Samsung CTR264KC01 Mode d’emploi

imagine the possibilities

Thank you for purchasing this Samsung product.

Ceramic Glass Hob

user & installation manual

CTR264KC01

CTR264KC01_XFA DG68-00446A-02_EN.indd 1 2016-09-02 �� 1:29:01

English - 2

contents

USING THIS MANUAL

4 Important safety symbols and

precautions

SAFETY INSTRUCTIONS

5 Safety instructions

DISPOSAL INSTRUCTIONS

9 Disposing of the packaging material

9 Proper disposal of your old appliance

INSTALLING THE HOB

10 Safety instructions for the installer

11 Connecting to the mains power supply

13 Installing into the countertop

PARTS AND FEATURES

15 Cooking zones

15 Control panel

16 Components

16 The key features of your appliance

18 Safety shuto

19 Residual heat indicator

19 Temperature detection

BEFORE YOU BEGIN

19 Initial cleaning

CTR264KC01_XFA DG68-00446A-02_EN.indd 2 2016-09-02 �� 1:29:01

English - 3

HOB USE

20 Using suitable cookware

22 Using the touch control sensors

22 Switching the appliance on

23 Select cooking zone and heat setting

24 Switching the appliance o

24 Switching a cooking zone o

25 Using the child safety lock

26 Timer

28 Suggested settings for cooking

speciﬁc foods

28 Auto heat up

CLEANING AND CARE

30 Hob

32 Hob frame (option)

32 To avoid damaging your appliance

WARRANTY AND SERVICE

33 FAQs and troubleshooting

35 Service

TECHNICAL DATA

36 Technical data

36 Cooking rings

CTR264KC01_XFA DG68-00446A-02_EN.indd 3 2016-09-02 �� 1:29:01

English - 4

using this manual

Please take the time to read this owner’s manual, paying particular attention

to the safety information contained in the following section, before using

your appliance. Keep this manual for future reference. If transferring

ownership of the appliance, please remember to pass the manual on to

the new owner.

IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS

The following symbols are used in the text of this Owner’s Manual :

WARNING

Hazards or unsafe practices that may result in

severe personal injury or death.

CAUTION

Hazards or unsafe practices that may result in

minor personal injury or property damage.

CAUTION

To reduce the risk of ﬁre, explosion, electric

shock, or personal injury when using your hob,

follow these basic safety precaution

Do NOT attempt.

Do NOT disassemble.

Do NOT touch.

Follow directions explicitly.

Unplug the power plug from the wall socket.

Make sure the machine is grounded to prevent

electric shock.

Call the service center for help.

Note

Important

CTR264KC01_XFA DG68-00446A-02_EN.indd 4 2016-09-02 �� 1:29:02

English - 5

safety instructions

The safety aspects of this appliance comply with all accepted technical

and safety standards. However, as manufacturers we also believe it is our

responsibility to familiarize you with the following safety instructions.

WARNING

This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a

person responsible for their safety.

Children should be supervised to ensure that they do

not play with the appliance.

If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly qualiﬁed

persons in order to avoid a hazard.

Appliance should allow the disconnection of the

appliance from the supply after installation. The

disconnection may be achieved by having the plug

accessible or by incorporating a switch in the ﬁxed

wiring in accordance with the wiring rules.

WARNING: If the surface is cracked, switch o the

appliance to avoid the possibility of electric shock.

During use the appliance becomes hot. Care should be

taken to avoid touching heating elements inside the hob.

WARNING: Accessible parts may become hot during

use. Young children should be kept away.

A steam cleaner is not to be used to clean the product.

Metallic objects such as knives, forks, spoons and lids

should not be placed on the hob surface since they

can get hot.

After use, switch o the hob element by its control and do

not rely on the pan detector.

USING THIS MANUAL & SAFETY INSTRUCTIONS

CTR264KC01_XFA DG68-00446A-02_EN.indd 5 2016-09-02 �� 1:29:02

English - 6

Do not use harsh abrasive cleaners or sharp metal

scrapers to clean the hob glass since they can scratch

the surface, which may result in shattering of the glass.

Appliance is not intended to be operated by means of

an external timer or separate remote-control system.

WARNING: The appliance and its accessible parts

become hot during use.

Care should be taken to avoid touching heating

elements inside the hob.

Children less than 8 years of age shall be kept away

unless continuously supervised.

This appliance can be used by children aged from

8years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved. Children

shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without

supervision.

WARNING: Unattended cooking on a hob with fat or

oil can be dangerous and may result in ﬁre.

NEVER try to extinguish a ﬁre with water, but switch o

the appliance and then cover ﬂame e.g. with a lid or a

ﬁre blanket.

WARNING: Danger of ﬁre: do not store items on the

cooking surfaces.

The temperature of accessible surfaces may be high

when the appliance is operating.

Keep the appliance and its cord out of reach of

children less than 8 years.

WARNING: Use only hob guards designed by the

manufacturer of the cooking appliance. The use of

inappropriate guards can cause accidents.

CTR264KC01_XFA DG68-00446A-02_EN.indd 6 2016-09-02 �� 1:29:02

English - 7

CAUTION

Be sure the appliance is properly installed and

grounded by a qualiﬁed technician.

The appliance should be serviced only by qualiﬁed

service personnel. Repairs carried out by unqualiﬁed

individuals may cause injury or serious malfunction. If

your appliance is in need of repair, contact your local

service centre. Failure to follow these instructions may

result in damage and void the warranty.

Flush - mounted appliances may be operated only after

they have been installed in cabinets and workplaces that

conform to the relevant standards. This ensures sucient

protection against contact for electrical units as required

by the essential safety standards.

If your appliance malfunctions or if fractures, cracks or

splits appear:

- switch o all cooking zones;

- disconnect the hob from the mains supply; and

- contact your local service centre.

If the cooktop cracks, turn the appliance o to avoid the

possibility of electric shock. Do not use your hob until the

glass surface has been replaced.

Do not use the hob to heat aluminium foil, products

wrapped in aluminium foil or frozen foods packaged in

aluminium cookware.

Liquid between the bottom of the pan and the hob can

produce steam pressure. Which may cause the pan to

jump.

Always ensure that the hotplate and the base of the pan

are kept dry.

The cooking zones will become hot when you cook.

Always keep small children away from the appliance.

Keep all packaging materials well out of the reach of

children, as packaging materials can be dangerous to

children.

USING THIS MANUAL & SAFETY INSTRUCTIONS

CTR264KC01_XFA DG68-00446A-02_EN.indd 7 2016-09-02 �� 1:29:02

English - 8

This appliance is to be used only for normal cooking

and frying in the home. It is not designed for

commercial or industrial use.

Never use the hob for heating the room.

Take care when plugging electrical appliances into

mains sockets near the hob. Mains leads must not

come into contact with the cooktop.

Overheated fat and oil can catch ﬁre quickly. Never

leave surface units unattended when preparing foods

in fat or oil, for example, when cooking chips.

Turn the cooking zones o after use.

Always keep the control panels clean and dry.

Never place combustible items on the hob, it may

cause ﬁre.

There is the risk of burns from the appliance if used

carelessly.

Cables from electrical appliances must not touch the

hot surface of the hob or hot cookware.

Do not use the hob to dry clothes.

WARNING : Users with Pacemakers and Active Heart

Implants must keep their upper body at a minimum

distance of 30 cm from induction cooking zones

when turned on. If in doubt, you should consult the

manufacturer of your device or your doctor. (Induction

hob model only)

Do not attempt to repair, disassemble, or modify the

appliance yourself.

Always turn the appliance o before cleaning.

Clean the hob in accordance with the cleaning and

care instructions contained in this manual.

CTR264KC01_XFA DG68-00446A-02_EN.indd 8 2016-09-02 �� 1:29:02

English - 9English - 9

disposal instructions

DISPOSING OF THE PACKAGING MATERIAL

All materials used to package the appliance are fully recyclable. Sheet and hard foam parts

are appropriately marked. Please dispose of packaging materials and old appliances with due

regard to safety and the environment.

PROPER DISPOSAL OF YOUR OLD APPLIANCE

WARNING : Before disposing of your old appliance, make it inoperable so that it cannot be a

source of danger.

To do this, have a qualiﬁed technician disconnect the appliance from the mains supply and

remove the mains lead.

The appliance may not be disposed of in the household rubbish.

Information about collection dates and public refuse disposal sites is available from your local

refuse department or council.

02 DISPOSAL INSTRUCTIONS

WARNING

CTR264KC01_XFA DG68-00446A-02_EN.indd 9 2016-09-02 �� 1:29:02

English - 10English - 10

installing the hob

Be sure the new appliance is installed and grounded only by

qualiﬁed personnel.

Please observe this instruction. The warranty will not

cover any damage that may occur as a result of improper

installation.

Technical data is provided at the end of this manual.

SAFETY INSTRUCTIONS FOR THE INSTALLER

• A device must be provided in the electrical installation that allows

the appliance to be disconnected from the mains at all poles with a

contact opening width of at least 3 mm. Suitable isolation devices

include line protecting cut - outs, fuses (screw type fuses are to be

removed from the holder), earth leakage trips and contactors.

• With respect to ﬁre protection, this appliance corresponds to EN

60335 - 2 - 6. This type of appliance may be installed with a high

cupboard or wall on one side.

• Drawers may not be ﬁtted underneath the hob.

• The installation must guarantee shock protection.

• The kitchen unit in which the appliance is ﬁtted must satisfy the

stability requirements of DIN 68930.

• For protection against moisture, all cut surfaces are to be sealed

with a suitable sealant.

• On tiled work surfaces, the joints in the area where the hob sits

must be completely ﬁlled with grout.

• On natural, artiﬁcial stone, or ceramic tops, the snap action springs

must be bonded in place with a suitable artiﬁcial resin or mixed

adhesive.

• Ensure that the seal is correctly seated against the work surface

without any gaps. Additional silicon sealant must not be applied;

this would make removal more dicult when servicing.

• The hob must be pressed out from below when removed.

• A board is to be installed underneath the hob.

WARNING

CTR264KC01_XFA DG68-00446A-02_EN.indd 10 2016-09-02 �� 1:29:02

Table des matières

Autres manuels Samsung Plaque

Samsung

Samsung C61RA series Manuel utilisateur

Samsung

Samsung CTN464FB Series Manuel utilisateur

Samsung

Samsung NZ63R3727BK Manuel utilisateur

Samsung

Samsung CTR164TB Series Manuel utilisateur

Samsung

Samsung NZ64R3747BK/EF Manuel utilisateur

Samsung

Samsung NZ64B6056FK Manuel utilisateur

Samsung

Samsung NZ64M3NM1BB/OL Manuel utilisateur

Samsung

Samsung CTR364T007 Manuel utilisateur

Samsung

Samsung NZ64N3707AS/UR Manuel utilisateur

Samsung

Samsung NZ64M3NM1BB Manuel utilisateur

Samsung

Samsung NZ63F3NM1AB Manuel utilisateur

Samsung

Samsung CTN364NC Series Manuel utilisateur

Samsung

Samsung C61RA series Manuel utilisateur

Samsung

Samsung GN 642 Series Guide de démarrage rapide

Samsung

Samsung NZ84F7NC Series Manuel utilisateur

Samsung

Samsung C21RJAN series Manuel utilisateur

Samsung

Samsung NZ64M3707AK Manuel utilisateur

Samsung

Samsung CTI613GI series Manuel utilisateur

Samsung

Samsung C21RJAN series Manuel utilisateur

Samsung

Samsung NZ63B5046 Series Manuel utilisateur

Samsung

Samsung NZ84T9770EK Manuel utilisateur

Samsung

Samsung CTI613EHD Manuel utilisateur

Samsung

Samsung NZ64K5747BK Manuel utilisateur

Samsung

Samsung C61IDGN0 Manuel utilisateur

Manuels Plaque populaires d'autres marques

Siemens

Siemens EX875KYV1E Fiche technique

AEG

AEG CERAMIC HOB 6010 K Manuel utilisateur

VALERA

VALERA CT 70A Manuel utilisateur

Zanussi

Zanussi ZGF 6420 Manuel utilisateur

Gaggenau

Gaggenau CI 273 Manuel utilisateur

G3 Ferrari

G3 Ferrari Energy Manuel utilisateur

Pkm

Pkm IN4B Manuel utilisateur

Award

Award H903BG Manuel utilisateur

Zanussi

Zanussi VCH 5005 RZ Manuel utilisateur

Miele

Miele KM 523 Manuel utilisateur

Hotpoint

Hotpoint IS67V8CCXT/E Manuel utilisateur

AEG

AEG HK854870XB Manuel utilisateur

Cookology

Cookology SEP600BK Manuel utilisateur

Bauknecht

Bauknecht Hob Manuel utilisateur

Zanussi

Zanussi ZGM 782 Manuel utilisateur

dipo INDUCTION

dipo INDUCTION DIBK218S Manuel utilisateur

Miele

Miele KM 5987 Manuel utilisateur

Miele

Miele KM 360 G Manuel utilisateur
