Samsung Galaxy A Series Manuel utilisateur

www.samsung.com

USER MANUAL

English. 06/2019. Rev.1.0

SM-G398FN

SM-G398FN/DS

Table of Contents

Basics

4 Read me first

7 Device overheating situations and

solutions

10 Device layout and functions

14 Battery

19 SIM or USIM card (microSIM card)

21 Memory card (microSD card)

23 Attaching a hand strap

24 Turning the device on and off

25 Initial setup

26 Samsung account

27 Transferring data from your previous

device (Smart Switch)

29 Understanding the screen

39 Notification panel

41 Entering text

Apps and features

43 Installing or uninstalling apps

45 Phone

50 Contacts

55 Messages

57 Internet

59 Email

60 Camera

70 Gallery

75 Multi window

78 Samsung Health

81 Galaxy Wearable

81 Samsung Members

81 Samsung Notes

82 Calendar

84 Voice Recorder

85 My Files

85 Clock

87 Calculator

87 Radio

88 Game Launcher

91 Bixby Home

93 Reminder

97 Kids Home

98 SmartThings

102 Sharing content

104 Google apps

Table of Contents

137 Device care

137 Optimising your device

138 Battery

139 Storage

139 Memory

139 Security

140 Apps

140 General management

141 Accessibility

142 Software update

142 User manual

143 About phone

Appendix

144 Troubleshooting

Settings

106 Introduction

106 Connections

107 Wi-Fi

109 Bluetooth

111 NFC and payment

113 Data saver

113 Mobile data only apps

114 SIM card manager (dual SIM

models)

114 Mobile Hotspot and Tethering

115 More connection settings

118 Sounds and vibration

118 Dolby Atmos (surround sound)

119 Separate app sound

119 Notifications

120 Display

121 Blue light filter

121 Night mode

122 Screensaver

122 Wallpapers and themes

123 Lock screen

123 Smart Lock

124 Security

125 Secure Folder

129 Accounts and backup

130 Samsung Cloud

132 Google

132 Advanced features

133 Motions and gestures

134 Dual Messenger

135 Digital wellbeing

Basics

Read me first

Please read this manual before using the device to ensure safe and proper use.

•

Descriptions are based on the device’s default settings.

•

Some content may differ from your device depending on the region, service provider,

model specifications, or device’s software.

•

Content (high quality content) that requires high CPU and RAM usage will affect the

overall performance of the device. Apps related to the content may not work properly

depending on the device’s specifications and the environment that it is used in.

•

Samsung is not liable for performance issues caused by apps supplied by providers other

than Samsung.

•

Samsung is not liable for performance issues or incompatibilities caused by edited

registry settings or modified operating system software. Attempting to customise the

operating system may cause the device or apps to work improperly.

•

Software, sound sources, wallpapers, images, and other media provided with this device

are licensed for limited use. Extracting and using these materials for commercial or other

purposes is an infringement of copyright laws. Users are entirely responsible for illegal

use of media.

•

You may incur additional charges for data services, such as messaging, uploading and

downloading, auto-syncing, or using location services depending on your data plan. For

large data transfers, it is recommended to use the Wi-Fi feature.

•

Default apps that come with the device are subject to updates and may no longer be

supported without prior notice. If you have questions about an app provided with

the device, contact a Samsung Service Centre. For user-installed apps, contact service

providers.

Basics

•

Modifying the device’s operating system or installing softwares from unofficial sources

may result in device malfunctions and data corruption or loss. These actions are violations

of your Samsung licence agreement and will void your warranty.

•

Depending on the region or service provider, a screen protector is attached for protection

during production and distribution. Damage to the attached screen protector is not

covered by the warranty.

•

You can see the touchscreen clearly even in strong outdoor sunlight by automatically

adjusting the contrast range based on the surrounding environment. Due to the nature

of the product, displaying fixed graphics for extended periods may result in afterimages

(screen burn-in) or ghosting.

–

It is recommended not to use fixed graphics on part or all of the touchscreen for

extended periods and turn off the touchscreen when not using the device.

–

You can set the touchscreen to turn off automatically when you are not using it.

Launch the

Settings

app, tap

Display

→

Screen timeout

, and then select the length

of time you want the device to wait before turning off the touchscreen.

–

To set the touchscreen to automatically adjust its brightness based on the

surrounding environment, launch the

Settings

app, tap

Display

, and then tap the

Adaptive brightness

switch to activate it.

•

Depending on the region, you can view the regulatory information on the device. To

view the information, launch the

Settings

app and tap

About phone

→

Regulatory

information

Maintaining water and dust resistance

Your device supports water- and dust-resistance. Follow these tips carefully to maintain the

water- and dust-resistance of your device. Failure to do so may result in damage to your

device.

•

Do not immerse the device in fresh water deeper than 1.5 m or keep it submerged for

more than 30 minutes. If you immerse the device in any liquid other than fresh water,

such as salt water, ionised water, or alcoholic beverage, liquid will enter the device faster.

•

Do not expose the device to water moving with force.

Basics

•

Do not open the device’s covers when the device is in water or in very humid places, such

as swimming pools or bathrooms.

•

Do not open the back cover using wet hands or when the device is wet.

•

The rubber seal fitted to the back cover is an important component of the device. Take

care when opening and closing the back cover to avoid damaging the rubber seal. Also,

ensure that the rubber seal is free from debris, such as sand or dust to prevent damage to

the device.

•

The back cover may be loosened if the device is dropped or receives an impact. Ensure

that all the covers are properly aligned and tightly closed.

•

If the device has been immersed in water or the microphone or speaker is wet,

sound may not be heard clearly during a call. After wiping the device with a dry cloth, dry

it thoroughly before using it.

•

Your device has been tested in a controlled environment and certified to be water-

and dust-resistant in specific situations (meets requirements of classification IP68 as

described by the international standard IEC 60529-Degrees of Protection provided by

Enclosures [IP Code]; test conditions: 15-35 °C, 86-106 kPa, fresh water, 1.5 metre, 30

minutes). Despite this classification, it is still possible for your device to be damaged in

certain situations.

Instructional icons

Warning: situations that could cause injury to yourself or others

Caution: situations that could cause damage to your device or other equipment

Notice: notes, usage tips, or additional information

Basics

Device overheating situations and solutions

When the device heats up while charging the battery

While charging, the device and the charger may become hot. During wireless charging or fast

charging, the device may feel hotter to the touch. This does not affect the device’s lifespan or

performance and is in the device’s normal range of operation. If the battery becomes too hot,

the charger may stop charging.

Do the following when the device heats up:

•

Disconnect the charger from the device and close any running apps. Wait for the

device to cool down and then begin charging the device again.

•

If the lower part of the device overheats, it could be because the connected USB

cable is damaged. Replace the damaged USB cable with a new Samsung-approved

one.

•

When using a wireless charger, do not place foreign materials, such as metal objects,

magnets, and magnetic stripe cards, between the device and the wireless charger.

The wireless charging or fast charging feature is only available on supported models.

When the device heats up during use

When you use features or apps that require more power or use them for extended periods,

your device may temporarily heat up due to increased battery consumption. Close any

running apps and do not use the device for a while.

The following are examples of situations in which the device may overheat. Depending on

the functions and apps you use, these examples may not apply to your model.

•

During the initial setup after purchase or when restoring data

•

When downloading large files

Basics

•

When using apps that require more power or using apps for extended periods

–

When playing high-quality games for extended periods

–

When recording videos for extended periods

–

When streaming videos while using the maximum brightness setting

–

When connecting to a TV

•

While multitasking (or, when running many apps in the background)

–

When using Multi window

–

When updating or installing apps while recording videos

–

When downloading large files during a video call

–

When recording videos while using a navigation app

•

When using large amount of data for syncing with the cloud, email, or other accounts

•

When using a navigation app in a car while the device is placed in direct sunlight

•

When using the mobile hotspot and tethering feature

•

When using the device in areas with weak signals or no reception

•

When charging the battery with a damaged USB cable

•

When the device’s multipurpose jack is damaged or exposed to foreign materials, such as

liquid, dust, metal powder, and pencil lead

•

When you are roaming

Do the following when the device heats up:

•

Keep the device updated with the latest software.

•

Conflicts between running apps may cause the device to heat up. Restart the device.

•

Deactivate the Wi-Fi, GPS, and Bluetooth features when not using them.

•

Close apps that increase battery consumption or that run in the background when

not in use.

•

Delete unnecessary files or unused apps.

•

Decrease the screen brightness.

•

If the device overheats or feels hot for a prolonged period, do not use it for a while. If

the device continues to overheat, contact a Samsung Service Centre.

Basics

Precautions for device overheating

If you begin to feel uncomfortable due to the device overheating, stop using the device.

When the device heats up, the features and performance may be limited or the device may

turn off to cool down. The feature is only available on supported models.

•

If the device overheats and reaches a certain temperature, a warning massage will appear

to prevent device failure, skin irritations and damages, and battery leakage. To lower the

device’s temperature, the screen brightness and the performance speed will be limited

and battery charging will stop. Running apps will be closed and all calling and other

features will be limited, except for emergency calls, until the device cools down.

•

If the second message appears due to a further increase of the device’s temperature, the

device will turn off. Do not use the device until the device’s temperature drops below the

specified level. If the second warning message appears during an emergency call, the call

will not be disconnected by a forced shut down.

Precautions for operating environment

Your device may heat up due to the environment in the following conditions. Use caution to

avoid shortening the battery’s lifespan, damaging the device, or causing a fire.

•

Do not store your device in very cold or very hot temperatures.

•

Do not expose your device to direct sunlight for extended periods.

•

Do not use or store your device for extended periods in very hot areas, such as inside a

car in the summertime.

•

Do not place the device in any areas that may overheat, such as on an electric heating

mat.

•

Do not store your device near or in heaters, microwaves, hot cooking equipment, or high

pressure containers.

•

Never use a damaged charger or battery.

Basics

Device layout and functions

Package contents

Refer to the quick start guide for package contents.

•

The items supplied with the device and any available accessories may vary

depending on the region or service provider.

•

The supplied items are designed only for this device and may not be compatible

with other devices.

•

Appearances and specifications are subject to change without prior notice.

•

You can purchase additional accessories from your local Samsung retailer. Make

sure they are compatible with the device before purchase.

•

Use only Samsung-approved accessories. Using unapproved accessories may cause

the performance problems and malfunctions that are not covered by the warranty.

•

Availability of all accessories is subject to change depending entirely on

manufacturing companies. For more information about available accessories, refer

to the Samsung website.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung Téléphone portable

Samsung

Samsung SCH R450 - Cricket CRKR450B - Messager Manuel utilisateur

Samsung

Samsung GT-I5500B Manuel utilisateur

Samsung

Samsung SM-T590 Manuel utilisateur

Samsung

Samsung SCH-R580 Manuel utilisateur

Samsung

Samsung SPH-I330 Manuel technique

Samsung

Samsung Impression SEGA877RBAATT Manuel utilisateur

Samsung

Samsung SGH-d357 Series Manuel utilisateur

Samsung

Samsung GT-S7278 Manuel utilisateur

Samsung

Samsung Captivate Glide SGH-I927 Guide de l'utilisateur

Samsung

Samsung Gleam Manuel utilisateur

Samsung

Samsung T249R Manuel utilisateur

Samsung

Samsung GALAXY MEGA Manuel utilisateur

Samsung

Samsung Galaxy mini GT-S5570I Manuel utilisateur

Samsung

Samsung GT-S3600I Manuel utilisateur

Samsung

Samsung SGH-X100 Manuel utilisateur

Samsung

Samsung SPH-M500 Manuel utilisateur

Samsung

Samsung SGH-P107 Manuel utilisateur

Samsung

Samsung SM-A9200 Manuel utilisateur

Samsung

Samsung Galaxy A11 Manuel utilisateur

Samsung

Samsung SCH-R910 Manuel utilisateur

Samsung

Samsung SCHU620 Manuel utilisateur

Samsung

Samsung Galaxy Note 10+ Manuel utilisateur

Samsung

Samsung SCH-R390X Guide de l'utilisateur

Samsung

Samsung TwoStep SCH-R470 Series Manuel utilisateur

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Nokia

Nokia Lumia 620 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur
