Samsung DV363EWBEUF/A1 Manuel

CLOTHES DRYER

Technical Information

CAUTION

All safety information must be follwed as provided in Service Manual of DV363, DV361.

WARNING

To avoid risk of electrical shock, personal injury or death; disconnect power to dryer

before servicing, unless testing requires power.

Code No. : DC68-02365J_EN

• Due to possibility of personal injury or property damage, always contact an authorized

technician for servicing or repair of this unit.

• Refer to Service Manual (DV363, DV361) for detailed installation, operating, testing,

troubleshooting, and disassembly instructions.

Technical_information-02365J_EN.indd 1 2012-06-05 �� 5:08:11

ERROR ITEMS AND DIAGNOSTIC CODES

An occurrence of an Error will make a sound of error melody for 5sec and con tinuously show one

of the Error Displays from the following errors.

Error Display Trigger Action Taken

LED LCD

The Termistor resistance is very

low or high.

Check for:

- Clogged lint screen.

- Restricted vent system.

- Check Thermistor resistance.

Invalid heating Temp in running

the dryer

Check for:

- Restricted vent system.

- Check Thermistor resistance.

Running the dryer with door

open

Check for:

- Close the door, and run the dryer

- Loose or open wire terminals in

Door Sense circuit.

dF Invalid door state for more than

256 milliseconds

Check for:

- Loose or open wire terminals

in Door Sense circuit.

bE2

Invalid state of key circuit short

for 30 secs(all models)

75 secs(DV339,DV338,DV448,D

V438,DV428)

Check for:

- Display PCB key circuit short or not

FE Invalid power source Frequency

Check for:

- Not using regular power source

frequency

- Invalid power frequency sense circuit

9E Electronic Control Problem

(Communication Error)

Check for:

- Check PCB and Wire harness.

- Replace PCB

od Invalid Dry time in excess Dry

time

Check for:

- Sensor bar Open

- using Adjust time Up excessively

Et Invalid state of Eeprom

communication

Check for :

- PCB with Eeprom circuit.

ALIGNMENT AND ADJUSTMENTS

WARNING

To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before

servicing, unless testing requires power.

Technical_information-02365J_EN.indd 2 2012-06-05 �� 5:08:12

TEST MODE

Continuous Run Mode:

1. Press Signal + Dry Level for 3 sec during Power On State (Normal User Mode) .

2. Once in Continuous Run Mode, 7-Segment will toggle display “total cycle” and the remaining

time.

3. The previous cycle will restart during Continuous Run Mode until continuous run mode is

disabled.

4. During Continuous Run Mode, press Signal + Dryness Level for 3 seconds to return to normal

user mode. 7-segment will no long display “total cycle ” and only display the remaining time.

Cycle Count Mode

Denition of Cycle Count Mode:

- While in Service Mode pressing the Signal key will put the dryer into the cycle count mode

- Cycle number executed will display.

How to Enter:

- To enter Special Test Mode press While in Service Mode pressing the Signal key for 3 seconds

or until the control beep.

Special Test Mode

Denition of Special Test Mode:

- Dryer must be on before Service Mode can be entered.

- Press Signal and Temp Keys for 3 seconds, or until 3 beeps are heard.

- The machine will now be in Service Mode.

- Upon entry into Service Mode, the Sensor Bar Touch Data will be shown (Default Special Test

Mode).

How to Enter:

- To enter Special Test Mode press Signal and Temp Keys for 3 seconds for 3 seconds or until

the control beep.

Sensor Bar Touch Data Mode

Denition of Sensor Bar Touch Data Mode:

- With Power On pressing Signal and Temp Keys for 3 seconds

- This action will put the dryer into sensor bar touch data mode

- Dryer will display Sensor Bar data. This mode is default mode of entering service mode

How to Enter:

- With Power On pressing Signal and Temp Keys for 3 seconds

ALIGNMENT AND ADJUSTMENTS

WARNING

To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before

servicing, unless testing requires power.

Technical_information-02365J_EN.indd 3 2012-06-05 �� 5:08:13

Temperature Display Mode(in Celsius)

Denition of Temperature Display Mode:

- With power on, Press Sinal and Wrinkle Prevent keys simultanously for 3 seconds.

- This action will put the dryer into Touch Sensor Mode

- Under “Touch Sensor Mode”, Press Time and Wrinkle Prevent Keys at the same time.

- Then the dryer will display the temperature of drum inside in Celsius.

How to Enter:

- Under normal User Mode, Press “Signal and Wrinkle Prevent” Keys simultanously for 3 seconds

- Then press “Time and Wrinkle Prevent” keys at the same time.

• Converting °C  °F

Celsius(°C) -30 -10 10 30 50 70 F =9/5C + 32

Fahrenheit(°F) -22 14 50 86 122 158

Software Version Mode

Denition of Software Version Mode:

- While in Service Mode pressing the Temp key will put the dryer into the software version

mode

How to Enter:

- To enter Special Test Mode press Temp Key until the control beep.

ex) In case of “U1 05”, U1 means major version “U1”, 05 means minor version “05”.

System Check Mode

Special Test Mode:

- While in Power O, pressing the Dryness Level + Power keys simultaneously will put the dryer

into the System Check mode

- “ t2 “ will display.

- System Check Mode Progress t2 mode Function Performed Start/Pause

Motor(CW) Relay On  Heater Relay On  Heater Relay O  Motor(CW) Relay O

(Circulation)

ALIGNMENT AND ADJUSTMENTS

WARNING

To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before

servicing, unless testing requires power.

Technical_information-02365J_EN.indd 4 2012-06-05 �� 5:08:13

TROUBLE DIAGNOSIS

- As the micom dry machine is congured of the complicate structure, there might be the

service call.

Below information is prepared for exact trouble diagnosis and suitable repair guide.

Caution for the Repair and Replacement

1) As some electronic components are damaged by the charged static electricity from the resin

part of dryer or the human body, prepare the human body earth or remove the potential

dier ence of the human body and dryer by contacting the power supply plug when the work

contacting to PCB is executed.

2) As the P.C.B assembly is designed for no trouble, do not replace the P.C.B assembly by the

wrong diagnosis and follow the procedure of the trouble diagnosis when the micom is not

operated normally.

ALIGNMENT AND ADJUSTMENTS

WARNING

To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before

servicing, unless testing requires power.

Please follow below instruction for the trouble diagnosis and parts replacement.

Technical_information-02365J_EN.indd 5 2012-06-05 �� 5:08:13

No Problem What To Do

1Will Not Start or Run

• All wires are hooked up to their corresponding terminals.

• Dryer is plugged in.

• Blown fuse or circuit breaker.

• Door switch functional...door closed. Check for error code 3 (See

Table for codedenition).

• Start/Pause rotary selector dial functional.

• Control Board operational.

• Belt o or broken and Belt Cut-o Switch operates.

• Drive motor functional.

• Check motor winding resistance: 2.88ohms between pin #3 and

4, 3.5ohms between pin #4 and 5.

2Motor runs/ tumbler

will not turn

• Belt o or broken/damaged.

• Idler tension spring too weak or stretched.

• Idler pulley jammed or stuck.

3Runs a few minutes

and then stops

• Lint buildup around drive motor.

• Low voltage present.

• Blower impeller blocked in blower housing.

• Drive motor - start switch contacts stuck closed.

4Blows fuses or trips

circuit breaker

- Is the belt connected well?

- Is the winding of the motor continuous?

(Rotor winding, stator winding, generator)

- Is the motor protector normal?

• If above points are not found, the PCB assembly is out of order.

Replace it.

Blows fuses or trips

circuit breaker (Gas

Model)

• During ignition the dryer will draw X amps. With the burner ON,

the dryer will draw X amps. If the dryer is drawing amperages

above this, then the house wiring, fuse box or circuit breaker is

suspected to be at fault.

• Igniter harness loose and shorted to base.

• Incorrect wiring or wire shorted to ground.

• Drive motor winding shorting to ground.

6Will not heat (motor

runs)

Open heating element.

• Hi-Limit trips easily or is open.

• Regulating thermostat trips easily or is open.

• Membrane switch open.

• Check Thermistor.

Will Not Dry Gas

Model Poor Gas

Ignition

When the dryer is operated on a heat setting, the igniter should be

energized and burner shall re within 45 seconds at 120 VAC. The

failure of a component in this system will usually be indicated by one

of three symptoms:

TROUBLE SHOOTING

WARNING

To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before

servicing, unless testing requires power.

Technical_information-02365J_EN.indd 6 2012-06-05 �� 5:08:13

No Problem What To Do

8The igniter does not

glow

If the igniter does not heat up, remove power and using an

ohmmeter, check the following:

• Open ame sensor

• Open igniter

• Shorted booster coil

• Open wiring

• Bad motor switch ( Neutral supply)

• No power from control ( L1 supply)

9Igniter glows - No gas

ignition

If the igniter heats up but the main burner ame is not ignited,

remove power and using an ohmmeter, check the following:

• Open secondary coil

• Open holding coil

• Open wire harness

• Stuck ame sensor (Stuck closed)

10 The gas is ignited but

the ame goes out

If a normal ignition takes place and after a short while the ame goes

out, check for the following:

• Radiant sensor contacts opening prematurely.

• Weak gas valve coil may open when stressed by higher Temps.

• Weak Hi-Limit

• Poor venting

• Bad drum seals

Improper drying

clothes wrinkled

Rough texture long

dry time

• Lint lter is not clean.

• Restriction in exhaust.

• Outside exhaust hood damper door stuck closed.

• Exhaust too long, too many elbows, ex ductwork installed.

• Poor intake air available for the dryer.

• Incorrect tumbler speed. Tumbler belt slipping.

•

Blower impeller bound; check for foreign material in blower area.

• Customer overloading dryer.

• Check clothing labels for fabric content and cycle selected.

• Clothes too wet due to insucient spin out by washer.

12 Noisy and/Or

Vibration

• Thumping Check for loose tumbler bae, rear tumbler roller(s)

worn or misaligned, out-of-round tumbler or high weld seam on

tumbler.

• Ticking Check for loose wire harness or object caught in blower

wheel area.

• Scraping Check for front or rear bulkhead felt seal out of

position or worn tumbler front bearings.

• Roaring Check for blower wheel rubbing on blower housing or

bad motor bearings.

• Popping or squealing sound. Check for a sticky or frayed belt.

TROUBLE SHOOTING

WARNING

To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before

servicing, unless testing requires power.

Technical_information-02365J_EN.indd 7 2012-06-05 �� 5:08:13

TROUBLE SHOOTING

WARNING

To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before

servicing, unless testing requires power.

COMPONENT TESTING PROCEDURES

Component Electrical Testing (with ohmmeter)

 Thermistor resistance 10K Ω @ 25°C 77°F

 Thermostat 1 resistance < 1Ω



Thermostat 3 resistance < 1Ω

- If resistance is innity, replace thermostat 3.



Thermostat 2 resistance < 1Ω

- If resistance is innity, replace thermostat 2.

 Heater resistance 10 Ω

- If resistance is innity, replace Heater.



Measure resistance of the following terminal

1) Door switch : open

Terminal : “COM” - “NC” (1-3) < 1Ω

Terminal : “COM” - “NO” (1-2) : ∞ Ω

2) Door switch push: On

Terminal : “COM” - “NC” (1-3) : ∞ Ω

Terminal : “COM” - “NO” (1-2) < 1Ω



Belt Cut-o S/W

- Lever open: Resistance value < 1Ω

- Lever push: Resistance value : ∞ Ω

 Lamp resistance 80~100 Ω (Violet & gray)

 Motor (Electronic & GAS)

Contacts

 = Contact closed

Centrifugal Switch (Motor)

2.88Ω between

Pin# 3 and 4

3.5Ω between

Pin# 4 and 5

Function 1M 2M 3M 5M 6M

Start

Run

Technical_information-02365J_EN.indd 8 2012-06-05 �� 5:08:15

GAS MODEL

TROUBLE SHOOTING

WARNING

To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before

servicing, unless testing requires power.

Radiant Sensor(10RS)

Resistance value < 1 Ω

If resistance is innite, replace Radiant sensor

Igniter(101D)

Resistance value 40~400 Ω

If resistance is innite, replace Igniter

Gas Valve(25M01A)

Valve 1-2 : Resistance value 1.2K Ω

Valve 1-3 : Resistance value 0.5K Ω

Valve 4-5 : Resistance value 1.2K Ω

If resistance is innity, replace Valve

Thermostat (60T21 Hi-Limit)230F-50F

Resistance value < 1 Ω

If resistance is innity, replace Thermostat

Technical_information-02365J_EN.indd 9 2012-06-05 �� 5:08:15

Steam Models Only

TROUBLE SHOOTING

WARNING

To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before

servicing, unless testing requires power.

CN1

1. AC Power Port

2. AC Power Off Detection

Sensor

3. Door Detection Sensor

RY5

- Motor Relay Switch

RY6

- Heater Relay Switch

Sensor Bars & temperature sensor check

Sensor Bars - Disconnect harness and test Pink

wire Pin 4 to Orange wire Pin 5.

Approx ∞ Ω without laundry

Approx 190Ω ± 10% with wet clothes

Cycling Thermostat - Disconnect harness and test

Blue wire Pin 2 to Red wire Pin 6.

Approx 10 KΩ at 25 °C/77 °F

Technical_information-02365J_EN.indd 10 2012-06-05 �� 5:08:16

Autres manuels pour DV363EWBEUF/A1

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Samsung Séchoir

Samsung

Samsung DV433ETGJWR/A1 Manuel utilisateur

Samsung

Samsung DV431AE Series Manuel utilisateur

Samsung

Samsung FlexDry DVE55M9600W Manuel utilisateur

Samsung

Samsung DV218AEW Manuel utilisateur

Samsung

Samsung DV431AEP/XAA Manuel utilisateur

Samsung

Samsung DV10B9750 Series Manuel utilisateur

Samsung

Samsung DVG45T6020 Series Manuel utilisateur

Samsung

Samsung DVG53BB8900 Series Manuel utilisateur

Samsung

Samsung DV36J4000E Series Manuel utilisateur

Samsung

Samsung DV3C6BGW/XAA Manuel utilisateur

Samsung

Samsung DVG45R6100W Manuel utilisateur

Samsung

Samsung DVEG50R5400 Series Manuel utilisateur

Samsung

Samsung DV9 Series Manuel utilisateur

Samsung

Samsung DV405 SERIES Manuel utilisateur

Samsung

Samsung DV330AE series Manuel utilisateur

Samsung

Samsung DV448AG series Manuel utilisateur

Samsung

Samsung DV90F5E6HGW Manuel utilisateur

Samsung

Samsung DV365ETBGWR/AC Manuel utilisateur

Samsung

Samsung DV25B6800E Series Manuel utilisateur

Samsung

Samsung DVG45T3200W/A3 Manuel utilisateur

Samsung

Samsung DV80T5420AB Manuel utilisateur

Samsung

Samsung DV CGC2 Series Manuel utilisateur

Samsung

Samsung DV22K6800 series Manuel utilisateur

Samsung

Samsung DV56H9100E Series Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
