Samsung E810 Manuel utilisateur

The Samsung E810 Quick Start

guide

In just a few minutes we’ll show you how easy it is to use the advanced

features of your new Samsung E810 (customised for Vodafone live!).

You’ll see how quickly you can take pictures and video clips with its

built-in digital camera, send photos and sounds in MMS messages, and

connect to Vodafone live!. You’ll also be able to personalise your phone

by simply downloading new ringtones, games and wallpapers.

Getting started

1. Insert your SIM card:

Slide your Vodafone SIM card into its slot, making sure that the gold

contacts of the SIM are facing down, and the cut-off edge is correctly

aligned.

2. Insert the battery:

Insert the battery (gold contact edge ﬁrst), and push it down until it

clicks shut. The battery may need charging (a full charge can take up to

4 hours).

3. Turn it on:

Press and hold the red key. (Do the same to turn it off again.)

E810 UK.indd 1 12/7/04 1:18:00 pm

1. The phone

Keys and navigation

Volume keys

Headphone

socket

E810 UK.indd 2 12/7/04 1:18:02 pm

Left soft key: selects whatever option is displayed in

the bottom left of the screen (usually Select). In standby

mode it opens Messages.

Right soft key: selects whatever option is displayed in

the bottom right of the screen (usually Back). In standby

mode it opens Vodafone live!.

Navigation key: press to OK an action or select

whatever option is highlighted. In standby mode it opens

the main Menu.

Move the navigation key sideways to move around icons

and menu lists. In standby mode, up starts the Camera,

right opens Calendar, down opens Contacts and left

opens My items.

Call key: Press to answer a call (or open the slider). In

standby mode it opens the Calls list.

End key: Press to end a call (or close the slider). Press

and hold to turn on and off. Press to return to standby

mode.

Clear key: press to delete a character of text.

Press and hold to delete all text.

Volume keys: press to change call volume.

Service Provider

07:30

Tue 09 Mar

E810 UK.indd 3 12/7/04 1:18:09 pm

2. The camera

With the built-in digital zoom camera it’s easy to take photos and video

clips. Photos can be sent to other people as a picture message (see

Section 3).

Take a photo

1. Turn on the camera:

In standby mode, press and hold the Camera key [ ] on the side

of the phone, or press the navigation key up.

2. Take the photo:

Rotate the lens to point in the right direction, then press the key

(or press the camera key again) to take the photo. To discard it, press

[Cancel].

Tips: In viewﬁnder mode, press and to zoom in or out, and

and to adjust the brightness. Press the volume key up to ﬂip the

picture upside down, and down to ﬂip it left to right. Press to adjust

the settings.

��

��

��

��

��

��

5. Camera

Select Back

Options 12 Apr

Send MMS

Send MMS Postcard

Rename

Set as wallpaper

Set as caller ID

Protection

Select Back

3. Save your photo:

Press [Save]. It’s saved in the My photos folder, found in My items/

Pictures in the main Menu. Press [Back] to take another photo, or

press [Options]. Choose Send MMS to send it as a picture message, or

Set as wallpaper to use it as your screen background. Set as caller

ID adds it to a contact detail so it will appear when they call.

E810 UK.indd 4 12/7/04 1:18:16 pm

Take a video clip

1. Take a video clip:

In standby mode, go to Menu/Camera/Record video (or in camera

viewﬁnder mode, press 1). Press to start recording, then press

it again to stop. Press [Save] (it’s saved in My items/My videos), or

press [Back] to discard it.

2. View your video clip:

Go to Camera/My videos to view your clips (press to play).

Tips: You can use the same adjustments as in Camera mode. You

can save up to 5 video clips, regardless of length (until you run out of

memory).

Rotating lens

E810 UK.indd 5 12/7/04 1:18:18 pm

3. Picture messaging

With multimedia messaging (MMS) you don’t have to just send a text

message. Now it’s just as simple to send pictures and sounds as well!

Your E810 is already enabled to send and receive MMS.

Create and send a new multimedia

message

1. Start a new message:

In standby mode, press [ ]. Select Create message, and

then MMS.

2. Enter a subject (optional):

Enter a subject (title) for your message, then press , or just press

to go straight to the Add screen.

3. Enter the text:

Press twice (or select [Options]/Add text) and write your message,

then press to return to the message screen.

Text tips: The Hash key adds a space, the 1 key cycles through

punctuation, and the Star key cycles between upper case, lower

case, numbers and symbols. Pressing and holding the Star key turns

predictive text (T9) on and off.

4. Add a photo:

Press twice (or [Options]/Add photo). Choose Take photo to take

a new photo, or My photos to choose a saved one. Press .

5. Add a sound clip:

Press twice again, and choose Record new to record and save

a new sound clip (this uses the Voice recorder in the Applications

folder. Sounds are saved in My sounds). Press .

6. Preview your message:

Press [Options]/Preview to see (and hear) your message. Press [OK],

then [Back]. ( To change any part of your message, highlight it with the

navigation key, then press [Options]/Edit....)

E810 UK.indd 6 12/7/04 1:18:23 pm

7. Send your message:

Press [Options]/Send message, then select To(Ø):. To send it to a

mobile choose Phone number, and enter the number. Choose E-mail

address to send it to an email address. Or choose Contacts list to

choose a number or email address from your Contacts. Then press

twice to send it.

��

��

��

��

��

��

1. Adding pages: In the Add screen, move the highlight from Add here

to Page 1/... and select [Options]/Add page. You can now add more

text, pictures and sounds to your message.

2. Sending to a mobile: Try sending one to yourself to see how it

works. Note that if you send a message to a phone that isn’t picture

message compatible, they’ll be sent a web address to view it on.

3. Sending to more than one person: To send your message to more

than one person, select Add contacts in the To menu..

Multimedia messaging tips

Messages 12 Apr

Create message

Inbox

My messages

Call voicemail

live! Studio

Vodafone mail

Select Back

Hey there 12 Apr

Options Back

Wait till you see this!

Page 1/Øk

Add here

E810 UK.indd 7 12/7/04 1:18:24 pm

4. Vodafone live!

Vodafone live! brings your mobile to life: full of information, downloads,

games, music and services. It’s easy to use, and the connection can be

‘always on’ so there’s no wait for dialling up.

Connect to

In standby mode, press [ ] to connect you to the Vodafone

live! main menu. To exit, press and hold the key.



New Vodafone Mail

Downloads Games

It works very like an ordinary web browser. Simply highlight the item you

want to select, then press the key to open that page.

Press [Back] to go back a page. Press and hold for the Browser

Menu setting menu.

Select Home

E810 UK.indd 8 12/7/04 1:18:28 pm

Vodafone live! links

You can also link directly to the Vodafone live! service you want using

your phone’s built-in links.

1. Links:

Go to Menu/Vodafone live!. This page is ofﬂine, so you won’t be

connected until you choose a link. Here are some of the services you

can choose:

Vodafone live!: connect to the Vodafone live! home page.

What’s new: what’s new in Vodafone live!.

Games: download games for your E810.

Ringtones: download sounds and ringtones.

Pictures: download images, animations and background wallpaper.

News: get the latest news reports and weather forecasts...

Tip: Vodafone live! is growing and changing all the time, so the options

may vary. Keep checking it out to see what’s new.

2. Bookmarks:

Go to Menu/Vodafone live!/Bookmarks to ﬁnd Sport (the latest

scores, results and news), as well as space to store your own favourite

bookmarks.

E810 UK.indd 9 12/7/04 1:18:30 pm

5. Downloads

Change your E810 whenever you want by downloading new polyphonic

ringtones, games and background wallpaper from Vodafone live!.

Download more

1. Download a new ringtone:

Go to Menu/My items/Sounds and choose Download more. Choose

the ringtone and follow the instructions to download it. To activate your

ringtone, go to My items/Sounds/Saved sounds. Highlight your

downloaded ringtone and select [Options]/Set as ringtone.

��

��

��

��

��

��

��

��

��

My items 12 Apr

Pictures

Games

Sounds

My videos

Templates

Memory status

Select Back

Pictures 12 Apr

My photos

Saved pictures

Download more

Select Back

2. Download new background wallpaper:

To choose a new background image for your phone, go to My items/

Pictures/Download more. Choose the image you’d like and follow

the instructions to download it. Then go to My items/Pictures/Saved

pictures, select your downloaded image and choose [Options]/Set as

wallpaper.

3. Download new games:

To add more high quality games to your handset, select My items/

Games/Download more. Choose a game to download, and you’ll ﬁnd

it in My items/Games/Saved games (there are some great games

there already).

E810 UK.indd 10 12/7/04 1:18:31 pm
