Samsung SGH-L170 Manuel utilisateur

SGH-L170

• 3G

• MobileBlog

•RSS reader

•Camera and camcorder

•Synchronisation with Windows Media Player

•Voice recorder

SGH-L170

Quick Start Guide

102

Features

Precautions

Phone Layout

Set & Link

Basic Use

Unpack

Solving Problem

01 CONTENTS

Contents

Contents_01

• Your phone is capable of operating in a 3G environment, allowing much greater data transfer speed, video

streaming, and video conferencing.

MOBILEBLOG

• Share your photos and videos on photo sharing websites and blogs.

RSS READER

• Use RSS reader to get the latest news from your favourite websites.

CAMERA AND CAMCORDER

• Use the camera module on your phone to take a photo or record a video.

SYNCHRONISATION WITH WINDOWS MEDIA PLAYER

• Transfer music les to your phone directly from Windows Media Player.

MUSIC PLAYER

• Play music les on your phone. You can use other phone functions while listening to music.

FM RADIO

• Listen to your favourite radio stations anytime, anywhere.

DIGITAL DATA PRINTING

• Print images, messages, and personal data directly from your phone.

BLUETOOTH

• Transfer media les and personal data, and connect to other devices using wireless Bluetooth technology.

WEB BROWSER

• Access the wireless web to get up-to-the-minute information and a wide variety of media content.

VOICE RECORDER

• Record memos or sounds.

Failure to comply with the following precautions may be dangerous or illegal.

DRIVE SAFELY AT ALL TIMES

• Do not use a hand-held phone while driving. Park your vehicle rst.

SWITCH OFF IN AN AIRCRAFT

• Wireless phones can cause interference.

Using them in an aircraft is both illegal and dangerous.

SWITCH OFF THE PHONE WHEN REFUELLING

• Do not use the phone at a refuelling point (service station) or near fuels or chemicals.

INTERFERENCE

• All wireless phones may be subject to interference, which could affect their performance.

02 FEaTurES

Features

Features / Precautions _02

03 PrECauTiONS

Precautions

SWITCH OFF THE PHONE NEAR ALL MEDICAL EQUIPMENT

• Hospitals or health care facilities may be using equipment that could be sensitive to external radio

frequency energy. Follow any regulations or rules in force.

BE AWARE OF SPECIAL REGULATIONS

• Meet any special regulations in force in any area and always switch off your phone whenever it is

forbidden to use it, or when it may cause interference or danger.

WATER RESISTANCE

• Your phone is not water-resistant. Keep it dry.

SENSIBLE USE

• Use only in the normal position (held to your ear). Avoid unnecessary contact with the antenna when

the phone is switched on.

EMERGENCY CALLS

• Key in the emergency number for your present location, then press .

KEEP YOUR PHONE AWAY FROM SMALL CHILDREN

• Keep the phone and all its parts, including acces sories, out of the reach of small children.

ACCESSORIES AND BATTERIES

• Use only Samsung-approved batteries and accessories, such as headsets and PC data cables.

Use of any unauthorised accessories could damage you or your phone and may be dangerous.

QUALIFIED SERVICE

• Only qualied service personnel may repair your phone

03 PrECauTiONS

Precautions

Precautions / Phone Layout _03

03 PhONE LayOuT

Phone Layout

The following illustrations show the main elements of your phone:

EARPIECE

DISPLAY

RIGHT SOFT KEY

POWER/MENU

EXIT KEY

FRONT CAMERA

LENS

MOUTHPIECE

MENU ACCESS OR

WEB ACCESS/

CONFIRM KEY

(CENTRE)

APPLICATION

SWITCH KEY

MULTIFUNCTION JACK

LEFT SOFT KEY

DIAL KEY

REAR CAMERA

LENS

VOLUME KEYS

CAMERA/

VIDEO CALL KEY

NAVIGATION KEY

(UP/DOWN/LEFT/RIGHT)

ALPHANUMERIC

KEYS

SPECIAL

FUNCTION KEYS

04 SET & LiNK

Set & Link

Set & Link / Basic Use _04

05 BaSiC uSE

Basic Use

The following illustrations show the main elements of your phone:

INSERT THE SIM CARD.

SREATTACH THE BATTERY COVER.

INSERT THE BATTERY.

PLUG THE TRAVEL ADAPTER INTO THE PHONE.

To AC power outlet

MAKE OR ANSWER CALLS

Making a call

To make a voice call:

1. In Idle mode, enter an area code and phone number.

2. Press [Send]. Press [Volume] to adjust the volume.

3. Press [End] to end the call.

To make a video call:

1. In Idle mode, enter an area code and phone number.

2. Press [ ].

3. Press [End] to end the call.

ANSWERING A CALL

1. When the phone rings, press [Send].

If it is a video call, press <Show me> to allow the

caller to see you via the camera.

2. Press [End] to end the call.

T9 MODE

To enter a word:

1. Press [2] to [9] to start entering a word.

2. Enter the whole word before editing or deleting

characters.

3. When the word displays correctly, press [#] to insert

a space.

Otherwise, press [0] to display alternative word choices.

ABC MODE

To enter a word:

Press the appropriate key until the character you want

appears on the display.

Unpack

Make sure you have each item

• Phone

• Travel adapter

• Battery

• User’s Guide

You can obtain various accessories from your local Samsung dealer.

Note: The items supplied with your phone and the accessories available at your

Samsung dealer may vary, depending on your country or service provider.

When you switch your phone on, the following messages may appear

“INSERT SIM”

•

Make sure that the SIM card is correctly installed

“PHONE LOCK”

•

The automatic locking function has been enabled.

You must enter the phone’s password before you can use the phone.

ENTER PUK

•

The PIN code was entered incorrectly three times in succession and the phone is now blocked.

Enter the PUK supplied by your service provider.

ENTER PIN

•

You are using your phone for the rst time.

You must enter the Personal Identication Number (PIN) supplied with the SIM card.

•

The PIN Check feature is enabled. Every time the phone is switcshed on,

the PIN has to be entered. To disable this feature, use the PIN check menu.

“NO SERVICE,” “NETWORK FAILURE,” OR “NOT DONE” DISPLAYS

•

The network connection has been lost. You may be in a weak signal area. Move and try again.

•

You are trying to access an option for which you have not taken out a subscription

with your service provider. Contact the service provider for further details.

YOU HAVE ENTERED A NUMBER BUT IT WAS NOT DIALLED

•

Make sure that you have pressed SEND

•

Make sure that you have accessed the right cellular network.

•

Make sure that you have not set an outgoing call barring option.

A CALLER CANNOT REACH YOU

•

Make sure that your phone is switched on. (Press END for more than one second.)

•

Make sure that you are accessing the correct cellular network.

•

Make sure that you have not set an incoming call barring

option.

06 uNPaCK

UNPACK / Solving Problem_05

07 SOLviNg PrOBLEm

Solving Problem

07 SOLviNg PrOBLEm

Solving Problem

Solving Problem_06

YOUR VOICE IS NOT HEARD AT THE OTHER END

•

Make sure that you have switched on the microphone.

•

Make sure that you are holding the phone close enough to your mouth.

The microphone is located at the bottom of the phone.

THE PHONE STARTS BEEPING AND “BATTERY LOW” FLASHES ON THE DISPLAY

•

Your battery is insufciently charged. Recharge the battery.

THE AUDIO QUALITY OF THE CALL IS POOR”

•

Check the signal strength indicator on the display ( ).

The number of bars indicates the signal strength from strong ( ) to weak( ).

•

Try moving the phone slightly or moving closer to a window if you are in a building.

NO NUMBER IS DIALLED WHEN YOU RE-CALL A ADDRESS ENTRY

•

Use the Phonebook feature to ensure the number has been stored correctly.

•

Store the number again, if necessary.

THE BATTERY DOESN’T CHARGE PROPERLY OR THE PHONE SOMETIMES

TURNS ITSELF OFF

•

Wipe the charging contacts both on the phone and on the battery with a clean soft cloth.

IF THE ABOVE GUIDELINES DO NOT HELP YOU TO SOLVE THE PROBLEM, TAKE NOTE OF

•

The model and serial numbers of your phone

•

Your warranty details

•

A clear description of the problem
