Samsung SP-D400 Manuel utilisateur

NETWORK VIDEO DECODER

User Manual SPD-400

Trademark

is the registered logo of Samsung Techwin Co., Ltd.

The name of this product is the registered trademark of Samsung Techwin Co., Ltd.

Other trademarks mentioned in this manual are the registered trademark of their respective company.

Restriction

Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no circumstances, this document shall

be reproduced, distributed or changed, partially or wholly, without formal authorization of Samsung Techwin.

Disclaimer

Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no

formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own

responsibility. Samsung Techwin reserves the right to change the contents of this document without prior notice.

Warranty

If the product does not operate properly in normal conditions, please let us know. Samsung Techwin will resolve the

problem for free of charge. The warranty period is 3 years. However, the followings are excluded:

•If the system behaves abnormally because you run a program irrelevant to the system operation.

•Deteriorated performance or natural worn-out in process of time

Design and specifications are subject to change without prior notice.

The default password can be exposed to a hacking thread so it is recommended to change the password

after installing the product.

Note that the security and other related issues caused by the unchanged password shall be responsible

for the user.

Network Video Decorder

User Manual

English _3

●OVERVIEW

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings, Install in accordance with the manufacturer’s

instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the third prong are provided for

your safety, If the provided plug does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/ accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by

the manufacturer, or sold with the apparatus. When a cart is used,

use caution when moving the cart/apparatus combination to avoid

injury from tip-over.

13. Unplug this apparatus during lighting storms or when unused for

long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus

has been damaged in any way, such as power-supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been dropped.

overview

4_ overview

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE

THIS PROCUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC

OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS

ON THE EQUIPMENT.

Apparatus shall not be exposed to dripping or splashing and that no objects

filled with liquids, such as vases, shall be placed on the apparatus.

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

EXPLANATION OF GRAPHICAL SYMBOLS

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of “dangerous voltage” within the product’s

enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended

to alert the user to the presence of important operating

and maintenance (servicing) instructions in the literature

accompanying the product.

English _5

●OVERVIEW

Class construction

An apparatus with CLASS construction shall be connected to a MAINS

socket outlet with a protective earthing connection.

Battery

Batteries(battery pack or batteries installed) shall not be exposed to excessive

heat such as sunshine, fire or the like.

It is essential that when changing the battery in the unit, the replacement

battery must be of the same type otherwise there may be a possibility of an

explosion.

CALIFORNIA USA ONLY

This Perchlorate warning applies only to primary CR (Manganese Dioxide)

Lithium coin cells in the product sold or distributed ONLY in California USA.

“Perchlorate Material - special handling may apply, See www.dtsc.ca.gov/

hazardouswaste/perchlorate.”

CAUTION

These servicing instructions are for use by qualified service personnel only.

To reduce the risk of electric shock do not perform any servicing other than

that contained in the operating instructions unless you are qualified to do so.

Please use the input power with just one camera and other devices must not

be connected.

overview

6_ overview

Please read the following recommend safety precautions carefully.

Do not Place this apparatus on an uneven surface.

Do not install on a surface where it is exposed to direct sunlight, near

heating equipment or heavy cold area.

Do not place this apparatus near conductive material.

Do not attempt to service this apparatus yourself.

Do not place a glass of water on the product.

Do not install near any magnetic sources.

Do not block any ventilation openings.

Do not place heavy items on the product.

User’s Manual is a guidance book how to use the products

The meaning of the using sign in the book is following

Reference : In case of providing information for helping of product’s usages

Notice : If there’s any possibility to occur any damages for the goods and

human caused by not following the instruction

Please read this manual for the safety before using of goods and keep it in

the safe place.

English _7

●OVERVIEW

CONTENTS

OVERVIEW

3Important Safety Instructions

9Product Features

9Recomended PC Specifications

10 What’s Included

11 At a Glance

INSTALLATION &

CONNECTION

14 Connecting with other Device

NETWORK CONNECTION

AND SETUP

19 Configuring Network Video Decoder in

LAN Environments

20 Connecting the Network Video

Decoder Directly to DHCP-Based

DSL/Cable Modem

21 Connecting the Network Video

Decoder and Broadband Router that

is Connected to the Cable Modem

22 Buttons used in IP Installer

23 Static IP Setup

27 Dynamic IP Setup

28 Connecting to the Network Device

from a Shared Local PC

overview

8_ overview

WEB VIEWER

29 Accessing the Network Video Decoder

30 Login

SETUP SCREEN

31 Setup

31 Audio & Video Setup

39 Network Setup

43 System Setup

APPENDIX

48 Specification

50 Product Overview

51 Troubleshooting

52 Open Source Announcement

54 GPL/LGPL Software License

English _9

●OVERVIEW

PRODUCT FEATURES

Supports Multi-format decoding

The network video decoder employs H.264/MPEG-4/MJPEG multi-format decoder to

decode and display up to 4 video streams transferred through network.

Supports Full-HD Video Display

The maximum supported output resolution is 1920x1080, and provides HDMI, VGA and

CVBS (BNC) output ports for display.

Alarm Monitoring

When an event occurs at a network camera or the encoder, the monitoring display switches

to the corresponding video according to the settings.

RECOMENDED PC SPECIFICATIONS

CPU : Intel(R) Core(TM)2 2.00 GHz or higher

Operating System : Windows XP, VISTA, 7

Mac OS

Resolution : 1280X1024 pixels or higher

RAM : 1GB or higher

Web Browser :

Internet Explorer 7.0 or 8.0, Firefox, Chrome, Safari

Video Memory : 128MB or higher

overview

10_ overview

WHAT’S INCLUDED

Please check if your network video decoder and accessories are all included in the product

package.

Appearance Item Name Quantity Description

VIDEO OUT

AUDIO OUT HDMI VGA

SPD-400 1

User Manual CD 1

Quick Guide 1

ASSY-Tapping Screw 4

Used for installation on the wall
