Rx Clear Universal 701460 Manuel utilisateur

MODEL 701460

Rx Clear® Universal

Booster Pump

Section1. IMPORTANT SAFETYINSTRUCTIONS

READ AND FOLLOWALLINSTRUCTIONS

1.1 SafetyInstructions

All electricalworkmustbe performed bya licensed electrician and conformto allnational, state, and

localcodes.When installing and usingthiselectricalequipment, basic safetyprecautionsshould always

be followed, includingthe following:

WARNING

lTo reduce theriskofinjury, do notpermit children to use thisproduct.

lToreduce the riskofpropertydamageorinjury,do notattempttochangethe backwash(multiport,slide,

orfull flow)valve position withthe pump running.

lBooster pumpsare powered bya high voltage electricmotorand mustbe installed bya licensed or

certified electrician ora qualified swimmingpoolservice technician.

lRISKOFELECTRICSHOCK,FIRE, PERSONALINJURY,ORDEATH. Connectonlyto a

branch circuitthatisprotected bya ground-faultcircuit-interrupter(GFCI). Contacta qualified

electrician if you cannotverifythatthe circuit isprotected bya GFCI. Make sure such a GFCIshould be

provided bythe installerand should be tested on a routine basis.Totestthe GFCI,push the testbutton.

TheGFCIshould interruptpower. Push the resetbutton. Powershould be restored. Ifthe GFCIfailsto

operateinthismanner, theGFCIisdefective. Ifthe GFCIinterruptspowerto the pump withoutthe test

button beingpushed, a ground currentisflowing, indicatingthe possibilityofelectricalshock. Do not

use the pump. Disconnectthe pump and have the problemcorrected bya qualifiedservice representative

before using.

Due tothe potentialriskoffire, electricshock, orinjuriestopersons, Booster Pumpsmustbe installed

in accordance with the NationalElectricalCode (NEC ), all localelectricalandsafetycodes, and the

OccupationalSafetyand HealthAct(OSHA ).

lIncorrectlyinstalled equipmentmayfail, causingsevere injuryorpropertydamage.

lDo notconnectthe systemto an unregulated citywatersystemorotherexternalsource ofpressurized

waterproducingpressuresgreaterthan 35 PSI.Trapped airinsystemcan causethe filterlid tobe blown

off, which can result in death, seriouspersonalinjury, orpropertydamage. Be sureall airisoutofthe

systembeforeoperating.

lTo minimize the riskofsevereinjuryordeaththe filterand/orpump should notbesubjected to the

pipingsystempressurization test.

Localcodesmayrequire the poolpipingsystemto be subjectedtoa pressuretest.Theserequirements

are generallynotintendedto applytothepoolequipmentsuch asfilters orpumps. The poolequipment

ispressuretested atthe factory. However, if the WARNING cannotbe followed and pressuretestingof

the pipingsystemmustinclude the filterand/orpump, BE SURETOCOMPLYWITHTHE

FOLLOWING SAFETYINSTRUCTIONS:

uCheckall clamps, bolts, lids, lockringsand systemaccessoriesto ensuretheyareproperlyinstalled

and secured before testing.

uRELEASEALLAIRin the systembeforetesting.

uWaterpressurefortestmustNOTEXCEED 35 PSI.

uWatertemperature fortestmustNOTEXCEED 100°F(38°C).

uLimit testto 24 hours.Aftertest, visuallychecksystemto be sureitisreadyforoperation.

lChemical spillsandfumescanweakenpool/spaequipment.Corrosioncancausefiltersand otherequipmenttofail,

resultinginsevereinjuryor propertydamage. Donotstorepoolchemicalsnearyour equipment.

CAUTION

lDo notstart pump dry!Runningthe pump dryforanylength oftime willcausesevere damage and will

void the warranty.

lThispump isforuse withpermanentlyinstalled poolsand mayalso be used withhottubsand spasif so

marked. Do notuse withstorable pools.Apermanentlyinstalled poolisconstructed in oron theground

orina buildingsuch thatit cannotbe readilydisassembled forstorage. Astorablepoolisconstructedso

thatitmaybe readilydisassembled forstorage andreassembled toitsoriginalintegrity.

lDo notinstallwithin an outdoorenclosure orbeneath the skirtofa hottub orportablespa. Thepump

requiresadequate ventilation to maintainairtemperature atlessthan the maximumambienttemperature

ratinglisted on the motorratingplate.

1.2 PoolPumpSuctionEntrapment PreventionGuidelines

WARNING

Pump suction ishazardousand can trap anddrownor disembowelbathers. Do notuse or operate

swimming pools, spa, or hottubsifa suction outletcover ismissing, broken, or loose. The following

guidelinesprovide information forpump installation thatminimizesthe riskofinjuryto users ofpools,spas,

and hottubs:

EntrapmentProtection -Thepump suction systemmustprovide protection againstthe hazardsofsuction

entrapment.

Suction OutletCovers -All suction outletsmusthave correctlyinstalled, screw-fastened covers in place.

All suction outlet(drain)covers mustbe maintained.Draincovers mustbe listed/certified tothe latest

version ofANSI /ASME A112.19.8 oritssuccessorstandard, ANSI/APSP-16. Theymustbe replaced if

cracked, broken, ormissing.

Number ofSuction OutletsPer Pump -Provide atleasttwo (2)hydraulically-balanced main drains, with

covers, assuction outletsforeach circulatingpump suction line. The centers ofthemain drains(suction

outlets) onanyone (1)suction linemustbe atleastthree (3)feetapart,centertocenter. See Figure1.

Thesystem must be built toinclude atleasttwo (2)suction outlets(drains) connected to the pump whenever

the pump isrunning. However, if two (2)main drainsrun into a singlesuction line, the singlesuction line

maybe equipped with a valve thatwillshutoff both main drainsfromthe pump. Thesystemshallbe

constructedsuchthatit shallnotallowforseparate orindependentshutofforisolation ofeach drain. See

Figure 1.

Morethan one (1)pump can be connected to a singlesuction lineaslongasthe requirementsabove are met.

Water Velocity -The maximumwatervelocitythrough the suction fittingorcoverforanysuction outlet

mustbe 1.5 feetpersecondunless the outletcomplieswiththe latestversion ofANSI/ASMEA112.19.8 or

its successorstandard, ANSI/APSP-16, the standardforSuction FittingsForUsein SwimmingPools,

WadingPools, Spas,and HotTubs. In anycase, do notexceed the suction fitting’smaximumdesigned flow

rate.

If100%ofthe pump’sflowcomesfromthe main drainsystem, the maximumwatervelocityinthepump

suction hydraulic systemmustbe six (6)feetpersecond orless, even ifone (1)main drain(suction outlet)is

completelyblocked. The flowthrough the remainingmain drain(s)mustcomplywiththe latestversion of

ANSI/ASMEA112.19.8 oritssuccessorstandard, ANSI/APSP-16, the standardforSuction FittingsForUse

in SwimmingPools, Wading Pools, Spas,and HotTubs.

Testing and Certification -Suction outletcoversmusthave been tested bya nationallyrecognized testing

laboratoryand found to complywith the latestversion ofANSI/ASMEA112.19.8 oritssuccessorstandard,

ANSI/APSP-16, the standard forSuction FittingsForUse in SwimmingPools, WadingPools, Spas, and Hot

Tubs.

Fittings -Fittingsrestrictflow;forbestefficiencyusefewestpossiblefittings(butatleasttwo (2)suction

outlets).

Avoid fittingswhich couldcausean air trap.

Poolcleanersuction fittingsmustconformto applicable InternationalAssociation ofPlumbingand

MechanicalOfficials(IAPMO )standards.

Section2. GeneralDescription

2.1 Introduction

Thismanualcontainsinformation forthe properinstallation, operation and maintenance ofthe high-pressure

pump. Proceduresin thismanualmustbe followed exactly. Foraddressinformation, see the backcoverof

thismanual.

2.2 Description

Thehigh-pressure pump supplieshigh pressure waterto the poolcleanerto optimize cleanerefficiency.The

pump isnotself-primingand should onlybe usedwhenthe poolfiltrationpump ison.

NOTICE: Runningthe high-pressure pump withoutafiltration pump will damage the high-pressure pump.

Improperoperation ofthe high-pressure pump willvoid the warranty.

2.3 Preparation

1. Upon receiptofthe pump, checkthe carton fordamage. Open thecartonand checkthe pump for

concealed damage, such ascracks, dentsora bentbase. Ifdamage isfound, contactthe shipperor

distributorwhere you purchased the pump.

2. Inspectthe contentsofthe carton and verifythatall the parts are included. ReplacementPartsList.

Figure1

Section3. Installation

3.1 Electrical

1. Thepumpmotormustbesecurelyand adequatelygrounded usingthe green screwprovided. Ground

before attemptingto connectto an electricalpowersupply. Do notgroundto agassupplyline.

2. Insulateallconnectionscarefullyto preventgroundingorshort-circuits. Sharp edgeson terminalsrequire

extra protection. To preventwire nutsfromloosening, tape themusinga suitable, listed (UL, ETL, CSA)

electricalinsulatingtape. Forsafety, and toprevententryofcontaminants, reinstallallconduit and

terminalbox covers. Do notforce connectionsintothe conduit box.

3. Aseparatetime clock(inaddition tothefiltration systemtime clock)isrecommended to controlthe

On/Offfunctionsofthe boosterpump. Amanualswitchcan alsobe used.

4. Ifa time clockisused,setittoturn the pump on atleasta halfan hourafterthe poolfiltration pump is

turned on, and turnthe pump offatleasthalfan hourbefore the filtration pump shutsoff. Periodically

checkthe time clocksettingsto make suretheyareproperlysynchronized.

3.2 Plumbing

NOTICE: Be carefulnottoovertighten anypipe fittingon theinletoroutletofthe boosterpump.

Overtighteningcan causethe housingto crack.

3.2.1 Requirements

Thehigh-pressure Pump requiresa dedicated returnline. Plumb the boosterpump intothesystemso

thatitalwaysreceivesflowfromthe filtration pump.

To ensureproperfunction ofthe pump and the cleaner,referto Figure2and adhereto the following

guidelinesforspecificequipment.

1. Plumb the dedicated lineupstreamofall airinducingequipment.

2. Ifa heaterisinstalled on the system, tap the inletforthe boosterpump intothe return line downstreamand

atleastthree (3)feet(1 meter) fromthe heaterdischarge. See Figure 2. Do nottapthe boosterpumpinlet

intothe three-foot(1 meter)section ofheatsink pipe thatcomesdirectly outofthe heater.

3. Some solarheating systemsutilize the entire water flowwhen the panelsare beingpurged ofair. Ifthe pump

isinstalled in anon-flowpipe duringsolarpanelpurges, install an automatic override to shutoffthe pump.

4. Plumb the boosterpump inlethigher, upstreamand asfarawayaspossiblefroma chlorinator.

3.2.2 Pipe Sizing

1. Use rigid PVCpipe witha minimumdiameterof3/4”, 1-1/2”isrecommended, forthe dedicated return

line. Flexible PVCpipingisnotrecommended forthe dedicated poolreturnline underground asitcan be

damaged byexpansion andmovementcaused bythe surge ofpump pressure. Referto Figures3 and 4.

2. Theboosterpump inletconnectionline should be atleast3/4”pipe.

3. Do nottap into the top ofa horizontalline.

4. Use 90°streetellsto minimize bendsand loopsinthe Polarisreinforced hose.

3.2.3 Pump Location

1. the pump withinone 1 foot(30 cm)above the waterlevel.The pump should notbe elevated morethan a

fewfeetabove the waterlevelofthe pool.

2. Ifthe pump islocated belowwaterlevel,isolation valvesmustbe installedon both the suction and return

linesto preventbackflowofpoolwaterduringanyroutine orrequired servicing

3. Thepump and othercirculation equipmentmustbe located morethan 5 feet(1,5 meter) fromthe water.

Choose a location thatwill minimize turnsinthe piping.

4. Thepumpmustbe placed on a solid foundation thatwillnotvibrate. Tofurtherreduce the possibilityof

vibration noise, bolt the pump to the foundation.

5. The pump foundation musthave adequate drainage topreventthe motorfromgettingwet.The pump needs

to be protected fromthe rain and sun.

6. Properventilation isrequiredforthe pump to operate normally.Allmotors generate heatthatmustbe

removed byprovidingproperventilation.

7. Provide access forfutureservice byleavinga cleararea around the pump. Allowplentyofspace above the

pump forservicing.

8. Ifthe equipmentisundercover, provide adequate lighting.

3.2.4 Install the Pump

1.Mountthe pump usingtwo (2)concrete expansion anchorstoensure stability.

2. Slide the quickconnectretainerringoverthe Softube quickconnectthreads. Installquickconnectsonto

pump discharge and supplyportsusingeithersiliconesealantorteflontape. Pipe dope should neverbe

used on quick connectthreads. Do notovertighten.

3. Measure andcutreinforced hose ensuringcutisclean, withno more than a 30ºoffstraightedge. Avoid

unnecessaryloopsorbendsin the hose.

4. Pushthe hose ontothe quickconnectuntil it isflushagainstthehose barb base.

5. Holdingthe hosein place, pulland twistthesleeveon the quickconnectoverthe hose asfaraspossible.

Snap the clipinto place.

3.2.5 InstallationRecommendations

1.Ifthe pump islocated belowwaterlevel,isolation valvesmustbe installed on both sidesofthe pump to

preventbackflowofpoolwaterduringanyroutine orrequired servicing.

2. To help preventdifficultyin priming, installthe suction pipe withouthigh points(above inletofpump-

inverted “U”sin plumbing), which can trap air.

3. Thepipingmustbe wellsupportedand notforced togetherwhere constantstresswillbe experienced.

4. Alwaysuse properlysized valves.

5. Use the fewestfittingspossible.Everyadditionalfittinghasthe effectofmovingthe equipmentfarther

awayfromthe water.

3.2.6 ConductPressureTest

WARNING

lWhen pressure testinga systemwith water, air isoften trapped in the systemduring the fillingprocess.

Thisair willcompresswhen the systemispressurized.Shouldthe systemfail, thistrapped aircan

propeldebrisata high speed and causeinjury. Everyefforttoremove trapped air mustbe taken,

includingopeningthe bleedvalve on the filterand looseningthe pump basketlid on the filterpump

whilefillingthe pump.

lTrapped air in systemcan causefilterlidto be blown off, which can resultin death, seriouspersonal

injury, orpropertydamage. Be sure allair isproperlyoutofsystembefore operating. DO NOTUSE

COMPRESSEDAIRTOPRESSURETESTOR CHECKFOR LEAKS.

lWhen pressure testingthesystemwith water,itisveryimportantto make surethatthe pump basketlid

on the filterpump iscompletelysecure.

lDo notpressure testabove35 PSI. Pressuretestingmustbe done bya trained poolprofessional.

Circulation equipmentthatisnottested properlycanfail, which could resultin severeinjuryorproperty

damage.

1. Fillthe systemwith water, usingcaretoeliminatetrapped air.

2. Pressurize the systemwith watertono more than 35 PSI.

3. Close the valve totrappressurized waterinthe system.

4. Observe the systemforleaksand/orpressure decay.

Section4. Operation

4.1 Start-up

CAUTION

²Neverrun the boosterpump withoutwater. Runningthe pump “dry”foranylength oftime can cause

severe damage to both the pump and motorand will void the warranty.

²Neverrun the boosterpump withoutthe cleanerconnected. Runningthe pump withoutthe cleaner

connectedwillcausedamage to the pump impellerand willvoid the warranty.

Ifthisisa newpoolinstallation,make sure allpipingisclearofconstruction debrisand hasbeen properly

pressure tested. The filtershould be checked forproperinstallation, verifyingallconnectionsand clampsare

secure accordingtothemanufacturer'srecommendations.

WARNING

To avoidriskofdamage orinjury, verifythatall poweristurned offbefore starting thisprocedure.

1. Turnfiltration pump ON.

2. Open the filterpressurereleaseto relieve the systemsystempressure until watercomesout.

3. Ifthe filterpump islocated belowthe waterlevelofthe pool, openingthe filterpressure release valve will

prime the pump with water.

4. Once all theairhasleftthe filter,closethe pressurerelease valve.

5. Turn on the powertothe boosterpump. Then turn onthe boosterpump.

6. The boosterpump should prime. The time it takesto prime willdepend on theelevation and length ofpipe

used on thesuction supplypipe.

7. Ifthe boosterpump doesnotprime and all theinstructionsto thispointhave been followed, checkfora

suction leak.

Section5. Maintenance

5.1 Winterizing thePump

CAUTION

ØThepump must be protected when freezingtemperaturesare expected. Allowingthe pump to freeze will

causeseveredamage and void the warranty.

ØDo notuseantifreeze solutionsin the pool, spa, orhottub systems! Antifreeze ishighlytoxic and may

damage the circulation system.The onlyexception tothisisPropylene Glycol. Formore information

see yourlocalpool/spa supplystore orcontacta qualified swimmingpoolservicecompany

1. Drain all waterfromthe pump, systemequipment, and piping.

2. Remove the drain plug. Storethe drainplugina safe location and reinstallitwhen the cold weatherseason

isover. Do notlosethe o-ring.

3. Keep the motorcovered and dry.

4. Whenthe systemisreopened foroperation, make sure all piping, valves, wiring, and equipmentarein

accordance withthe manufacturer'srecommendations.Paycloseattention tothefilterand electrical

connections.

5. Thepumpmustbe primed priorto starting;referto Section 4.1, Start-up.

Section6. TROUBLESHOOTING

SYMPTOMS possiblecause WHATTO DO

1.The motor does

not start and makes

no noise.

A.Checkthe electricconnections.

B.Checkthat the motor islive.

C.Checkthe protectionfuses.

C. Iftheyareburnt-out, change

them.

N.B. Ifthe fault isrepeated

immediatelythismeansthat the

motorisshort circuiting.

2.The motor does

not start but makes

noise.

A.Ensurethat the mains voltage isthe

sameas the valueon the plate.

B.Ensurethat the connections havebeen

made correctly.

C.Checkthat all thephases arepresent on

the terminalboard.

D.Lookfor possibleblockages inthe pump

or motor.

E.Checkthe condition ofthe capacitor.

B.Correct anyerrors.

C. Ifnot, restorethe missing phase.

D.Removethe blockage.

E.Replace the capacitor.

3.The motor turns

withdifficulty.

A.Checkthe voltagewhichmaybe

insufficient.

B.Checkwhether anymoving partsare

scraping against fixedparts.

B.Eliminatethe cause ofthe

scraping.

4.The pumpdoes

not deliver.

A.The pumphasnot beenprimed

correctly.

B.The diameter ofthe intakepipe is

insufficient.

C.Blocked foot valve.

B.Replace the pipe withone witha

larger diameter.

C. Cleanthe foot valve.

5.The pumpdoes

not prime.

A.The intake pipe orthe footvalveistaking

inair.

B.The downwardslopeof the intakepipe

favoursthe formation ofair pockets.

A.Eliminatethe phenomenon and

primeagain.

B.Correct the inclinationofthe

intakepipe.

6.The pump

supplies insufficient

flow.

A.Blockedfoot valve.

B.The impeller iswornorblocked.

C.The diameter ofthe intakepipe is

insufficient.

A.Clean the foot valve.

B.Removethe obstructions or

replace the wornparts.

C.Replace the pipe withone witha

larger diameter.

7.The pump

vibrates and

operates noisily.

A.Checkthat the pumpand the pipes are

firmlyanchored.

B.Thereiscavitation inthepump, that is

the demandfor water ishigher than it is

abletopump.

C.The pumpisrunning aboveitsplate

characteristics.

A.Fixthe loose partsmore

carefully.

B.Reduce the intake height or

checkfor load losses.

C. It maybe usefultolimit the flow

at delivery.

TECHNICALDATA

Model HP RPM Volte/ HZ Amps

701460 1.0HP 3450 115V/230V/60HZ

11.5

Partslisting:

Ref. No. PartNo. Description QTY

1 88601007 Drainplug 2

2 65432002080 Gasket 2

3 647255271 Pump housing 1

4 65221015000 ScrewM8*55 4

5 65244005000 GasketM8 5

6 65431142080 O-ring 1

7 647255204 Base 1

8 65233022000 NutM8 1

9 647255209 Sleeve 1

10 647255208 Undertheimpellerboxcover 3

11 647276071 Impeller 3

12 647255207 Impellerboxsuperstructure 3

13 647255203 Limittablets 1

14 65244023000 Gasket 1

15 65028069000 Seal assembly 1

16 65431143080 O-ring 1

17 647255202 Pump cover 1

18 647255210 Mounting foot 1

19 65231004000 NutM8 4

20 65023153000 1.0HP motor 1

21 647276001 Supporting foot 1

Table des matières

Autres manuels Rx Clear Pompe à eau

Rx Clear

Rx Clear Niagara Rapid Manuel utilisateur

Manuels Pompe à eau populaires d'autres marques

Neptun

Neptun NPHW 5500 Manuel utilisateur

Sensidyne

Sensidyne Gilian BDX-II Instructions d'installation et d'utilisation

Draper

Draper 47808 Manuel utilisateur

Trolla

Trolla 12820 Manuel utilisateur

Sunfab

Sunfab SVH Series Manuel utilisateur

WilTec

WilTec 50740 Manuel utilisateur

Fieldmann

Fieldmann FVC 5015 EK Manuel utilisateur

Everbilt

Everbilt EFSUB5-122HD Manuel utilisateur

Graco

Graco Husky 3300e Manuel utilisateur

esotec

esotec 101018 Manuel utilisateur

moyno

moyno 2000 CC Manuel utilisateur

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manuel utilisateur

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guide de dépannage

DUROMAX

DUROMAX XP WX Series Manuel utilisateur

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manuel utilisateur

Franklin Electric

Franklin Electric IPS Manuel utilisateur

Xylem

Xylem e-1532 Series Manuel utilisateur

Milton Roy

Milton Roy PRIMEROYAL Manuel utilisateur
