TABLE OF CONTENTS
MODEL 810M CHIPPER
COVER & TABLE OF CONTENTS……………………………….…………..Pages 1 – 2
STATEMENT OF FACT …………………………………..…………………… Page - 3
SPECIFICATIONS & FEATURES ……………………..………..……………….Page - 4
MACHINE REGISTRATION ………………………………………….………….Page - 5
SAFETY INSTRUCTIONS & COPIES OF DECALS…………..…….…..…Pages 6 – 10
OPERATING INSTRUCTIONS………………………………….……………….Page - 11
SERVICE & MAINTENANCE INSTRUCTIONS ……………….……….…Pages 12 - 13
PARTS DIAGRAMS ………………………………..……………….………Pages 14 – 40
TORQUE CHARTS …………………………………………………………………Page 41
WARRANTY POLICY & PROCEDURE ………………………….……….……...Page 42
COPY OF WARRANTY CLAIM FORM….…………………….……….………...Page 43
COPY OF DEALER DELIVERY RECEIPT & WARRANTY CARD……………..Page 44
SERVICE SCHEDULE LOG ……………………………………..………………...Page 45
SALSCO, INC.
105 School House Road
Cheshire, CT 06410 USA
800-872-5726, 203-271-1682
203-271-2596 (Fax)
www.salsco.com, [email protected]
O:\Manuals\810M\810M MANUAL P.W. 10.30.2017.doc 3
STATEMENT OF FACT
You have just purchased the highest quality, most dependable, Chipper on the
market today. This unit has the ability to meet exact standards and perform for
years with minimum downtime. HOWEVER, it cannot read nor will it
understand this manual no matter how long you leave it on top of the machine.
It is your responsibility to read and understand this manual; it is also your
responsibility to be certain this information is passed along to anyone who is
expected to operate this equipment. Should you choose not to read, understand
and pass along the information provided you, please expect equipment failure and
possible injuries to persons around this equipment.
For the safety of the operator, it is imperative that this manual is carefully read and
understood.
Once you have read this manual, it is your responsibility to be sure that all new
operators read and understand this manual, especially all cautions stated.
As a manufacturer of equipment, we have a responsibility to design a safe piece of
equipment. NOTE: The important safeguards and instructions in this manual are
not meant to cover all possible conditions and situations that may occur. It must
be understood that common sense, caution, and care are factors, which cannot be
built into any product. These factors must be supplied by the person(s) caring for
and operating this equipment.
ONLY YOU CAN PREVENT ACCIDENTS!
O:\Manuals\810M\810M MANUAL P.W. 10.30.2017.doc 4
SPECIFICATIONS & FEATURES
The Salsco Model 810M is ruggedly built to withstand high volume usage by many different
industries. Rental –Tree Care –Commercial Lawn and Golf Courses, just to name a few.
Some of the standard features and options include heavy duty ¼” diamond plate fenders with
enclosed light guards, lockable tanks, extra large hydraulic and fuel tanks with drain plugs,
5,000-lb. axle, large, high speed, 28.10” diameter tires, bolt on feed hopper, two bed knives
and 360swivel chute.
The trailer frame is constructed of 2” x 4” rectangular steel tubing, continuous weld for
strength and gussets where needed. The 5,000-lb Torflex axle features an independent
suspension, cushioned with rubber, providing a smoother, quieter ride with no transfer of road
shock from one wheel to the other.
Model 810M has a huge 10” x 18” chipper inlet opening and a 21” diameter feed roll. This,
coupled with the largest infeed hopper in the industry, 1,881 square inches, allows our
machine to ingest whole trees, branches and all. Even the largest home Christmas trees are no
problem. Our Model 810, because of our feed roll design, will not only handle the hard woods
of the North, but the grassy palm fronds of the Southern states. This unit will handle all your
chipping needs, no matter what type of tree or plant.
The feed roll receives its power through a jackshaft from a hydraulic motor. This allows a
double gear reduction and thus an increase of available torque. You’ll be amazed with the
smoothness and ease of this feed system.
We use two bed knives, one horizontal and one vertical, which allows our machine to cut,
where others might shred.
Safety is our main concern and we have gone the extra mile. However, only you can
save yourself and your employees from the danger, which lies in these machines. It is
your responsibility as the buyer of this machine, to make sure the operator has been
trained. Talk to your operators every day –hold classes. Do something to help yourself.
We can only go so far.
O:\Manuals\810M\810M MANUAL P.W. 10.30.2017.doc 5
MACHINE REGISTRATION
MANUFACTURED BY: SALSCO, INC.
105 School House Rd., Cheshire, CT 06410
800-872-5726, 203-271-1682, 203-271-2596 (Fax)
THIS MANUAL COVERS MODEL: 810M, WOOD/BRUSH CHIPPER
This company reserves the right to discontinue, add improvements to, or change the design of any model or
product at any time without obligation to improve existing machines, either by changing the design or adding new
parts.
It has been and will continue to be the policy of SALSCO to update existing machines at its own discretion.
Whenever possible, new designs will be made in such a way that they can be "Retro Fit" if so desired.
Record in the space provided below the model and serial number of this unit. Please retain these numbers for
future reference.
NO PARTS ORDERS will be accepted WITHOUT MODEL NUMBERS OR PART NUMBERS. All part
numbers are listed in this manual.
_____________________________________________ ___________________
Serial Number Model Number
NOTE: Be sure to complete your warranty card. This will insure immediate processing of any warranty claims.
READ AND UNDERSTAND THIS MANUAL BEFORE STARTING THE MACHINE
1/06
O:\Manuals\810M\810M MANUAL P.W. 10.30.2017.doc 6
CAUTIONS
READ THOROUGHLY THE OPERATOR SAFETY INSTRUCTIONS ON THE FOLLOWING
PAGES WHICH ARE THE AMERICAN NATIONAL STANDARD OF POWERED
SHREDDERS/GRINDERS SAFETY SPECIFICATIONS, PROVIDED BY ANSI AND THE O.P.E.I.
THE FOLLOWING CAdUTIONS ARE PROVIDED BY SALSCO AS A QUICK REFERENCE
ONLY AND ARE NOT MEANT TO REPLACE THE PRECAUTIONS ON THE FOLLOWING
PAGES.
- THINK -
1. ALWAYS use protective eyewear when machine is in operation.
2. ALWAYS use gloves and wear ear protection when machine is in operation.
3. NEVER put hands, legs or any part of your body into or near the chipper intake or discharge
openings.
4. NEVER run machine with guards removed.
5. ALWAYS allow machine to cool off, remove key and put engine in neutral before attempting
any maintenance or repair.
6. BE SURE machine has stopped completely, engine is off, key is removed and spark plug is
disconnected before attempting any service or maintenance.
7. NEVER stand in front of chipper infeed hopper. It is possible for a chip or piece of wood to be
thrown out.
8. BE SURE the machine is parked on a dry level surface before starting operation.
9. DO NOT operate with loose clothing or long unrestrained hair. BE SURE vines and branches
are not wrapped around your body parts.
10. DO NOT operate on ice or any other slippery surface. BE SURE area around machine is clear
and clean. You don’t want to trip or fall into the machine.
11. NEVER leave machine running unattended, especially around youngsters or persons not
instructed in the safe operation of this machine.
12. READ and understand federal guidelines provided with this manual on the following pages.
-IT’S YOUR HAND OR FOOT -
O:\Manuals\810M\810M MANUAL P.W. 10.30.2017.doc 7
BRUSH CHIPPERS
ANSI Z133.1-2006
American National Standard for Arboricultural Operations
Safety Requirements
O:\Manuals\810M\810M MANUAL P.W. 10.30.2017.doc 8
BRUSH REMOVAL AND CHIPPING
ANSI Z133.1-2006
American National Standard for Arboricultural Operations
Safety Requirements
O:\Manuals\810M\810M MANUAL P.W. 10.30.2017.doc 9
SAFETY DECALS
PART # 0314020
PART # 0314062
PART # 0314049
PART # 0314029
O:\Manuals\810M\810M MANUAL P.W. 10.30.2017.doc 10
-
-SAFETY DECALS
PART # 0314060
PART # 0314062
PART # 0314015
PART # 0314063
