Samsung DVG45M5500 Series Manuel utilisateur

Dryer

User manual

DVE(G)45M5500*

DV5500M_03381G_EN.indd 1 12/26/2016 11:01:56 AM

Contents

English2

Contents

Safety information 4

What you need to know about the safety instructions 4

Important safety symbols 4

Important safety precautions 6

Warnings 8

Cautions 8

Installation requirements 10

Key installation requirements 10

Location considerations 10

Alcove or closet installations 11

Ducting requirements 14

Exhausting requirements 15

Gas requirements 16

Electrical requirements 17

Installation 19

What’s included 19

Step-by-step installation 21

Vent blockage test 28

Exhaust ducting guide 29

Door reversal 30

Before you start 33

Sort and load 33

Functional prerequisite 33

Operations 34

Feature panel 34

Simple steps to start 37

Cycle overview 38

Drying guide 39

Special features 40

DV5500M_03381G_EN.indd 2 12/26/2016 11:01:57 AM

Contents

English 3

Maintenance 42

Vent sensor 42

Cleaning 43

Troubleshooting 44

Checkpoints 44

Information codes 47

Specications 48

Fabric care chart 48

Protecting the environment 49

Specication sheet 50

Cycle chart 51

DV5500M_03381G_EN.indd 3 12/26/2016 11:01:57 AM

Safety information

SAVE THESE INSTRUCTIONS

English4

Safety information

Congratulations on your new Samsung dryer. This manual contains important information

on the installation, use and care of your appliance. Please take some time to read this

manual to take full advantage of your dryer’s many benets and features.

What you need to know about the safety instructions

Please read this manual thoroughly to ensure that you know how to safely and efciently

operate the extensive features and functions of your new appliance. Please store the

manual in a safe location close to the appliance for future reference. Use this appliance

only for its intended purpose as described in this instruction manual.

Warnings and Important Safety Instructions in this manual do not cover all possible

conditions and situations that may occur. It is your responsibility to use common sense,

caution and care when installing, maintaining and operating your dryer.

Because the following operating instructions cover various models, the characteristics of

your dryer may differ slightly from those described in this manual and not all warning

signs may be applicable. If you have any questions or concerns, contact your nearest

service center or nd help and information online at www.samsung.com.

Important safety symbols

What the icons and signs in this user manual mean:

WARNING

Hazards or unsafe practices that may result in severe personal injury, death and/or

property damage.

CAUTION

Hazards or unsafe practices that may result in personal injury and/or property damage.

NOTE

Indicates that a risk of personal injury or material damage exists.

DV5500M_03381G_EN.indd 4 12/26/2016 11:01:57 AM

Safety information

SAVE THESE INSTRUCTIONSSAVE THESE INSTRUCTIONS

English 5

These warning signs are here to prevent injury to yourself and others.

Please follow them explicitly.

After reading this manual, store it in a safe place for future reference.

Read all instructions before using the appliance.

As with any equipment that uses electricity and moving parts, potential hazards exist.

To safely operate this appliance, familiarize yourself with its operation and exercise care

when using it.

WARNING - Gas Appliances:

• State of California Proposition 65 Warning (US only)

This product contains chemicals known to the State of California to cause cancer and

birth defects or other reproductive harm.

• Gas appliances can cause low-level exposure to Proposition 65 listed substances,

including but not limited to, benzene, carbon monoxide, formaldehyde and soot,

substances resulting from the incomplete combustion of natural gas or LP fuels.

WARNING - Risk of Fire

• Clothes dryer installation must be performed by a qualied installer.

• Install the clothes dryer according to the manufacturer’s instructions and local codes.

• Do not install a clothes dryer with exible plastic venting materials. If exible metal

(foil type) duct is installed, it must be of a specic type identied by the appliance

manufacturer as suitable for use with clothes dryers. Flexible venting materials are

known to collapse, be easily crushed, and trap lint. These conditions will obstruct

clothes dryer airow and increase the risk of re.

• To reduce the risk of severe injury or death, follow all installation instructions.

• Save these instructions.

DV5500M_03381G_EN.indd 5 12/26/2016 11:01:57 AM

Safety information

SAVE THESE INSTRUCTIONS

Safety information

SAVE THESE INSTRUCTIONS

English6

Important safety precautions

WARNING

To reduce the risk of re, electric shock, or injury to persons when using your appliance,

follow basic precautions, including the following:

1. Read all instructions before using this appliance.

2. Do not dry articles that have been previously cleaned in, washed in, soaked in,

or spotted with gasoline, dry-cleaning solvents, or other ammable or explosive

substances, as they give off vapors that could ignite or explode.

3. Do not use the dryer to dry clothes which have traces of any ammable substance,

such as vegetable oil, cooking oil, machine oil, ammable chemicals, paint thinner,

etc., or anything containing wax or chemicals, such as mops and cleaning cloths.

Flammable substances may cause the fabric to catch re by itself.

4. Do not store or use gasoline or other ammable vapors and liquids near this or any

other appliance.

5. Do not allow children to play on or in the appliance. Close supervision of children is

necessary when the appliance is used near children.

6. Before the appliance is removed from service or discarded, remove the door to the

drying compartment.

7. Do not reach into the appliance if the drum is moving.

8. Do not install or store this appliance where it will be exposed to the weather.

9. Do not tamper with internal controls.

10. Do not repair or replace any part of the appliance or attempt any service unless

specically recommended in the user-maintenance instructions or in published user-

repair instructions that you understand and have the skills to carry out.

11. Do not use fabric softeners or products to eliminate static unless recommended by the

manufacturer of the fabric softener or product.

12. Clean the lint screen before or after each load.

13. Do not use heat to dry articles containing foam rubber or similarly textured rubber-

like materials.

14. Keep area around the exhaust opening and adjacent surrounding areas free from the

accumulation of lint, dust, and dirt.

15. The interior of the appliance and exhaust duct should be cleaned periodically by

qualied service personnel.

DV5500M_03381G_EN.indd 6 12/26/2016 11:01:57 AM

Safety information

SAVE THESE INSTRUCTIONSSAVE THESE INSTRUCTIONS

English 7

16. Do not place items exposed to cooking oils in your dryer. Items contaminated with

cooking oils may contribute to a chemical reaction that could cause a load to catch

re.

17. This appliance must be grounded. See “Electrical requirements” and ”Grounding” in

“Installation” section.

18. Do not allow children to play on or in the appliance. Close supervision of children is

necessary when the appliance is used near children.

19. Do not insert your hand under the dryer.

• This may result in injury.

20. Take care that children’s ngers are not caught in the door when closing it.

• This may result in injury.

21. The control board and inlet valve are intentionally not grounded and may present a

risk of electric shock only during servicing.

• Do not contact these parts while the appliance is energized.

WARNING - To reduce the risk of re or explosion:

• Do not dry items that have been previously cleaned, washed, soaked, or spotted with

gasoline, dry cleaning solvents, or other ammable or explosive substances. They

emit vapors that could ignite or explode. Any material that has been in contact with a

cleaning solvent or ammable liquids or solids should not be placed in the dryer until

all traces of these ammable liquids or solids and their fumes have been removed.

There are many highly ammable items used in homes, such as acetone, denatured

alcohol, gasoline, kerosene, some liquid household cleaners, some spot removers,

turpentine, waxes, and wax removers.

• Items containing foam rubber (which may be labeled latex foam) or similarly

textured rubberlike materials must not be dried on a heat setting. Heated foam

rubber materials can, under certain circumstances, ignite spontaneously.

DV5500M_03381G_EN.indd 7 12/26/2016 11:01:57 AM

Safety information

SAVE THESE INSTRUCTIONS

Safety information

SAVE THESE INSTRUCTIONS

English8

WARNING - What to do if you smell gas:

• Do not try to light any appliance.

• Do not turn on the appliance.

• Do not touch any electrical switch.

• Do not use any phone in your building.

• Clear the room, building or area of all occupants.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s

instructions.

• If you cannot reach your gas supplier, call the re department.

• Installation and service must be performed by a qualied installer, service agency, or

the gas supplier.

Warnings

WARNING

• Ensure pockets are free of small, irregularly shaped hard objects and foreign material,

i.e. coins, knives, pins, etc. These objects could damage your dryer.

• Gas leaks may occur in your system, resulting in a dangerous situation.

Cautions

CAUTION

• Do not allow children or pets to play on, in, or in front of the appliance. Close

supervision is necessary when the appliance is used near children and pets.

• Before discarding or removing your dryer from service, remove the door to the drying

compartment to prevent children or animals from becoming trapped inside.

• Do not reach into the appliance when the drum is moving.

• Do not install or store this appliance where it will be exposed to the weather.

• Do not tamper with the controls.

• Do not repair, replace, or attempt to service any part of the appliance unless

specically instructed to in the user-repair instructions and you have the

understanding and skills to carry out the procedure.

DV5500M_03381G_EN.indd 8 12/26/2016 11:01:57 AM

Safety information

SAVE THESE INSTRUCTIONSSAVE THESE INSTRUCTIONS

English 9

• Do not use fabric softeners or products to eliminate static unless the softener or

product is recommended for dryer use by the manufacturer of the fabric softener or

product.

• Clean the lint screen before or after each load.

• Keep the area around the exhaust opening and surrounding areas free from lint, dust,

and dirt.

• The interior of the dryer and exhaust duct should be cleaned periodically by qualied

service personnel.

• This appliance must be properly grounded. Never plug the power cord into a receptacle

that is not grounded adequately or not in accordance with local and national codes. See

the installation instructions for information about grounding this appliance.

• Do not sit on top of the dryer.

• Do not dry clothing with large buckles, buttons, or other heavy metal or solid objects.

• Gas leaks may not be detected by smell alone.

• Gas suppliers recommend you purchase and install a UL-approved gas detector.

• Install and use in accordance with the manufacturer’s instructions.

• Do not place items in your dryer that have been spotted or soaked with vegetable oil

or cooking oil. Even after being washed, these items may contain signicant amounts

of these oils.

• Residual oil on clothing can ignite spontaneoulsy. The potential for spontaneous

combustion increases when items containing vegetable oil or cooking oil are exposed

to heat. Heat sources such as your dryer can warm these items, allowing an oxidation

reaction in the oil to occur. Oxidation creates heat. If this heat cannot escape, the items

can become hot enough to catch re. Piling, stacking, or storing these kinds of items

may prevent heat from escaping and can create a re hazard.

• All washed and unwashed fabrics that contain vegetable oil or cooking oil can be

dangerous.

Washing these items in hot water with extra detergent will reduce, but not eliminate,

the hazard. Always use the Cool Down cycle for these items to reduce their

temperature. Never remove these items from the dryer hot or interrupt the drying

cycle until the items have run through the Cool Down cycle. Never pile or stack these

items when they are hot.

DV5500M_03381G_EN.indd 9 12/26/2016 11:01:57 AM

Installation requirements

English10

Installation requirements

Read through the following instructions before installing the dryer and keep this manual

for future reference.

WARNING

The control board and inlet valve are intentionally not grounded and may present a risk of

electric shock only during servicing.

Service personnel - Do not contact these parts while the appliance is energized.

Key installation requirements

• A grounded electrical outlet.

• A power cord for electric dryers (except

in Canada).

• Gas lines (for gas models) that must

meet national and local regulations.

• An exhaust system made of rigid metal

or exible stiff-walled metal exhaust

ducting.

WARNING

Remove the door from all discarded

appliances to prevent a child from

suffocating.

Location considerations

The dryer should be located where there

is enough space at the front for loading

the dryer, and enough space behind for

the exhaust system. This dryer is factory-

ready for the rear exhaust option. To

exhaust out the bottom, right or the left,

use the accessory exhaust kit. Instructions

are included with the kit. Make sure

the room in which the dryer is located

has enough fresh air. The dryer must

be located where there are no air-ow

obstructions. For gas dryers, adequate

clearance must be maintained as noted

on the data plate to ensure adequate

air for combustion and the proper dryer

operation.

The dryer must not be installed or stored

in an area where it will be exposed to

water and/or weather. The dryer area must

be kept clear of combustible materials,

gasoline, and other ammable vapors and

liquids. A dryer produces combustible lint.

The area around the dryer should be kept

lint-free.

DV5500M_03381G_EN.indd 10 12/26/2016 11:01:57 AM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung Séchoir

Samsung

Samsung DV45K7100E(G) series Manuel utilisateur

Samsung

Samsung DV11H4100CW Manuel utilisateur

Samsung

Samsung DVE45M5500 Series Manuel utilisateur

Samsung

Samsung DV231AE Series Manuel utilisateur

Samsung

Samsung DV665JS Manuel utilisateur

Samsung

Samsung DV306LEW Manuel utilisateur

Samsung

Samsung DVEG53BB8900 Series Manuel utilisateur

Samsung

Samsung DVE51CG8005 Series Manuel utilisateur

Samsung

Samsung DV365 Series Manuel utilisateur

Samsung

Samsung DV484ETHAWR/A1-0001 Manuel utilisateur

Samsung

Samsung FlexDry DVE55M9600W Manuel utilisateur

Samsung

Samsung SDC14709 Manuel utilisateur

Samsung

Samsung DV338AEW Manuel utilisateur

Samsung

Samsung DVG45T6200 Series Manuel utilisateur

Samsung

Samsung DV393ETPARA/A1 Manuel utilisateur

Samsung

Samsung DV25B6800E Series Manuel utilisateur

Samsung

Samsung DV410AE series Manuel utilisateur

Samsung

Samsung DV52J8700E(G) series Manuel utilisateur

Samsung

Samsung DV431AE Series Manuel utilisateur

Samsung

Samsung DVG45R6100P/A3 Manuel utilisateur

Samsung

Samsung DV5451AEWXAC Manuel utilisateur

Samsung

Samsung DV218AEW Manuel utilisateur

Samsung

Samsung DV210AGW Manuel utilisateur

Samsung

Samsung DVE22N6850 Series Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
