SAB SABIP1200 Manuel utilisateur
User
User Manual
Manual
Outdoor HD Wireless IP Camera
Model: SABIP1200
V1.0
1
Table of Contents
1 Overviews............................................................................................................................................................... 3
1.1 Key Features.......................................................................................................................................................................3
1.2 Read Before Use................................................................................................................................................................4
1.3 Packing Contents............................................................................................................................................................... 4
1.4 Physical Description.......................................................................................................................................................... 4
1.5 Hardware Installation......................................................................................................................................................... 6
2 Accessing the Network Camera........................................................................................................................6
2.1 Hardware Connection & Software Installation............................................................................................................... 6
2.2 Access the Camera in LAN...............................................................................................................................................7
2.2.1 Wired connection........................................................................................................................................................ 7
2.2.2 Wireless connection................................................................................................................................................... 8
2.3 Access the Camera in LAN...............................................................................................................................................8
2.3.1 Static IP Addresses.....................................................................................................................................................8
2.3.2 Remote Access........................................................................................................................................................... 8
2.4 Using the VLC player.......................................................................................................................................................11
2.5 IP camera connection to the server.............................................................................................................................. 13
3 Surveillance Software GUI............................................................................................................................... 14
3.1 Login Window................................................................................................................................................................... 14
3.2 Surveillance Window....................................................................................................................................................... 17
4 Advanced Camera Settings..............................................................................................................................21
4.1 Setup Wizard.................................................................................................................................................................... 21
4.2 Device Status....................................................................................................................................................................21
4.2.1 Device Information....................................................................................................................................................22
4.2.2 Device Status.............................................................................................................................................................22
4.2.3 Session status........................................................................................................................................................... 23
4.2.4 Log...............................................................................................................................................................................23
4.3 Basic Settings................................................................................................................................................................... 23
4.3.1 Camera Name........................................................................................................................................................... 23
4.3.2 Camera Time............................................................................................................................................................. 24
4.3.3 User Accounts........................................................................................................................................................... 25
4.4 Network..............................................................................................................................................................................32
4.4.1 IP Configuration.........................................................................................................................................................32
4.4.2 Wireless Settings...................................................................................................................................................... 34
4.4.3 DDNS..........................................................................................................................................................................34
4.3.5 UPnP...........................................................................................................................................................................38
2
4.4.5 Port..............................................................................................................................................................................38
4.4.6 Mail Settings.............................................................................................................................................................. 40
4.4.7 FTP Settings.............................................................................................................................................................. 42
4.4.8 P2P..............................................................................................................................................................................43
4.5 Video.................................................................................................................................................................................. 43
4.5.1 Video Settings........................................................................................................................................................... 43
4.5.2 On Screen Display....................................................................................................................................................44
4.5.3 Snapshot Settings.....................................................................................................................................................45
4.5.4 IR LED Schedule.......................................................................................................................................................45
4.5.5 Lens Distortion Correction....................................................................................................................................... 46
4.6 Alarm.................................................................................................................................................................................. 46
4.7 Record............................................................................................................................................................................... 50
4.7.1 Storage Location.......................................................................................................................................................50
4.7.2 Alarm Record............................................................................................................................................................. 50
4.7.3 Local Alarm Location................................................................................................................................................ 50
4.7.4 Record Schedule.......................................................................................................................................................51
4.8 Firewall.............................................................................................................................................................................. 51
4.9 System............................................................................................................................................................................... 52
4.9.1 Back-up& Restore.....................................................................................................................................................52
4.9.2 System Upgrade....................................................................................................................................................... 53
4.9.3 Patch Installation.......................................................................................................................................................54
4.9.4 Factory Reset............................................................................................................................................................ 55
4.9.5 Reboot........................................................................................................................................................................ 55
5 Appendix............................................................................................................................................................... 56
Install the add-on of Firefox browser, Google Chrome and IE Chrome..................................................................... 56
5.1.2 Uninstall the add-on of Firefox browser, Google Chrome and IE Chrome...................................................... 59
5.1.3 I have forgotten the administrator password........................................................................................................ 60
5.1.4 Subnet doesn’t match...............................................................................................................................................60
5.1.5 Camera can not record............................................................................................................................................ 61
5.1.6 No Pictures Problems...............................................................................................................................................61
5.1.7 Can’t access IP camera in internet........................................................................................................................ 62
5.1.8 UPnP always failed...................................................................................................................................................62
5.1.9 Camera can not connect wireless.......................................................................................................................... 62
5.2 Default Parameters..........................................................................................................................................................62
5.3 Specification......................................................................................................................................................................63
5.4 CE & FCC..........................................................................................................................................................................64
3
1 Overviews
The outdoor HD IP Camera is integrated IP Camera with a color CMOS sensor enabling viewing in High
Definition resolution. It combines a high quality digital video camera, with a powerful web server, to bring clear
video to your desktop from anywhere on your local network or over the Internet.
The IP Camera supports the industry-standard H.264 compression technology, drastically reducing file sizes
and conserving valuable network bandwidth.
The IP Camera is based on the TCP/IP standard. There is a WEB server inside which could support Internet
Explore. Therefore the management and maintenance of your device is simplified by using the network to
achieve the remote configuration and start-up.
The camera is designed for outdoor surveillance applications such as courtyards, supermarket, and school.
Controlling the IPCAM and managing images are simplified by using the provided web interface across the
network utilizing wireless connectivity.
1.1 Key Features
Standard H.264 video compression algorithm to satisfy the transmission of high definition video in narrow
bandwidth network
1.0 Mega-Pixel
Supports IE/Firefox/Google/Safari browser or any other standard browsers
Supports WEP,WPA and WPA2 Encryption
Wi-Fi compliant with wireless standards IEEE 802.11b/g/n
IR night vision (Range:20m)
Supports image snapshot
Supports dual-stream
Supports IR-Cut and the filter change automatically
Embedded DDNS(dynamic domain name service) Service
Supports remote viewing & record from anywhere anytime
Multi-level users management with password protection
Motion detection alert via email or upload image to FTP
Supporting Third Party Domain name
Providing Phone APPs for Android and iPhone users
Supports multiple network protocols: HTTP /HTTPS/ RTSP/ TCP /IP /UDP /FTP /DHCP /DDNS / UPNP
/ONVIF
Providing Central Management Software to manage or monitor multi-cameras
4
1.2 Read Before Use
Please first verify that all contents received are complete according to the Package Contents listed below.
Before the Network Camera is installed, please carefully read and follow the instructions in the Quick
Installation Guide to avoid damage due to faulty assembly and installation. This also ensures the product is
used properly as intended.
1.3 Packing Contents
● IPCAM×1
● Network Cable×1
● Wi-Fi Antenna×1
● CD×1
● DC Power Supply×1
●Quick Installation Guide ×1
● Mounting bracket×1
1.4 Physical Description
Front Panel
Figure 1.1
1 WIFI Antenna: Wireless Antenna
2 Infrared Lamp Array
3 LENS: CMOS sensor with fixed focus lens
4 Induction IC
1
4
3
2
5
Interface
Figure 1.2
1 LAN
10/100M adaptive Ethernet interface. Through this interface, IPCAM can be connected with various network
devices, such as hub, router, etc.
2 Power Interface
Connect the external power adapter, request for 12V/1A power.
3 Reset button
Press and hold on the reset button for 5 seconds. Releasing the reset button, the password will back to the
factory default administrator password. The default administrator user is admin with no password.
4 Audio output interface:
The jack is used to plug external output device such as loud speaker directly. Here microphone cannot directly
insert to the interface, it must connect to adapter first.
5 Audio input interface:
The jack is used to plug external input device such as sound pick up device directly. Here microphone cannot
directly insert to the interface, it must connect to adapter first.
Bottom View
There are some labels located at the bottom of the camera; this is an important feature of original cameras. If
your camera does not have labels, it may be a clone. Cloned cameras can not use original firmware and are
6
not eligible for warranty or technical services.
1.5 Hardware Installation
1. Screw the mount on the wall with the 3 screws provided.
2. Install the camera on the mounting bracket with 1 screw to complete installation.
Please Note:
The tail line’s wall hole must be lower than socket, ensure that the rain will not wet out device through tail line.
2 Accessing the Network Camera
2.1 Hardware Connection & Software Installation
Figure 2.1
1. Mount the antenna and make it stand vertically(Only for the device with external antenna).
2. Connect the camera to the LAN network (Router or Switch) via network cable.
3. Connect the power adapter to the camera.
4. Insert the CD into the CD drive of your computer.
5. Go to the folder “IP Camera Search Tool” and find the folder “For Windows OS”or “For Mac OS”. Copy
7
and paste the IP camera tool file to your computer, or drag it onto your Desktop.
Shortcut icon for Windows / Mac OS
2.2 Access the Camera in LAN
2.2.1 Wired connection
Thecamera supports HTTP and HTTPS protocols, you can access the camera in two ways.
(1) Http:// LAN IP + Http Port No.
The default HTTP port NO. is 88. Double click the IP Camera Tool icon to run, and it should find the camera’s
IP address automatically after you plug in the network cable.
Figure 2.2
Double click the IP address of the camera; the camera login page should be open in your default browser.
Https:// LAN IP + Https Port no.
The default HTTPS port NO. is 443. You can use the URL to access the camera: https:// LAN IP + HTTPS port
NO.
Go to Settings - Network - Port panel, you can see and change the HTTP and HTTPS port NO.
Figure 2.3
NOTE：
When logging in for the first time, you will need to download and install the add-on.
8
2.2.2 Wireless connection
Camera support EZLink wireless connection , please refer to the Quick Installation Guide.
2.3 Access the Camera in LAN
2.3.1 Static IP Addresses
Users who have static IP addresses do not need to set DDNS service settings for remote access. When you
have finished connecting the camera using the LAN IP address and port forwarding, you can access the
camera directly from the Internet using the WAN IP address and port number.
How to Obtain the WAN IP address from a public website ?
To obtain your WAN IP address, enter the following URL in your browser: http://www.whatismyip.com.The
webpage at this address will show you the current WAN IP.
Figure 2.5
Access your IP Camera from the Internet
You can access the IP Camera from the Internet (remote access). Enter the WAN IP address and port number
in your standard browser. For example, you would enter http://183.37.28.254:88
2.3.2 Remote Access
If you want to access your camera by web browser outside of your LAN, you need to configure following
configurations.
1. Choose “Settings” on the top of the camera web page, then go to the “Network > IP Configuration” section
9
on the left side of the screen, then uncheck the Obtain IP DHCP.
Figure 2.6
2. Enable UPnP and DDNS in the camera’s settings page. We recommend you to use the DDNS by factory
default.
Figure 2.7
Figure 2.8
3. You can see the port of your camera here. If you want to set Remote Access for several cameras on the
same network, you will need to change the HTTPS port for each camera.
IP Address: Set this in the same subnet
as your computer , or keep it as default.
Subnet Mask: Keep it as default.
Gateway and DNS Server: Set it to the
IP address of your router.
Select Yes and click Save.
Click Enable DDNS and click Save.
The content in the Manufacture’s DDNS
column is the domain name of your camera.
Table des matières
Autres manuels SAB Caméra de sécurité
