Safety 1st Pronto Manuel utilisateur

Pronto, Crossover

Booster Seat

4358-7228

3.18.19

KEEP INSTRUCTIONS FOR FUTURE USE.

Read all instructions before using this booster seat.

WARNING: Failure to follow the

warnings on the labels and in the

instruction manual can result in

serious injury or death

to your child.

Quick NavigationOverview

Welcome to the Safety 1st family and thank you for choosing

this car seat, also known as a child restraint!

To help you get started using your child’s new car seat, here are

the 3 main tasks you’ll need to complete.

Your child’s safety is worth the time it will take to read and follow

these instructions.

Ready? Let’s go!

Pages 1-3 will introduce you to the parts of the car seat.

Page 34 has our contact information. If at any point you would like

assistance, please feel free to reach out to us.

Measure Your Child

Place Booster Seat into Your Vehicle

Buckle Up!

Preparing

Booster Seat

PAGE 5

Backless:

Lap/Shoulder Belt

PAGE 18

Backless

Booster Seat

Child Fit

PAGE 17

Backed

Booster Seat

Child Fit

PAGE 21

Backed:

Lap/Shoulder Belt

PAGE 22

BACKED

BOOSTER SEAT

18-45 kg (40-100 lb) and

102-145 cm (40-57 in.)

PAGE 4

BACKLESS

BOOSTER SEAT

18-45 kg (40-100 lb) and

102-145 cm (40-57 in.)

PAGE 4

Getting Started

Parts of the Booster Seat .................................................1

Cup Holder Use..............................................................2

Booster Seat Requirements...........................................3

Preparing Booster Seat For Use ....................................5

Making Adjustments to Booster Seat

Installing Backrest/Headrest............................................11

Removing Backrest/Headrest...........................................12

Adjusting Headrest Height.............................................13

Reclining Backrest..........................................................14

Knowing Your Vehicle Belts .................................15

Installation in Vehicle

Backless Booster Seat...................................................16

Backless: Booster Seat Child Fit....................................17

Backless Booster: Lap/Shoulder Belt Use ........................18

Backed Booster Seat .....................................................20

Backed: Booster Seat Child Fit ......................................21

Backed Booster: Lap/Shoulder Belt Use...........................22

Car Seat Pad Use and Care

Removing Seat Pad Set for Cleaning .................................24

Safety Information

Replacement and Expiration of Car Seat ........................27

Aircraft Information ......................................................28

Child Restraint Use...........................................................28

Installation in Vehicle........................................................29

Vehicle Seating Position ...................................................29

Transport Canada Regulations...........................................29

Registration and Safety Notices.........................................31

Additional Information

Warranty .........................................................................32

Replacement Parts List ....................................................33

Dorel Juvenile Group Information ......................................34

Contents

Parts of the Booster Seat

Instruction

Manual Storage

Headrest

Cup Holder

Seat

Base

Armrest

Removable

Backrest

Shoulder Belt-

Positioning

Guide

Backrest

Release Tab

Backrest

Release Tab

Headrest

Adjustment

Lock

Shell

Pull out cup holder to use.

Cup Holder Use

Push the cup holder in when

not in use.

WARNING

Measure your child’s weight and height

(do not guess) before using this booster seat.

Your child’s height, weight, and age determine how a car seat

should be placed in the vehicle.

Children vary widely in body size, shape, and temperament—

please consult your doctor before switching between any

types or modes of a car seat within the limits and ﬁt require-

ments of the seat.

State/Province Laws

Please be certain to follow your state’s or province’s laws regarding

car seat use.

American Academy of Pediatrics Recommendations

Infants and Toddlers

Should ride in a rear-facing car seat as long as possible, until they

reach the highest weight or height allowed by their seat.

Toddlers and Preschoolers

Once they are facing-forward, children should use a forward-facing

car seat with a harness for as long as possible, until they reach the

height and weight limits for their seats.

School-Aged Children

Once they have outgrown their forward-facing car seat, children

should use a belt-positioning booster seat until the vehicle’s lap

and shoulder seat belt ﬁts properly. This is often when they have

reached at least 4 feet 9 inches in height and are 8 to 12 years old.

Older Children

All children younger than 13 years should be restrained in the rear

seats of vehicles for optimal protection.

Booster Seat Requirements

BACKLESS BOOSTER SEAT

18-45 kg (40-100 lb) and

102-145 cm (40-57 in)

Your child can remain in this Booster Seat until they outgrow

any one of the following:

Weight Limit: 45 kg (100 lb); OR

Height Limit: 145 cm (57 in.); OR

Booster Seat child ﬁt requirements. See page 17.

BACKED BOOSTER SEAT

18-45 kg (40-100 lb) and

102-145 cm (40-57 in)

Your child can remain in this Booster Seat

until they outgrow any one of the following:

Weight Limit: 45 kg (100 lb); OR

Height Limit: 145 cm (57 in.); OR

Booster Seat child ﬁt requirements. See page 21.

continued on next page

Preparing Booster Seat for Use

Install Seat Pad

Slide seat pad onto the front of

the seat base.

Slide the elastic strap over

each armrest.

Wrap Elastic Straps

Under Back Corners of

Seat Base

Pull Seat Pad Around Cup

Holder

Remove the headrest from the backrest in order to install the

headrest and backrest pads.

If your pad comes in a plastic bag, remove the pad from the plastic

bag and discard the plastic bag.

Removing Headrest from Backrest Installing Seat Pad

Separate Headrest from

Backrest

Slide the headrest out of the track

on the backrest.

Unlock Headrest from

Backrest

With the headrest and backrest

facing down, lift headrest adjuster

lock up and pull headrest up out

of all locked positions.

Install Backrest Pad

Slide backrest pad onto one side

of the backrest. Pull pad tight

and slide the pad over the other

side of backrest. Bottom of the

headrest pad should be behind

the backrest pad as shown.

Install Headrest Pad

Slide the pad over one side of

the headrest.

Repeat for other side.

Attach the Elastic Straps

From the back of headrest,

attach the elastic straps to the

hooks above the shoulder belt-

positioning guides as shown.

Attach Headrest to

Backrest

With the headrest and backrest

facing down, slide the headrest

into the track on the back of the

backrest.

Determine Style of Headrest Pad

Installing Backrest/Headrest Pads Version A

If back of headrest pad has a sewn

on plastic piece (image A), follow

steps for Installing Backrest/

Headrest Pads Version A.

See step 1 below.

If the headrest pad does not have

plastic piece (image B), follow

steps for Installing Backrest/

Headrest Pads Version B.

See page 9.

Lock Headrest

Lift headrest adjuster lock up and

pull headrest down into a locked

position.

To use the booster seat with backrest/headrest, follow the

instructions below to install the backrest/headrest pads.

To install backrest/headrest to booster seat, see page 11.

Attach Headrest to Backrest

With the headrest and backrest

facing down, slide the headrest

into the track on the back of the

backrest.

Install Backrest Pad

Slide backrest pad onto one side

of the backrest.

Pull pad tight and slide the pad

over the other side of backrest.

Install Headrest Pad

Attach headrest pad by attaching

bottom of pad to tabs near the

bottom of the headrest.

109

Slide the Pad Over One

Side of the Headrest

Repeat for other side.

Installing Backrest/Headrest Pads Version B

To install backrest/headrest to booster seat, see page 11.

3Attach the Elastic Straps

From the back of headrest,

attach the elastic straps to the

hooks above the shoulder belt-

positioning guides.

Lock Headrest

Lift headrest adjuster lock up

and pull headrest down into a

locked position.

Locate the Backrest

Opening in Seat Base

Hold down the rectangular

shaped flap at the rear of the

seat base pad to fully reveal the

backrest opening.

Removing Backrest/Headrest 12

Installing Backrest/Headrest

Attach Backrest to Seat

Base

With the backrest laying flat

(horizontal), insert the backrest

hook into the backrest opening

at the rear of the seat base.

Make sure the seat base pad

does not get caught between

the moving parts.

The backrest may not connect

properly if the pad is in the way.

Rotate Backrest Up

Rotate backrest all the way up

into the locked position. In the

locked position, the backrest

will remain upright.

Tuck flap on seat base pad

under backrest pad.

Lay Backrest Flat

To remove backrest/headrest

from seat base, backrest needs

to be in the most upright position.

See page 14.

Press firmly on backrest release

tab (1) and rotate seat back until

it lays flat (2).

Remove Backrest/

Headrest

Lift backrest hook out of

opening in seat base.

Lay flap on seat base pad

over backrest opening.

Store backrest/headrest for

future use.

To remove headrest from backrest, see page 5.

Reclining Backrest 14

Adjusting Headrest Height

The headrest and backrest must always be used together.

To Recline Backrest

Push ﬁrmly on the backrest

release tab and rotate top of seat

back about 2.5 cm (1 in.).

The backrest is now in the semi-

recline mode.

Backrest Has 2 Positions

Backrest has an upright and

semi-reclined position.

The semi-reclined position is to

be used only to install the booster

seat ﬂush against the vehicle seat

back, if needed.

Headrest Has Multiple

Height Positions

To Raise or Lower Headrest

Grasp the top of the headrest with

one hand and push down on the

headrest while pulling out on the

headrest adjustment lock with the

other.

Raise or lower headrest to selected

position. Release the headrest

adjustment lock into one of

headrest heights.

Check to make sure the headrest

is locked by pushing and pulling

headrest up and down.

Headrest will move slightly when it

is locked.

For Backed Booster Seat Child Fit, see page 21.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Safety 1st siège auto

Safety 1st

Safety 1st TravelSafe Guide de dépannage

Safety 1st

Safety 1st Go Hybrid Booster Manuel utilisateur

Safety 1st

Safety 1st onBoard 35 LT Manuel utilisateur

Safety 1st

Safety 1st Summit Deluxe Manuel utilisateur

Safety 1st

Safety 1st GREENER BAB COMFORT RIDE LITE BOOSTER CAR... Manuel utilisateur

Safety 1st

Safety 1st TriFit TriMate Manuel utilisateur

Safety 1st

Safety 1st Guide 65 Manuel utilisateur

Safety 1st

Safety 1st CCA 2010 A Manuel utilisateur

Safety 1st

Safety 1st onBoard 35 LT Manuel utilisateur

Safety 1st

Safety 1st Grow Manuel utilisateur

Safety 1st

Safety 1st Babycool Guide de dépannage

Safety 1st

Safety 1st SportFit 65 Manuel utilisateur

Safety 1st

Safety 1st Guide 65 Manuel utilisateur

Safety 1st

Safety 1st Advance SE 65 air+ Manuel utilisateur

Safety 1st

Safety 1st MultiFit Manuel utilisateur

Safety 1st

Safety 1st Alpha Elite 65 Manuel utilisateur

Safety 1st

Safety 1st Grow and Go Extend N Ride Manuel utilisateur

Safety 1st

Safety 1st Urban Trek Manuel utilisateur

Safety 1st

Safety 1st onBoard 35 Air Manuel utilisateur

Safety 1st

Safety 1st advance 70 air plus Manuel utilisateur

Safety 1st

Safety 1st Alpha Omega 65 Manuel utilisateur

Safety 1st

Safety 1st SlimRide EverSlim Manuel utilisateur

Safety 1st

Safety 1st Crosstown Manuel utilisateur

Safety 1st

Safety 1st Grow and Go Comfort Cool Manuel utilisateur

Manuels siège auto populaires d'autres marques

Britax

Britax PARKWAY SGL Manuel utilisateur

JANE

JANE nurse cruiser Manuel utilisateur

Digicom

Digicom Tippy Pad Manuel utilisateur

Fisher-Price

Fisher-Price Futura 20/60 Manuel utilisateur

Giordani

Giordani orion 012 Manuel utilisateur

BRIO

BRIO ZENTO Manuel utilisateur

Combi

Combi Zeus Turn 8815 Series Manuel utilisateur

Graco

Graco Car Booster Seat Manuel utilisateur

Coccolle

Coccolle Atira Manuel utilisateur

hifold

hifold HF01-GL Manuel utilisateur

CYBEX

CYBEX SOLUTION X2-FIX Manuel utilisateur

kiwy

kiwy SLF 123 Manuel utilisateur

Graco

Graco NAUTILUS Manuel utilisateur

Britax

Britax Multi-Tech BB0-702-00 Manuel utilisateur

Grammer

Grammer MSG45/421 Mode d'emploi

Nuna

Nuna REBL PLUS Manuel utilisateur

Graco

Graco Child Restraint Manuel utilisateur

Little Tikes

Little Tikes Highway Manuel utilisateur
