Samsung UPROAR SPH-m100 Guide de configuration

DUAL-BAND TRAINING GUIDE

TECHNICAL SUPPORT: 888.987.HELP NOT FOR RETAIL DISTRIBUTION

Specifications may change without notification.

Telephone Controls

TALK

Press to:

■

place and answer calls,

■

initiate Three-Way Calling,

■

answer a Call Waiting call,

■

review the last 5 outgoing, incoming and missed calls from Standby mode.

Press twice quickly to redial the last outgoing number.

CLEAR

Press to:

■

erase one character at a time,

■

return to the previous screen,

■

view phonebook entries from Standby mode.

Press and hold to:

■

erase all entered characters,

■

return to Standby mode while viewing menu options.

END / POWER

Press to:

■

end a call,

■

return to Standby mode,

■

mute the ringer on an incoming call,

■

exit MP3 player mode.

Press and hold to turn the phone on and off.

Press to display the Main Menu and to scan menu options a page at a time.

OK / MESSAGES

Press to:

■

save menu option settings and Internal Phone Book entries,

■

access voicemail, pages, text / browser messages or E-mail from Standby mode,

■

mute the ringer on an incoming call.

Press and hold to access voice messages in one step.

MP3 KEY

Press the MP3 key to scan menu options, entries in the Internal

Phone Book and Call Logs.

In Standby mode, press to enter MP3 Player mode.

POUND

You can skip a space when entering text by pressing .

ASTERISK

When entering text, lets you select upper or lower case.

VOLUME

Press the VOLUME buttons to:

■

adjust voice volume during conversation,

■

adjust ringer volume in Standby mode,

■

mute the ringer during an incoming call,

■

scroll menus, name/number entries and songs.

VOICE MEMO

Press to:

■

enter the voice memo menu.

Press and hold to:

■

record voice memos,

■

disable Key Guard.

Standard Package Contains:

■Dual-Band Samsung Uproar

■

Standard Lithium Ion Battery

■

Dual-Slot Desktop Charger

■

Stereo Headset and Remote

■

Headset Carry Case

■

USB Cable

■

MusicMatch Jukebox Plus Software

■Handstrap

■User Guide

■Quick Reference Card

■Accessory Guide

(Not actual size)

Samsung Uproar™

Charging Time With Accessories

Standard Battery Extended Battery

Dual-Slot Charger (front slot) 3 hrs. 4 hrs.

Travel Charger 3 hrs. 4 hrs.

Hands-Free Car Kit 3 hrs. 4 hrs.

Cigarette Lighter Adapter 3 hrs. 4 hrs.

Appearances and specifications subject to change without notice.

Accessories shown smaller than actual size.

Cigarette Lighter Adapter

The cigarette lighter adapter

offers the convenience of

operating or charging your

phone’s battery from vehicle

cigarette lighter sockets.

USB Cable

The USB cable connects

your phone to a personal

computer so you can

manage your MP3 play list.

Travel Charger

The travel charger is a

compact unit that plugs

into a wall outlet to charge

your phone’s battery when

you are traveling.

Hands-Free Car Kit *

The hands-free car kit

provides safety, freedom and

convenience in your vehicle.

*Professional installation is recommended.

Data Cable

Lets you use your Phone

linked to a laptop PC,

handheld or palm-sized

computing device to send

and receive e-mail messages

and browse the Internet.

Stereo Headset and

Remote

The stereo headset includes

earpieces, a microphone, and

an MP3 remote control in a

convenient, lightweight unit.

Dual-Slot Desktop Charger

The dual-slot desktop charger

efficiently charges the battery

at your home or office.

Lithium Ion Batteries

The standard LiIon battery

is ideal for everyday use.

The extended LiIon battery

provides longer talk and

standby times.

Standby Menu

Main Menu Menu Level 1 Menu Level 2

1) Music Mode ➪1) Play List ➪1) Play

2) Information

3) Erase

2) Play Mode ➪1) Rewind

2) Play/ Pause

3) Forward

4) Time Display

5) Repeating

6) Equalizer

3) Call Alert

4) Memory

5) Erase All

2) Calls ➪1) Outgoing

2) Incoming

3) Missed

4) Erase History ➪1) Outgoing

2) Incoming

3) Missed

4) All Calls

5) Air Time ➪1) Last Call

2) Lifetime

3) Phone Book ➪1) Find Name

2) Add New Entry

3) My Phone#

4) Find Entry

5) Services ➪1) Client Care

2) Dir Assist

4 ) Wireless Web (Content is determined by service provider)

5) Messages ➪1) Voicemail 1) Listen

2) Reset

2) Page/Text

3) Web Alerts

4) Erase 1) Page / Text

2) Web Alerts

6) Network ➪1) Set Mode

7) Calendar ➪1) Today

2) Month View

3) Jump to Date

4) To Do List

5) Countdown

6) Alarm Clock

7) World Clock

8) Set Time

8) Voice Dial ➪1) Record

2) Review

3) Erase All

4) Set Active SEND only

SEND / Flip

9) Setup/Tools ➪1) Sounds ➪1) Ringer Volume

2) Ringer Type

3) Key Beep

4) Tone Length

5) Alert

6) Roam Ringer

2) Display ➪1) Backlight

2) Banner

3) Contrast

4) Version

3) Data / Fax In

4) Security ➪1) Lock Phone

2) Change Lock

3) Special #

4) Erase Phonebook

5) Reset Phone

5) Call Answer ➪Any Key

SEND Key

Flip Open

6) Auto Answer ➪Ye s

Car Kit Only

7) Web Guard ➪To Start

Both

To End

None

8) Language English

Français

9) Calculator

0) SEND Key

(H x W x D)

Specifications

Operating Frequency PCS 1900 MHz / Analog 800 MHz

Graphic LCD 5 Lines (4 text lines, 1 icon line)

Battery Type

Standard: 800 mAh Lithium Ion

Extended: 1300 mAh Lithium Ion

PCS Antenna Dual Band Retractable

Standard Battery Extended Battery

Dimensions

4.1 x 1.8 x 0.9 in 4.1 x 1.8 x 1.0 in

106 x 45 x 23 mm 106 x 45 x 26 mm

Weight 4.2 oz 4.8 oz

119 g 136 g

Talk Time 3.3 hrs. digital 5.0 hrs. digital

(up to) 1.0 hrs. analog 1.5 hrs. analog

Standby Time 140 hrs. digital 210 hrs. digital

(up to) 16 hrs. analog 24 hrs. analog

In Use Menu

The In Use Menu options are available in Conversation Mode

1. (Un)Mute

2. 3-Way Call

3. Calls

4. Messages

5. Phone Book

6. Calendar

0. Version

(Not actual size)

Basic Operations

Turn On / Off Press and hold .

Menu Scrolling Press , and then , or .

Make Calls Enter number, and then press .

Correct Mistakes Press .

Redial Call Press twice.

1, 2 or 3-touch Dialing

Enter memory location, and hold the

final digit.

End Call Press .

Answer Call Press .

Save Numbers After entering number, press and

follow the screen prompts.

Outgoing Numbers Press , , in sequence to

review the last 10 outgoing calls.

Incoming Numbers Press , , in sequence to

review the last 10 incoming calls.

Missed Calls Press , , in sequence to

review the last 10 missed calls.

Phone Book Press in standby mode.

Display Icons

Graphic LCD Screen

Signal

Strength

Roaming Analog

Mode

Battery

Strength

No Service

/ In Use

New

Message

Vibrate

Alert

Special Functions

1. Digital Voice Activated Dialing

You can train the phone to recognize up to 20 verbal entries.

Record and review entries through the Main Menu. To place a call,

press and hold or open the flip (according to your menu

setting), wait for the prompt, and then say the name into the

phone. This feature works wherever digital service is available.

2. Finding Phone Book Entries

The phone stores 229 name / number entries alphabetically and

by Phone Book entry number. Press ,, in

sequence to review name entries alphabetically.

3. Call Logs

Logs the last 10 outgoing, incoming and missed calls. To access

call logs, press ,, in sequence for outgoing calls,

press ,, in sequence for incoming calls, and press

,, in sequence for missed calls.

4. Vibrate Alert

The Vibrate option provides a silent incoming call alert.

Press or in standby mode to scroll through alert

options in order to set Vibrate Alert.

5. Ring Tone Mute

Mute the ringer during an incoming call by pressing or .

Samsung Uproar™Features

■64MB of MP3 Storage

■Voice Dialing (20 locations)

■Dual Band / Dual Mode

■Web Browser

■Animated User Interface

■Vibrate Alert

■Voice Memo

■Data & Fax Capable

■Organizer

■Text Messaging

■Caller ID

■Ring Tone Mute

■229 Phone Book Entries

■Active Flip

*Voice-activated dialing is only available on PCS digital networks.

MP3 Player Controls

PLAY / PAUSE

Press to:

■

play current song,

■

pause a song that is playing,

■

return to Music Mode from Standby mode while playing.

REWIND

Press to:

■ j

ump to previous song during first two seconds of a song,

■

return to the beginning of a song after the first two seconds.

Press and hold to:

■

rewind portions of a song that is playing.

PLAY / PAUSE

Press to:

■

play current song,

■

pause a song that is playing.

FORWARD

Press to:

■ j

ump to next song.

Press and hold to:

■

fast forward through portions of a song that is playing.

TIME

Press to display the currently playing song’s total length

and elapsed time.

REPEAT

Press to select between the repeat options:

Normal – each song will play in order one time,

– the current song will replay until stopped,

– each song will play in order continuously,

– songs in the play list will be chosen randomly.

EQUALIZER

Pressing the key lets you to select one of these equalization

settings: Normal, , , or .

RECORD CLIP

By pressing and holding you can mark a portion of a song

to repeat. When you release the button, that passage will replay

twice and then regular play will resume.

Stereo Headset

The Stereo Headset with Remote plugs into

the Headset Jack as shown. The MP3 player

can also be used with any headset or

self-powered multi-media style speakers that

has a standard 1/8 inch plug. When doing so,

you will lose the included headset’s hands-free

abilities and remote control.

With appropriate cables, the Samsung Uproar

can even be used as an audio source for a home

stereo, portable stereo or car stereo that offers

an auxiliary input. These cables are widely

available, and any salesperson knowledgeable

in electronics and audio should be able to

help select the correct one.

Pressed within first two

seconds of a song, jumps to

previous track; after two

seconds jumps to beginning

of the current song.

Press and hold to rewind

within same track.

Secondary Headset

Volume Control

This control and the

phone’s volume work

independently. Always check

both before playing music.

Press to jump to

the next track.

Press and hold to

fast forward within

the same track.

The remote’s buttons

are disabled when set

in “HOLD” position.

Play / Pause

Press and hold to mark

a passage to repeat.

Press to answer an

incoming call or press

and hold to initiate

voice dialing.

Headset Remote Functions

Audio controls on the headset remote will mute the

ringer on incoming calls.

Downloading MP3 Music Files

Before downloading MP3 music files into your phone, you must

download them from the appropriate Internet site to your PC or

record (“rip”) them yourself from CD’s or other sources.

Downloading MP3 files on your PC to your phone:

1. Insert one end of the download cable sup-

plied with the phone to the connector on

the bottom of your phone.

2. Insert the other end of the cable into the

USB port on the PC.

3. The phone will display a screen indicating

that it is properly connected.

4. Double-click the MusicMatch Jukebox

icon on the PC’s Desktop.

5. You can also open the MusicMatch

Jukebox by selecting programs from the

Start menu, then selecting MusicMatch

Jukebox.

6. The MusicMatch Jukebox window opens.

It may take a couple of seconds for your

phone to connect with the PC.

Samsung Telecommunications America Background Information

Samsung Telecommunications America, Inc. (STA), based in Dallas,Texas, was established in

1997 to research, develop and market handheld wireless phones, wireless communications

infrastructure systems and network products. Less than one year after its U.S. launch STA

reached an industry milestone by shipping more than one million wireless handsets to the

U.S. market. In addition, the company has more than a decade of experience in supplying

wireless infrastructure and handsets to the world's largest CDMA system in service today.

In the wireless terminals market, the company has signed contracts with several leading

providers of wireless communications services, including Sprint PCS, Bell Mobility and

AT&T Wireless Services.The company supplies Code Division Multiple Access (CDMA)

handsets, including single-band CDMA, dual-band/dual-mode CDMA, tri-mode CDMA and

dual-mode cellular handsets.

Samsung Telecommunications America, a Dallas-based subsidiary of Samsung Electronics

Company, researches, develops, and markets telecommunications and data communications

systems and products throughout North America. STA has four main business groups:

Wireless Terminals,Wireless Systems, Broadband Network Terminals and Business

Communications. Samsung Electronics Company, Ltd., a $22.8 billion flagship company of

the Samsung Group, is a worldwide producer of telecommunications systems, consumer

appliances,A/V equipment, computers, printers, and semiconductors.

Printed in Canada

19220000028

02/01.4,000

SAMSUNG TELECOMMUNICATIONS AMERICA

1130 E. Arapaho Road

Richardson,TX 75081

1-800-SAMSUNG

www.samsung.ca

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung Téléphone portable

Samsung

Samsung SM-T377W Manuel utilisateur

Samsung

Samsung Galaxy S6 edge Manuel utilisateur

Samsung

Samsung Wave GT-S8500 Manuel utilisateur

Samsung

Samsung SGH-200 Manuel utilisateur

Samsung

Samsung SM-J700H/DS Manuel utilisateur

Samsung

Samsung B2700 Manuel utilisateur

Samsung

Samsung Galaxy TAB4 Manuel utilisateur

Samsung

Samsung SM-A510FD Manuel utilisateur

Samsung

Samsung Comment SCH-R380 Manuel utilisateur

Samsung

Samsung GT-E1195 Manuel utilisateur

Samsung

Samsung Galaxy J7 Manuel utilisateur

Samsung

Samsung SGH-T259 Series Manuel utilisateur

Samsung

Samsung Galaxy S4 Manuel utilisateur

Samsung

Samsung Galaxy S23 Manuel utilisateur

Samsung

Samsung GALAXY SIII Manuel utilisateur

Samsung

Samsung GT-S5600H Manuel utilisateur

Samsung

Samsung SGH F480 Manuel utilisateur

Samsung

Samsung Galaxy S7 Edge SM-G935F Manuel utilisateur

Samsung

Samsung SM-J600F Manuel utilisateur

Samsung

Samsung GALAXY J7 PERX Manuel utilisateur

Samsung

Samsung SGH-i728 Manuel utilisateur

Samsung

Samsung SGH-ZV10 Manuel utilisateur

Samsung

Samsung GT-B7330 Manuel utilisateur

Samsung

Samsung SCH-A630 Series Manuel utilisateur

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Nokia

Nokia Lumia 620 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur
