Russound SRM-2.1 Manuel utilisateur

SRM-2.1

Instruction Manual

SPEAKER RELAY MODULE

SRM 2.1

AMPLIFIER INPUT

Speaker

Relay

Module

SRM-2.1 manual 4/11/00 2:01 PM Page 2

Introduction

The SRM-2.1 is an accessory to the CA-LCD Keypad and CP4.6 Audio

Distribution System. The SRM-2.1 allows for automatic selection of the

local (in-room) audio source or the whole-house audio system. When the

CA-LCD Keypad is off (or the CP4.6 zone is off), the local source will play

through the system speakers. When the CA-LCD keypad or the CP4.6 zone

is turned on, the speakers will automatically be connected to the audio dis-

tribution system and bypass the local source.

Connections

1) CA-LCD (fig 1): Wire the +,- terminal of the CA-LCD to the +,- termi-

nals of the SRM-2.1. Skip to step 3.

2) CP4.6 (fig 2): This connection requires the use of a 1/8”male phono

plug. Wire the + terminal of the SRM-2.1 to the tip of the connector.

Wire the - terminal of the SRM-2.1 the sleeve of the connector. On the

rear of the CP4.6, plug the 1/8”phono connector into the 12VDC

Trigger Output of the zone where the local source unit will be.

12345678

L+

L–

R–

R+

L+L–R–R+

AMPLIFIED ZONE

INPUT FROM MULTI-

ZONE SYSTEM

AMPLIFIED

OUTPUTTO

IN-WALL SPEAKERS

fig 1

SRM-2.1

CA-LCD

SRM-2.1 manual 4/11/00 2:01 PM Page 3

L+

L–

R–

R+

L+L–R–R+

AMPLIFIED ZONE

INPUT FROM MULTI-

ZONE SYSTEM

AMPLIFIED

OUTPUTTO

IN-WALL SPEAKERS

SPEAKER RELAY MODULE

SRM 2.1

AMPLIFIER INPUT

90.9

SPEAKER OUTPUT

fig 2

fig 3

3) Connect the positive and negative leads from each speaker ouput of the

local source to the front of the SRM-2.1 wall plate. See fig 3.

4) Connect the speakers to the speaker connector on the back of the wall

plate. Connect the audio distribution system to the input. This is shown

in both figures 1 and 2.

SRM-2.1 CP 4.6

SRM-2.1 Local Source

SRM-2.1 manual 4/11/00 2:01 PM Page 4

Limited Warranty

The Russound SRM-2.1 is fully guaranteed for Two (2) years from the date

of purchase against all defects in materials and workmanship. During this

period Russound will replace any defective parts and correct any defect in

workmanship without charge for either parts or labor. For this warranty to

apply, the unit must be installed and used according to its written instruc-

tions. If service is necessary, it must be performed by Russound. The unit

must be returned to Russound at the owner’s expense and with prior writ-

ten permission. Accidental damage and shipping damage are not consid-

ered defects under the terms of the warranty. Russound assumes no respon-

sibility for defects resulting from abuse or servicing performed by an

agency or person not specifically authorized in writing by Russound.

Damage to or destruction of components due to improper use voids the

warranty. In these cases the repair will be made at the owner’s expense. To

return for repairs, the unit must be shipped to Russound at the owner’s

expense, along with a note explaining the nature of the service required.

Be sure to pack in a corrugated container with at least 3 inches of resilient

material to protect the unit from damage in transit.

5 Forbes Rd. Newmarket, NH 03857, USA

☎ 603.659.5170 • Fax 603.659.5388

e-mail: tec[email protected]

Come visit us at:

SRM-2.1 manual 4/11/00 2:01 PM Page 1
