Samsung Infuse i997

Screen Repair Guide

Touch Screen & LCD Screen Repair

For more instructional repair guides for other makes or models, view our full catalog of Repair Guides!

This is the Samsung Infuse i997 take apart repair guide. Following this guide will help you take apart the Samsung Infuse

i997 fairly easily in a step by step manner giving you a chance to replace faulty parts. Once you have replaced the parts

you want, the guide can be used in reverse to put everything back together again.

This guide will help you to install the following Samsung Infuse i997 parts:

•Samsung Infuse i997 LCD + Touch Screen Digitizer Replacement

•And Other Samsung Infuse i997 Parts

Tools Required:

•Safe Open Pry Tool

•Small Phillips Screwdriver

•Adhesive Strips

•Heat Gun / Hair Dryer

Samsung Infuse i997 take apart/repair guide:

•To get in started, make sure that the device is off and remove the back battery cover. Also remove the battery, the

memory card, and the sim card.

•Now, we have six (6) small Phillips screws to remove as shown in Figure 1.

Figure 1

•With the screws released, turn the phone over and use a safe open pry tool between the screen assembly and

back housing.

•Use a safe open pry tool as shown on Figure 2 to release the clips and remove the back housing.

Figure 2

•We have two (2) small Phillips screws that need to be removed - located in orange in Figure 3. Use a safe open

pry tool to release the four (4) pop connectors (red) on the motherboard.

Figure 3

•You can now ease off the motherboard carefully, being sure not to rip any cables.

•Now, use a heat gun or hair dryer to warm the adhesive holding the screen assembly to the front housing. Use

medium heat on the front of the screen, consistently moving around the screen edges. This should take no longer

than 1 minute.

•Use a safe open pry tool to release the screen assembly from the housing. Reheat if the adhesive is still strong.

•Remove the screen from the housing and replace.

Your Samsung Infuse is now disassembled and ready for replacement of part(s). Reverse the

instructions above to reassemble your Infuse.

Notice:

Repairs Universe's guides are for informational purposes only. Please click here for details.

Learn about restrictions on reproduction and re-use of Repairs Universe's repair/take-apart/installation guides, and about

creating hyperlinks to our guides.
