Samsung SGH-I530 Manuel utilisateur

Mobile Power Tool and

Communicator

SGH-i530

Quick Reference Guide

Welcome

This quick reference guide for the SGH-i530 PDA

phone contains information on basic features and

uses for your PDA phone, such as installing the

battery and SIM card, charging the battery, and

making calls. This guide will help your to get to

know your PDA phone quickly and easily.

For further details about using your PDA phone

features, please refer to the User’s Guide on the

supplied CD-ROM.

Important Safety

Precautions

Read these guidelines before using your wireless

phone. Failure to comply with them may be

dangerous or illegal.

Road Safety at All Times

Do not use a hand-held phone while driving; park

the vehicle first.

Switching Off When Refuelling

Do not use the phone at a refuelling point

(service station) or near fuels or chemicals.

Switching Off in Aircraft

Wireless phones can cause interference. Using

them in an aircraft is both illegal and dangerous.

Switching Off in Hospitals

Switch off your phone near medical equipment.

Follow any regulations or rules in force.

Interference

All wireless phones may be subject to

interference, which could affect their

performance.

Special Regulations

Meet any special regulations in force in the area

you are in and always switch off your phone

whenever it is forbidden to use it, or when it may

cause interference or danger (in a hospital for

example).

Sensible Use

Use only in the normal position (held to the ear).

Avoid unnecessary contact with the antenna

when the phone is switched on.

Emergency Call

Ensure the phone is switched on and in service.

Cancel all running applications before making an

emergency call. Key in the emergency number

for your present location, then press the

button. Give all the necessary information as

accurately as possible. Do not cut off the call

until given permission to do so.

Water Resistance

Your phone is not water-resistant. Keep it dry.

Accessories and Batteries

Use only Samsung-approved accessories and

batteries.

Qualified Service

Only qualified service personnel may install or

repair your phone.

For more detailed safety information, see “Health

and Safety Information” on page 20.

CAUTION

RISK OF EXPLOSION IF A BATTERY IS REPLACED BY

AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE

INSTRUCTIONS.

What’s in the Box?

Your package contains the following items:

Note:

The items supplied with your PDA phone

may differ depending on your country.

Getting to Know Your

PDA Phone

Front View

With the phone closed

Handset Batteries Travel Charger

Desktop Holder

& USB Cable

Straight Headset PC Install CD

Quick Reference

Guide

Stylus Pen Finger Strap

Front display

Camera

Service light/

Camera flash

With the phone open

Side View

Left

Right

Microphone

Home/Left

soft button

DDM (Drop Down Menu)

/Right soft button

Ta l k b u t t o n Clear button

Scroll buttons

Number keypad

End button

Reset

button

Application

buttons

Earpiece

OK button

Charging/

communication

port

Tool icons

panel

Main display

Volume buttons

Infrared port

Headset jack

Camera button

Home/Phone switch,

Camera flash on/off

button

Expansion card slot

Stylus

Rear View

Buttons

Button Description

Volume buttons

• Adjust the earpiece volume during a call.

• Scroll the screen up or down by one

page in the Application Launcher.

• Scroll through the records or options

when a record or pick list opens.

• Adjust the key tone volume in the

Phone’s Standby mode.

Battery

Antenna

Battery lock Speaker

Stylus

Application buttons

Activate the individual applications that

correspond to the icons on the buttons;

Phonebook, Date Book, Browser, and

Messaging. You can reassign these buttons

to activate any application.

Home button

(

Left soft button

)

• Switches to the Application Launcher in

an application.

• Allows you to view the applications by

category in the Application Launcher.

• Performs the functions indicated by the

text above it, on the bottom line of the

display in the Phone application.

Drop down menu button

(

Right soft

button

)

• Opens or closes the drop-down menu bar

in the Application Launcher.

• Performs the functions indicated by the

text above it, on the bottom line of the

display in the Phone application.

Button Description

Scroll buttons

• Scroll through application icons in the

Application Launcher.

• Scroll through the records or options

when a record or pick list opens.

• The Up and Down buttons scroll through

the records or options when a record or

pick list opens. They move the cursor up

or down

in a text input field

OK button

Confirms your selection or input.

Talk button

• Makes or answers a call.

• Retrieves the last numbers dialled or

received in the Phone’s Standby mode.

Clear button

• Deletes the character to the left from the

display.

• Deletes all of the characters when held

down.

End button

• Switches to the Phone application in any

application.

• Ends the call in the Phone application.

• Turns the phone on or off when held

down.

Button Description

Alphanumeric buttons

Enter numbers, letters, and some special

characters.

Asterisk button

Changes the text input mode in a text

input field when held down. Also changes

the letter-case in a text input mode.

Pound button

• Enters or exits Quiet mode when held

down in the Phone’s Standby mode.

• Enters a space in a text input field.

Home/Phone Switch button

• Switches between the Application

Launcher and Phone application.

• Turns on or off the flash in the Camera’s

Preview mode.

Camera button

• Opens the Camera application and

switches to Preview mode when held

down.

• Takes a photo in Preview mode.

Button Description

Tool Icons

Display Indicators

When your PDA phone is powered on, the

folloiwng icons are availble on the top line of the

display:

Icon Description

Home icon

• Opens the Application Launcher.

• Allows you to view the applications by

category when tapped repeatedly.

Menu icon

: Opens/closes the drop-down

menu list in an application.

Find icon

: Allows you to find specific text

in records or notes.

Graffiti icon

: Allows you to use the

Graffiti commands.

Keyboard icon

: Opens the onscreen

keyboard in the text input field.

Icon Description

Shows the received signal strength. The

more bars, the stronger the signal.

Appears when a call is in progress.

Appears when you are out of a service

area. When it displays, you cannot make

or receive a call.

Appears when you have set an alarm or a

wake-up call to ring at a specified time.

Appears when a new message has been

received. The following indicators are

available, depending on the message

type:

• : MMS message

• : Voice mail

• : SMS message

Appears when you set incoming calls to be

diverted to another destination.

Appears when Graffiti input mode is

enabled.

Getting Your PDA

Phone Ready to Go

1. Insert the SIM Card

Insert and slide the SIM card under the two tabs,

as shown, ensuring that the gold coloured metal

contacts of the card face down into the PDA

phone.

2. Install the Battery

1. Place the battery on the back of your PDA

phone.

Appears when you are out of a service

area and have logged onto a different

network; for example, when travelling in

other countries.

Appears when your PDA phone is

connected to the GPRS network.

Appears when you are in the Home zone,

if your service provider supports it.

Appears when you are in the Office zone,

if your service provider supports it.

Appears to tell you the current text input

mode. The following indicators are

available, depending on the input mode:

• : T9 mode

• : ABC mode

• : Number mode

Appears when you set the phone to

vibrate at an incoming call.

Appears when Quiet mode is active.

Shows the level of your battery power.

The more bars you see, the more power

you have remaining.

Icon Description

2. Slide the battery upwards until it clicks into

place.

3. Charge the Battery

Using the Desktop Holder

1. Plug the connector of the travel charger into

the jack at the rear end of the desktop holder.

2. Plug the travel charger into the AC wall outlet.

The indicators on the desktop holder blink.

3. Lift the frame towards the base so that it is at

a 45

angle and cannot move back any

further.

4. Select one of the following:

• Place the entire phone with the battery

attached into the desktop holder, bottom

first, so the data connector is inserted. Then

push the PDA phone backwards into the

frame until you hear a click.

Battery charge

indicator

Phone charge

indicator

Base

Frame
