Samsung NX-N2 Manuel utilisateur

User Manual

NX-N2

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00400A-00

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

4 Copyright

5 Icons used in this manual

5 Symbols for safety precautions

6 Securing the Installation Space

6 Precautions for storage

7 Safety Precautions

7 Electricity and Safety

8 Installation and Safety

10 Operation and Safety

PREPARATIONS 14 Checking the Components

14 Checking the Components

16 Parts

16 Front view

18 Reverse Side

19 Installation

19 Attaching the cradle

20 Attaching Products

21 Anti-theft Lock

USING "PCOIP" 22 What is a "PC over IP"?

23 Connection to Use "PCoIP"

23 Connection Using the DP Cable

24 Connecting to a Secondary Monitor

25 Connecting to Headphones

25 Connecting a Microphone

26 LAN Connection

27 Connecting USB Devices

28 Connecting the Power

29 Connect to the host PC using a LAN

cable

Table Of Contents

Table Of Contents 3

30 "PCoIP"

30 On Screen Display (OSD)

30 Connect Screen

31 OSD Options Menu

32 Configuration Window

46 Diagnostics Window

50 Information Window

52 User Settings Window

59 Password Window

61 Wake On LAN

62 Wake on USB

63 OSD Logo Upload

64 Firmwre Update

TROUBLESHOOTING

GUIDE

65 Requirements Before Contacting

Samsung Customer Service Center

65 Check the following.

SPECIFICATIONS 66 General

67 Power consumption

APPENDIX 68 Contact SAMSUNG WORLD WIDE

74 Responsibility for the Pay Service

(Cost to Customers)

74 Not a product defect

74 A Product damage caused by customer's fault

74 Others

76 Correct Disposal

76 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

76 Correct disposal of batteries in this product

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

The SAMSUNG logo is a registered trademark of Samsung Electronics.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair centre and there is no defect in the product

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is

carried out.

Before Using the Product

Icons used in this manual

Symbols for safety precautions

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Warning A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire and

damage the product. Be sure to allow the amount of space as shown below or greater when installing

the product.

The exterior may differ depending on the product.

This product can be installed in portrait or landscape orientation.

Precautions for storage

For information on how to clean the inside of the product, contact the service center (page 69) first.

(A service fee will be charged.)

3.93 inches

(10 cm)

3.93 inches

(10 cm)

3.93 inches

(10 cm)

3.93 inches

(10 cm)

3.93 inches

(10 cm)

Before Using the Product

Safety Precautions

The following images are for reference only. Real-life situations may differ from what is shown in

the images.

Electricity and Safety

Warning

Do not use a damaged power cable or plug, or a loose power socket.

An electric shock or fire may result.

Do not plug many products into the same power socket.

Otherwise, the socket may overheat and cause a fire.

Do not touch the power cable with wet hands.

Otherwise, an electric shock may result.

Insert the power cable all the way in so it is not loose.

An unstable connection may cause a fire.

Ensure you connect the power cable to a grounded power socket.

(type 1 insulated devices only).

An electric shock or injury may result.

Do not bend or pull the power cable with force. Do not weigh the power cable

down with a heavy object.

A damaged power cord may cause an electric shock or fire.

Do not place the power cable or product near heat sources.

An electric shock or fire may result.

If the power cable pins or power outlet is covered with a foreign substance (dust,

etc.), wipe it off using a dry cloth.

Otherwise, a fire may result.

Before Using the Product

Caution

Installation and Safety

Warning

Do not unplug the power cable when the product is in use.

The product may become damaged by an electric shock.

Do not use the power cable for products other than authorized products supplied

by Samsung.

An electric shock or fire may result.

Keep the power socket where the power cable is connected unobstructed.

If any problem occurs in the product, unplug the power cable to completely

cut the power to the product.

You cannot cut the power off completely using only the power button on the

product.

Hold the plug when disconnecting the power cable from the power socket.

An electric shock or fire may result.

DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP

OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.

Otherwise, a fire may result.

Avoid installing the product in a narrow space with bad ventilation, such as a

bookshelf or wall closet.

Otherwise, a fire may result due to an increased internal temperature.

Keep the plastic packaging bag for the product in a place that cannot be reached

by children.

Children may suffocate.

Before Using the Product

Caution

Do not install the product on an unstable or vibrating surface (insecure shelf,

sloped surface, etc.).

The product may fall and break or cause a personal injury.

Using the product in an area with excess vibration may damage the product

or cause a fire.

Do not install the product in a vehicle or a place exposed to dust, moisture (water

drips, etc.), oil, or smoke.

An electric shock or fire may result.

Do not expose the product to direct sunlight, heat, or a hot object such as a

stove.

Otherwise, the product lifespan may be reduced, or a fire may result.

Do not install the product within the reach of young children.

The product may fall and injure children.

Edible oil, such as soybean oil, can damage or deform the product. Do not install

the product in a kitchen or near a kitchen counter.

Take care not to drop the product when moving it.

Otherwise, product failure or personal injury may result.

Put down the product carefully.

The product may fall and break or cause a personal injury.

Before Using the Product

Operation and Safety

Warning

Installing the product in an unusual place (a place exposed to a lot of fine dust,

chemical substances, extreme temperatures or a significant presence of

moisture, or a place where the product will operate continuously for an extended

period of time) may seriously affect its performance.

Be sure to consult Samsung Customer Service Center (page 69) before

installation if you want to install the product at such a place.

Do not leave or install the product on the floor.

Abrupt force such as kicking or extra weight such as stepping on the

product may cause a product failure or personal injury.

High voltage runs through the product. Do not attempt to disassemble, repair, or

modify the product on your own.

An electric shock or fire may result.

Contact Samsung Customer Service Center (page 69) for repair.

Before moving the product, turn off the power and disconnect the power cable

and all other connected cables.

Otherwise, the power cord may be damaged and a fire or electric shock may

result.

If the product generates a strange noise, a burning smell, or smoke, remove the

power cable immediately and contact Samsung Customer Service Center

(page 69).

An electric shock or fire may result.

Ensure children do not sit on the product or kick the product.

The product may fall, and your child may become injured or seriously

harmed.

If the product falls or the exterior is damaged, power off the product, remove the

power cable, and contact Samsung Customer Service Center (page 69).

Otherwise, an electric shock or fire may result.

Do not sit on the product.

The product housing or connectors may get damaged or personal injury may

result.

SAMSUNG
