Samsung LE32N71B Manuel utilisateur

TFT-LCD TV

Chassis GNM32SEU

GNM40SEU

GNM46SEU

Model LE32N71B

LE40N71B

LE46N71B

Manual

SERVICE

TFT-LCD TV Fashion Feature

- Luxurious Slim Design

- Supreme Picture Quality

- Supreme Sound Quality

- Supreme Convenience Quality

- Convenience for Users

This manual may not, in whole or in part, be copied,

photocopied, reproduced, translated, or converted to

any electronic or machine readable form without prior

written permission of Samsung Electronics Co., Ltd.

LE32N71B/LE40N71B/LE46N71B Service Manual

First edition June 2006.

Printed in Korea.

Trademarks

Samsung is the registered trademark of Samsung

Electronics Co., Ltd.

LE32N71B/LE40N71B/LE46N71B and MacMaster

Cable Adapter are trademarks of Samsung Electronics

Co., Ltd.

Macintosh, Power Macintosh are trademarks of Apple

Computer, Inc.

All other trademarks are the property of their respective

owners.

Contents

Samsung Electronics Co.,Ltd.

416, Maetan-3Dong, Yeongtong-Gu, Suwon City,

Gyeonggi-Do, Korea, 443-742

Printed in Korea

P/N : BN82-00145F-00

URL : http://itself.sec.samsung.co.kr/

- This Service Manual is a property of

Samsung Electronics Co., Ltd.

Any unauthorized use of Manual can be

punished under applicable International

and/or domestic law.

2 Product Specifications

2-1

2 Product specifications

2-1 Fashion Feature

Wise link

- Accept 10 types of Memory Cards including USB (10 in 3 )

Excellent Compatibility. SD/MMC/CF/MD/MS/MSPRO/XD/SM

Wide Color Gamut

- More natural and vivid picture quality by UWCG (100%)

High Dynamic Contrast

- 6000:1 Highest dynamic Contrast Ratio

Best Off-Angle Viewing

- Widened Viewing Angle , 178 / 178 (Left/Right)

Game Mode

- Present the most suitable picture for gaming

Swivel Stand

- 20 / 20 (left/right)

2 Product Specifications

2-2

2-2 LE32N71BX Specifications

LCD Panel

TFT-LCD panel, RGB vertical stripe, normaly white, 32-Inch viewable, 0.511 (H) x 0.511 (V) mm pixel pitch

Scanning Frequency Horizontal : 30 kHz ~ 61 kHz (Automatic) / Vertical : 60 Hz ~ 75 Hz (Automatic)

Display Colors 16,777,216 colours

Maximum Resolution Horizontal : 1366 Pixels

Vertical : 768 Pixels

Input Video Signal Analog 0.7 Vp-p ± 5% positive at 75 , internally terminated

Input Sync Signal Type : Seperate H/V

Level : TTL level

Maximum Pixel Clock rate

80 MHz

Active Display

Horizontal/Vertical 556.4 mm / 339.8 mm

AC power voltage & Frequency AC 220 ~ 240V, 50 ~ 60 Hz

Power Consumption 150 W

Dimensions(W x D x H)

Set

802.8X244.0X578.0mm(31.6x9.92x22.76 inches) After installation Stand

802.8x88.2x539.2mm(31.6x3.47x21.23 inches) Without Stand

Weight

Set(After installation Stand) 15.5 Kg (34.1 lbs)

TV System Tunning Frequency Synthesize

System PAL, SECAM

Sound MONO, STEREO, NICAM

Environmental Considerations Operating Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating Humidity : 10 % ~ 80 %

Storage Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage Humidity : 5 % ~ 95 %

Antena Input 75

-MAX Internal speaker Out : Right : 10W / Left : 10W

-BASS Control Range : -8 dB ~ + 8dB

Sound Characteristic -TREBLE Control Range : -8 dB ~ +8 dB

-Headphone Out : 10 mW MAX

-Output Frequency : RF : 80 Hz ~ 15 kHz

A/V : 80 Hz ~ 20 kHz

Item Description

2 Product Specifications

2-3

2-3 LE40N71BX Specifications

LCD Panel

TFT-LCD panel, RGB vertical stripe, normaly white, 40-Inch viewable, 0.648(H) x 0.216(V) mm pixel pitch

Scanning Frequency Horizontal : 30 kHz ~ 61 kHz (Automatic) / Vertical : 100 Hz ~ 120 Hz (Automatic)

Display Colors 16,777,216 colours

Maximum Resolution Horizontal : 1366 Pixels

Vertical : 768 Pixels

Input Video Signal Analog 0.7 Vp-p ± 5% positive at 75 , internally terminated

Input Sync Signal Type : Seperate H/V

Level : TTL level

Maximum Pixel Clock rate

80 MHz

Active Display

Horizontal/Vertical 556.4 mm / 339.8 mm

AC power voltage & Frequency AC 220 ~ 240V, 50 ~ 60 Hz

Power Consumption 210 W

Dimensions(W x D x H)

Set

994 x 290 x 696 mm(39.13 x 11.42 x 27.40 inches) After Installation Stand

994 x 92 x 647 mm(39.13 x 3.62 x 25.47 inches) Without Stand

Weight

Set(After installation Stand) 31.6 Kg (69.52 lbs)

TV System Tunning Frequency Synthesize

System PAL, SECAM

Sound MONO, STEREO, NICAM

Environmental Considerations Operating Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating Humidity : 10 % ~ 80 %

Storage Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage Humidity : 5 % ~ 95 %

Antena Input 75

-MAX Internal speaker Out : Right : 10W / Left : 10W

-BASS Control Range : -8 dB ~ + 8dB

Sound Characteristic -TREBLE Control Range : -8 dB ~ +8 dB

-Headphone Out : 10 mW MAX

-Output Frequency : RF : 80 Hz ~ 15 kHz

A/V : 80 Hz ~ 20 kHz

Item Description

2 Product Specifications

2-4

2-4 LE46N71BX Specifications

LCD Panel

TFT-LCD panel, RGB vertical stripe, normaly white, 46-Inch viewable, 0.648(H) x 0.216(V) mm pixel pitch

Scanning Frequency Horizontal : 30 kHz ~ 61 kHz (Automatic) / Vertical : 100 Hz ~ 120 Hz (Automatic)

Display Colors 16,777,216 colours

Maximum Resolution Horizontal : 1366 Pixels

Vertical : 768 Pixels

Input Video Signal Analog 0.7 Vp-p ± 5% positive at 75 , internally terminated

Input Sync Signal Type : Seperate H/V

Level : TTL level

Maximum Pixel Clock rate

80 MHz

Active Display

Horizontal/Vertical 556.4 mm / 339.8 mm

AC power voltage & Frequency AC 220 ~ 240V, 50 ~ 60 Hz

Power Consumption 275 W

Dimensions(W x D x H)

Set

1129 x 320 x 788 mm (44.45 x 12.6 x 31.02 inches) After Installation Stand

1129 x 106 x 732 mm (44.45 x 4.17 x 28.82 inches) Without Stand

Weight

Set (After installation Stand) 43.8 Kg (96.36 lbs)

TV System Tunning Frequency Synthesize

System PAL, SECAM

Sound MONO, STEREO, NICAM

Environmental Considerations Operating Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating Humidity : 10 % ~ 80 %

Storage Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage Humidity : 5 % ~ 95 %

Antena Input 75

-MAX Internal speaker Out : Right : 10W / Left : 10W

-BASS Control Range : -8 dB ~ + 8dB

Sound Characteristic -TREBLE Control Range : -8 dB ~ +8 dB

-Headphone Out : 10 mW MAX

-Output Frequency : RF : 80 Hz ~ 15 kHz

A/V : 80 Hz ~ 20 kHz

Item Description

2 Product Specifications

2-5

LE32N71B/LE40N71B/LE46N71BModel

Design

Frequency

Horizontal

Vertical

Display Color

30 ~ 61 kHz

100 ~ 120 Hz

16,777,216 colors

30 ~ 61 kHz

60 ~ 75 Hz

16,777,216 colors

PC Resolution

Maximum mode

Input Signal

Sync Signal

Video Signal

Power

Consumption

Normal

Power Saving

150W / 210W / 275W

< 1W 100W / 125W / 205W

< 1W

H/V Separate, TTL, P. or N.

0.7 Vp-p @ 75ohm H/V Separate, TTL, P. or N.

0.7 Vp-p @ 75ohm

WXGA, 1366 x 768 @ 60 Hz WXGA, 1360 x 768 @ 60 Hz

LE26R71B / LE32R71B / LE40R71B

2-5 Spec Comparison
