Ryobi RLT-710 Manuel d'utilisation

6986679 (STD)

02-13

RLT-710

SAFETY ALERT SYMBOL

Indicates danger, caution or warning.

May be used in conjunction with other

symbols or pictures.

DESCRIPTION

1. Rear handle

2. Trigger switch

3. Cable strain relief

4. Power cord

5. Locking sleeve for length adjustment

6. Telescopic tube

7. Unlocking button for trimmer head angle ad-

justment

8. Unlocking button for pivot head adjustment

9. Air vent

10. Edging support wheel

11. Trimmer head

12. Edge guide

13. Auxiliary handle fixing bolt

14. Handle support

15. Auxiliary handle locking lever

16. Auxiliary handle

17. Cutting head cover

18. Release latch for cutting head cover

19. Safety guard

20. Line spool

21. Trimming line

22. Screws – mounting safety guard and wheel

assy

23. Knife

24. Fastenings – mounting safety guard and

trimmer head

a. Bolt

b. Spring washer

c. Washer

21 18

22 19

24a

24b 24c

x 3

FITTING GUARD

1. Align the edging support wheel (10) with the safety guard (19) (Fig. 1)

2. Secure the edging support wheel and the safety guard with the screws (22) (Fig. 2).

3. Align the spigot of the edging support wheel-guard assy with the notch at the trimmer head (11) and place the

wheel-guard-assembly on the trimmer head (Fig. 3).

4. Turn the wheel-guard assy along with the trimmer head anticlockwise until it locks in place (Fig. 4).

5. Secure the wheel-guard assy with the mounting bolt (24a), spring washer (24b) and washer (24c) (Fig. 5).

FITTING AND ADJUSTING AUXILIARY HANDLE

1. Ensure the auxiliary handle locking lever (15) is in down position.

2. Loosen the auxiliary handle fixing bolt (13) anticlockwise and remove it from the auxiliary handle (16).

3. Align the auxiliary handle with the handle support (14) (Fig. 6).

Fig. 1

19 Fig. 2

Fig. 3

Fig. 4 Fig. 5

24b

24a

24c

Fig. 8

Fig. 6

Fig. 7

PREPARATION

Warning! Do not connect the machine to the mains socket before it is completely assembled.

4. Insert in the auxiliary handle fixing bolt and tighten clockwise by hand (Fig. 7, 8)

5. Adjust the auxiliary handle to required position (Fig. 9, 10, 11)

6. Tighten the auxiliary handle fixing bolt clockwise and clamp the auxiliary handle locking lever in upper posi-

tion to fix the auxiliary handle in place (Fig. 12, 13).

NOTE: The tooth system must interlock.

NOTE: Only tighten the quick release bolt so that it is possible to clamp the lever down with light

pressure. If the lever cannot be clamped, slightly loosen the bolt. If the lever can be clamped without

resistance, tighten the bolt.

ADJUSTING LENGTH (Fig. 14)

Adjust the length to suit your height. It is recommended to use the product with the pole fully extended.

1. Loosen the locking sleeve for length adjustment (5) in anticlockwise direction.

2. Pull the telescopic tube (6) to desired length.

3. Tighten the locking sleeve in clockwise direction.

Fig. 11

Fig. 9 Fig. 10

Fig. 12 Fig. 13

Fig. 14

PREPARATION

ADJUSTING TRIMMER HEAD ANGLE

Adjust the angle of the trimmer head (11) according to the intended operation.

1. Press the unlock button for trimmer head angle adjustment (7) and hold it in position.

2. Adjust to desired position: Adjust to 0° when trimming grass on the flat ground (Fig. 15).

Adjust to 90° when trimming near edges and walls (Fig. 16).

3. Ensure that the unlock button for trimmer head angle adjustment snaps in place.

WARNING! Always ensure that the locking slider snaps in place! Only adjust to indicated angles!

Never adjust to any other intermediate position!

ADJUSTING PIVOT HEAD

Adjust the trimmer head to suitable angle. The joint has 3 snap-in positions between 0° and 90°.

1. Press the unlocking button for pivot head adjustment (8) and hold it in position.

2. Adjust to desired position (Fig. 17, 18).

Fig. 16

Fig. 15

Fig. 17

0°

Fig. 18

90°
