Samsung Galaxy Note 3 Instructions d'installation

•

5-0016 Small Phillips Screwdriver

5-0019 Plasc Opening Tools

5-0022 Nylon Spudger

5-0458 An-Stac Wrist Strap

5-1370 Fine Tip Curved Tweezers

Heat Gun / Blow Dryer

Samsung Galaxy Note 3 (SM-N900T)

DISASSEMBLE GUIDE

Page 1 of 7

Recommended Tools

hp://www.ﬁxez.com/

This guide will show you how to completely disassemble the Samsung Galaxy Note 3 smartphone, assisng in

making the DIY repair of the device both simple, and safe. Following the comprehensive steps we have

provided will help you quickly replace not only a broken Note 3 display assembly, but also any other internal

components that may have become faulty or damaged.

You can ﬁnd a full archive of ﬁxez.com disassemble guides and HD repair videos, for numerous makes and

models of smartphones and tablets, by vising hp://www.ﬁxez.com.

Samsung Galaxy Note 3 (SM-N900T) – Disassemble Guide

Page 2 of 7

hp://www.ﬁxez.com/

Baery

On the audio jack side of the smartphone, insert the

plastic opening tool in the notch located in the back

cover. Work your way around the entire Note 3, gently

free the clips and then remove the back battery cover

from the smartphone.

Use the plastic opening tool to pry the battery up and

out of its secured location.

The SIM card and the microSD card should now both be

easily accessible, remove them from the Galaxy Note 3.

Next, locate and remove the twelve small Phillips screws

(#00) that secure the rear housing and loudspeaker to

the front housing and display assembly.

Loud Speaker

Samsung Galaxy Note 3 (SM-N900T) – Disassemble Guide

Page 3 of 7

hp://www.ﬁxez.com/

Slide the stylus pen out of its location and remove it

from the smartphone.

The rear housing and loudspeaker can be removed

using your curved tweezers. Begin the separation

toward the bottom of the smartphone and work

around the entire perimeter releasing the clips and

removing the rear housing.

Locate and release the coaxial cable connections, use

the nylon spudger or fine tip curved tweezers to pry

them up from their sockets (marked with orange

circles).

Now locate and release the six wafer connections, use

the nylon spudger or fine tip curved tweezers and pry

them up from their sockets (marked with orange

rectangles).

Samsung Galaxy Note 3 (SM-N900T) – Disassemble Guide

Page 4 of 7

hp://www.ﬁxez.com/

You can now remove the motherboard from the Note 3.

Carefully maneuver it around the released connections

and lift it away from the smartphone.

With your fine tip curved tweezers, remove the

rear-facing camera by prying up and releasing the cable

on the bottom side of the motherboard.

There is a metal clip securing the front-facing camera

and proximity sensor assembly into the smartphone.

Remove the clip and then use the fine tip curved

tweezers or nylon spudger to pry up and release the

front-facing camera and proximity sensor assembly

cable.

Rear-Facing Camera

Front-Facing Camera & Proximity Sensor Assembly

Samsung Galaxy Note 3 (SM-N900T) – Disassemble Guide

Page 5 of 7

hp://www.ﬁxez.com/

Locate and remove the one small Phillips screw (#00)

that secures the audio jack and earpiece speaker

assembly (marked with orange circle).

Now use the fine tip curved tweezers to gently

maneuver the assembly up and out of the Note 3.

10.

The dock connector assembly is held in place by

adhesive, with your nylon spudger gently pry it up and

remove it from the Galaxy Note 3 (the use of a heat

gun is optional to soften the adhesive).

11.

At this time, the display assembly (LCD & touch screen) is

fused together and cannot be separated. It is secured to

the front housing/frame of the smartphone with a lot of

adhesive that will require heat and patience in order to

separate.

This procedure is recommended only on a Note 3 with a

display assembly that is already cracked or damaged.

Using the heat gun, begin warming up the adhesive that

secures the LCD & touch screen digitizer assembly to the

smartphones front housing/frame.

12.

Audio Jack & Earpiece Speaker Assembly

Dock Connector Assembly

Display Assembly (LCD & Touch Screen Digizer)

Samsung Galaxy Note 3 (SM-N900T) – Disassemble Guide

Page 6 of 7

hp://www.ﬁxez.com/

Home Buon Assembly

Next, to begin the separation of the display assembly

from the front housing/frame, use a small screwdriver

and through the front-facing camera hole push the

damaged display away from the front housing/frame.

Make sure you have a firm grip of the front

housing/frame.

13.

Using your nylon spudger or plastic opening tool, and

additional heat if necessary, continue working the

display assembly away from the front housing/frame.

Be mindful of the home button assembly toward the

bottom of the Note 3, it can easily become damaged if

you’re too aggressive around its location.

14.

With your display assembly completely peeled away

from the front housing/frame, you can now use the

nylon spudger to carefully remove the home button

assembly.

15.

Breakdown

Samsung Galaxy Note 3 (SM-N900T) – Disassemble Guide

Page 7 of 7

hp://www.ﬁxez.com/

1. Samsung Galaxy Note 3 Back Cover

2. Samsung Galaxy Note 3 Rear Housing

3. Samsung Galaxy Note 3 Frame/Front Housing

4. Samsung Galaxy Note 3 Display Assembly (LCD & Touch

4. Screen)

5. Samsung Galaxy Note 3 Motherboard

6. Samsung Galaxy Note 3 Battery

7. Samsung Galaxy Note 3 Home Button Assembly

8. Samsung Galaxy Note 3 Stylus Pen

9. Samsung Galaxy Note 3 Rear-Facing Camera

10. Samsung Galaxy Note 3 Front-Facing Camera & Proximity

10. Sensor Assembly

11. Samsung Galaxy Note 3 Audio Jack & Earpiece Speaker

11. Assembly

12. Samsung Galaxy Note 3 Home Button

13. Samsung Galaxy Note 3 Dock Connector Assembly

1 2 34

910 11

Noce/Warning:

FIXEZ.COM DOES NOT ACCEPT ANY LIABILITY FOR DAMAGE, OR INJURY CAUSED, WHILE YOU ARE

FOLLOWING OUR DISASSEMBLE GUIDES. WE MAKE NO REPRESENTATIONS, WARRANTIES, OR

CONDITIONS OF ANY KIND, EXPRESS OR IMPLIED. UTILIZING THESE GUIDES TO HELP ASSIST YOU IN

REPAIRING YOUR MOBILE DEVICES WILL VOID YOUR WARRANTY. FIXEZ.COM STRICTLY PROHIBITS

ALTERING OR MODIFYING OUR DISASSEMBLE GUIDES FOR COMMERCIAL USE, REPRODUCTION, OR

PUBLICATION.
