Samsung SC-D107 Manuel utilisateur

Connecting a Power Source

Camcorder Quick Start Guide AD68-00762S

Power Switch

1. Attach the battery pack to the camcorder.

2. Connect the AC Power adapter to an AC cord and connect

the AC cord to a wall socket.

3. Connect the DC cable to the DC jack socket on the

camcorder.

4. Turn the Camera power switch to off, and the charging indica-

tor will start to flash, showing that the battery is charging.

Battery charge time

SB - LS110 : Approx 2hr

SB - LS220 : Approx 3hr 30min

TAPE

MEMORY

CARD

MENU button

MENU dial (VOL/MF)

ENTER button

1. Imsert the Lithium battery with the positive (+) side face down.

2. Insert a Cassette.

3. Select the appropriate OSD Language among the English, French,

Spanish, Portuguese, German and Italian.

➀Press the MENU button.

➁Turn the MENU DIAL to highlight INITIAL and press the ENTER button.

➂Using the MENU DIAL, select the LANGUAGE.

➃Press the ENTER button to confirm the OSD Language.

➄To exit, press the MENU button.

●CLOCK SET

➀Press the MENU button.

➁Turn the MENU DIAL to highlight INITIAL and press the ENTER button.

➂Use the MENU DIAL to select CLOCK SET from the submenu.

➃Press the ENTER button to enter SETTING mode.

A blinking item indicates the item to be changed.

➄Using the MENU DIAL and ENTER button, change the year, month,

day, and hour setting.

➅The word COMPLETE! will appear, and a few seconds later, the menu

screen will automatically return to the sub menu.

1. Connect a Power source to the camcorder.

2. Remove the LENS CAP.

3. Set the mode switch to the TAPE position.

4. Set the power switch to the CAMERA position.

5. To start recording, press the START/STOP button.

Preparation

Basic Recording

DELTA2-107-Quick Guide-(D107) 5/21/04 10:52 AM Page 1

IEEE

1394

USB

A/V

S-VIDEO

MIC

S-VIDEO

Audio/Video

CAMCORDER

VIDEO

AUDIO(L)

AUDIO(R)

EASY

REC SEARCH FADE BLC

REV FWD S.SHOW MULTI DISP.

TAPE

MEMORY

CARD


TAPE PLAYBACK

1.Connect the camcorder to a TV with the AUDIO/VIDEO cable.

■The yellow plug : Video

■The white plug : Audio(L) - Mono

■The red plug : Audio(R)

Set the mode switch to the TAPE position.

3. Set the power switch on the camcorder to PLAYER mode.

4. Using the (FF) and (REW) buttons, find the first position

you wish to play back.

Press the (PLAY/STILL) button.

1. Turn the Power switch to OFF.

2. Insert the Memory Card into the Memory Card slot located on

the bottom of the camcorder, in the direction of the arrow.

Set the mode switch to MEMORY CARD.

4. Set the power switch to the CAMERA mode.

5. ■Still Image : ➀Press the PHOTO button to record a picture.

■MPEG4 : ➀Press START/STOP button to start recording.

(up to 20 seconds)

DSC Recording

TAPE

MEMORY

CARD

455

123

TAPE

MEMORY

CARD

1. Turn the Power switch to OFF.

2. Insert the Memory Card into the Memory Card slot located

beneath the camcorder, in the direction of the arrow.

Set the mode switch to MEMORY CARD.

Set the power switch to the PLAYER mode.

Select the Storage Media (MPEG4,PHOTO) to playback

➀Press the MENU button and turn the MENU DIAL to high-

light MEMORY.

➁Press the ENTER button to enter sub-menu.

➂Use the MENU DIAL to select MPEG4(PHOTO) from the

sub-menu. (M. PLAY SELECT)

➃

To exit the menu, push the MENU button.

DSC PLAYBACK

DELTA2-107-Quick Guide-(D107) 5/21/04 10:52 AM Page 2
