18238

Visit uk.russellhobbs.com/product-registration You must register within 28 days of purchase

H B

Read the instructions, keep them safe, pass them on if you pass the appliance on.

Remove all packaging before use.

IMPORTANT SAFEGUARDS

Follow basic safety precautions, including:

This appliance shall not be used by children from 0 years to 8 years.

This appliance can be used by children aged from 8 years and

above if they are continuously supervised. This appliance can be

used by people with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance in

a safe way and understand the hazards involved. Keep the

appliance and its cord out of reach of children aged less than 8

years. Cleaning and user maintenance shall not be made by

children.

This product must be positioned on a stable surface with the

handles positioned to avoid the spillage of hot liquids.

h The surfaces of the appliance will get hot during use.

Never operate the product by means of an external timer or

separate remote-control system.

Clean all surfaces that come into contact with food or oil. See Care

and Maintenance.

If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualied persons in

order to avoid a hazard.

bDo not use this appliance near bathtubs, showers, basins or other vessels containing water.

• Don’t carry or pass anything through the space over or near the appliance – if anything

drops into the appliance, hot oil will splash out.

• Don’t leave the appliance unattended while plugged in.

• Don’t move the appliance when it contains hot oil.

• Don’t use the appliance near or below curtains or other combustible materials, and watch it while in use.

• Don’t cover the appliance or put anything on top of it.

• Unwind the cable fully before use.

• Unplug the appliance when not in use.

• Don’t use accessories or attachments other than those we supply.

• Don’t use the appliance for any purpose other than those described in these instructions.

• Don’t use the appliance if it’s damaged or malfunctions.

HOUSEHOLD USE ONLY

PARTS

1. Handle

2. Basket

3. Thermostat light

4. Temperature control

5. Bowl

6. Body

PREPARATION

1. Sit the appliance on a stable, level, heat-resistant surface.

2. Leave a space of at least 50mm all round the appliance.

3. Position the appliance so that the basket handle doesn’t extend up to or over the edge of

the work surface, where it is likely to be caught accidentally when passing.

4. Unfold the basket handle and push the uprights over the latch above the hinge.

5. Line a colander with kitchen paper, to drain the food after it’s cooked.

ASSEMBLY

• The basket handle is packed separately and must be tted to the basket before use.

1. Sqeeze the arms of the handle together then insert the ends through the two loops on the

bracket inside the basket (g. A).

2. Release the arms of the handle. Rotate the handle backwards so that it clips over the metal

clip and locks in place (g. B).

3. Make sure that the handle is securely tted before using your fryer.

FILLING

1. Fill the bowl with good quality liquid cooking oil to between the MIN (450 ml) and MAX

(900 ml) marks on the side of the bowl.

2. Don’t use solid cooking oil, fat, butter or margarine.

3. Don’t mix oils of dierent types, as they will have dierent temperature characteristics.

FOOD PREPARATION

1. Cut food into uniformly sized pieces.

2. Coat wet foods (e.g. sh, pineapple) with our, breadcrumbs, batter, etc.

3. Don’t use the appliance to defrost food. Any food other than pre-cooked, quick-frozen

foods must be fully defrosted before putting into the appliance.

4. When cooking pre-packed foods, follow any guidelines on the package or label.

5. When cooking raw vegetables (e.g. potato chips or slices), dry the pieces o with kitchen

paper or a tea towel.

USING YOUR FRYER

1. Set the temperature control to the required temperature (80-190°C).

2. Put the plug into the power socket.

3. The thermostat light will come on, then cycle on and o as the thermostat maintains the temperature.

4. Wait till the light goes out before cooking.

5. Put the prepared food pieces in the basket.

6. Try not to put more than two layers of food in the basket. If you need to cook more, do it in

batches.

7. Using the oven glove, hold the basket by the handle and lower the basket slowly and gently into the oil.

8. The oil will foam as it comes into contact with water from the food. As long as the foam

doesn’t threaten to overow the bowl, this should not be a cause for alarm.

9. If the foam threatens to overow the bowl, remove the basket, set it back on the kitchen

paper, then see the “problems” section.

10. Wait till the food has cooked.

11. Check it’s cooked. If you’re in doubt, cook it a bit more.

12. Using the oven glove, lift the basket by the handle.

13. Empty the food into the colander, to drain further before serving.

14. Return the empty basket to the rim of the bowl.

15. If you want to cook another batch of food, check the oil level and top up as necessary.

16. Once nished, unplug the appliance.

HINTS AND TIPS

• Adding food to the oil reduces the temperature of the oil.

• If you add a little food, the temperature will recover quickly, and the food will be cooked

properly.

• When you put food into the appliance, you should see bubbles given o.

• This is steam, formed when the moisture inside the food heats up.

• The steam coming out of the food prevents oil from soaking into the food.

• The food cooks uniformly – rm and crisp.

• If you add too much food, the temperature will not recover, and your food will absorb oil.

COATINGS AND BATTERS

Coat all foods, except those high in starch, like potatoes and doughnuts. The coating protects

the food, helps prevent juices leaking into the oil, and gives a crisp tasty result. Generally,

coatings won’t stick to frozen foods.

Seasoned our

Thicker coatings don’t stick well to wet/damp foods, so coat them rst in seasoned our. Use on

its own to coat small whole oily sh like whitebait.

Egg and breadcrumbs

Popular on sh, chicken, and scotch eggs, it gives an attractive, crisp, crunchy exterior. Ideal for

foods that are to be served cold, as it stays crisp for hours.

1. Coat in seasoned our, to dry the food. Dip in beaten egg, then breadcrumbs, repeat till

fully coated, press well, then shake o any excess.

2. Fresh breadcrumbs give a rough appearance. Make dry breadcrumbs or raspings by baking

scraps of bread till golden, then crush or process to a ne crumb.

Basic batter

• 100g self raising our

• 1 pinch salt

• water

Sift the our into a bowl. Add the salt. Just before it’s needed, stir in enough water to form a

smooth batter.

Basic fritter batter

• 100g self raising our

• 5ml vegetable oil

• 1 pinch salt

• water

Sift the our into a bowl. Add the salt. Beat in the oil. Just before it’s needed, stir in enough

water to form a smooth batter.

Fritter batter with egg white

• 100g plain our

• 150ml liquid

• 15ml vegetable oil

• 1 pinch salt

• 1 egg

The liquid can be water, milk, beer, sparkling water, etc.

Separate the egg. Sift the our into a bowl. Add the salt. Stir in the egg yolk, then the liquid. Beat

in the oil. Just before it’s needed, whisk the egg white and fold into the batter.

Crispy Chinese batter

• 75g cornour

• 5ml vegetable oil

• 10g baking powder

• 1 egg

• 1 pinch salt

• water

Mix the egg, cornour, salt and oil with enough cold water to form a creamy base on which to

add either egg and breadcrumbs or batter.

FRYING TIMES

Use these times purely as a guide.

Cook meat, poultry, and derivatives (mince, burgers, etc.) till the juices run clear. Cook sh till the

esh is opaque throughout. Chips (french fries) and other vegetables should be crisp.

Chips (french fries)

• Use a chipping potato, like King Edward, Cara, Maris Piper, Romano or Desirée.

• Peel, cut, rinse, drain, and dry thoroughly. Don’t put more than two layers of chips in the

basket at a time. For best results, cook in two stages:

Stage 1 – fry for 5-10 minutes (depending on quantity) at 170°C. When the chips reach pale gold,

and the outside is rm, lift the basket out of the oil, and leave the chips to drain and cool

Stage 2 – fry for 2-4 minutes at 190°C. When golden brown and crisp, remove from the oil, and

drain in a colander lined with kitchen towel.

Frozen chips (french fries)

Follow the instructions on the package.

Other vegetables

Many vegetables may be deep fried – onion rings, mushrooms, cauliower orets. They can be

cooked from fresh or frozen, and should be coated.

FROZEN FOOD

• Frozen food cools oil quickly, so fry a single layer at a time.

• Shake o excess ice or water before adding the food to the oil.

• Keep the pieces apart, or they’ll stick together.

• Use the highest temperature setting, and lower the basket slowly into the oil to reduce

foaming.

• When cooking pre-packed foods, follow any guidelines on the package or label.

Fish – frozen

You may fry pre-coated sh – follow the directions on the package.

Type Temperature (ºC) Time (mins)

Plaice 190 5 - 6

Fillets 170 10 - 15

Goujons 190 3

Scampi 170 3 - 5

Fish cakes - small 170 3

Fish cakes - medium/large 170 4 - 5

Whitebait 190 2 - 3

Fish – fresh

Fish has a high water content. Dry with paper towel, and coat before frying. Use whole, or cut

into llets, cutlets or goujons.

Type Temperature (ºC) Time (mins)

Fillets, goujons, scampi, sh cakes 190 3 - 4

Whitebait 190 1 - 2

Meat

Only deep fry fresh/thawed meat. Coat in egg and breadcrumbs or batter. For frozen meat

products, follow directions on the package.

Type Temperature (ºC) Time (mins)

Goujons 190 3

Chops/cutlets - small/large 170 10/15

Scotch eggs 170 10

Rissoles, meat balls 190 6

Weiner schnitzel (depending on thickness) 170 3-8

Poultry

Only deep fry fresh or thawed poultry. Coat in egg and breadcrumbs or batter. Remove the skin

for better results. Allow time for poultry to cook to the centre. A crisp golden exterior doesn’t

necessarily denote this, so test before serving. For frozen poultry product, follow directions on

the package.

Type Temperature (ºC) Time (mins)

Goujons 170 4

Drumsticks 170 14 - 15

Croquettes 190 2 - 3

Chicken in breadcrumbs - small 170 15 - 20

Chicken in breadcrumbs - large 170 20 - 30

Bread, cakes, fritters

Type Temperature (ºC) Time (mins)

Ring doughnuts 190 2

Pineapple, banana or apple fritters 190 2 - 3

Croutons (diced bread) 190 1

PROBLEMS

• If the oil foams and threatens to overow, there’s too much food in the basket (take some

out), the food is too moist (dry it a bit and try again), or the oil is old or contaminated

(replace it).

• Every time oil is heated, it deteriorates.

• Every time food is put into it, moisture, particles of food and fat, our and spices from

coatings, water from frozen foods, cause further deterioration.

• Particles blacken, burn, and stick to the next batch of food, altering its look and taste.

Filtering can alleviate this a bit.

• Even ltered oil will be past its best after 10 to 12 uses.

• Pre-cooked and oven chips have a coating of oil from the pre-cooking process. This will

thicken or discolour the oil in your fryer.

• If you cook coated foods regularly, it might be worth keeping two lots of oil, one for coated

foods and one for “oil-friendly” foods.

• As a rough guide, if you notice a marked improvement in avour after changing the oil, you

should have changed it earlier.

• Your Local Authority will have a depot where old oil can be taken for recycling or

environmentally friendly disposal.

CARE AND MAINTENANCE

Unplug the appliance and let it cool down before cleaning or storing away.

Normal cleaning

1. Wipe outer surfaces with a damp cloth.

2. Put the lid on top of the bowl, to keep dust, etc. out of the oil.

Full cleaning (after every few uses)

• Cover the work surface with at least 3 layers of kitchen paper.

• You’ll need a 2 litre container and a wide necked funnel.

• If you want to lter the oil, use a sieve lined with muslin or lter paper.

1. Pour the oil into the funnel.

2. Wipe the outside surfaces of the appliance with a clean damp cloth.

`You may wash these parts in a dishwasher.

• If you use a dishwasher, the harsh environment inside the dishwasher will aect the surface

nishes.

• The damage should be cosmetic only, and should not aect the operation of the appliance.

• If residue builds up on the element, clean it with detergent, and clean more often.

• Remove all trace of detergent and dry before reassembling.

Table des matières

Autres manuels Russell Hobbs Friteuse

Russell Hobbs

Russell Hobbs Cook@Home RHDF320 Manuel utilisateur

Russell Hobbs

Russell Hobbs RDF360 Manuel utilisateur

Russell Hobbs

Russell Hobbs RHGDF14 Classic Satin Manuel utilisateur

Russell Hobbs

Russell Hobbs PURIFRY RHAF3000 Manuel d'instructions d'installation

Russell Hobbs

Russell Hobbs 27160AU Manuel utilisateur

Russell Hobbs

Russell Hobbs 20810 Guide d'installation

Russell Hobbs

Russell Hobbs 24580 Manuel utilisateur

Russell Hobbs

Russell Hobbs SATISFRY BROOKLYN Manuel d'instructions d'installation

Russell Hobbs

Russell Hobbs 20810 Manuel utilisateur

Russell Hobbs

Russell Hobbs 14559 Manuel utilisateur

Russell Hobbs

Russell Hobbs RDF300 Guide d'installation

Russell Hobbs

Russell Hobbs 20810-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs 26500-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs RHDAF11 Caractéristiques techniques

Russell Hobbs

Russell Hobbs 22101-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs 17892 Manuel utilisateur

Russell Hobbs

Russell Hobbs BROOKLYN RHAF15 Guide d'installation

Russell Hobbs

Russell Hobbs 21840-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs 27170-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs 27290-56 Manuel utilisateur

Russell Hobbs

Russell Hobbs RHDF35D Manuel d'instructions d'installation

Russell Hobbs

Russell Hobbs RHDF3000 Manuel d'instructions d'installation

Russell Hobbs

Russell Hobbs Brooklyn 5L Manuel d'instructions d'installation

Russell Hobbs

Russell Hobbs 19771 Manuel utilisateur

Manuels Friteuse populaires d'autres marques

Innsky

Innsky 55SA1US Manuel utilisateur

Falcon

Falcon G350/11 Guide de l'utilisateur

GoWISE USA

GoWISE USA GW22612 Manuel utilisateur

Wolf

Wolf IF15/S Manuel utilisateur

Electrolux

Electrolux Thermetic 9CHG583284 Guide rapide

Gourmia

Gourmia GAF799 Manuel utilisateur

DeLonghi

DeLonghi D677UX Manuel utilisateur

SEVERIN

SEVERIN DEEP FRYER - Guide de l'utilisateur

Toastmaster

Toastmaster TMFG18-NAT Manuel utilisateur

Domo

Domo DO465FR Manuel utilisateur

Henny Penny

Henny Penny PFG-691 Manuel utilisateur

Farberware

Farberware FBW FT 43721 B Manuel utilisateur

GERMANICA

GERMANICA GEAF5L3LD Manuel utilisateur

Roller Grill

Roller Grill MF 120 R Manuel d'utilisation

Philips

Philips HD9211 Manuel utilisateur

Linea 2000

Linea 2000 Domo DO536FR Manuel utilisateur

Lakeland

Lakeland 31796 Manuel utilisateur

Dash

Dash Tasti-Crisp DFAF755 Manuel utilisateur
