Samsung LN32A450C1 Manuel utilisateur

LCD TV

quick start guide

imagine the possibilities

Thank you for purchasing a Samsung product.

To receive a more complete service, please

www.samsung.com/global/register

Pearl550-SA-Eng-0320.indd 1 2008-04-07 �� 5:58:49

English - 1

Connect an HDMI Cable(Not supplied) between the HDMI IN (1, 2or 3) jack on the TV and the HDMI jack on the

Cable Box/Satellite receiver (Set-Top Box).

No additional Audio connection is needed for an HDMI to HDMI connection.

CABLE BOX/SATELLITE

RECEIVER (SET-TOP BOX)

REAR PANEL

TV REAR PANEL

TV SIDE PANEL

Connections

CONNECTINg A CABLE BOX/SATELLITE RECEIVER (SET-TOP BOX)

VIA HDMI

Caution

● When connecting an external device, match the colour of the connection terminal to the cable.

● The product colour and shape may vary depending on the model.

● Each Cable Box/Satellite receiver (Set-Top Box) has a different back panel conguration.

● Whenever you connect an external device to your TV, make sure that power on the unit is turned off.

CABLE BOX/SATELLITE

RECEIVER (SET-TOP BOX)

REAR PANEL

TV REAR PANEL

TV SIDE PANEL

Pearl550-SA-Eng-0320.indd 1 2008-04-07 �� 5:58:50

English - 2

CONNECTINg A CABLE BOX/SATELLITE RECEIVER (SET-TOP BOX)

VIA DVI

CABLE BOX/SATELLITE

RECEIVER(SET-TOP BOX)

REAR PANEL

TV REAR PANEL

Connect an HDMI Cable(Not supplied) between the HDMI IN 2 jack on the TV and the HDMI jack on the Cable

Box/Satellite receiver (Set-Top Box).

Connect Audio Cables(Not supplied) between the DVI IN (HDMI 2) [R-AUDIO-L] jack on the TV and the Cable

Box/Satellite receiver (Set-Top Box).

When using an HDMI/DVI cable(Not supplied) connection, you must use the HDMI IN2 jack.

CABLE BOX/SATELLITE

RECEIVER(SET-TOP BOX)

REAR PANEL

TV REAR PANEL

Pearl550-SA-Eng-0320.indd 2 2008-04-07 �� 5:58:50

English - 3

CONNECTINg A CABLE BOX/SATELLITE RECEIVER (SET-TOP BOX)

VIA COMPONENT CABLES

CABLE BOX/SATELLITE

RECEIVER (SET-TOP BOX)

REAR PANEL

Connect a Component Cable(Not supplied) between the COMPONENT IN (1 or 2) [Y, PB, PR ]jacks on the TV and

the COMPONENT jacks on the Cable Box/Satellite receiver (Set-Top Box).

Connect Audio Cables(Not supplied) between the COMPONENT IN (1 or 2) [R-AUDIO-L] jacks on the TV and the

AUDIO OUT jacks on the Cable Box/Satellite receiver (Set-Top Box).

TV REAR PANEL

CABLE BOX/SATELLITE

RECEIVER (SET-TOP BOX)

REAR PANEL

Pearl550-SA-Eng-0320.indd 3 2008-04-07 �� 5:58:51

English - 4

Memorizing the Channels

Your TV can memorize and store all of the available channels for both “off-air” (Air) and “Cable” channels. After the

available channels are memorized, use the CH or CH button to scan through the channels. This eliminates the

need to change channels by entering the channel digits. There are three steps for memorizing channels: selecting a

broadcast source, memorizing the channels (automatic) and adding or deleting channels (Channel Manager).

Selecting the Video Signal-source

Before your television can begin memorizing the available channels, you must

specify the type of signal source that is connected to the TV (i.e. an Air or a

Cable system).

Press the MENU button to display the menu.

Press the ▲ or ▼ button to select "Channel", then press the ENTER

button.

Press the ENTER button.

Repeatedly press the ▲ or ▼ button to cycle through these choices: “Air”, “STD”, “HRC”, or “IRC” (all cable TV)

Press the ENTER button to select.

STD, HRC and IRC identify various types of cable TV systems.

Contact your local cable company to identify the type of cable system that exists in your particular area.

At this point, the signal source has been selected

Storing Channels in Memory (Automatic Method)

First, select the correct signal source (Air, STD, HRC, or IRC).

Press the ▲ or ▼ button to select “Auto Program”, then press the ENTER

button.

Press the ENTER button to select “Start”.

The TV will begin memorizing all of the available channels.

The TV automatically cycles through all of the available channels and stores

them in memory. This takes about one to two minutes. Press the ENTER button at any time to interrupt the memorization

process and return to the “Channel” menu.

After all the available channels are stored, the “Channel” menu reappears. Press the EXIT button to exit.

To stop the search before it has nished, press the ENTER button with “Stop” selected.

Channel

Air / Cable :

Air



Auto Program 

Channel Manager 

Fine Tune 

Color System : Auto 

Move Enter Return

Channel

Air / Cable :

Air



Auto Program 

Channel Manager 

Fine Tune 

Color System : Auto 

Move Enter Return

Pearl550-SA-Eng-0320.indd 4 2008-04-07 �� 5:58:52

English - 5

Troubleshooting

My TV is out of order. Why? Try this.

TV HD is displayed, but

the visual quality is not

good.

• The visual quality may be degraded

when the broadcasting stations convert

the analog signal to digital. (Although

you are watching digital broadcasting,

the video source is analog.)

• Check the transmitting signal of the

corresponding cable TV network or

broadcasting station.

The picture on the

TV screen is broken

intermittently (a mosaic or

distorted).

• This may occur when the broadcast

signal received by the TV is too weak

or unstable.

• Check the transmitting signal of the

corresponding cable TV network or

broadcasting station.

• If you are using a publically shared

antenna, check the signal by asking

your apartment manager.

I cannot control the TV

using the remote control.

• When the battery is at.

• When it is not in TV mode.

• When the remote control malfunctions

temporarily.

• Replace the battery and then retry.

• Press the TV button on the remote

control to select TV mode.

A strange sound is

generated by the TV.

• Sound may be generated by the

temporary swelling and shrinking of the

plastics in the TV due to temperature

and humidity changes.

• Temporary electronic oscillation

sounds may be generated due to the

characteristics of the TV

• Some noise can be heard due to the

characteristics of the product.

Pearl550-SA-Eng-0320.indd 5 2008-04-07 �� 5:58:52

COUNTRY Customer Care Center

Web Site

ARgENTINE 0800-333-3733 www.samsung.com/ar

BRAZIL 0800-124-421

4004-0000 www.samsung.com

CHILE 800-SAMSUNg(726-7864) www.samsung.com/cl

COLOMBIA 01-8000112112 www.samsung.com.co

COSTA RICA 0-800-507-7267 www.samsung.com/latin

ECUADOR 1-800-10-7267 www.samsung.com/latin

EL SALVADOR 800-6225 www.samsung.com/latin

gUATEMALA 1-800-299-0013 www.samsung.com/latin

HONDURAS 800-7919267 -

JAMAICA 1-800-234-7267 www.samsung.com/latin

PANAMA 800-7267 www.samsung.com/latin

PUERTO RICO 1-800-682-3180 www.samsung.com/latin

REP. DOMINICA 1-800-751-2676 www.samsung.com/latin

NICARAgUA 00-1800-5077267 -

MEXICO 01-800-SAMSUNg(726-7864) www.samsung.com

TRINIDAD & TOBAgO 1-800-SAMSUNg(726-7864) www.samsung.com/latin

VENEZUELA 0-800-100-5303 www.samsung.com/latin

Contact SAMSUNG WORLDWIDE

If you have any questions or comments relating to Samsung products,

please contact the SAMSUNG customer care center.

IMPORTADO POR:

AV. PRESIDENTE MASARIK #111 INT701

COL. CHAPULTEPEC MORALES C.P.11570

DELEgACION MIgUEL HIDALgO MEXICO. DISTRITO FEDERAL

Tel: 01-55-5747-5100 / 01-800-726-7864

Pearl550-SA-Eng-0320.indd 6 2008-04-07 �� 5:58:52
