep the plastic bags used to pack
the product away from children.
yIf children place the plastic
bags over their heads, they may
suffocate.
Avoid installing the product in a
location that is unstable or exposed
to excessive vibration such as on an
unstable or slanted shelf.
yThe product may fall and this may
result in damage to the product or
injury.
yIf you use the product in a location
exposed to excessive vibrations,
it may result in a problem with the
product or fire.
!
Avoid installing the product in a
location exposed to dust, moisture
(sauna), oil, smoke or water (rain
drops) and installing it within a vehicle.
yThis may result in electric shock
or fire.
6
Getting Started
English
Avoid installing the product in a location
exposed to direct sunlight and installing
the product near a heat source such as
a fireplace or heater.
yThis may shorten the product life
cycle or cause fire.
Avoid installing the product where
children may reach it.
yIf a child touches the product,
the product may fall and this may
result in injury.
ySince the front part is heavier,
install the product on a flat and
stable surface.
!
Bend the outdoor antenna cable
downwards at the location where it
comes in the house so that rainwater
does not flow in.
yIf rainwater enters the product, it
may result in electric shock or fire.
!
Install the antenna far away from any
high voltage cables.
yIf the antenna touches or falls onto
a high voltage cable, it may result
in electric shock or fire.
Caution
!
Do not let the product drop while
moving it.
yThis may result in a problem with
the product or injury.
Do not place the product face down
on the floor.
yThis may damage the panel of the
product.
When installing the product on a
console or shelf, make sure that the
front of the product does not protrude
out of the console or shelf.
yOtherwise, this may cause the
product to fall off and result in a
malfunction or injury.
yMake sure to use a cabinet or shelf
suitable to the size of the product.
!
When putting the product down,
handle it gently.
yOtherwise, it may result in a
problem with the product or injury.
SAMSUNG
!
If the product is installed in a location
where the operating conditions vary
considerably, a serious quality problem
may occur due to the surrounding
environment. In this case, install the
product only after consulting one of our
service engineers about the matter.
yPlaces exposed to microscopic
dust, chemicals, too high or low
temperature, high humidity, airports
or stations where the product is
continuously used.
7
Getting Started
English
Cleaning Related
Warning
!
Before cleaning the product, unplug
the power cord.
yOtherwise, it may result in
electric shock or fire.
When cleaning the product, do not
spray water directly over the product
parts.
yMake sure that water does not
enter the product.
yOtherwise, it may result in fire,
electric shock or a problem with
the product.
Caution
Avoid spraying cleansing agent
directly onto the product.
yThis may result in discoloration
or cracking of the exterior of the
product or the panel coming off.
!
When cleaning the product, disconnect
the power cord and clean the product
with the supplied cleaning cloth.
yAvoid using chemicals such as
wax, benzene, alcohol, thinner,
mosquito-repellent, fragrance,
lubrication or cleansing agent when
cleaning the product.
This may result in the exterior
being deformed or the print being
removed.
!
If you can't get the product clean
with just the supplied cloth, use a
soft, damp cloth with a "monitor-
exclusive cleansing agent" and wipe
the product with it.
yIf no monitor-exclusive cleansing
agent is available, dilute a
cleansing agent with water at a
ratio of 1:10 before cleaning the
product.
!
Since the exterior of the product is
easily scratched, be sure to use the
supplied cleansing cloth.
Usage Related
Warning
Since a high voltage runs through the
product, never disassemble, repair or
modify the product yourself.
yOtherwise, it may result in fire or
electric shock.
yIf the product needs to be fixed,
contact a service centre.
!
To move the product, turn the power
off and unplug the power cord, the
antenna cable and any other wires
connected to the product.
yOtherwise, it may result in
electric shock or fire due to the
damaged power cord.
8
Getting Started
English
!
If the product generates a strange
noise, a burning smell, or smoke,
unplug the power plug immediately and
contact a service centre.
yOtherwise, it may result in electric
shock or fire.
Avoid letting children hang or climb
onto the product.
yOtherwise, it may result in the
product falling and this may
result in injury or death.
If you drop the product or the case
is damaged, turn the power off and
unplug the power cord. Contact a
service centre.
yOtherwise, it may result in fire or
electric shock.
Avoid placing objects such as toys
and cookies on top of the product.
yIf a child hangs over the product
to grab an object, the object
or the product may fall and
this may result in injury or even
death.
!
When thunder or lighting occurs,
unplug the power cord and under no
circumstance touch the antenna cable
as this is dangerous.
yOtherwise, it may result in electric
shock or fire.
!
Avoid dropping an object over the
product or cause impact to the
product.
yOtherwise, it may result in
electric shock or fire.
Avoid moving the product by pulling the
power cord or antenna cable.
yOtherwise, it may result in electric
shock, fire or a problem with the
product due to damage to the
cable.
!
GAS
When a gas leak occurs, do not
touch the product or the power plug
and ventilate immediately.
yA spark may result in an
explosion or fire.
yDuring a thunder or lighting
storm, do not touch the power
cord or antenna cable.
Avoid lifting up or moving the product
by holding only the power cord or
signal cable.
yOtherwise, it may result in electric
shock, fire or a problem with the
product due to damage to the
cable.
!
Avoid using or placing inflammable
spray or objects near the product.
yThis may result in an explosion
or fire.
Take care not to block the vent by a
table cloth or curtain.
yOtherwise, it may result in fire due
to internal overheating.
100
Avoid inserting metal objects such
as a chopsticks, coins or hairpins, or
inflammable objects into the product
(the vents, ports, etc).
yIf water or substances enters
the product, turn the power
off, unplug the power cord and
contact a service centre.
yOtherwise, it may result in a
problem with the product,
electric shock or fire.
9
Getting Started
English
Avoid placing a liquid container such as
a vase, flowerpot, beverage, cosmetics
or drugs, or a metal object over the
product.
yIf water or substances enter the
product, turn the power off, unplug
the power cord and contact a
service centre.
yOtherwise, it may result in a
problem with the product, electric
shock or fire.
Do not press down hard on the
product. The product may become
deformed or damaged.
Caution
!
Displaying a still image for a long time
may create a persistent image or stain
on the screen.
yIf you do not use the product for
a long time, use the power-saving
mode or set the screensaver to the
moving picture mode.
-_-
!
When not using the product for
a long time such as leaving your
home, unplug the power cord from
the wall outlet.
yOtherwise, it may cause dust
accumulation and result in fire
caused by overheating or short
circuit or result in an electric
shock.
!
Set the appropriate resolution and
frequency for the product.
yOtherwise, it may result in eye
strain.
Avoid turning the product upside
down or move the product holding
only the stand.
yThis may cause the product to
fall, resulting in damage to the
product or injury.
Do not place the adapter on top of
another adapter.
yOtherwise, it may result in fire.
Keep power adaptor away from any
other heat source.
yOtherwise, it may result in fire.
Remove the vinyl cover of the adapter
before using the adaptor.
yOtherwise, it may result in fire.
Always keep power adaptor in well-
ventilated area.
Be careful that adaptor should not be
in contact with water and therefore not
be wet.
yThis may cause a malfunction,
electric shock or fire. Do not
use adaptor by the waterside or
outside particularly when it rains
or snows. Be careful that adaptor
should not be wet while cleaning
floor with water.
!
Watching the product from too
close a distance continuously may
damage your eyesight.
10
Getting Started
English
Avoid using a humidifier or cooker near
the product.
yOtherwise, it may result in electric
shock or fire.
!
It is important to give your eyes
some rest (5 minutes every hour)
when viewing the product screen for
long periods of time.
yThis will alleviate any eye strain.
Since the display panel is hot after
using it for a long time, do not touch
the product.
!
Keep the small accessories in a
location out of the reach of children.
!
Take care when adjusting the angle of
the product or the height of the stand.
yIf your hand or finger is caught, you
may be injured.
yIf the product is tilted excessively,
the product may fall and this may
result in injury.
Avoid placing a heavy object over
the product.
yOtherwise, it may result in a
problem with the product or
injury.
When using headphones or earphones,
do not turn the volume too high.
yHaving the sound too loud may
damage your hearing.
Be careful that children do not place
the batteries in their mouths when
removed from the remote control.
Place the battery in a location that
children or infants cannot reach.
yIf children have had the battery
in their mouths, consult your
doctor immediately.
!
When replacing the batteries, insert
them with right polarity (+, -).
yOtherwise, the battery may
become damaged or it may cause
fire, personal injury or damage due
to leakage of the internal liquid.
Use only specified standard
batteries. Do not use new and used
batteries together.
yThis may cause a battery to
break or leak and may cause
fire, injury, or contamination
(damage).
!
The batteries (and rechargeable
batteries) are not ordinary refuse
and must be returned for recycling
purposes. The customer is responsible
for returning the used or rechargeable
batteries for recycling.
yThe customer can return used or
rechargeable batteries to a nearby
public recycling centre or to a store
selling the same type of the battery
or rechargeable battery.
Autres manuels pour SyncMaster T23A750
1
Ce manuel convient aux modèles suivants
4
Table des matières
Autres manuels Samsung Téléviseur LED
Samsung
Samsung The Terrace LST7T Series Manuel utilisateur
Samsung
Samsung UN46C8000 Manuel utilisateur
Samsung
Samsung UE40ES8000U Manuel utilisateur
Samsung
Samsung UE43TU7070 Manuel utilisateur
Samsung
Samsung HG32EE590 Manuel utilisateur
Samsung
Samsung PDP 5500 Series Mode d’emploi
Samsung
Samsung UN65LS03NAFXZAOM Manuel utilisateur
Samsung
Samsung Q900R series Manuel utilisateur
Samsung
Samsung UN32EH4003 Manuel utilisateur
Samsung
Samsung QE85Q950TSUXCE Manuel utilisateur
Samsung
Samsung UN40FH6030 Manuel utilisateur
Samsung
Samsung UE22D5010 Manuel utilisateur
Samsung
Samsung UN65C6500VF Guide de l'utilisateur
Samsung
Samsung UE55J6200 Mode d’emploi
Samsung
Samsung HG32ED450SWXEN Manuel utilisateur
Samsung
Samsung LED 8000 series Manuel utilisateur
Samsung
Samsung 6030 SERIES Manuel utilisateur
Samsung
Samsung UE65KS9502 Manuel utilisateur
Samsung
Samsung UA40D6400 Manuel utilisateur
Samsung
Samsung Galaxy 8 Manuel utilisateur
