Installation process
• Make sure the key cap compatibility (pry and replace the default key
cap if necessary)
• Check and confirm the load compatibility
• Turn OFF the mains electricity supply before commencing installation
• Connect the switch according to the wiring diagram
• Turn ON the mains electricity supply, wait for 10 seconds, then test the
switch operation by pressing the switch button.
5. Operation
6. How to download App
Scan QR code or go to App store (IOS) or Google Play (Android) to download the free PIXIE app
to your smart phone.
• IOS: Requires IOS 6.0 or later. Compatible with iPhone, iPad and iPad touch
• Android: Requires Android 4.4 or above, devices must support Bluetooth 4.0 Specifications
above are for reference only and may vary without prior notice.
7. Warranty
In accordance with SAL’s standard terms and conditions of sale, SAL warrant this product to be free from defects in materials and or workmanship for a period as stated
below for goods not subject to incorrect installation, maintenance, operation, mishandling, environmental, unauthorised modifications or electrical operating conditions
outside the nominated product specification as detailed in these installation instructions. The benefits to you given by this warranty are in addition to other rights and
remedies you have under law. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund
for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail
to be of acceptable quality and the failure does not amount to a major failure.
Warranty term – Residential usage (12) months, Commercial usage (12) months
8. Scan QR code to get full
installation instruction
Step #3 - Upon review of your claim and if the product is required to be returned to SAL for technical evaluation, then at the owners expense the product must be
returned to SAL as per the above nominated locations.
Step #4 - Pending the evaluation, the claim will be validated resulting in the product being repaired or replaced with the same or best equivalent product at the
discretion of SAL, or rejected if the product fault was found to be caused by conditions beyond the responsibility of SAL warranty obligations. Consideration of installation,
product removal, return freight and or testing fees are not the responsibility of SAL.
The smart timer switch can work under two modes,
Timer Mode: The switch is expected to automatically disconnect the electricity to
the load after being turned on for a predetermined time duration.
Manual override mode: The swtich supplies electricity permanently until further
operation to switch off or exit this mode
Manual setting time duration (optional, programming in the App is more recom-
mended)
1, Turn off the switch
2, Push and hold the button for 10 seconds, the LED indicator will start to slowly
cycle indicating the programming mode has launched
3, To program, press the button between 1 and 24 times according to the desired
delay in hours. E.g, 8 presses will result in a delay of 8 hours. Pressing more than 24
times will result in a time duration of 24 hours. Programming mode expires 10
seconds after the last button press. At this time the new timer duration is saved.
(Note: If no button press is detected in programming mode, the time duration will
be unchanged.)
Manual setting time pairing (optional, for multi-way time delay control)
1, Turn off the switch
2, Quickly press the button of STS600BTAM 4 times, make sure the LED indicator is
flashing in blue and white
3, Quickly press the button of SMF/BTAS or SMRM/BTAS 4 times within 30s. When their
LED indicator flashe twice and then remain lit for 2s, the pairing is successful.
Note: If the STS600BTAM changes HOME setup in the App or reset to factory, the
pairing process will need to be repeated.
MASTER
Operation
1 Click Turn on the switch and start timer mode Quickly flash for 5s then
flash every 3s
Enter pairing mode, this mode stays 30s Quickly flash in blue and
white for 30s
Flash in blue and white
3s then stay lit for 2s
Turn on the switch in an untimed
manner (manual override mode)
Reset all the settings to factory
Static high brightness
4 Clicks
Long press for 2
seconds then release
9 Click
Function Description LED Indicator
Operation
1 Click Turn off the switch and cancel timer Static low brightness
Keep switch on, timer will count again Quickly flash for 5s then
flash every 3s
Enter manual override mode, the
switch stays on in an untimed manner Static high brightness
2 Clicks
Long press for 2
seconds then release
Function Description LED Indicator
Operation
1 Click Exit manual override mode, start timer Quickly flash for 5s then
flash every 3s
Turn off the switch, exit manual override
mode Static low brightness
Long press for 2
seconds then release
Function Description LED Indicator
When in off state
When in timer mode
When in manual override mode
7.1 How to make a claim?
Step #1 – Within 30 days of the fault discovery, please contact the original place of the SAL product purchase during standard (local) business hours, with the following
information (a) proof of purchase (b) description and quantity of the claimed fault (c) address of installation. (d) operating hours of the product.
Step #2 – It is then the responsibility of the original place of product purchase to report the matter to SAL aftersales;
